Tripp Lite U444-06N-V-C User manual

1
Owner’s Manual
USB 3.1 Gen 1 USB-C™
to VGA Adapter
Models:
(Charging) U444-06N-V-C, U444-06N-VB-C
(USB-A and USB-C Hub Ports) U444-06N-VU-C,
U444-06N-VUB-C
(Gigabit Ethernet+USB-A Hub Port+Charging)
U444-06N-VGU-C, U444-06N-VGUB-C
USB Type-C and USB-C are trademarks of USB Implementers Forum
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
Español 9 • Français 16 • Русский 23
17-12-057-9336FA.indb 1 12/12/2017 12:49:40 PM

2
Package Includes
Product Features
• U444-06N-V-C, U444-06N-VB-C, U444-06N-VU-C,
U444-06N-VUB-C, U444-06N-VGU-C or
U444-06N-VGUB-C
• Owner’s Manual
Note: This section lists features for all USB Type-C models
referenced in this manual. See the USB Type-C Features
chart to determine which features your model supports.
• Supports USB DisplayPort Alternate Mode for
connecting a VGA monitor via a USB-C port
• Supports VGA video resolutions up to
1920 x 1080, including 1080p (60 Hz)
• Ethernet port supports true 10/100/1000 Mbps
network speeds
• USB-A and USB-C hub ports support data transfer
rates up to 5 Gbps; backward compatible with
previous USB generations
Optional Accessories
• P502-Series High-Resolution VGA Cables
• U322-Series USB 3.0 A/B Device Cables
• U326-Series USB 3.0 Micro-B Device Cables
• N201-Series Cat6 Gigabit Snagless Patch Cables
• U420-003 USB 3.1 Gen 1 USB-C Male/Male
Cable – 3 ft.
17-12-057-9336FA.indb 2 12/12/2017 12:49:40 PM

3
Product Features
USB Type-C Features
Models U444-06N-V-C / U444-06N-VB-C U444-06N-VU-C / U444-06N-VUB-C U444-06N-VGU-C / U444-06N-VGUB-C
VGA Port Y Y Y
USB-A Hub Port N Y Y
Gigabit Ethernet Port N N Y
USB-C Port Charging Support Y Y Y
USB-C Port Data Support N Y N
• USB-C port supports both data transfer and USB
Power Delivery (PD) charging with power input up to
20V 3A (60W)
• Plug and play; no software or drivers required
17-12-057-9336FA.indb 3 12/12/2017 12:49:40 PM

4
Installation
Note: When the unit is connected to the USB-C port on your
computer and to a network via Cat5e/6 cabling, a network
connection will be automatically established. If no connection
is made, you can manually establish one by going to your
computer’s network settings page. For example, on a Mac
you would navigate to the Network section found in System
Preferences, click the ‘Assist Me’ button to get to the Network
Setup Assistant, then follow the prompts to establish a
connection.
1. Connect the adapter’s USB Type-C connector to
the USB-C port on your laptop, tablet or other
compatible device.
2. Connect the adapter’s VGA port to the monitor’s
VGA port using a VGA cable (such as Tripp Lite’s
P502-Series VGA cables).
3. Charge your device by connecting its USB-C charger
to the adapter’s USB-C port.*
4. Connect a USB device to the adapter’s USB-A hub
port.*
5. Connect the adapter’s RJ45 port to a network using
a UTP cable (such as Tripp Lite’s N201-Series Cat6
cables).**
*USB-C port for U444-06N-VU-C and U444-06N-VUB-C
models support both data transfer and charging.
**See the USB Type-C Features chart for the features your
product supports.
17-12-057-9336FA.indb 4 12/12/2017 12:49:40 PM

5
Models U444-06N-V-C / U444-06N-VB-C U444-06N-VU-C / U444-06N-VUB-C U444-06N-VGU-C / U444-06N-VGUB-C
Input Connectors
USB USB-C
(Male)
USB-C
(Male)
USB-C
(Male)
USB-C Port Charging
Support Y Y Y
USB-C Port Data Support N Y N
Output Connectors
VGA VGA
(Female)
VGA
(Female)
VGA
(Female)
USB N/A USB-A
(Female)
USB-A
(Female)
Ethernet N/A N/A RJ45
(Female)
Environmental
Operating Temperature 32°F to 113°F (0°C to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature 14°F to 158°F (-10°C to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
USB-C Charging Port Supports up to 20V 3A (60W) Input
USB 3.0 Port N/A Provides up to 5V 1A
(5W) Output
Specifications
17-12-057-9336FA.indb 5 12/12/2017 12:49:40 PM

