INTRODUCTION
Water is an important part of all process applications. In order to
always provide the highest quality of water to the end consumer,
we must make sure to have all the required parameters for
each application. Correct information is important in order to
safeguard the welfare of consumers when it comes to water
quality for food processing, beverages or whatever the final
application may be. Proper selection of treatment technology
must be evaluated in a case by case basis.
The physical, chemical and microbiological characteristics of
water vary from one source to another. Proper water analysis is
important in order to know the unique parameters of the water
to be treated. Remember that water is a universal solvent and
each water supply has dierent quality characteristics.
It is worth mentioning that in water analysis: dissolved solids (ions
or dissolved minerals) whose concentration determine water
salinity is measured as TDS (total dissolved solids) or electrical
conductivity. Suspended solids and colloids are the ones that
give the characteristics of water turbidity. Organic components
and micro-biological and other chemical parameters such as pH,
dissolved gases, hardness, silica and dissolved metals are equally
important to determine the quality of incoming water to any
water conditioning process.
Tritton IXC-850 RO systems have been designed and tested
to provide high quality water and are built with quality com-
ponents that provide you not just high grade water, but also
gives you full condence in its operation and durability.
SYSTEM SPECIFICATIONS
MODEL: ROS-IXC-850
PRODUCTION
(GPD) 850 -1000* gpd
MEMBRANE HLP-4021
SYSTEM
PRESSURE
150 - 200 psi
ROTARY PUMP
CAPACITY
100 gph
INLET-OUTLET
PORT
3/8"
SYSTEM
DIMENSIONS 26”x 23”x 20”
WEIGHT
(LBS)
75 lbs (34.02 kgs)
ELECTRICAL
POWER SUPPLY 120 V/60 Hz
* The system production rate is based on minimum feed water quality below 1,000 PPM, feed
water temp 77° F, and SDI < 5. Use a suitable pretreatment capable of removing all membrane
damaging substances.
If you purchased any of these systems with some variation or special design and it is not described
in this manual, please contact us indicating the corresponding serial number.
Please read the information contained in this manual before starting operation of the Reverse
Osmosis system. Any misapplication could void the warranty or cause equipment damage.
Introduction / System Specications
THIS REVERSE OSMOSIS SYSTEM IS DESIGNED FOR WATER PURIFICATION PURPOSES ONLY.
THIS REVERSE OSMOSIS SYSTEM MUST BE PROTECTED FROM NATURAL ELEMENTS.
RAIN AND EXPOSURE TO UV RAYS CAN CAUSE PERMANENT DAMAGE TO THE SYSTEM.
EXPOSURE TO VERY HIGH HUMIDITY MAY CAUSE DAMAGE TO PUMP MOTOR AND
ELECTRONIC CONTROLS.
Page 5 of 20
TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
I. Principles of Reverse Osmosis Technology
How the Reverse Osmosis process works?
Reverse Osmosis (RO) is a process in which water is forced to pass
through a semipermeable membrane by pressure.
As the water passes through the membrane dissolved particles
are rejected by the membrane in its spiral layers of semipermeable
material formed around a central perforated tube.
Semipermeable Membrane
The Reverse Osmosis system uses the properties of a microporous
membrane that works as an ecient particulate lter up to the
size of chemical molecules or ions.The rejection of these particles
is compared to molecular weight and ionic charge. For example,
we can expect a 90% rejection of sodium chloride, which means
that the product passing through the membrane will have a
concentration of about one tenth of the incoming water. The
rejection of calcium carbonate (hardness) will be about 95%,
while most of the salts will be rejected approximately 98% to 99%.
Ion rejection or organic material is basically done by mechanical
ltration. Most substances with molecular weight of more than
100 will be completely rejected by the membrane. Particles with
very low molecular weight such as formaldehyde or free phenol
can pass through the membrane (RO), like most dissolved gases.
Disposal of unwanted particles is accomplished by constant flow
of water that is circulating, making the function of rinsing the
membrane, which prevents saturating surface and reduces the
tendency to form scale.
Factors that aect the operation and
life of the membrane
There are 5 main factors aecting the Reverse Osmosis membrane:
1. Pressure: Excessive pressure may deform and compress the
membrane which can cause decrease water production.
2. Hydrolysis: It is a chemical reaction of water that aects the
membrane. This happens when the water temperature is very
high and the pH is below 2.5 or above 7. To avoid this, keep the
pH between 5 and 6.
3. Bacterium: The presence of bacteria deteriorates the surface
layer of the membrane and reduces the ability of the membrane
to reject salts.
4. Temperature: Avoid temperatures above 95° F (35° C) to avoid
damaging the membrane structure.
5. Saturation: These are salts (calcium carbonate, etc.) that are
precipitated on the membrane. These salts clog the pores and
channels reducing the amount of water produced.
Temperature in Reverse Osmosis units:
The units are designed for a temperature of 77° F (25° C). The
production ow is reduced at low temperatures. On average
membranes lose at least 1.8% of production for each degree
below 77° F.
Some common terms and definitions
related to Reverse Osmosis
Incoming (feed) water- Pre-filtered and softened water introduced
to the Reverse Osmosis modules.
Product Water - Puried water produced by Reverse Osmosis
membranes.
Water Concentrate (rejection) - High waste containing water
(reject) that goes directly to the drain.
Membrane - Internal semipermeable element core of your
Reverse Osmosis system.
Module - is the complete membrane inside a pressure vessel.
GPD (Gallons per day) - Unit of measure which determines the
water production of the membranes. (maximum working 24
hours / day).
PPM (Parts per million) - Method used to measure the quality of
water in the Reverse Osmosis.
Percentage Recovery - The amount of water recovered through
the membranes. Example: If you enter 100 gallons of water into
the membrane, and produce 60 gallons of clean water to 40 gallons
of reject water, this means the RO System has a 60% recovery.
Percentage Rejection - The amount of salts and chemicals rejected
or removed by Reverse Osmosis membranes.
