Trotec PT 4500 S User manual

TRT-BA-PT4500S-PT6500S-PT15000S-PT23000S-TC220504TTRT01-009-EN
PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
EN
ORIGINAL INSTRUCTIONS
AIR CONDITIONER

2 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Table of contents
Notes regarding the instructions ..........................................2
Safety .....................................................................................3
Information about the device................................................5
Transport and storage...........................................................9
Assembly and start-up........................................................10
Operation .............................................................................14
Available accessories..........................................................15
Errors and faults..................................................................16
Maintenance ........................................................................18
Technical annex...................................................................22
Disposal ...............................................................................49
Declaration of conformity ...................................................49
Notes regarding the instructions
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Danger
This symbol indicates dangers to the life and health of
persons due to suspended loads.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
instructions must be observed.
Wear safety glasses
Information marked with this symbol indicates that you
should wear eye protection.
Wear a protective mask
Information marked with this symbol indicates that you
should wear a protective mask.
Wear protective gloves
Information marked with this symbol indicates that you
should wear protective gloves.
Wear foot protection
Information marked with this symbol indicates that you
should wear safety boots.

EN 3
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
You can download the current version of the instructions via the
following link:
PT 4500 S
https://hub.trotec.com/?id=43855
PT 6500 S
https://hub.trotec.com/?id=40996
PT 15000 S
https://hub.trotec.com/?id=42206
PT 23000 S
https:https://hub.trotec.com/?id=45165
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Only put up the device in an upright, stable position on firm
ground.
• Never drink the water/ glycol mixture! Dispose of the
water/ glycol mixture properly!
• Never fill the tank directly from a water line. Use a suitable
vessel or other means.
• Let the device dry out after a wet clean. Do not operate it
when wet.
• Do not use the device with wet or damp hands.
• Do not expose the device to directly squirting water.
• Never insert any objects or limbs into the device.
• Do not cover the device during operation.
• Do not sit on the device.
• This appliance is not a toy. Keep away from children and
animals. Do not leave the device unattended during
operation.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The mains connection must correspond to the
specifications in the Technical annex.
• Insert the mains plug into a properly fused mains socket.

4 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
• Observe the technical data when selecting extensions to
the power cable. Completely unroll the extension cable.
Avoid electrical overload.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• When positioning the device, observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
annex.
• Make sure that the air inlet and outlet are not obstructed.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Make sure that the suction side is kept free of dirt and
loose objects.
• Discharge the collected condensate before transport and
storage. Do not drink it. Health hazard!
• Only transport the device in an upright position.
Intended use
Only use the device for cooling, ventilating and dehumidifying
indoor air whilst adhering to the technical data.
Foreseeable misuse
• Do not place the device on wet or flooded ground.
• Do not place any objects, e.g. clothing, on the device.
• Do not use the device out of doors.
• Do not make any unauthorised modifications, alterations or
structural changes to the device.
• Any use other than the intended use is regarded as a
reasonably foreseeable misuse.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric devices in damp areas.
• have read and understood the instructions, especially the
Safety chapter.
Maintenance tasks which require the housing to be opened
must only be carried out by specialist companies for cooling and
air-conditioning or by Trotec.
Electrically skilled person
Electrically skilled personnel must be able to read and
understand electric circuit diagrams, to put electrical systems
into service and to maintain them, to wire control cabinets, to
ensure the functionality of electrical components and to identify
possible hazards from electrical and electronic systems.
Personal protective equipment
Wear safety glasses
For start-up, maintenance and troubleshooting always
wear suitable safety glasses.
Wear a protective mask
For cleaning and maintenance tasks wear an
appropriate protective mask.
Wear protective gloves
For start-up, maintenance and troubleshooting always
wear suitable protective gloves.
Wear foot protection
For transportation, start-up, maintenance and
troubleshooting always wear suitable foot protection.

