Tritech Tornado User manual

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 1© Tritech International Ltd.
Tornado Low Light Camera
Product Manual
0691-SOM-00006, Issue: 01

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 2© Tritech International Ltd.
© Tritech International Ltd
The copyright in this document is the property of Tritech International Ltd. The document is supplied by Tritech International Ltd on the
understanding that it may not be copied, used, or disclosed to others except as authorised in writing by Tritech International Ltd.
Tritech International Ltd reserves the right to change, modify and update designs and specifications as part of their ongoing product development
programme.
All product names are trademarks of their respective companies.

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 3© Tritech International Ltd.
Table of Contents
Help & Support ........................................................................................................ 4
Warning Symbols ..................................................................................................... 5
1. Introduction .......................................................................................................... 6
2. Specification ........................................................................................................ 7
3. Installation ............................................................................................................ 9
3.1. General Guidelines ................................................................................... 9
3.2. Test Cable Wiring .................................................................................... 9
4. Operating Conditions ......................................................................................... 11
5. Maintenance ....................................................................................................... 12
Glossary .................................................................................................................. 13

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 4© Tritech International Ltd.
Help & Support
First please read this manual thoroughly (particularly the Troubleshooting section,
if present). If a warranty is applicable, further details can be found in a Warranty
Statement at the end of the manual.
Tritech International Ltd can be contacted as follows:
Mail
Telephone
Email
Website
Tritech International Ltd
Peregrine Road
Westhill Business Park
Westhill, Aberdeenshire
AB32 6JL, UK
[phone]
[email protected]
www.tritech.co.uk
Prior to contacting Tritech International Ltd please ensure that the following is
available:
1. The Serial Numbers of the product and any Tritech International Ltd equipment
connected directly or indirectly to it.
2. Software or firmware revision numbers.
3. A clear fault description.
4. Details of any remedial action implemented.
Contamination
If the product has been used in a contaminated or hazardous environment
you must de-contaminate the product and report any hazards prior to
returning the unit for repair. Under no circumstances should a product be
returned that is contaminated with radioactive material.
The name of the organisation which purchased the system is held on record at
Tritech International Ltd and details of new software or hardware packages will be
announced at regular intervals. This manual may not detail every aspect of operation
and for the latest revision of the manual please refer to www.tritech.co.uk
Tritech International Ltd can only undertake to provide software support of systems
loaded with the software in accordance with the instructions given in this manual. It
is the customer's responsibility to ensure the compatibility of any other package they
choose to use.

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 5© Tritech International Ltd.
Warning Symbols
Throughout this manual the following symbols may be used where applicable to
denote any particular hazards or areas which should be given special attention:
Note
This symbol highlights anything which would be of particular interest to
the reader or provides extra information outside of the current topic.
Important
When this is shown there is potential to cause harm to the device
due to static discharge. The components should not be handled without
appropriate protection to prevent such a discharge occurring.
Caution
This highlights areas where extra care is needed to ensure that certain
delicate components are not damaged.
Warning
DANGER OF INJURY TO SELF OR OTHERS
Where this symbol is present there is a serious risk of injury or loss of life.
Care should be taken to follow the instructions correctly and also conduct
a separate Risk Assessment prior to commencing work.

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 6© Tritech International Ltd.
1. Introduction
The Tritech Tornado is an underwater video camera specifically designed to work
in low light conditions. The Tornado is robust, low light, high resolution and
monochrome CCD camera.
The camera offers a near SIT performance and high quality images and is supplied
with either an NTSC or PAL module.