Pressure Vessel
Fiberglass
Membrane Shell
Permeate Tube
Feed Water
Membrane Element
Adhesive
Permeate
Carrier
Fabric
Backing
Feed Spacer Concentrate
Permeate
Membrane
Principles of Reverse Osmosis
Page 6 of 20 TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
Principles of Reverse Osmosis / Identifying System Components
Feed Water Requirements
TYPICAL EXPECTED ION REJECTION
IN A TFC MEMBRANE TYPE:
TYPICAL EXPECTED ION REJECTION IN A TFC MEMBRANE TYPE
SODIUM 85-94 %
LEAD 95-98 %
SULFATE 96-98 %
ARSENIC 92-96 %
CALCIUM 94-98 %
MAGNESIUM 94-98 %
POTASSIUM 85-95 %
NICKEL 96-98 %
NITRATE 60-75 %
FLUORIDE 85-92 %
IRON 94-98 %
MANGANESE 94-98 %
ZINC 95-98 %
CADMIUM 95-98 %
MERCURY 95-98 %
BARIUM 95-98 %
SELENIUM 94-96 %
CYANIDE 84-92 %
PHOSPHATE 96-98 %
CHLORIDE 85-92 %
WATER SUPPLY REQUIREMENTS:
TYPICAL REJECTION OF A REVERSE OSMOSIS MEMBRANE
TEMPERATURE 8-27° C
HARDNESS < 20 PPM
RESIDUAL CHLORINE 0 PPM
TDS < 1000 PPM
pH 5 to 6
IRON < 0.01
SILICA < 10 PPM
MANGANESE < 0.05 PPM
INLET PRESSURE 30 - 60 PSI
II.- SYSTEM COMPONENTS
1. PREFILTER PRESSURE GAUGE: Glycerin lled pressure gauge
(0-100 psi). Standard on all units and is located on the front of the
panel.This gauge measures the water pressure in PSI at the outlet
of the pre-lter, a minimum pressure of 30 PSI is recommended.
2. SYSTEM PRESSURE GAUGE: Glycerin lled pressure gauge
(0-300 psi). Standard on all units. Located in front of the panel and
indicates the pump pressure discharge. This gauge measures the
pressure of water in PSI which is applied through the membrane.
(Maximum recommended operating pressure is 180 - 200 PSI,
depending on the type of membrane).
The operating pressure of the system can be adjusted by
regulating these combined valves:
- Turning waste valve handle to the right the pressure increases;
turning the valve handle to the left pressure will decrease.
- By adjusting the recirculation valve located next to the waste
valve above.
- Turn right to increase pressure and close recirculation flow
or turn the handle to the left to decrease pressure and open
recirculation ow.
3. CONCENTRATE WATER FLOWMETER (WASTE): Located on
the front of the panel, this meter is calibrated in gallons per
minute. Its purpose is to measure the amount of waste water that
the system is producing.
4. PRODUCT WATER FLOWMETER (PERMEATE): Located on
the front panel, its purpose is to measure the amount of product
water in gallons per minute.
5. REVERSE OSMOSIS MODULE: It consists of a membrane
housing and the membrane. The assembly is placed horizontal
on IXC- 850 model.
6. WASTE VALVE: This valve is located on the front panel. Its
purpose is to restrict the ow of concentrated water leaving the
module, it creates the necessary pressure inside the module so
that water is forced into the membrane creating the Reverse
Osmosis eect.
Turning the valve knob will control the ratio of water discharged/
water produced.
- Turning clockwise will increase pressure inside of the module and
reduce the amount of waste water.
- Turning counterclockwise will decrease pressure within the
module and increase the amount of waste water.
CAUTION! DO NOT CLOSE THIS VALVE COMPLETELY.
Page 7 of 20
TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
CAUTION! KEEP IN MIND THE RECOVERY PRODUCT/
REJECTION SUGGESTED BY YOUR DEALER BASED
ON WATER ANALYSIS DONE.
CAUTION! WASTE VALVE SHOULD NEVER BE
COMPLETELY SHUT.
WARNING! DO NOT EXCEED THE RECOMMENDED
PRESSURE OF MEMBRANE PARAMETERS.
7. RECIRCULATION VALVE: This valve is located on the upper
front panel. Its propose is to adjust the amount of waste water
that recirculates into the feed water of the system. It is used to
refine and adjust pump pressure. You should be cautious of
the incoming waters charecteristics, not to exceed the rate
of salinization with imbedded tendency such as calcium,
magnesium, silica and avoid membrane fouling problems.
8. PRE-FILTER: This filter is a 5-micron pre-filter. It is used to
remove any particles that may have passed through pre-
treatment or released by pretreatment materials. After this
sediment filter there is a second filtration stage, a 5-micron
carbon block filter. If the cartridge is dirty it can cause
pressure loss.
9. HIGH PRESSURE PUMP: This creates high pressure for
proper Reverse Osmosis operation. The pressure of the system
is adjusted by the waste valve and the recirculation valve.
Additionally, if necessary, this pump has a pressure increase
screw at the top of the pump, the pressure increases by turning
the screw to the right and the pressure decreases by loosening
the screw to the left. This screw is already adjusted when the
system has been factory tested.
CAUTION! NEVER USE THE PUMP WITHOUT WATER.
10. CONTROL BOX: The Reverse Osmosis system is designed to
be automatically operated by an electronic controller.The EC-100
controller monitors the operation parameters of the system and
sends continuous information to the screen.
In addition, the system has security features integrated into its
design to protect components and continuously monitor the
quality of product water produced.
Pump Motor overload - Amperage surges are addressed by a
thermal relay located on the motor contactor installed for the
high-pressure pump.
Start Timer delay - The start delay or pump start delay is
10 seconds. This helps detect potential problems with the
solenoid valve or voltage spikes.
Low Pressure Switch- Protects the high-pressure pump to not
operate without water, detects no or low pressure in the system
and immediately shuts down the system and sends an alarm to
the screen. Low pressure switch is activated at 10 PSI.
Product Water Level Connections in the Storage Tank -
Option A: When using an atmospheric tank, a High Level Switch
( provided with the system ) is used. Option B: When using a
pressurized tank it is required to use a Cut Switch as if it were a
stop and start signal of a jet pump, it is recommended to use a
range of 20-40 psi. (See page 15)
Product Water Quality Sensor - The system has an integrated
TDS sensor for monitoring water quality and is constantly
visible on the control screen. The TDS sensor can be read in PPM
and can be set to trigger an alarm if water quality is abnormal.
11. INLET SOLENOID VALVE: Normally closed solenoid valve
(NC). This valve is located on the feed side of the pressure pump.
Its purpose is to stop the water supply when the unit is not
operating. If the power fails, this valve will close.
NOTICE: NEVER USE THIS FILTER AS THE ONLY WAY
OF PRETREATMENT FOR YOUR REVERSE
OSMOSIS SYSTEM.
Identifying System Components
Page 8 of 20 TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
III. PRE INSTALLATION REFERENCES
Inlet Feed Water - enters through the pre-filter housing.
The housing connection is 3/8”using a flexible tubing supplied
with the system and is located on the rst prelter.
The system has 4 stages of purification:
Stage 1 - Sediment Prelter:
- (1) Sediments 2.5” x 10”, 5 MIC, Polyspun (SDC-25-1005)
Hydronix Water Technology
Stage 2 - Carbon Block Prelter:
- (1) Carbon Block 2.5” x 10”, 5 MIC (CB - 25 -1005)
Hydronix Water Technology
Stage 3 - Membrane:
-(1) Membrane 4” x 21”- Rejection of salts of 95 -98%
Hydron Membrane Technology (HLP-4021)
Stage 4 - Postlter:
- (1) Carbon Block 2.5” x 10”, 5 MIC (CB-25-1005)
Hydronix Water Technology
Outlet Product Water - On model IXC-850 system, the permeate
water output exits through the product water flow meter,
it is fed to an activated carbon Postfilter. The location of the
product water is at the outlet of the activated carbon post-lter.