EN 5
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Do not touch the mains plug with wet or damp hands.
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
Risk of death due to suspended loads!
Make sure that nobody is situated in the immediate
proximity.
Danger
Keep the water/ glycol mixture away from your eyes at
all times! Should the water/ glycol mixture contact
your eyes, immediately rinse them with clear water!
Danger
Never drink the water/ glycol mixture! Glycol is unfit
for human consumption and harmful to health!
Note
To avoid damages to the device, only transport and
operate the device in an upright position! It must
neither be tilted nor laid down!
Note
Do not operate the device without an inserted air filter!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
Behaviour in the event of an emergency
1. Switch the device off.
2. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.
3. Do not reconnect a defective device to the mains.
Information about the device
Device description
The devices PT4500S, PT6500S, PT15000S and PT23000S
are chiefly used for cooling room air. Moreover, the devices also
provide the opportunity of air circulation without cooling effect.
The devices are operated via the control panel(1) at the
respective device.
The devices are air conditioners with split cooling circuits. The
refrigerant circuit of the basic device(2) is self-contained. For
the dissipation of warmth it is emitted via one or two heat
exchangers to a second cooling circuit. A second circuit
transports warmed water/ glycol mixture to the external heat
exchanger(6) to cool it down again.
The air conditioners PT4500S and PT6500S can be used with
one heat exchanger. The PT15000S requires two heat
exchangers. The PT23000S operates with three heat
exchangers.
The devices cool the room air by withdrawing warmth. The
refrigerant cools down the air coming from the room and in
doing so absorbs the heat. The thusly cooled air is introduced to
the room, where the device is positioned, via the fan.
Accumulating condensate is discharged via a separate
hose(3,11) to the external heat exchanger in order to be
drained or to evaporate there.
The "operating hours counter" option is already integrated in
the control. As standard the PT15000S and PT23000S come
with an installed energy meter. For PT4500S and PT6500S
you can optionally order a dual counter.

6 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Device depiction
PT4500S/ PT6500S
20
18
17
16
1
2
19
21
35
15
14
13
3
4
5
6
7
8
9
35
36
37
10
11
12
No. Operating element
1Control panel with integrated operating hours counter
2Basic device
3Condensation hose connection
4Line to the external heat exchanger
5Compensation tank with screw-on lid for water circuit
6External heat exchanger
7Fan
8Spacer
9Mains connection external heat exchanger
10 Connection for the line to the basic device
11 Connection for the line from the basic device
12 Condensation hose connection
13 Line from the external heat exchanger
14 Mains connection to external heat exchanger
15 Mains connection with power plug
16 Wheel with parking brake
17 Carrying handle
18 Air inlet with air filter
19 Louvre and air outlet
20 Transport handles
21 Dual counter for operating hours and energy consumption (MID-
compliant) optional
35 Earthing connection
36 Protective earth conductor
37 Vent valve for water circuit

EN 7
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
PT15000S
20
19
18
17
16
1
2
21 a
34
35
13
14
15
4
14
5
13
35
6
7
37
38
12
11
935
10
No. Operating element
1Control panel with integrated operating hours counter
2Basic device
3Condensation hose connection
4Line to the external heat exchanger
5Compensation tank with screw-on lid for water circuit
6External heat exchanger
7Fan
9Mains connection external heat exchanger
10 Connection for the line to the basic device
11 Connection for the line from the basic device
12 Condensation hose connection
13 Line from the external heat exchanger
14 Mains connection to external heat exchanger
15 Mains connection with power plug
16 Wheel with parking brake
17 Carrying handle
18 Air inlet with air filter
19 Louvre and air outlet
20 Transport handles
21 a Energy meter (MID-compliant)
35 Earthing connection
37 Vent valve for water circuit
38 Adjustable spacer for device protection

