Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: F007-015
15-ft. IEEE 1394 FireWire® Cable (6pin/4pin)
Highlights
Premium quadruple-shielded cables with tinned copper braid and aluminum
mylar foil on each twisted pair as well as on the cable as a whole
Gold plated connectors provide superior conductivity
Description
Tripp Lite's new Firewire series is a perfect compliment to your connectivity solutions. This 15Ft. IEEE-1394 Firewire cable has 6-pin male to 4-pin
male connectors supports data transmission of 100~400Mbps and used most commonly to connect a PC device to an A/V device. Firewire cables
have gold-plated connectors and gold-plated copper contacts for superior conductivity. Premium double-shielded cable with both a braid and a foil
shield to virtually eliminate crosstalk and reduce EMI/RFI interference.
System Requirements
Firewire 1394 device with a 6-Pin connector and a Firewire device with a 4-Pin connector
Package Includes
15-ft. Firewire IEEE 1394 6Pin/4Pin with Gold Connectors
Features
All Tripp Lite Firewire (IEEE 1394) cabling includes superior foil shielding for reliable error-free data communications.
Firewire cable meets IEEE 1394 standards as set by the institute of electrical and electronic engineers.
Premium quadruple-shielded cables with tinned copper braid and aluminum
Mylar foil on each twisted pair as well as on the cable as a whole.
Gold plated connectors provide superior conductivity.
Supports data transmission of 100~400Mbps
Specifications
OVERVIEW
Intended Application Connecting Peripherals
Model Type 1394a (Standard)
INPUT
Cable Length (ft.) 15

Cable Length (m) 4.57
PHYSICAL
Color Black
Style FireWire
CONNECTIONS
Connector A
6 PIN (MALE)
Connector B
4 PIN (MALE)
CERTIFICATIONS
Certifications RoHS-Compliant
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
Firewire Cables F005-006 6-ft. IEEE 1394 FireWire® Cable
(6pin/6pin)
1
Firewire Cables F007-003 3-ft. IEEE 1394 FireWire Cable
(6pin/4pin)
1
Firewire Cables F007-006 6-ft. IEEE 1394 FireWire® Cable
(6pin/4pin)
1
Firewire Cables F009-006 6-ft. IEEE 1394 FireWire® Cable
(4pin/4pin)
1