Outlet Waste Water - On model IXC- 8 50, waste water or
concentrate exits the reject water owmeter through the back
of the system. The output connection is located at the rear of
the equipment and a ¼” tube is connected.
Control Box Power and Voltage Connections - Model
IXC-850
is supplied with standard 120 volts, single phase.
All systems
must be installed according to local regulations.
Switch and Product Water Level Connections in the Storage
Tank - The cable connections for the liquid level switch are
located directly on the back side of the electrical control box.
The two wires are connected together with the level switch
cables. When the switch is closed, the Reverse Osmosis system
is switched on. When the switch is open the Reverse Osmosis
system is switched o.
IV. REVERSE OSMOSIS SYSTEM INSTALLATION
INSTALL FOLLOWING THESE STEPS:
1. Choose a place that is covered and has enough space for
the system. The location should also have feed water, electricity
and a specied area for drainage. It is not recommended to install
the system in an area exposed to the elements. Start by connecting
all water connections to the system and its pre-treatment.
2. Install the filter inside the housing or make sure it’s inside
the housing prior to start-up.
3. Install the membrane(s) in the membrane housing(s). The
membrane housings have an arrow indicating the direction
of ow. The seal of the membrane should always be installed
in the same direction as the inlet water. (See diagram below,
chapter V of this manual).
4. Open the recycle and rejection valves completely.
5. Make all electrical installations including the storage water
tank level switch. Make sure the system is connected to an
independent designated main breaker.
V. MEMBRANE INSTALLATION
- To insert the membranes into the membrane housing, It is
recommended to only remove a cap where the water inlet
is fed, there is an arrow indicating the feed ow, instead of
disconnecting the quick connectors and high pressure tubing.
- When installing the membrane you have to make sure of
which position the arrow is pointing (this indicates how the ow
should be directed according to the design of the System), it also
indicates in which position the o-ring of the brine seal is located
to feed the membrane.
*Note the direction of the membrane seal in the following diagram.
IT IS EXTREMELY IMPORTANT TO MAKE SURE YOU
KNOW ALL REGULATIONS PERTAINING TO LOCAL,
BUILDING, ELECTRICAL AND PLUMBING PARAMETERS
OF THE SITE WHERE YOU ARE INSTALLING THE SYSTEM.
ALWAYS FOLLOW SAFETY PROCEDURES WHEN
INSTALLING THE UNIT.
MEMBRANE SEAL SHOULD ALWAYS BE INSTALLED
IN THE SAME DIRECTION AS THE FLOW OF
INCOMING WATER.
Pre Installation References
Page 9 of 20
TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
VI. PROGRAMMING THE EC100 CONTROLLER
NAVIGATION AND PROGRAMMING MENU:
SET key, is access to settings mode.
UP key increases the setting values.
DOWN key decreases the setting values.
Main screen: Displays the operating status:
FLUSH (Activated) - Purges at low pressure (Valid on systems
with Fast Flush option) Does not apply for model IXC-850.
LOW - Indicates that the system is protected by low pressure
and is off (stand by) until there is sufficient inlet pressure to
restore system operation.
FULL-Indicates that the system is in standby as the stop signal
was received by high product water level in the storage tank.
TIMER -The time the system has been in continuous operation.
The Timer on the screen changes under dierent cycles of time,
at the beginning it shows (minutes: seconds) and later when it
reaches one hour changes to (hour: minute).
When the system is in (Stand by), the display will show the total
accumulated time that has been operating after 9999 hr the timer
will start a new cycle starting from scratch again.
- At initial start-up, the system counts in seconds until it reaches
minutes and later to hours as in the example below.
By default the controller provides a 10 second delay in start-up
of the system when you place the selector switch in AUTO for
double electrical protection of the system.
TDS - Registers the quality of the product water by measuring
the total dissolved solids in PPM units.
CONTROLLER PROGRAMMING:
The IXC-850 Reverse Osmosis System has already been factory
programmed with pre-set parameters for basic operation,
however if you want to adjust time setting for models pur-
chased with fast integrated ush, then follow these instructions
for adjustment:
1. With the system pluged and selector switch in AUTO, press
and hold down the SET key for 3 seconds to enter the settings
mode until you hear a "Beep" then enter the options menu
to adjust the setting parameters. P1 starts with the UP and
DOWN keys to adjust the parameter as needed. Once com-
plete press the SET key again to pass to the next parameter
(P2) and so on until you make your adjustments up to P6
and then go back to the home screen.
CONTROLLER
EC-
100
00:00
TIMER
000
T.D.S
LOW FULL
MAIN
PUMP
FLUSH
00:0 0
TIMER
000
T.D.S
LOW FULL
MAIN
PUMP
FLUSH
IXC SYSTEMS DO NOT KEEP CONTINUOUS TIME
IF POWER IS LOST OR IF A LOW PRESSURE OR WATER
LEVEL ALERT IS INDICATED AND THE SYSTEM
IS SHUTOFF.
00:59
TIMER
(seconds)
01:00
TIMER
(minutes)
01:10
TIMER
(hours)
IF POWER IS INTERRUPTED OR IF THE SYSTEM IS
SHUTOFF BY A WARNING SWITCH. THE SYSTEM WILL
START FROM ZERO AGAIN.
Programming the EC-100 Controller
Page 10 of 20 TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
INFORMATION DISPLAYED ON SCREEN:
Timer -Indicates the time the system has
been working and starts measuring a range
of time (minutes : seconds), after an hour of
operation this changes its time reference
to: (hour: minute).
You can also view here when the membrane
is in fast flush mode. It will display a count-
down in seconds.
TDS - Shows the quality of product water
in TDS PPM being produced at that time.
LOW - When this appears on the screen,
it indicates low pressure in the system.
FLUSH-When membrane flush is activated,
droplets above the word FLUSH are dis
played. Does not apply to model IXC-850.
MAIN PUMP - This display represents the
high pressure pump of the System
is activated.
FULL -Appears on the screen when a signal
is received that the storage tank is full.
SETTING PARAMETERS:
P1-Time Setting adjustment for the duration of the membrane
fast flush; 15 sec, 30 sec, 45 sec, 60 sec. (Model IXC- 850 does not
have this option).
P2 -Setting for adjusting the start-up delay time to start if the
system receives any signal by the low pressure or high
level switch.
P3 -Select frequency or time between each membrane fast
ush when the system is operating; P3 only used when purchasing
a system with fast ush integrated. IXC-850 does not have this option.
P4 -Select frequency or time between each membrane ush
when the system is in standby; P4 only used when purchasing a
system with fast ush integrated. IXC-850 does not have this option.
