Tripp Lite NetCommander B070-008-19 User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model Number: B070-008-19
NetCommander 19" VGA Console Cat5 KVM Switch - 8 Port
Highlights
8-port Cat5 KVM Switch with built-in 19" Monitor, Keyboard, and Mouse
Expandable: Connect and control up to 128 computers
Compatible with all major operating systems
Description
Tripp Lite's B070-008-19 NetCommander Rackmount Console KVM switch is a cost effective and highly flexible system for controlling up to 128
computers from a single 19" display console. This console can be cascaded with Tripp Lites stand-alone B072 NetCommander series KVM switches.
Switching between attached servers can be accomplished via the On Screen Display (OSD) menu or Hotkey commands.
Utilizing Tripp Lite's B078-101-Series server interface units, KVM cabling is kept to a minimum via inexpensive Cat5/5e/6 patch cables. Servers can
be located up to 100 ft. away from the switch.
Add Remote access over IP by connecting Tripp Lite B051-000 Remote IP Access Unit.
Password feature provides additional security to prevent unauthorized access to attached computers. All rackmount hardware is included, and is
designed for easy, one person installation. Fits into any rack from 27" to 42" deep. 2-post rackmounting available using Tripp Lite's B019-000.
Compatible with all major operating systems. Constructed of heavy-duty steel housing.
System Requirements
PS/2 or USB computer / server
(1) B078-101-PS2 (PS/2) or B078-101-USB (USB) Server Interface Unit is required for each connected computer/server
Compatible with all major operating systems
Package Includes
B070-008-19, 8-port Cat5 KVM 19" Console
Power Cord
Serial Firmware Upgrade Cable
KVM/Console Jumper cable
Owners manual CD
Features
8-port Cat5 KVM Switch with built-in 19" Monitor, Keyboard, and Mouse
Supports resolutions up to 1280 x 1024 (60Hz)
Connect and control up to 128 computers locally or remotely
Standard EIA 19" rackmounting

Use in racks from 27" to 42" deep
OSD menu for intuitive operation and easy control
USB and PS/2 mouse/keyboard support
Password protection and auto-logout features
Firmware upgradeable
Hot-swappable: disconnect and reconnect USB computers w/o reboot
Easy port selection via On Screen Display (OSD) or Hotkey commands
Rugged ball bearing slides offer long life usage
Uses readily availabe Cat5/5e/6 patch cables to locate computers up to 100 ft. from the KVM
IP upgradeable using Tripp Lite B051-000 IP Remote Unit
Compatible with all major operating systems
Constructed of heavy-duty steel housing
Specifications
OVERVIEW
# Of Users 1
Console Yes
Port Control Hotkeys, OSD
Max CPU 128
PC/Server PS/2
Cat5 KVM Switch Yes
IP Remote Access No
INPUT
Electrical Consumption (Line Mode) 30W / (Standby Mode) 5W
Nominal input voltage
description
Internal Switching 100-240 VAC 50/60Hz
PHYSICAL
Unit Dimensions (HWD/in) 1.7" x 19" x 26.8"
Unit Dimensions (HWD/cm) 4.32 x 48.26 x 68.07
Unit weight (lbs) 36.0
Unit weight (kg) 16.33
Color Black
Style 1U Rackmount Console
LCD Monitor (in.) 19
LCD Monitor (cm) 48.26
ENVIRONMENTAL
Storage Temperature Range -40F to 158F
Relative Humidity 80% Non-condensing Relative Humidity
Operating Temperature 32F to 104F
BTUs (Line Mode) 102 BTU/Hr / (Standby Mode) 17.06 BTU/Hr
CONNECTIONS

Ports 8
Computer/Server Ports 8 x RJ45
Firmware Upgrade Port RJ45
FEATURES/SPECIFICATIONS
Autoscan (Y,N) Y
Autoscan Duration Variable
WARRANTY
Product Warranty Period
(Worldwide)
1-year limited warranty
Related Items
Required Products
Related Model Description Qty.
B078-101-PS2 KVM Switch Accessories - NetCommander PS2 Server Interface Module 1
0SU51079 KVM Switch Accessories - NetCommander USB Server Interface Module 1
Optional Products
Related Model Description Qty.
N201-010-GY 10-ft. Cat6 Gigabit Snagless Molded Patch Cable
(RJ45 M/M) - Gray
1
N201-014-GY 14-ft. Cat6 Gigabit Snagless Molded Patch Cable
(RJ45 M/M) - Gray
1
N201-025-GY 25-ft. Cat6 Gigabit Snagless Molded Patch Cable
(RJ45 M/M) - Gray
1
B051-000 IP Remote Access Unit ( KVM over IP ) 1
B019-000 KVM Switch Accessories - 2-Post Rackmount Bracket for B020,B021, B040, and B070
Consoles and KVM Consoles
1
B070-016-19 NetCommander 19" VGA Console Cat5 KVM Switch - 16 Port 1
B070-016-19-IP NetCommander 19" Console w/ 16-Port Cat5 IP KVM Switch 1
B072-008-1 KVM Switch - 8-Port NetCommander 1U Rackmount Cat5 KVM Switch 1
B072-016-1 KVM Switch - 16-Port NetCommander 1U Rackmount Cat5 KVM Switch 1
B072-016-1-IP KVM Switches- 16-Port NetCommander 1U Rackmount Cat5 KVM Switch w/IP 1
WEXT-KVM-B1 1-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1
WEXT-KVM-B2 2-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1
WEXT-KVM-B3 3-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1
WEXT-KVM-B4 4-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
http://www.tripplite.com/sku/B070-008-19.
Copyright © 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
