Trotec BD22 User manual

TRT-BA-BD22-TC210826TTRT02-001-EN
BD22
EN
OPERATING MANUAL
LASER DISTANCE MEASURING
DEVICE

2 EN
laser distance measuring device BD22
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the device................................................3
Transport and storage...........................................................5
Operation ...............................................................................5
Maintenance and repair ......................................................11
Errors and faults..................................................................11
Disposal ...............................................................................12
Notes regarding the operating manual
Symbols
Warning of laser radiation
This symbol indicates dangers to the health of persons
due to laser radiation.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
BD22
https://hub.trotec.com/?id=45780
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Do not immerse the device in water. Do not allow liquids to
penetrate into the device.
• The device may only be used in dry surroundings and must
not be used in the rain or at a relative humidity exceeding
the operating conditions.
• Protect the device from permanent direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device.
• Avoid looking directly into the laser beam.
• Never point the laser beam at people or animals.
• Only use the device, if sufficient safety precautions were
taken at the surveyed location (e.g. when performing
measurements along public roads, on building sites etc.).
Otherwise do not use the device.
• Observe the storage and operating conditions (see
Technical data).

EN 3
laser distance measuring device BD22
Intended use
Only use the device for measuring distances, areas and volumes
by means of the integrated laser and within the measuring
range specified in the technical data. Observe and comply with
the technical data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Foreseeable misuse
Do not use the device in potentially explosive atmospheres, or
for measurements in liquids. Never point it at people or animals.
Trotec accepts no liability for damages resulting from improper
use. In such a case, any warranty claims will be voided.
Any unauthorised modifications, alterations or structural
changes to the device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
laser measuring devices.
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Warning of laser radiation
Laser class2, Pmax.: <1mW, λ: 400-700nm,
EN60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The laser distance measuring device BD22 is used to determine
distances, areas and volumes in interior spaces. Indirect
measurements (e.g. height measurements of walls or furniture)
are carried out using the Pythagoras function.
The integrated measuring wheel enables the measurement of
curved lines, curves and circumferences. The timer allows to
perform delayed measurements after10seconds.
The device is equipped with separate operating elements for the
different measuring functions. The multi-line, backlit display
indicates the determined values and measuring functions.
Measured values can be added or subtracted and up
to50measurements can be retrieved from the data memory.
Measuring distance
The range of the device can be gathered from the Technical
data chapter. Under certain conditions – e.g. at night, in twilight
or when the target is hidden in the shade – greater distances
are possible even without target plate. During the day use a
target plate to increase the distance for poorly reflecting targets.
Target surfaces
There might be measurement errors when the laser encounters
colourless liquids (e.g. water), dust-free glass, styrofoam or
other semi-permeable materials. The measurement result may
also be falsified if the laser encounters a high-gloss surface and
is deflected by it. Non-glossy, non-reflective or dark surfaces
can extend the measurement duration.

4 EN
laser distance measuring device BD22
Device depiction
1
2
3
4
5
6
No. Designation
1 Cover of the battery compartment
2 Measuring wheel
3 Spirit level
4 Operating elements
5 Display
6 Laser
Operating elements
7
8
9
10
11
12
13
No. Designation Function
7button Press briefly: switching the device on/
measuring
Press for a long time:
starting continuous distance measurement
8button Press briefly: change the reference point
Press for a long time: call up history
9−button Press briefly: browse downwards in history
Press for a long time: clear history
10 C/Offbutton Press briefly: deleting last value
Press for a long time: Switching the device
off
11 Unit/
button
Press briefly: pin dimension measurement
Press for a long time: change units
(m/ft/ft+in/in)
12 +button Request next value in the history
No. Designation Function
13 button Press briefly: change measuring mode
Press for a long time: enable or disable
acoustic signal
Display
28
26
14
15
16
17
18
19
20
21
22
23
24
25
MAX
MIN
29
27
No. Display element
14 Battery status
15 Area measurement
Volume measurement
16 Trapezoidal measurement
17 Indication of measured value1 (incl. unit)
18 Indication of measured value2 (incl. unit)
19 Indication of measured value3 (incl. unit)
20 Lower measurement value display: indicates the last
measured value or the result of a calculation (incl.unit).
21 +/-indication: Addition/subtraction of measured values
22 Memory space indication
23 MAX/MIN indication
24 Reference point indication (front/rear)
25 Laser active
26 Indirect measurement (two auxiliary measurements)
Indirect measurement (three auxiliary measurements)
Indirect measurement of partial heights (three
auxiliary measurements)
27 Timer indication
28 Acoustic signal indication on/off
29 Pin dimension measurement