P5 -TDS range selection (set point) if you want to send an alarm
signal indicating that water quality has changed; 0 = OFF
(function o), it can be adjusted 10 PPM to 200 PPM. The control
will trigger an alarm indicating that the quality of water changed,
then the alarm will repeat every hour, until you identify and
correct the problem with the TDS.
P6 -Parameter based on the sensitivity setting of the TDS meter.
The lower this parameter the best sensitivity will be for this sensor.
It is suggested to be set to less than 15 PPM as a good option.
The calibration of the sensor should be done with TDS < 15.
The last screen in the parameter setting records the last 5 events
of "non operation" presented by the system and how long it
was off. Up and Down Arrow reads T1, T2, T3, T4 and T5 are
records in the memory of the“non operation”and indicates which
switch was deactivated.
Parameter settings recommended for basic operation:
P1 = 15 P2 = 0 P3 = 0
P4 = 0 P5 = 50 P6 = 15
1:0 0
TIMER
158
T.D.S
LOW
FLUSH
MAIN
PUMP
FULL
Information displayed on screen
Page 11 of 20
TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
CABLE CONNECTION IDENTIFICATION:
Violet: Low level Switch in the raw water tank (SW1) (*)
Blue: Shut-O Switch for the pre-treatment (SW2) (*)
Green: Storage tank level switch (FULL)
Yellow: Low pressure switch (LOW)
Gray: Booster Pump System (FEED) (*)
Orange: Solenoid Valve for membrane ush ( FLUSH) (*)
Brown: High Pressure Pump System
Red: Solenoid Valve water feed system
Black: Power 110 V-240 V
(*) Deactivated in IXC-850 model.
TDS SENSOR CALIBRATION CONTROLLER:
- The controller has a basic TDS sensor that gives you a reading
of the quality of your product water that lls your tank.
- If you want to verify the calibration of the sensor, we recommend
calibration solutions in the range of 5 PPM to 10 PPM maximum.
-
Set the System selector switch to AUTO, take out the sensor from
its original position and
reintroduce it into the solution of
reference and check the reading on screen.
- If there is a dierence between what we read on the screen,
then press the SET button for 3 seconds and go to parameter
P6 and select the value of the reference solution with the UP
or DOWN keys and then press SET.
- Reconnect the sensor in its original connection.
CONTROL BOX FEATURES:
- Nema 4 Box: ABS
- Electrical Contactor: 24 AMPS
- Low Pressure Switch range: 4-12 PSI
- Selector Switch: 2 positions (OFF - AUTO)
- Level switch: Provided for eld installation
- Power supply: 120 V / 60 Hz
FUSE TYPE:
VIOLET
BLUE
GREEN
YELLOW
GRAY
ORANGE
BROWN
RED
BLACK
2 A
Cable connection identication
Page 12 of 20 TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
VII. STARTUP
1. Make sure that everything related to the pre-treatment
process is operating properly and has been backwashed several
times to avoid nes from entering the system.
2. Install main valve near the system.
3. All pressure gauges will read 0 before opening the supply
valve to the system.
4. Open the feed water.
5. Make sure the waste and recirculation valves are fully open.
6. The inlet pressure gauge should climb to 30 psi. When the
inlet pressure reaches approximately 20 psi the low pressure
indicator light will turn o.
7. After 10 seconds the pump will come on. After the pump turns
on the system pressure gauge will begin to rise.
8. Purge for 10 minutes before adjusting the waste valve by
closing it slowly until the product and waste indicator show the
same values in GPM.
It is recommended to use a 50-50% conversion (product-rejection).
9. Adjust the waste valve by slowly closing it until the system
pressure is in the range of 130 -150 psi depending on the type
of membrane used.
10. The Reverse Osmosis unit is now in operation. Check for leaks.
PPM product water will take approximately 60 minutes to reach
the optimum final quality since the membranes must be ushed
from preservants.
INITIAL TESTS
After 15-30 minutes both the feedwater and the product water
must be monitored with the TDS meter. You must obtan at
least 95% rejection in the nal product water quality.
If the rejection is less than 95% recheck the installation of the
membrane and that they are positioned in the right direction
by making sure the seals of the membrane are in the same
direction of the ow of water. Also check o-rings and membrane
caps to identify where the problem is.
- After testing the water quality, now you have to verify the wiring
signal that goes to the product water level switch. These two wires
are located at the top of the control box.
Disconnect the cables from the level switch and make sure that:
1. The system pump turns o automatically.
2. There should be pressure on your pre-lter and remain stable.
3. The pump system is switched o and both the ow to product
and waste stop (no output).
4. The control box must remain on and the screen illuminated
when the level switch is open, the screen will show full.
Reconnect the wires to the liquid level switch. The pump will
automatically turn on. The pressure will increase and the water
will ow through the product and waste ow meters.
NEVER COMPLETELY CLOSE THE WASTE VALVE.
NEVER ALLOW THE GAUGE PRESSURE TO EXCEED 200 PSI.
WARNING: THE REVERSE OSMOSIS SYSTEM MUST BE
FLUSHED THOROUGHLY FOR ONE HOUR BEFORE USING
THE PRODUCT WATER. THE CONCENTRATE AND PERMEATE
SHOULD RUN TO A SUITABLE DRAIN FOR FLUSHING THE
SYSTEM. THE SYSTEM MUST BE PURGED AT LOW PRESSURE
WITH HIGH FLOW RATES.
Start-Up
Page 13 of 20
TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
VIII. TROUBLESHOOTING GUIDES
SYMPTOM POSSIBLE CAUSE SOLUTION
THE REVERSE OSMOSIS
SYSTEM WILL NOT START.
Power switch is o. Place in AUTO position.
No power.
Check power outlet and make sure system is plugged in.
Check 2AMP fuse on back of controller.
Not enough inlet pressure
and the low pressure switch is not activated.
Verify that the feed valve is fully open.
Make sure your pre-treatment pump is operating properly
to supply pressure to the Reverse Osmosis system.
Check continuity in the low-pressure switch to ensure
it is in good condition and / repair or replace.
Check that pretreatment does not exceed the pressure drop
as this low feed can lead to insucient water pressure to system.
Magnetic starter is burned. Check continuity and replace the coil of starter if necessary.
The level Switch is open. Check to see if the storage tank is lled with product water.
Pump motor burned. Check with a multimeter all electrical connections and switches
to determine cause of failure before replacing the motor.
NO HIGH PRESSURE
IN THE SYSTEM.
Air in the system.
It is normal for the system to have and purge air.
Let the system run for a while (at least 5 minutes)
before starting to adjust the pressure.
Waste Valve open. Adjust the recommended pressure to the membrane type selected.
Recirculation valve completely open. Check and Adjust.
Faulty pressure gauge. Check and Replace.
Tubing or hose kinked or blocked. Check, replace the tubing.