8 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
PT23000S
20
19
18
17
16
1
2
21
15
4
35 35 35
33
44
55
13 13
13
14 14
14
6
7
37
38
12
11
935
10
No. Operating element
1Control panel with integrated operating hours counter
2Basic device
3Condensation hose connection
4Line to the external heat exchanger
5Compensation tank with screw-on lid for water circuit
6External heat exchanger
7Fan
9Mains connection external heat exchanger
10 Connection for the line to the basic device
11 Connection for the line from the basic device
12 Condensation hose connection
13 Line from the external heat exchanger
14 Mains connection to external heat exchanger
15 Mains connection with power plug
16 Wheel with parking brake
17 Carrying handle
18 Air inlet with air filter
19 Louvre and air outlet
20 Transport handles
21 a Energy meter (MID-compliant)
35 Earthing connection
37 Vent valve for water circuit
38 Adjustable spacer for device protection

EN 9
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
To make the device easier to transport, it is fitted with wheels.
To make the device easier to transport, it is fitted with a carry
handle.
Wear foot protection
For transportation, start-up, maintenance and
troubleshooting always wear suitable foot protection.
Always utilize the help of another person to transport the device.
Do not try to transport the device without the help of another
person. To lift the device, use a forklift or an elevating truck as
appropriate.
Before transporting the device, observe the following:
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Drain the remaining condensate from the device.
• Do not use the power cable to drag the device.
• Disconnect the connection to the external unit.
• Release the brakes at the castors.
• Only wheel the device on firm and level surfaces.
While transporting the device, observe the following:
• Only transport the device in an upright position.
• Only hold the basic device by the transport handles when
wheeling the device.
• Use the carrying handles to carry the basic device. Always
utilize the help of another person to carry the device.
After transporting the device, proceed as follows:
• Set up the device in an upright position after transport.
• Apply and lock the brakes at the wheels again.
Transportation by crane – crane lugs (optional)
Danger
Suspended loads!
Risk of death due to falling loads.
• Proceed with the utmost care when lifting loads and
putting them down.
• Only use the crane lugs specified in the instructions (see
chapter Available accessories).
• Regularly check the crane lugs for wear.
• Ensure the unobstructed view of the load during your work.
• Never stand underneath suspended loads or in their
immediate vicinity.
• Keep other persons away from the danger area. Make use
of suitable barriers or assign supervisors.
• When setting the load down, avoid touching close-by
objects and a resulting inclined position.
• Always lift the loads vertically off the ground. Any
inclination is prohibited due to the associated risk of
accidents.
• Never exceed the permissible load-carrying capacity of the
employed lifting equipment.

10 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Wear foot protection
For transportation, start-up, maintenance and
troubleshooting always wear suitable foot protection.
max.
45°
Storage
Before storing the device, proceed as follows:
• Drain the remaining condensate from the device.
• Empty the tank and dispose of the water/ glycol mixture
properly.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
When the device is not being used, observe the following
storage conditions:
• Store the device in a dry location and protected from frost
and heat.
• Store the device in an upright position where it is protected
from dust and direct sunlight.
• If required, use a cover to protect the device from invasive
dust.
• Place no further devices or objects on top of the device to
prevent it from being damaged.
Assembly and start-up
Scope of delivery
PT4500S
• 1x Device
• 1x External heat exchanger
• 1x 10m connection set
• 1x manual
PT6500S
• 1x Device
• 1x External heat exchanger
• 1x 10m connection set
• 1x manual
PT15000S
• 1x Device
• 2x External heat exchanger
• 2x 10m connection set
• 1x manual
PT23000S
• 1x Device
• 3x External heat exchanger
• 3x 10m connection set
• 1x manual

