Model #: SRW18US13
SmartRack Slim 18U Swinging Wall-Mount Rack Enclosure Cabinet
Highlights
Slim design for shallow network switches and patch panels
18U with dual threaded front rails
Locking, reversible front door
Hinged cabinet swings away from wall bracket for easy equipment access
(swing direction is reversible)
Fully assembled for quick installation
PCI-Compliant: meets stringent physical security requirements
Description
The SRW18US13 slim 18U Wall-Mount Rack Enclosure is designed to safely store shallow network switches and patch panels. It integrates
wall-mounting, easy equipment access and cable management in Telco environments with limited floor space. Ventilated top and bottom panels
allows generous airflow to keep equipment operating safely. Top panel offers a convenient cable access cutout with cover. Adjustable front mounting
rails have square holes (default position) and tapped holes to accommodate 18U of equipment. A sturdy hinge between the cabinet and the
wall-mount bracket allows the cabinet to swing away from the wall for easy access to equipment and cabling. Supports up to 250lbs of equipment.
The SRW18US13 comes with a 5-year product warranty.
Package Includes
SRW18US13 Wall-Mount Rack Enclosure
Mounting Hardware
Keys
Owner's Manual
Features
18U slim wall-mounted enclosure
Dual threaded rail option
Ventilated top and bottom panels for increased airflow
Locking, reversible front door
Hinged cabinet swings away from wall bracket for easy equipment and cable access
Fully assembled for quick installation
PCI-Compliant: meets stringent physical security requirements
Specifications
PHYSICAL
Installed whole system
maximum rack depth (inches)
13
Rack Height 18U
Shipping Dimensions
(HWD/in)
41.61 x 25.6 x 14.96

Shipping weight (lbs) 98
Unit Dimensions (HWD/in) EXTERNAL DIMENSIONS: 35.6 x 23.62 x 13
Unit weight (lbs) 83.77
Color Black
Style Wall Mounted
Weight Capacity - Stationary
(lbs)
250
Cable Access Hole
Measurement (inches)
9.812 x 2.35 (l x w)
SPECIAL FEATURES
Grounding lug Front door frame
CERTIFICATIONS
Certifications EIA-310-E
NOM (Mexico) Tested to NOM (Mexico)
Approvals RoHS
WARRANTY
Product Warranty Period
(Worldwide)
5-year limited warranty
Related Items
Optional Products
Related Model Description Qty.
SRFANWM Wall-Mounted Roof Fan Kit, 120V (2 high-performance fans; 5-15P plug) 1
SRFAN3U 3U Fan Panel, 120V (3 high-performance fans; 210 CFM; 5-15P plug) 1
SRXFAN3U 3U Fan Panel; 230V (3 high-performance fans; 210 CFM; C14 inlet) 1
SR1UPANEL10 1U Blanking Panel Kit (10 pieces; toolless mounting) 1
SRCABLEDUCT1U 1U Horizontal Cable Manager (Finger duct with cover) 1
SRCABLERING1U 1U Horizontal Cable Manager (Flexible ring type) 1
SRCABLERING2U 2U Horizontal Cable Manager (Flexible ring type) 1
SRSHELF2P1U 1U Cantilever Fixed Shelf (40 lb / 18 kg capacity; 12-in / 305 mm depth) 1
SRSWITCH Magnetic Door Switch Kit for Front and Rear Doors; requires ENVIROSENSE 1
SRCAGENUTS Square Hole Hardware Kit (Includes 50 M6 screws and washers) 1
SRCASTER Heavy-Duty Rolling Caster Kit (Includes 4 casters. Casters are included with 48/42/25U
enclosures)
1
UPSHDEARKIT Heavy-Duty Mounting Ear Kit - Supports 2U Cabinets up to 65 lb / 28 kg from Front
Vertical Rails in 4-post or 2-Post Racks and Enclosures.
1
SRCABLEDUCT1UHD 1U High Capacity Horizontal Cable Manager (Finger duct with dual-hinge cover) 1
SRCABLEDUCT2UHD 2U High Capacity Horizontal Cable Manager (Finger duct with dual-hinge cover) 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=5450.