Pump impellers are worn or damaged. Check impellers and replace if necessary.
There is not sucient water pressure feeding the system and
the pump is also sucking and pressurizing at the same time.
DANGER! This can collapse pressure tanks on pre-treatment.
Check system feed pump as well as its pre-treatment and correct.
Wrong voltage feed.
Make sure the power supply is the voltage that corresponds to your system
and make adjustments if necessary.
Measure motor amperage and verify that it is within the range of motor
nameplate for supply voltage. Make adjustments necessary.
Clogged or faulty solenoid. Check if your solenoid valve is operating properly
and does not have something stuck internally, Check and correct.
NO WATER OR
TOO LITTLE REJECTION.
Membrane Fouled / Open.
Check the TDS on the product line, if the TDS is the same as the feed water line,
the membrane is fouled open or there is a leak of reject water through an o-ring.
Check and if necessary change o-rings on membrane housing caps or replace
the membrane.
Waste valve clogged.
The pressure exceeds the initial set limit indicating that
salts saturation was excessive and is obstructing the waste valve or drain line.
Verify that the drain tubing is not bent or kinked, conrm the cause and correct.
Troubleshooting Guides
Page 14 of 20 TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
SYMPTOM POSSIBLE CAUSE SOLUTION
NO PRODUCT OR TOO LITTLE
WATER PRODUCTION.
Saturated or dirty membrane. Check, clean, replace if necessary.
The water temperature is very low. Check your feed water temperature, check your correction factor
for the temperature and make sure that the ow is at an acceptable level.
Low pressure in the system. Check other causes mentioned in this manual under issues
of not having enough pressure.
PRODUCT WATER WITH HIGH
CONTENT OF DISSOLVED
SALTS TDS.
Low pressure in the system.
Waste valve open, check and adjust.
Check other causes mentioned in this manual under issues
of not having enough pressure.
Osmosis membrane seal is not seated or
in good condition inside the membrane housing.
Check that the membrane is installed properly and for leaks
in the o-ring or cap causing a mixture of water and waste-product.
Reverse Osmosis membrane exhausted. The membrane life is on average 2 years.
Replace the membrane if life already exhausted.
Product lines and waste water are reversed. Change and correct reversed connections.
The amount of TDS in the feedwater changed.
An increase in its raw water TDS can alter product water quality,
verify the cause of this increase and that the membrane is rejecting
the percentage of suitable salts.
DIFFERENT TASTE
AND ODOR IN WATER
PRODUCT.
Saturated and polluted membrane (bacteria). Check, perform chemical cleaning, replace if necessary.
Presence of foreign matter in the tank storage.
Clean, empty and sanitize the tank.
Replace lter cartridges.
Product lines and waste water are reversed. Change and correct reversed connections.
Presence of foreign matter in the tank storage. Integrate special pre-treatment to remove gases.
Problems with your pre-treatment.
Exhausted lter media.
Softener without sucient rinse time and sends saltwater
into the Reverse Osmosis system. Correct the problem.
Reverse Osmosis membrane exhausted. The membrane life is on average 2 years.
Replace the membrane if life has been exhausted.
Osmosis membrane sealing is not perfect
in the membrane housing.
Check that the membrane is installed properly and for leaks
in the o-ring or cap causing a mixture of water and waste-product.
Post-carbon lter is exhausted. Replace the Post-carbon lter block if one is installed.
Troubleshooting Guides
Page 15 of 20
TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
IX. PRETREATMENT REQUIRED FOR
REVERSE OSMOSIS SYSTEMS.
It is advisable to ensure that raw feed water is microbiologically
safe and/or has been subjected to a purification process, if
this has not occurred or in doubt, Disinfection should be a
considered step by injecting liquid chlorine (preferably) and
allowing a contact time of at least 30 minutes. As part of a
primary pre-treatment it is recommended that the following
be considered in a pretreatment installation:
1. Sediment filter: These filters are designed to remove sedi-
ment present in the raw water and are important to prevent
dirt from reaching the membrane and fouling it quickly.
Various filtering materials such as: multimedia, silica sand,
cartridge or bag filters may be used.
2. Activated carbon lter: The membranes (central part) of the
Reverse Osmosis system cannot tolerate chlorine. It is extremely
important to give proper maintenance to the unit by changing
carbon lter material within recommended time frames, doing
this will increase the lifetime of the membranes.
3. Water softener: When you have hardness of > 100 ppm,
to avoid saturation and fouling of the membranes a water
softener is recommended before Reverse Osmosis.
1 2 3
4
EQUIPMENT DESCRIPTION:
1. Pressure Gauges
(100 & 300 psi)
2. Needle Valves
(Waste and Recirculation)
3. Controller Box
4. Flow Meters
(Product / Waste)
SYSTEM COMPONENTS
1 2 4
3
STAGE DESCRIPTION:
1. Stage 1:
Sediment Filter
SDC-25-1005
2. Stage 2:
Carbon Block Filter
CB-25-1005
3. Stage 3:
RO Membrane
HLP-4021
4. Stage 4:
Carbon Block Filter
CB-25-1005
Reverse Osmosis Pre-Treatment / System Components
Page 16 of 20 TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
ENTRY EXIT Green Cable - Exit
Green Cable - Entry
Level / Output Switch
connection coming from
AQT-EC-100 Controller
(Green Wires located
on the top of the
box controller.)
ELECTRICAL INSTALLATION OPTIONS
ENTRY
EXIT
Level Switch
(Green Cable - Entry)
Level Switch
(Green Cable - Exit)
Level / Output Switch connection
coming from AQT-EC-100 Controller
(Green Wires located on the top of
the box controller.)
OPTION 1: When using atmospheric storage tank
OPTION 2 : When using pressurized tank
Electrical Installation Options
Page 17 of 20
TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
Liability and Warranty
The products described in this document are hereby oered for sale to be established by Hydrot Quick Connect Fittings, Polaris Scientic
Ultraviolet, Hydron Membranes, Aquatrol, Shok Blok, HydroGuard, Hydronix Water Technology, any of its subsidiaries and its authorized
distributors.This oer and its acceptance by any customer (the ”Buyer”) shall be governed by all of the followingTerms and Conditions. Buyer’s
order for any item described in this document, when communicated to Hydrot Quick Connect Fittings, Polaris Scientic Ultraviolet, Hydron
Membranes, Aquatrol, Shok Blok, HydroGuard, Hydronix Water Technology, its subsidiaries or an authorized distributor (the ”Seller”) verbally
or in writing, shall constitute acceptance of this oer. Provided, however, that these terms and conditions shall not operate as a rejection of the
Buyer’s oer unless such oer contains variances in the description, quantity, price, or delivery schedule of the items.
