Tripp Lite ISOBAR6DBS User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: ISOBAR6DBS
Isobar Home/Business Theater Surge Suppressor - Premium-performance surge and line noise protection for
all components
Highlights
6 outlets / 6-ft. cord
2850 joule rating
Isolated Filter Banks / all-metal housing
2-line coaxial (gold) surge protection
1-line tel/modem surge protection
$250,000 Ultimate Lifetime Insurance (USA and Canada only)
Description
Tripp Lite's ISOBAR6DBS Isobar Home/Business Theater Surge Suppressor provides premium protection--2850 joules--stopping damaging surges
and filtering disruptive line noise so components perform at their peak! You can see and hear the difference: sharper, crisper video; deeper, fuller
audio and longer component life spans. Perfect for small-to-medium home/business theater installations: high-definition TVs, satellite and A/V
receivers, DVD/CD players and more. Exclusive Isolated Filter Banks eliminate noise interference between components. 6 outlets (with transformer
spacing and plug-in safety covers), 2-line coaxial protection and 1-line tel/modem protection safeguard an entire home/business theater system.
$250,000 Ultimate Lifetime Insurance coverage (USA and Canada only). Includes all-metal housing, three diagnostic LEDs, 6-ft. cord with a
right-angle plug, 6-ft. coaxial cable and 6-ft. phone cord.
Applications
Perfect for small-to-medium home/business theater installations: high-definition TVs, satellite and A/V receivers, DVD/CD players and more
Package Includes
ISOBAR6DBS Home/Business Theater Surge Suppressor
6 ft. coaxial cable
6 ft. phone cord
Instruction manual with warranty information
Features
2850 joules surge suppression rating with EMI/RFI line noise filtering help components perform at their peak (sharper, crisper video; deeper,
fuller audio and longer component life spans)
$250,000 Ultimate Lifetime Insurance (USA and Canada only) covers connected components against surge damage...for life!
Isolated Filter Banks eliminate interference between connected components
All-metal housing safely withstands the strongest surges
6 surge-protected NEMA 5-15R AC outlets safeguard an entire home/business theater system
Widely spaced outlets accommodate up to 3 transformers
Four plug-in safety covers protect against accidental contact
2 sets of surge-protected Type F gold coaxial connectors (with included 6-ft. coaxial cable) safeguard components on cable, satellite or
antenna line

1-line tel/modem surge protection (with included 6-ft. phone cord) safeguards personal video recorders (PVRs) on a single dial-up line.
6-ft. cord with right-angle NEMA 5-15P plug provides convenient location anywhere within a home/business theater system
3 diagnostic LEDs alert user to protection, line power and fault status
Keyhole slots provide convenient wall or cabinet mounting
Illuminated master switch provides one-touch power control over all components. Circuit breaker protects against dangerous system
overload
All-metal housing (black) stands up to the most demanding environments
UL and cUL listed
Lifetime product warranty
Specifications
OVERVIEW
Intended Application Home/Office, Computer Networks, Audio/Video
SYSTEM OVERVIEW
Voltage compatibility 120 VAC
Frequency compatibility 50/60 Hz
OUTPUT
Output volt amp capacity
(amps)
12
Output watts 1440
Outlet quantity / type 6 NEMA 5-15R
Transformer accommodation Accommodates 3 transformers
INPUT
Input connection type NEMA 5-15P
Input cord gauge, type 14 gauge, SJT
Input cord length (ft.) 6 ft.
Input cord length (m) 1.8
Recommended Electrical
Service
120V (110-125V)
Input plug features Space-saving right angle input plug
LEDS ALARMS & SWITCHES
Diagnostic LEDs PROTECTION PRESENT (green), LINE FAULT (red) and LINE OK (green)
Switches Two position red illuminated on/off power switch
SURGE / NOISE SUPPRESSION
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
AC suppression joule rating 2850 joules
Clamping voltage (RMS) 140V
AC suppression response
time
NM = 0 ns. CM =
UL1499 let through rating 330V - UL verified
EMI / RFI filtering Up to 40 dB40-80 dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection
Details
1 line
Cable (Coax) Protection Yes
Cable (Coax) Protection
Details
2 line

Network (Ethernet) Protection No
PHYSICAL
Shipping weight (lbs) 3.6
Shipping weight (kg) 1.6
Shipping Dimensions
(HWD/in)
3 x 11.5 x 7
Shipping Dimensions
(HWD/cm)
7.62 x 29.2 x 17.8
Unit weight (lbs) 2.8
Unit weight (kg) 1.27
Unit Dimensions (HWD/in) 2.5 x 9 x 3.5
Unit Dimensions (HWD/cm) 6.35 x 22.9 x 8.9
Material of construction Metal
Integrated keyhole mounting
tabs
Keyhole mounting slots allow desk or wall mounting
Receptacle Color Black
AC line cord color Black
Style Strip
SPECIAL FEATURES
Appearance Rugged all-metal corded strip format with high quality duplex receptacles
CERTIFICATIONS
UL1449 1998 Rev. (AC
Suppression)
UL1449
UL1363 (Power Tap) UL1363UL1363
UL497A (Communications) UL497A
FCC Part 68
(Communications)
FCC PFCC Part 68art 68
cUL / CSA (Canada) cULcUL
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period Lifetime
Connected Equipment
Coverage
Up to $250,000
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=2814.
©2009 Tripp Lite. All Rights Reserved.
