Trotec BD5A User manual

TRT-BA-BD5A-TC-001-EN
BD5A
EN
OPERATING MANUAL
CROSS LINE LASER

1 EN
Operating manual – cross line laser BD5A
Table of contents
Notes regarding the operating manual.................................1
Safety .....................................................................................2
Information about the device................................................3
Transport and storage...........................................................4
Operation ...............................................................................5
Maintenance and repair ........................................................9
Disposal .................................................................................9
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of laser radiation
This symbol indicates dangers to the health of persons
due to laser radiation.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Notice
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
BD5A
http://hub.trotec.com/?id=40083
Legal notice
This release replaces all previous versions. No part of this
publication may be reproduced without written permission from
TrotecGmbH&Co.KG. The same applies for electronically
processing, duplicating or spreading the publication. Subject to
technical changes. All rights reserved. Trademarks are used
without guarantee that they may be used freely and primarily
following the spelling of the manufacturer. Product names are
registered.
Changes to construction in the interests of constant
improvements to the product, as well as changes to the shape
and colour are reserved.
The scope of delivery may vary from product images. This
document was created with all due care.
TrotecGmbH&Co.KG accepts no liability whatsoever for
possible mistakes or omissions.
The only party responsible for determining valid measured
results, drawing conclusions and deriving actions is the user.
TrotecGmbH&Co.KG accepts no claims of warranty for the
correctness of the determined measured values or measured
results.
Further, TrotecGmbH&Co.KG accepts no liability whatsoever
for possible mistakes or damage which have been caused by
utilising the determined measured results.
© TrotecGmbH&Co.KG

EN 2
Operating manual – cross line laser BD5A
Warranty and liability
The device complies with the fundamental health and safety
requirements of the applicable EU regulations and was tested at
the factory for perfect functionality multiple times.
If malfunctions occur nonetheless, please contact your dealer or
distributor.
When making a warranty claim, supply the device number (see
label on the device).
When manufacturer's instructions or legal regulations have not
been followed, or after unauthorised changes to the device are
made, the manufacturer is not responsible for the resulting
damages. Changes to the device or unauthorised replacement
of individual parts can drastically impact the electrical safety of
this product and will result in the loss of the warranty. Liability
does not extend to damages to people or property caused by the
device being used other than as described in the instructions in
this operating manual. Subject to changes to technical design
and model changes as part of constant development and
product improvement without prior notice.
No liability is accepted for damages resulting from improper
use. In such a case, any warranty claims will be voided also.
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Do not immerse the device in water. Do not allow liquids to
penetrate into the device.
• The device may only be used in dry surroundings and must
not be used in the rain or at a relative humidity exceeding
the operating conditions.
• Protect the device from permanent direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device with a tool.
• Avoid looking directly into the laser beam.
• Never point the laser beam at people or animals.
• Only use the device if sufficient safety precautions were
taken at the surveyed location (e.g. when performing
measurements along public roads, on building sites etc.).
Otherwise do not use the device.
• Observe the storage and operating conditions (see chapter
Technical data).
Intended use
Only use the device for the projection on non-reflective surfaces
as an aid to determine and check horizontal, vertical and/ or
parallel lines. Observe and comply with the technical data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Improper use
Do not use the device in potentially explosive atmospheres or in
liquids. Never point it at people or animals. Trotec accepts no
liability for damages resulting from improper use. In such a
case, any warranty claims will be voided.
Any unauthorised modifications, alterations or structural
changes to the device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
laser measuring devices.
• have read and understood the operating manual, especially
the Safety chapter.

3 EN
Operating manual – cross line laser BD5A
Residual risks
Warning of laser radiation
Laser class2, P max.: > 1mW, λ: 650nm,
EN 60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Notice
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Notice
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The cross line laserBD5A projects laser lines on surfaces, e.g.
to drill holes in a straight line – similar to using a spirit level.
The device comes with the following features:
• Projects light-intense laser lines up to a distance of 10m
• Self-levelling up to an inclination of 4°
• Laser projection either as cross lines or as individual
horizontal or vertical line
• Battery-operated
• Integrated ¼ inch tripod connection
Device depiction
1
2
4
3
5
No. Designation
1 ON/ OFF/ operating mode button
2 ON/ OFF/ lock switch
3 1/4inch tripod connection (bottom)
4 Battery compartment with cover
5 Laser outlet opening