EN 11
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.
Start-up
When positioning the device, observe the minimum distance
from walls or other objects as described in the Technical data
chapter.
A
B
C
C
D
• Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.
• Only put up the device in an upright, stable position on firm
ground.
• Do not create tripping hazards when laying the power
cable or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.
• Make sure that extension cables are completely unrolled.
• Keep air inlets and outlets as well as the exhaust air hose
connection free.
• Make sure that no curtains or other objects interfere with
the air flow.
Installation of the external heat exchanger
Please note, that to the front the external heat exchanger
requires a minimum distance of 3m to the wall or other objects.
Towards the rear a spacer(8) fitted to the external heat
exchanger of the device ensures a sufficient spacing.
Connecting basic device and external heat exchanger
Wear safety glasses
For start-up, maintenance and troubleshooting always
wear suitable safety glasses.
Wear protective gloves
For start-up, maintenance and troubleshooting always
wear suitable protective gloves.
Wear foot protection
For transportation, start-up, maintenance and
troubleshooting always wear suitable foot protection.
Warning of electrical voltage
Earth the air conditioner properly.
Electrical work on the air conditioner must only be
carried out by a qualified electrician.
Incorrect earthing can lead to electric shocks.
Connect the earth connections(35) of the external heat
exchanger(s) to the basic device.
Use proper protective earth conductors.
Never connect protective earth conductors to gas
pipes, water pipes, lightning arresters or the earthing
conductor of communication systems.

12 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
PT4500S/ PT6500S
1. Connect the condensation hose to the designated
connections(3,12) at the basic device and at the external
heat exchanger.
2. Connect the power cable of the external heat exchanger(9)
to the mains connection(14) at the basic device.
3. Connect the hose lines between basic device and external
heat exchanger.
The scope of delivery includes a 10m connection line.
With further connection sets (see chapter Available
accessories) it may be extended to a length of up to 30m.
Note
The hoses are already filled with a water/ glycol
mixture. Therefore, a little liquid exits during coupling.
This loss is compensated for with the liquid from the
compensation tank(5).
35
14
3
5
12 8
35
9
PT15000S/ PT23000S
1. Connect the condensation hose to the designated
connections(3,12) at the basic device and at the external
heat exchanger.
2. Connect the power cable of the external heat exchanger(9)
to the mains connection(14) at the basic device. When
using the PT15000S, always connect both external heat
exchangers. When using the PT23000S, always connect
all three external heat exchangers.
3. Connect the hose lines between the basic device and the
external heat exchangers.
The scope of delivery includes a 10m connection line.
With further connection sets (see chapter Available
accessories) it may be extended to a length of up to 30m.
Note
The hoses are already filled with a water/ glycol
mixture. Therefore, a little liquid exits during coupling.
This loss is compensated for with the liquid from the
compensation tank(5).
9
12
35
View of the PT15000S:
35
35
3
5
14 14
View of the PT23000S:
35 335 35
3
5
514 14
14

EN 13
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Inserting the air filter
Note
Do not operate the device without an inserted air filter!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
• Make sure that the air filter is installed before switching
the device on.
18
Measures to be taken before start-up
1. Check air inlet(18) and outlet(19) for foreign objects and
remove these, if necessary.
2. Check the air filter for dirt and clean it, if required (see
chapter Maintenance).
3. Ensure that the basic device(12) and the external heat
exchanger(6) are properly connected to each other.
4. Check whether there is sufficient water in the tank(5).
Also check the glycol content (using an antifreeze tester).
Note
Only use monopropylene glycol and do not mix
different types of glycol. The maximum glycol
concentration amounts to30% (see technical data).
Installing the optional dual counter (PT4500S/ PT6500S)
An optional dual counter can be connected to the device
PT4500S or PT6500S. Please proceed as follows to install the
optional dual counter:
Note
The optional dual counter may only be installed by a
qualified electrician!
• The previously described steps for the start-up of the
device PT4500S or PT6500S have been carried out.
1. Switch the device off.
2. Hold onto the mains plug while pulling the power cable out
of the mains socket.
3. Remove the cover of the control cabinet at the device.
4. Use the circuit diagram in chapter Technical data to
identify terminal2 and terminal3.
5. Remove the red jumper between terminal2 and
terminal3.
6. Connect the L-in input at the dual counter to terminal2.
7. Connect the L-out output at the dual counter to terminal3.
8. Connect the Noutput at the dual counter to the blue
Nterminal in the control cabinet.
9. Position the dual counter correctly at the rear of the
device(21).
10. Reattach the cover of the control cabinet to the device.
11. The device may now be reconnected as described in
chapter Start-up.