1. Terms and Conditions of Sale.
All descriptions, quotations, proposals, oers, acknowledgments, acceptances and sales of the Seller’s products are subject to and shall be
governed exclusively by the terms and conditions stated herein (the ”Agreement”). The Buyer’s acceptance of any oer to sell is limited to the
terms and conditions in the Agreement. Any terms or conditions in addition to or inconsistent with those stated in the Agreement, proposed by
the Buyer in any acceptance of an oer by the Seller, are hereby rejected. No such additional, dierent or inconsistent terms and conditions shall
become part of the agreement between the Buyer and the Seller unless expressly accepted in writing by the Seller.The Seller’s acceptance of any
oer to purchase by the Buyer is expressly conditioned upon the Buyer’s assent to all the terms and conditions in this Agreement, irrespective of
any terms in addition to, or inconsistent with those contained in the Buyer’s oer. Acceptance of the Seller’s products shall in all events constitute
such assent.
2. Documents.
Unless provided otherwise in the Agreement, all catalog descriptions, illustrations, drawings and literature or independently submitted
estimates of performance, weights and measurements or other specications provided by the Seller are mere approximations and the Seller
reserves the right to alter or amend them at any time. The Seller reserves the right to correct clerical or technical errors in the contract documents.
The Buyer shall furnish with his order all necessary specications and information. The Seller takes no responsibility for goods manufactured,
priced or delivered not in accordance with the order or the specications unless the Buyer’s order and specications are clear and correct.
3. Prices.
Unless otherwise provided, all prices contained in our quotations and written acceptances are ex-works and do not include the cost of packing. All
orders are accepted on the condition that all such prices are subject to revision by the Seller at any time before the goods are dispatched to take
account of any price change. In the event that the Buyer does not place the entire order quoted by the Seller for the Buyer, the Seller reserves the
right to revise its prices. The Seller also reserves the right to revise its prices if the Buyer modies the specication or quantity of the goods or the
delivery requirements after the order has been accepted by the Seller.
4. Advice.
All advice given in connection with the Seller’s goods is provided without charge to the Buyer. ANY ADVICE AND ASSISTANCE GIVEN BY THE SELLER
TOTHE BUYER IS GIVEN ATTHE BUYER’S RISK, AND THE SELLER SHALL NOT BE LIABLE FOR ANY LOSS, DAMAGE OR CLAIM ARISING THEREFROM.
5. Payment.
(a) Unless otherwise provided in the Agreement, or explicitly agreed upon in writing by the Seller, payment is due in full 30 days from date
of shipment of the items purchased herein under. (b) In the case of an installment contract, deliveries or parts, payment for each installment
delivery or part shall be made under sub-clause (a) as if the same constituted a separate agreement. (c) Amounts not timely paid shall bear
interest at the rate of 2-1/2% above the Seller’s bank’s prime rate from time to time in force. (d) In the event that the Buyer fails within one
calendar month of the date for payment to eect any payment which may be due under the Agreement or any agreement with the Seller, or
if the Buyer commits any breach of the Agreement, or if the Buyer becomes insolvent or commits any act of bankruptcy or contemplation of
liquidation, the Seller will be entitled, without prejudice to the Seller’s other rights, to terminate the Agreement or any unfullled part thereof,
or at the Seller’s option to make partial deliveries.
6. Modifications and Cancellations.
This Agreement is not subject to oral modication or cancellation. A Buyer’s request for modication or cancellation will not be incorporated
into the Agreement unless the request is accepted by the Seller in a writing that amends the Agreement. Acceptance of any such requested
modication or cancellation shall be at the Seller’s discretion and shall be upon such terms and conditions as the Seller may require.
7. Handling Charge.
Goods supplied in accordance with the Buyer’s order may later be returned to the Seller at the Seller’s discretion provided the return is pre-
authorized in writing, and the merchandise is unused, in original packages, unaltered, clean and no older than 60 days from the date of shipment
by the Seller.The Buyer will be required to pay to the Seller a handling charge of 25% of the purchase price of the returned goods. A copy of the
original invoice for the merchandise must accompany all returns.
8. Delivery.
(a) Any delivery dates quoted are approximate only and the Seller shall have no liability for any delays in delivery. (b) Unless provided otherwise,
delivery of the goods shall be made when the Seller has notied the Buyer that the goods are ready for dispatch. Regardless of the method of
delivery, delivery shall be made F.O.B. Seller’s plant, where the risk of loss shall thereupon pass to the Buyer upon the Seller’s delivery to a carrier.
Notwithstanding that the Seller’s prices are ex-works, the Seller is prepared by special contract to procure carriage or freight and insurance on
behalf of the Buyer and at Buyer’s cost in which event the Seller shall be under no liability for damage in transit or loss or damage to the goods
beyond the point at which the Seller contracts to deliver the same. (c)The Seller will not make drop shipments.
9. Inspection and Rejection.
(a) The following provisions shall apply in relation to all deliveries of goods: the Seller shall not be held liable for any claims of damage in transit,
shortage of delivery or loss of goods, unless in the case of shortage of delivery, a separate notice in writing is given to the carrier concerned and
to the Seller within three (3) days of the receipt of the goods, followed by a complete claim in writing within ve (5) days of receipt of the goods
and in the case of loss of goods, a separate notice in writing is given to the carrier concerned and to the Seller and a complete claim in writing
made within thirty (30) days of the date of consignment. The Buyer must inspect the goods on arrival from the carrier; however, where goods
are accepted from the carrier concerned without being inspected, the delivery book of the carrier concerned must be signed ”not examined”.
The Seller shall have the right to inspect the goods at the Buyer’s premises in respect to any such claims made by the Buyer and the Buyer shall
retain such goods until the Seller has inspected such goods or until the Seller has notied the Buyer that the Seller does not wish to inspect such
goods. Any breach of these conditions in this provision shall serve as a waiver to any claim brought by the buyer. (b) Without prejudice to the
Seller’s other rights, should the Buyer fail for any reason to send the Seller forwarding instructions within ninety (90) days after the date of the
Seller’s notication that the goods are ready for dispatch or to accept delivery of the goods, the Seller shall be entitled at the Buyer’s risk and
expense to store the goods and/or to procure or eect storage of the goods elsewhere. Goods so stored shall be paid for as if they had been
dispatched and/or accepted.
10. Special Tooling.
Where it is necessary for the Seller to manufacture or to purchase special tooling, including without limitation tools, dies, jigs, mandrills, xtures,
molds, and patterns, in order to execute a contract, the Buyer will be charged with all or a proportion of the cost of such special tools. Such special
tooling shall be and remain the Seller’s property notwithstanding payment of any charges made by the Buyer. In no event will the Buyer acquire
any interest in apparatus belonging to the Seller which is utilized in the manufacture of the items sold hereunder, even if such apparatus has been
specially converted or adopted for such manufacture and notwithstanding any charges paid by the Buyer therefore. Unless otherwise agreed,
the Seller shall have the right to alter, discard or otherwise dispose of any special tooling or other property in its sole discretion at any time.