EN 4
Operating manual – cross line laser BD5A
Multifunctional mount
6
7
8
9
12
11
10
No. Designation
6 Screw (for tripod connection)
7 Wing nut (for ball joints)
8 Locking screw (for retainer with jaws)
9 Lever (for suction cup)
10 Suction cup
11 Retainer with jaws
12 Ball joint
Technical data
Parameter Value
Model: BD5A
Weight: 275 g
Dimensions (length x width x
height): 83 x 60 x 72 mm
Accuracy – laser: at 0° to 4°: ±0.8mm/m
at ≥4°: ±1mm/m
Range: 10 m
Operating temperature: -20 °C to 50 °C
Storage temperature: -20 °C to 50 °C
Laser output: < 1 mW (650 nm)
Laser class: 2
Power supply: 2x AlkalineAA, 1.5V batteries
Scope of delivery
• 1x Cross line laser BD5A
• 2x AlkalineAA, 1.5V batteries
• 1x Multifunctional mount
• 1 x Quick guide
Transport and storage
Notice
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device use a suitable bag to protect it from
external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• Dry and protected from frost and heat
• Protected from dust and direct sunlight
• With a cover to protect it from invasive dust if necessary
• The storage temperature is the same as the range given in
the Technical data chapter
• Remove the batteries from the device

5 EN
Operating manual – cross line laser BD5A
Operation
Inserting the batteries
Insert the supplied batteries into the device before first use.
Notice
Make sure that the surface of the device is dry and the
device is switched off.
1. Open the cover(4) of the battery compartment.
4
2. If applicable, remove the old batteries.
3. Insert the new batteries in the battery compartment with
correct polarity.
4. Then close the cover of the battery compartment(4) again.
Switching the device on
Warning of laser radiation
Laser class2, P max.: > 1mW, λ: 650nm,
EN 60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
The device has 2different modes of operation. On the one hand,
you can use the device with the automatic self-levelling
function, on the other, it is possible to set the laser to a fix
position.

EN 6
Operating manual – cross line laser BD5A
Self-levelling function of the laser
1. Slide the on/off switch(2) to to switch the device on.
2
ðBoth the vertical and the horizontal laser switch on.
ðThe operating mode button(1) is illuminated in green.
ðIf the operating mode button(1) is illuminated in red
and the laser flashes, the permissible inclination range
of 4° is exceeded. Position the device horizontally.
2. By means of the operating mode button(1) you can select
whether both lasers are to be activated or only either the
horizontal or the vertical laser.
2x
1x
1
3. When positioning the device as desired, the self-levelling
function of the lasers commences automatically.
ðWhen exceeding the permissible inclination range of 4°,
the lasers begin to flash and the operating mode
button(1) will be illuminated in red. If so, the self-
levelling will not function properly. Position the device
horizontally.
4. Slide the on/off switch(2) back to to switch the device
off.
ðPlease note that the lasers' current position is fixed.
Fixed position of the laser
Before using the lasers with a fixed position, perform a self-
levelling operation to make sure the lasers are properly aligned.
1. Check whether the lock switch(2) is set to .
2. Press the on/off button(1) to switch both lasers on.
3. Press the on/off button(1) a second time to only activate
the horizontal laser.
4. Press the on/off button(1) a third time to only activate the
vertical laser.
5. Press the on/off button(1) a fourth time to switch the device
off.
Info
You can activate the self-levelling function at any time
(by setting the on/off switch(2) to ). Please note
that in this case the device can only be switched off via
the on/off switch(2).
Using the multifunctional mount
Proceed as follows to use the multifunctional mount with the
device:
1. Screw the mount into the tripod connection at the device.
By means of the suction cup you can affix the mount to smooth
surfaces such as tiles or glass.
Alternatively, the clamping jaws can be used to fasten it to a
shelf or the edge of a table.

7 EN
Operating manual – cross line laser BD5A
Swivelling the device
1. Loosen the wing nut(7).
2. Swivel the device on the ball joints to move it into the
desired position.
3. Retighten the wing nut(7).
Application example for the universal clamp
1. Loosen the screw(8) and push the clamping jaws(11) apart
until they fit onto the carrier (here: shelf).
2. Tighten the screw(8) until the jaws(11) of the universal
clamp are firmly attached to the carrier and the mount can
no longer be moved to and fro.
3. To unfasten the clamping jaws(11), loosen the screw(8)
until the retainer can be removed from the carrier without
difficulty.

EN 8
Operating manual – cross line laser BD5A
Application example for the suction cup
1. Make sure that the surface is smooth and clean.
2. Disengage the lever(9) at the suction cup(10).
3. Press the suction cup(10) against the surface (here: tiles).
4. Engage the lever(9) until it locks in place.
5. Check the suction cup(10) for tight fit.
6. In order to remove the suction cup(10) again, release the
lever(9), then pull at the lug of the suction cup.

9 EN
Operating manual – cross line laser BD5A
Maintenance and repair
Battery change
A battery change is required when the device can no longer be
switched on (see chapter Inserting the battery).
Cleaning
Clean the device with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Do not use any sprays,
solvents, alcohol-based cleaning agents or abrasive cleaners,
but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
You are responsible for deleting any personal data stored on the
waste equipment to be disposed of.
In the European Union, batteries and accumulators must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September 2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.

Trotec GmbH & Co. KG
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