14 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Operation Control panel PT4500S/ PT6500S/ PT15000S/
PT23000S
25 26
22 23 24
32 31 30 29 28 27
No. Designation Function
22 VENT. indication Is illuminated when ventilation mode is activated.
23 POWER indication Is illuminated in green when mains voltage is applied to the device.
Flashes green when the compressor is not running.
24 ALARM indication Is illuminated in red if an error has occurred at the device, see chapter Errors and faults.
25 Display Indicates the current ambient temperature.
Displays dEFr when the device operates in defrost mode (automatic defrosting).
Indicates an error message in case of a fault (see chapter Errors and faults).
26 FAN SPEED
indication
Indicates the selected fan stage.
(The device PT4500S is equipped with 2fan stages.)
27 FAN SPEED button To select the fan speed.
28 HOURS button To activate or deactivate the operating hours display.
The operating hours will be indicated on the display(23).
29 SET+ button To increase or reduce the target temperature for cooling.
30 SET- button
31 ON/OFF button Switches the device on or off.
32 VENT. button To activate or deactivate ventilation mode.

EN 15
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Switching the device on
1. Insert the mains plug(15) into a properly fused mains
socket.
2. Press the ON/OFF button(31) to switch the device on.
ðThe device starts with the previously selected setting.
ðThe display indicates the current ambient temperature.
3. Use the buttons SET+(29) and SET-(30) to select the
desired target temperature.
4. Select the desired fan speed by use of the FAN SPEED
button(27).
5. Press the HOURS button(28) to display the operating
hours.
ðThe operating hours will be indicated on the
display(25).
Setting the operating mode
The following operating modes are available:
•cooling: The room air is circulated by the device and
cooled at the same time.
•ventilation: The room air is circulated by the device.
The device will start up in cooling mode approx.3.5min after
switch-on.
• You can select ventilation mode (without cooling) by means
of the VENT. button(32).
– The VENT. indication(22) will be illuminated when
ventilation mode is activated.
Automatic defrost
At low ambient temperatures, ice may form at the evaporator
during dehumidification.
The device then carries out an automatic defrost by means of
the hot gas feed. Here, a hot cooling agent is led into the iced
evaporator for its surfaces to defrost.
The duration of the defrost process can vary. The hot gas
automatic defrost system integrated in the device automatically
switches on the defrost cycle at regular intervals.
Do not switch the device off during automatic defrost. Do not
remove the mains plug from the mains socket.
After automatic defrosting the device keeps running for approx.
90s for the purpose of air circulation – regardless of the
ambient temperature and the desired room temperature.
Afterwards the device resumes operation with the set values.
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch off the device.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• If necessary, remove the condensation drain hose and any
residual fluid from it.
• Clean the device according to the Maintenance chapter.
• Store the device according to the Transport and storage
chapter.
Available accessories
Designation Article number
Connection set, 10m 1.210.000.133
Connection set, 5m 1.210.000.134
Spot cooling attachment PT4500S 1.210.000.149
Spot cooling attachment PT6500S 1.210.000.151
Spot cooling attachment PT15000S 1.210.000.153
Spot cooling attachment PT23000S 1.210.000.154
PT4500S/ PT6500S air transport hose
TronectSP-T, I=7.6m, diameter 203mm
6.100.001.200
PT15000S/ PT23000S air transport hose
TronectSP-T, I=7.6m, diameter 305mm
6.100.001.205
PlanoPT connection feedthrough
underneath doors
1.210.000.101
DualHex coupling 1.210.000.104
Crane lugs for PT4500S/ PT6500S 1.210.000.105
Crane lugs for PT15000S/ PT23000S 1.210.000.106
Weather protection cover PT4500S 1.210.000.160
Weather protection cover PT6500S 1.210.000.161
Weather protection cover PT15000S 1.210.000.162
Weather protection cover PT23000S 1.210.000.163