11. Test and Performance.
(a) The Seller’s goods are, where practicable, submitted to the Seller’s standard test before delivery. If special tests are required, these shall be
made at the Seller’s premises unless otherwise agreed, and will be subject to an extra charge. (b) The Seller accepts no liability for failure to attain
any performance gures quoted by the Seller unless the Seller specically has guaranteed them with an agreed sum as liquidation damages
and the Buyer has suered actual loss by reason of the failure to attain the gures quoted. (c) Any particulars of weights and measurements,
power and consumption, power output or performance relating to the goods and like matters furnished by the Seller to the Buyer in the Seller’s
catalogs, literature or otherwise, are approximate and are intended only to present a general idea of the goods to be supplied and unless
previously agreed specically in writing shall not form part of the Agreement.
12. Buyer’s Property.
Any designs, tools, patterns, materials, drawings, condential information or equipment furnished to the Seller by the Buyer, or any other items
which become the Buyer’s property, may be considered obsolete and may be destroyed by the Seller after two (2) consecutive years have elapsed
without the Buyer placing an order for the items which are manufactured using such property.The Seller shall not be responsible for any loss or
damage to such property while it is in the Seller’s possession or control.
13. Taxes.
Unless otherwise indicated, all prices and charges are exclusive of excise, sales, use, property, occupational or like taxes which may be imposed
by any taxing authority upon the manufacture, sale or delivery of the items sold hereunder. If any such taxes must be paid by the Seller, or if the
Seller is liable for the collection of such tax, the amount thereof shall be in addition to the amounts for the item sold. The Buyer agrees to pay all
such taxes or to reimburse the Seller therefore upon receipt of its invoice. If the Buyer claims exemption from any sales, use or other tax imposed
by any taxing authority, the Buyer shall promptly indemnify and hold the Seller harmless from and against any such tax, as well as any interest
or penalties thereon which may be assessed if the items are held to be taxable.
14. Warranty.
EXCEPT AS EXPRESSLY WARRANTED IN WRITING BY THE SELLER, THE GOODS SOLD BY THE SELLER ARE PURCHASED BY THE BUYER ”AS IS.” THE
SELLER DOES NOT WARRANT THAT THE GOODS ARE OF MERCHANTABLE QUALITY OR THAT THEY CAN BE USED FOR ANY PARTICULAR PURPOSE.
EXCEPT AS EXPRESSLY WARRANTED IN WRITING BY THE SELLER, THE SELLER MAKES NO REPRESENTATION OR WARRANTY OF ANY KIND WITH
RESPECT TOTHE PRODUCTS.
(a) The Seller warrants that the items sold hereunder shall be free from defects in material or workmanship at the time of shipment by the Seller.
The Seller warrants that if within 12 months of delivery of the goods to the Buyer the Buyer returns immediately to the Seller’s premises any of
the said goods which the Buyer believes to be defective, carrier paid, properly packed and clearly marked with the Buyer’s full name and address
and any other information such as serial numbers which may be necessary to enable the goods to be identied, together with a complete
description of the alleged defect, they will be repaired or new goods will be supplied in exchange and the goods so repaired or such new goods
will be delivered to the Buyer free of charge at the Seller’s premises; provided, however, that the foregoing warranty shall be applicable only if
upon demand by the Seller, the Buyer proves to the Seller’s satisfaction: (i) that the defect was due solely to defective workmanship; (ii) that
no alterations or repairs have been made to the goods except with the Seller’s written consent; (iii) that the defect was not caused by any act
of the Buyer or its agents; and (iv) that the defect was not caused by any matter beyond the reasonable control of the Seller, including, without
limitation, accident or normal wear and tear. (b) THISWARRANTY DOES NOT APPLY UNLESSTHE SELLER’S PRODUCTS ARE: (I) USED IN DOMESTIC
PLUMBING APPLICATIONS; (II) INSTALLED BY A LICENSED CONTRACTOR, PLUMBER OR QUALIFIED EQUIPMENT INSTALLATION PROFESSIONAL; AND
(III) INSTALLED AND OPERATED IN ACCORDANCEWITH PUBLISHED HYDROFIT / HYDRONIX WATERTECHNOLOGY SPECIFICATIONS. (c) All costs and
expenses, including freight charges, customs duties, and insurance incurred in returning the goods to the Seller’s premises in accordance with
this provision shall be paid by the Buyer. The benet of this warranty shall not be assignable by the Buyer. (d)THIS WARRANTY DOES NOT EXTEND
TO ANY GOODS NOT MANUFACTURED BY THE SELLER EVEN THOUGH SUPPLIED BY THE SELLER NOR DOES IT EXTEND TO ANY SECOND-HAND OR
RECONDITIONED GOODS NOR DOES IT EXTEND TO COMPONENTS MANUFACTURED BYTHE SELLER BUT INSTALLED, ATTACHED OR WELDED BY THE
BUYER OR HIS CUSTOMER ON EQUIPMENT NOT MANUFACTURED BY THE SELLER. GOODS NOT MANUFACTURED BY THE SELLER CARRY ONLY THE
WARRANTY (IF ANY) OF THEIR MAKERS AND THE BUYER IS ENTITLED TO THE BENEFIT THEREOF ONLY SO FAR AS THE SELLER HAS THE POWER
TO TRANSFER IT. (E) THIS WARRANTY COMPRISES THE SOLE AND ENTIRE WARRANTY PERTAINING TO ITEMS PROVIDED HEREUNDER; THE SELLER
MAKES NO OTHER WARRANTY, GUARANTEE, OR REPRESENTATION OF ANY KIND WHATSOEVER. ALL OTHER WARRANTIES, INCLUDING BUT NOT
LIMITED TO MERCHANTABILITY AND FITNESS FOR PURPOSE, WHETHER EXPRESSED OR IMPLIED, OR ARISING BY OPERATION OF LAW, TRADE USAGE,
OR COURSE OF DEALING, ARE HEREBY DISCLAIMED. (f) NOTWITHSTANDING THE FOREGOING,THERE ARE NO WARRANTIES WHATSOEVER ON ITEMS
BUILT OR ACQUIRED WHOLLY OR PARTIALLY TOTHE BUYER’S DESIGNS OR SPECIFICATIONS.
15. Limited Remedy.
THE SELLER’S LIABILITY ARISING FROM OR IN ANY WAY CONNECTEDWITH THE ITEMS SOLD ORTHIS AGREEMENT SHALL BE LIMITED EXCLUSIVELY
TO REPAIR OR REPLACEMENT OF THE ITEMS SOLD. IN NO EVENT SHALL THE SELLER BE LIABLE TO THE BUYER OR ANY THIRD PARTY FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES OF ANY KIND OR NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOST PROFITS
ARISING FROM OR IN ANY WAY CONNECTED WITH THIS AGREEMENT OR ANY ITEMS SOLD, WHETHER ALLEGED TO ARISE FROM BREACH OF
CONTRACT, EXPRESS OR IMPLIED WARRANTY, OR INTORT, INCLUDING WITHOUT LIMITATION, NEGLIGENCE, FAILURE TOWARN OR STRICT LIABILITY.