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 7© Tritech International Ltd.
2. Specification
Physical
Weight in air Stainless steel: 2.8kg, Titanium: 1.8kg
Weight in water Stainless steel: 1.8kg, Titanium: 0.8kg
Diameter 78mm
Length 172mm
Depth rating 4000m
Materials Stainless steel (titanium alloy optional)
Connector options Tritech, Subconn BH/MCBH, Burton/Seaconn 5506, Schilling SeaNet
Shock DEF STAN 00-35 Part 3, chapter 2-03
30gn for 6ms in each axis (while operating)
Vibration DEF STAN 00-35 Part 3, chapter 2-01
Sinusoidal sweep & dwell in each axis from 5 to 150Hz at 10gn
Temperature rating -10 to 40°C in operation (-30 to 70°C in storage)
Camera Module
Minimum illumination 0.0003 lux at faceplate
Gamma characteristic y=0.45, y=0.6, y=1
Resolution >570 TV lines
Video output 1V (peak to peak) 75Ω
Pick-up element ½" Interline transfer CCD image sensor
Scanning system 2:1 Interlace
Signal to noise ratio >50dB (AGC off)
Power requirement 12 to 39V DC
Lens
Focal length 4mm
Aperture F1.2
Angle of view D72°, H39°, V41°
Object distance 0.1m - infinity

Specification Tornado Low Light Camera
0691-SOM-00006, Issue: 01 8© Tritech International Ltd.
Standard Connector Pin-Out
The standard connector fitted to the Tornado camera is the Tritech International
Ltd 6-pin 4000m water block. Other connectors are available and for alternative
connectors please refer to the original purchase order for the camera (or contact
Tritech International Ltd Technical Support).
Tritech Waterblock
Pin Function
1 not connected
2 not connected
3 +DC Power
4 -DC Power
5 Video Out
6 not connected

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 9© Tritech International Ltd.
3. Installation
3.1. General Guidelines
Caution
Although the camera is rugged, it should be handled with care, particularly
the connector and transducer.
The camera should be secured by clamping on the cylindrical body section such that
the lens is unimpeded and not shielded. A guard can be fitted around the head to
protect from impact damage but this must obstruct the field of view.
Caution
It is important that no clamping force is applied to the lens end cap.
The clamp should be applied centrally to the body tube and should not be over-
tightened. Any metallic clamps should be electrically insulated from the body by
means of rubber or plastic strips or mount brackets of at least 3mm thickness and
extending at least 3mm beyond the clamp boundary to reduce any galvanic corrosion
effect. Non-metallic clamps are preferable and if metallic clamps are used they should
be painted or lacquered with at least two or three coatings.
It may not be possible to determine the orientation prior to installation so it is
advisable to install the camera in such a way that rotation of the unit is possible to
correct for any mis-alignment of the displayed image.
Caution
Ensure the correct polarity of the power supply cable prior to connecting
the lead. Incorrect polarity may cause damage to the internal electronics.
Before attaching the connector to the camera ensure that the 'O' ring gasket is in
position and lightly smeared with lubricant (Dow Corning #111 or equivalent is
recommended).
3.2. Test Cable Wiring
To connect the camera to a computer for testing or operation it will be necessary
to construct an appropriate test cable. The pin-out diagram for units fitted with the
Tritech 6 pin standard water block is shown in the specification section, for any other
connectors it will be necessary to refer to the documentation that was provided with
the camera to establish the correct wiring scheme.

Installation Tornado Low Light Camera
0691-SOM-00006, Issue: 01 10 © Tritech International Ltd.
To connect to a computer it will be necessary to provide the camera a minimum of
three connections:
1. DC Power
2. DC Ground
3. The video capture output.

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 11 © Tritech International Ltd.
4. Operating Conditions
The camera is compatible with any video recorders or monitors working with the
PAL standard.
Caution
The camera is designed for use underwater. Water has a cooling effect
which means that it will become hot when operated in air.
It is not recommended that the camera be left to operate in air for extended
periods.

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 12 © Tritech International Ltd.
5. Maintenance
There are no user serviceable parts within the camera and no reason to dismantle it.
Routine maintenance should be restricted to rinsing with clean water after periods
of submersion.
Visually inspect the camera for any signs of damage and contact Tritech International
Ltd if any part requires replacement.

Tornado Low Light Camera
0691-SOM-00006, Issue: 01 13 © Tritech International Ltd.
Glossary
CCD Charge-coupled device - an electronic light sensor used in digital
cameras.
DC Direct Current
NTSC National Television System Committee - an analogue television
standard used in most of North America.
PAL Phase Alternating Line - an analogue television colour encoding
system.
Tritech waterblock The 4000m depth rated connector developed by Tritech
International Ltd for their subsea equipment.