16 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
Wear safety glasses
For start-up, maintenance and troubleshooting always
wear suitable safety glasses.
Wear protective gloves
For start-up, maintenance and troubleshooting always
wear suitable protective gloves.
Wear foot protection
For transportation, start-up, maintenance and
troubleshooting always wear suitable foot protection.
The device does not start:
• Check the power connection.
• Check the on-site fusing.
• Observe the operating temperature according to the
chapter Technical annex.
• Check whether the POWER(23) indication is illuminated. If
not, check the power connection and the plug. The fuses
inside the plug and/ or on the mainboard might be
defective.
In case of defective fuses also check the points listed
under the error message HIPS.
• Wait for 10minutes before restarting the device. If the
device is not starting, have the electrics checked by a
specialist company or by Trotec.
The device works with reduced or no cooling capacity:
• Check whether cooling mode is selected.
• Check the air filter(s) for dirt. If necessary, clean or replace
the air filter(s).
• Check the minimum distance to walls or other objects.
Position the device a little more in the room's centre if
required.
• Check whether any windows and/or doors of the room are
open. If so, close them.
• Check the temperature setting at the device. Reduce the
set temperature if it is higher than the room temperature.
• Also check the points listed under the error message HIPS.
The device is loud or vibrates:
• Check whether the device is set up in a stable and upright
position.
Condensate is leaking from the basic device:
• Check the device for leaks.
The compressor does not start:
• Check whether the overheating protection of the
compressor has tripped. Disconnect the device from the
mains and let it cool down for approx. 10minutes before
reconnecting it.
• The compressor may start up with a delay of 3minutes, as
it is provided with an internal protection against direct
restart.
The device gets very warm, is loud or is losing
performance:
• Check the air inlets and air filters for dirt. Remove external
dirt.
• From the outside, check the device for dirt (see chapter
Maintenance). If the inside of the device is dirty, have it
cleaned by a specialist company for cooling and air-
conditioning or by Trotec.
• Air may have accumulated in the water-glycol circuit of the
external unit that is higher positioned. Actuate the air vent
valve(37) on the external unit to completely bleed the
circuit.
Note
Wait for at least 3minutes after maintenance and
repair work. Only then switch the device back on.
The device still does not operate correctly after these
checks:
Please contact the customer service. If necessary, bring the
device to a specialist company for cooling and air-conditioning
or to Trotec for repair.

EN 17
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Error codes Error messages
When the Alarm LED lights up, the following error messages
might be displayed:
Message Cause Troubleshooting
PunP • The internal pump alarm is activated. • Empty the pump container (e.g. by means of a suction pump), then
check whether the pump operates properly again. The alarm stops as
soon as the water has been completely drained from the pump
container.
LOPS • The air filter might be contaminated. • Check the air filter for dirt. If required, clean the air filter (see chapter
Maintenance).
• When the fault has been eliminated, disconnect the mains plug and plug
it back in after 5s to reset the alarm.
• There might be a leak in the internal
refrigerant circuit.
• Have the device checked by a specialist company for cooling and air-
conditioning.
• When the fault has been eliminated, disconnect the mains plug and plug
it back in after 5s to reset the alarm.
HIPS • Plug connections at the external
cooling circuit do not fit properly.
• The pump of the external cooling
circuit is not operating properly.
• The fan of the external heat
exchanger does not operate.
• The device might not be operating
due to excessive ambient
temperatures.
• There is insufficient water in the
cooling circuit between the basic
device and the external unit.
• Check the plug connections at the external heat exchanger.
• Check the internal brass filter of the pump for dirt and clean it if
necessary (see “Water filter” in exploded assembly drawings).
• Check the pump. If necessary, have the pump checked by a specialist
company for cooling and air-conditioning.
• Check the fan. If necessary, have the fan checked by a specialist
company for cooling and air-conditioning.
• Check the outside temperature (temperatures above 35°C can be
critical).
• After the inspection press the RESET button(40).
• Disconnect the mains plug and plug it back in after 5s to reset the
alarm.
40
• Check whether there is sufficient water in the tank(5).
Note:
After eliminating the HIPS fault, vent the external heat exchanger at the vent
valve for the water circuit(37).
PHAS
(PT15000S and
PT23000S)
• The wrong rotating field is set. • Exchange both phases in the mains plug.