6
Warranty and Product Registration
3-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials
and workmanship for a period of three (3) years from the date of
initial purchase. TRIPP LITE’s obligation under this warranty is limited
to repairing or replacing (at its sole option) any such defective
products. To obtain service under this warranty, you must obtain a
Returned Material Authorization (RMA) number from TRIPP LITE or
an authorized TRIPP LITE service center. Products must be returned
to TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by a brief
description of the problem encountered and proof of date and place
of purchase. This warranty does not apply to equipment, which has
been damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s) may
not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as
lost profits or revenue, loss of equipment, loss of use of equipment,
loss of software, loss of data, costs of substitutes, claims by third
parties, or otherwise.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite
product. You’ll be automatically entered into a drawing for a chance
to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions
apply. See website for details.
17-12-057-9336FA.indb 6 12/12/2017 12:49:40 PM

7
Warranty and Product Registration
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate this
equipment.
17-12-057-9336FA.indb 7 12/12/2017 12:49:40 PM

8
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
WEEE Compliance Information for Tripp Lite Customers and
Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations, when
customers buy new electrical and electronic equipment
from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like
basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately
becomes waste
Use of this equipment in life support applications where failure of
this equipment can reasonably be expected to cause the failure
of the life support equipment or to significantly affect its safety or
effectiveness is not recommended. Do not use this equipment in
the presence of a flammable anesthetic mixture with air, oxygen or
nitrous oxide.
Tripp Lite has a policy of continuous improvement. Specifications are
subject to change without notice.
Warranty and Product Registration
17-12-057-9336FA.indb 8 12/12/2017 12:49:41 PM

9
Manual del Propietario
Adaptador de USB 3.1
Gen 1 USB-C™ a VGA
Modelos:
(Carga) U444-06N-V-C, U444-06N-VB-C
(Puertos de Hub USB-A y USB-C) U444-06N-VU-C,
U444-06N-VUB-C
(Gigabit Ethernet+Puerto de Hub USB-A+Carga)
U444-06N-VGU-C, U444-06N-VGUB-C
USB Type-C y USB-C son marcas comerciales registradas del USB
Implementers Forum
1111 W. 35th Street, Chicago, IL 60609 EE UU
www.tripplite.com/support
Copyright © 2017 Tripp Lite. Todos los derechos reservados.
English 1 • Français 16 • Русский 23
17-12-057-9336FA.indb 9 12/12/2017 12:49:41 PM

10
El paquete incluye
Características del Producto
• U444-06N-V-C, U444-06N-VB-C, U444-06N-VU-C,
U444-06N-VUB-C, U444-06N-VGU-C o
U444-06N-VGUB-C
• Manual del Propietario
Nota: Esta sección lista las características para todos los
modelos con USB Type-C referidos en este manual. Para
determinar qué funciones soporta su modelo, consulte la tabla
Características de USB Type-C.
• Soporta USB DisplayPort de Modo Alterno para
conectar un monitor VGA mediante un puerto
USB-C
• Soporta resoluciones de video VGA hasta
1920 x 1080, incluyendo 1080p (60 Hz)
• El puerto Ethernet soporta velocidades de red de
10/100/1000 Mbps
Accesorios Opcionales
• Cables VGA de Alta Resolución de la Serie P502
• Cables para Dispositivo USB 3.0 A/B de la Serie
U322
• Cables para Dispositivo USB 3.0 Micro-B de la
Serie U326
• Cables Patch Gigabit Snagless Cat6 Serie N201
• Cable USB 3.1 Gen 1 USB-C Macho/Macho
U420-003 – 91 cm [3 pies]
17-12-057-9336FA.indb 10 12/12/2017 12:49:41 PM