IN NO EVENT SHALL THE SELLER BE LIABLETOTHE BUYER OR ANY OTHER ENTITY FOR MORETHAN THE INVOICE PRICE RECEIVED BY THE SELLER FOR
ANY NON-CONFORMING PRODUCTS. THE SELLER SHALL NOT BE LIABLETO THE BUYER OR ANY OTHER ENTITY FOR PERSONAL INJURY, PROPERTY
DAMAGE, OR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE, EXEMPLARY, SPECIAL, OR OTHER DAMAGES OF ANY KIND,
INCLUDING WITHOUT LIMITATION THE COST OF PROCUREMENT OF SUBSTITUTE GOODS, THE LOSS OF PROFITS, PRODUCTS, OR PRODUCTION, OR
THE INTERRUPTION OF BUSINESS, HOWEVER CAUSED. THE SELLER SHALL NOT BE LIABLETO THE BUYER OR ANY OTHER ENTITY ON ANY THEORY OF
LIABILITY INCLUDING WITHOUT LIMITATION BREACH OF CONTRACT OR EXPRESS OR IMPLIED WARRANTY, TORT, NEGLIGENCE, FAILURE TO WARN,
OR STRICT LIABILITY, AND WHETHER OR NOT THE SELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE ESSENTIAL PURPOSE
OF THIS PROVISION IS TO LIMIT THE LIABILITY OF THE SELLER ARISING OUT OF THE SALE OF PRODUCTS TO THE BUYERWHETHER FOR BREACH OF
CONTRACT, NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY. THESE LIMITATIONS SHALL APPLY NOTWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY AND NOTWITHSTANDINGTHE PROVISIONS OF ANY OTHER AGREEMENT BETWEENTHE SELLER AND THE BUYER.
16. Indemnity for Infringement of Intellectual Property Rights.
(a) The Buyer shall defend and indemnify the Seller against all actions, claims, demands, penalties and costs by third parties in tort, or for
infringement, or alleged infringement, of patents, trademarks, copyrights, trade dress, trade secret or other rights of any third party resulting
from the goods manufactured in accordance with the Buyer’s specications or based on any information provided by the Buyer. The Buyer will
defend any action against the Seller for title, patent, trademark, copyright infringement, or other claimed by a third party at the Buyer’s sole
cost and expense. (b) The Seller shall have no liability for infringement of any patents, trademarks, copyrights, trade dress, trade secrets or
similar rights except as provided in this provision.The Seller will defend and indemnify the Buyer against allegations of infringement of patents,
trademarks, copyrights, trade dress and trade secrets (”Intellectual Property Rights”). The Seller will defend at its expense and will pay the cost
of any settlement or damages awarded in an action brought against the Buyer based on an allegation that an item sold pursuant to this contract
infringes the Intellectual Property Rights of a third party. The Seller’s obligation to defend and indemnify the Buyer is contingent on the Buyer
notifying the Seller within 10 days after sole control over the defense of any allegations or actions, including all negotiations for settlement or
compromise. If an item sold hereunder is subject to a claim that it infringes the Intellectual Property Rights of a third party, the Seller may, at its
sole expense and option, procure for the Buyer the right to continue using said item, replace or modify said item so as to make it non-infringing,
or oer to accept return of said item and return the purchase price less a reasonable allowance for depreciation. Notwithstanding the foregoing,
the Seller shall have no liability for claims of infringement based on information provided by Buyer, or directed to items delivered hereunder for
which the designs are specied in combination or use in a system of any item sold hereunder.The foregoing in this provision shall constitute the
Seller’s sole and exclusive liability and the Buyer’s sole and exclusive remedy for infringement of Intellectual Property Rights.
17. Lien.
In addition to any right of lien to which the Seller may by law be entitled, the Seller shall have a general lien on all goods of the Buyer in the
Seller’s possession (although such goods or some of them may have been paid for) for the unpaid price of any other goods sold and delivered to
the Buyer by the Seller under the same or other contracts.
18. Waiver.
The Seller’s rights shall not be aected or restricted by any indulgence or forbearance granted to the Buyer. No waiver by the Seller of any breach
shall operate as a waiver of any later breach.
19. Force Majeure.
The Seller shall be excused from performing any of its obligations under this Agreement which are prevented or delayed by any occurrence
not within the reasonable control of the Seller, including but not limited to, accidents, acts of God, destruction or damage to the goods or the
Seller’s manufacturing plant, delays or failures in delivery of carriers or suppliers, shortages of materials, strikes or other labor matters, oods,
earthquakes, re, riots, explosions, or any regulations, rules, ordinances or orders of any governmental authority, federal, state or local, whether
such cause exists at the date of the order or not.
20. Buyer’s Representation of Solvency.
The Buyer hereby represents that as of the signing of this Agreement it was not insolvent within the meaning of the Uniform Commercial Code
or any Bankruptcy Laws.
21. Assignment and Delegation.
The rights and obligations of the parties under this Agreement may not be assigned or delegated, except on the express written consent of the
other party to the assignment or delegation.
22. Integration.
The rights and obligations of the parties and the terms and conditions set forth herein, together with any amendments, modications and any
dierent terms and conditions expressly accepted by the Seller in writing, shall constitute a complete and exclusive statement of the terms of this
Agreement. This Agreement supersedes not only all prior agreements, but also oral agreements made contemporaneously with the execution of
this Agreement. All such materials may not be used to supplement, explain, or contradict the terms of this Agreement.
23. Severability.
If any of these conditions or any part thereof purports to exclude or restrict or limit any liability and such exclusion or restriction or limitation is
prohibited or rendered void or unenforceable by any legislation to which it is subject, or is itself prohibited or rendered void or unenforceable
by any legislation to which it is subject, then the exclusion, restriction or limitation on the condition or part thereof in question shall be so
prohibited or rendered void or unenforceable and the validity or enforceability of any other part of these provisions shall not thereby be aected.
24. Governing Law/Limitation on Actions.
The terms, conditions, rights, and obligations under this Agreement shall be construed under the laws of the State of California, without regard
to principles of conicts of laws. No actions arising out of the sale of the items sold hereunder or this Agreement may be brought by the Buyer
more than two (2) years after such cause of action accrues.
Page 18 of 20 TRITTON IXC | P.O. Box 2235 Chino Hills, CA 91709 • USA
WATER PURIFICATION SYSTEM
SERIES IXC-850
Notes
LIT-IXC-850-MAN 01/07/20 © 2019 - 2020 Tritton IXC. All Rights Reserved.
This manual suits for next models
1
Table of contents
