Tripp Lite N820-15M User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: N820-15M
15M (50-ft.) 10Gb Duplex MMF 50/125 OM3 LSZH Patch Cable, (LC/LC) - Aqua
Highlights
Designed for 10-Gig Ethernet applications...OM3 Rated
Backward compatible with existing 50/125 fiber
Max 10Gb distance of 300 meters @850nm
Low-Smoke, Zero Halogen (LSZH) Aqua jacket
Description
Tripp Lite introduces it's new OM3 Laser-Optimized Multimode Fiber (LOMMF) "Aqua" cables, for use with 10Gb Ethernet applications. These new
technology, 50/125um, LC/LC Fiber Optic cables, provide nearly three times the bandwidth over conventional 62.5um multimode fiber, with
performance rivaling that of Single mode cable, at a much reduced cost. LOMMF cable allows 10Gb serial transmission over extended distances in
the 850nm wavelength window, where low-cost Vertical Cavity Surface Emitting Lasers (VCSELs) enable a cost-effective, high-bandwidth solution.
LOMMF is ideally suited for LAN's, SAN's, and high-speed parallel interconnects for head-ends, central offices, and data centers.
Applications
For use with 10-Gigabit Ethernet equipment
Package Includes
15 meter Duplex Multimode 50/125 OM3 Aqua Fiber Patch Cable, LC/LC
Features
15 Meter (50ft ) LC/LC, OM3 Rated
10gb Ethernet speed to 300 meters @850nm
Use with VCSEL and LED laser light sources
High-Speed, High-Bandwidth, Low-Cost
Backward compatible with legacy LAN's
Ideal for Fibre Channel (SAN) applications
IEEE 802.3ae and TIA LOMMF compliant
Specifications
OVERVIEW
Clad Diameter 125um
Core Diameter 50um
Fiber Type 50/125 LOMMF
Number of Fibers 2
Intended Application Computer Networking (Fiber)

INPUT
Cable Length (m) 15
PHYSICAL
Color Aqua
Style Fiber Optic
CONNECTIONS
Connector A
LC
Connector B
LC
Number of Connectors 4
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
Fiber Optic Cables &
Adapters
N806-03M 3M (10-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable
(SC/SC) - Aqua
1
Fiber Optic Cables &
Adapters
N806-10M 10M (33-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable, (SC/SC) -
Aqua
1
Fiber Optic Cables &
Adapters
N806-15M 15M (50-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable, (SC/SC) -
Aqua
1
Fiber Optic Cables &
Adapters
N816-03M 3M (10-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable
(LC/SC) - Aqua
1
Fiber Optic Cables &
Adapters
N816-10M 10M (33-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable
(LC/SC) - Aqua
1
Fiber Optic Cables &
Adapters
N816-15M 15M (50-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable
(LC/SC) - Aqua
1
Fiber Optic Cables &
Adapters
N820-03M 3M (10-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable
(LC/LC) - Aqua
1
Fiber Optic Cables &
Adapters
N820-10M 10M (33-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable, (LC/LC) -
Aqua
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3004.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
