Model #: N806-01M
1M (3-ft.) 10Gb Duplex MMF 50/125 OM3 LSZH Patch Cable (SC/SC) - Aqua
Highlights
Designed for 10-Gig Ethernet applications...OM3 Rated
Backward compatible with existing 50/125 fiber
Max 10Gb distance of 300 meters @850nm
Low-Smoke, Zero Halogen (LSZH) Aqua jacket
Description
Tripp Lite introduces it's new OM3 Laser-Optimized Multimode Fiber (LOMMF) "Aqua" cables, for use with 10Gb Ethernet applications. These new
technology, 50/125um, SC/SC Fiber Optic cables, provide nearly three times the bandwidth over conventional 62.5um multimode fiber, with
performance rivaling that of Singlemode cable, at a much reduced cost. LOMMF cable allows 10Gb serial transmission over extended distances in
the 850nm wavelength window, where low-cost Vertical Cavity Surface Emitting Lasers (VCSELs) enable a cost-effective, high-bandwidth solution.
LOMMF is ideally suited for LAN's, SAN's, and high-speed parallel interconnects for head-ends, central offices, and data centers.
Applications
For use with 10-Gigabit Ethernet equipment
Package Includes
1 meter ( 3ft ) Duplex Multimode 50/125 Aqua OM3 Fiber Patch Cable, SC/SC
Features
1 Meter ( 3ft ) SC/SC 10Gig, OM3 rated
Use with VCSEL and LED laser light sources
High-Speed, High-Bandwidth, Low-Cost
Backward compatible with legacy LAN's
Ideal for Fibre Channel (SAN) applications
IEEE 802.3ae and TIA LOMMF compliant
10gb Ethernet speed to 300 meters @850nm
Specifications
OVERVIEW
Intended Application Computer Networking (Fiber)
INPUT
Cable Length (m) 1
PHYSICAL
Color Aqua

Style Fiber Optic
CONNECTIONS
Connector A
SC
Connector B
SC
Number of Connectors 4
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