18 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Maintenance Maintenance intervals
Maintenance and care interval before every start-
up
as needed at least every
2weeks
at least every
4weeks
at least every
6months
at least annually
Check air inlet and outlet for dirt and
foreign objects and clean ifnecessary
X X
Clean the exterior X X
Visually check the inside of the device for
dirt
X X
Check the air filter for dirt and foreign
objects and clean or replace if necessary
X X
Replace the air filter X
Check for damage X
Check the attachment screws X X
Test run X
Maintenance and care log
Device type: ............................................. Device number: ....................................
Maintenance and care interval 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Check air inlets and outlets for dirt and
foreign objects and clean ifnecessary
Check the air filter for dirt and foreign
objects and clean or replace if necessary
Clean the exterior
Visually check the inside of the device for
dirt
Replace the air filter
Check the attachment screws
Test run
1. Date: ........................................
Signature: .....................................
2. Date: ..........................................
Signature: ......................................
3. Date: ..........................................
Signature: ......................................
4. Date: ..........................................
Signature: ......................................
5. Date: ........................................
Signature: .....................................
6. Date: ..........................................
Signature: ......................................
7. Date: ..........................................
Signature: ......................................
8. Date: ..........................................
Signature: ......................................
9. Date: ........................................
Signature: .....................................
10. Date: ........................................
Signature: ......................................
11. Date: ........................................
Signature: ......................................
12. Date: ........................................
Signature: ......................................
13. Date: ......................................
Signature: .....................................
14. Date: ........................................
Signature: ......................................
15. Date: ........................................
Signature: ......................................
16. Date: ........................................
Signature: ......................................

EN 19
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Activities required before starting maintenance
Wear safety glasses
For start-up, maintenance and troubleshooting always
wear suitable safety glasses.
Wear a protective mask
For cleaning and maintenance tasks wear an
appropriate protective mask.
Wear protective gloves
For start-up, maintenance and troubleshooting always
wear suitable protective gloves.
Wear foot protection
For transportation, start-up, maintenance and
troubleshooting always wear suitable foot protection.
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
Warning of electrical voltage
Tasks which require the device to be opened must
only be carried out by authorised specialist
companies or by Trotec.
Refrigerant circuit
• The refrigerant circuit of the basic device is a
maintenance-free, hermetically sealed system and may
only be maintained or repaired by specialist companies for
cooling and air-conditioning or by Trotec.
Cleaning the housing
Clean the housing with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Checking the pump for free rotation
This task shall be performed when the air conditioner has not
been in use for over a month.
1. Use a screwdriver to check the pump for unobstructed
movement.
If the pump is jammed, please contact an authorised specialist
company or Trotec.

20 EN
air conditioner PT 4500 S / PT 6500 S / PT 15000 S / PT 23000 S
Visual inspection of the inside of the device for dirt
1. Remove the air filter.
2. Use a torch to illuminate the openings of the device.
3. Check the inside of the device for dirt.
4. If you see a thick layer of dust, have the inside of the
device cleaned by a specialist company for cooling and air-
conditioning or by Trotec.
5. Put the air filter back in.
Cleaning the air filter
The air filter has to be cleaned as soon as it is dirty. This is
brought to light e.g. by a reduced capacity (see chapter Errors
and faults).
Warning
Ensure that the air filter is not worn or damaged. The
corners and edges of the air filter must not be
deformed or rounded. Before reinserting the air filter,
make sure that it is undamaged and dry!
1. Loosen the two attachment screws(33) at the air inlet
cover(18).
33
33
18
2. Slightly lift the air inlet cover(18).
18