EN 5
laser distance measuring device BD22
Technical data
Parameter Value
Model BD22
Weight 128.5g
Dimensions (Hx Wx D) 130 x 51 x 28mm
Measuring range of laser 0.05 to 50m/
0.164 to 164 ft
Measuring range measuring
wheel
0 to 10m
Measuring units m/ft/ft+in
Accuracy ±2mm
Measuring range resolution 1mm
Number of recordings logged
in the history
50
Operating temperature 0 °C to 40 °C
Storage temperature -10 °C to 60 °C
Relative humidity max. 75%
Laser output <1mW (630-670nm)
Laser class II
Device switch-off After approx. 3minutes of
non-use
Automatic switch-off of the
laser
After approx. 30seconds of
non-use
Power supply 2x 1.5V battery (typeAAA)
Scope of delivery
• 1x Device BD22
• 2x 1.5V battery AAA
• 1 x Quick guide
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
When transporting the device, ensure dry conditions and and
protect the device from external influences e.g. by using a
suitable bag.
When transporting the product, ensure dry conditions and
protect the device from external influences e.g. by using a
suitable bag.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• the storage temperature complies with the values specified
in the Technical data
• Remove the batteries from the device.
Operation
Inserting the batteries
Note
Make sure that the surface of the device is dry and the
device is switched off.
1. Loosen the cover of the battery compartment(1)with a
screwdriver.
2. Insert two batteries of typeAAA (1.5V, included in the
scope of delivery) into the battery compartment with
correct polarity (+/-).
3. Put the cover of the battery compartment back onto the
device and tighten it with the screws.
Switch-on
1. Press the button(7) for approx. 1second.
ðThe display will be switched on and the device ready for
operation.
Basic settings
Switching the acoustic signal on/off
1. Press the button(13) for a long time to switch the
acoustic signal on or off.
ðThe switch-on/off process is confirmed by a brief
acoustic signal.
Aborting the measurement and deleting the display
1. Briefly press the C/Offbutton(10) to abort the current
measurement or to delete the displayed measured values
one at a time.

6 EN
laser distance measuring device BD22
Adjusting the reference point
The device always measures the total distance starting at the
reference point. This means that if the rear end of the device is
set as reference point, the length of the device will be part of
the measurement. By default the reference point is set to the
rear of the device. You can, however, also relocate the
reference point to the front part of the device. Please proceed as
follows:
1. Press the button(8) to relocate the reference point to
the front end of the device.
ðAn acoustic signal is emitted each time the reference
point is relocated. In addition, the reference point
display(24) indicates the selected reference point.
When switching the device off and then on again, the reference
point will automatically be relocated to the rear end of the
device.
Changing the units
Press the Unit/ button(11) for a long time to switch between
the units for the measured values. You can set the following
indications one after the other:
• 0.000m (indication in metres, accuracy1mm)
• 0.00 m (indication in metres, accuracy1cm)
• 0.01 ft (indication in feet, accuracy 1/10ft)
• 0' 0"1/8 (indication in feet and 1/8inch, accuracy 1/8inch)
• 0.1in (indication in inches, accuracy 1/10inch)
• 0 1/8in (indication in inch and 1/8inch, accuracy 1/8inch)
Calling up a measured value in the device history
The device automatically saves the last 50measured values.
The saved measured values can be called up as follows:
1. Press the button(8) for a long time to call up the history.
2. Briefly press the +button(12) or the −button(9) to
navigate through the history and call up the saved
measured values.
3. Press the −button(9) for a long time to delete the saved
measured values.
4. Briefly press the button, the button(13) or the
C/Offbutton(10) to return to the measuring menu.
Press the Unit/ button(11) to return to the pin dimension
measuring mode.
Briefly press the C/Offbutton(10) to return to the laser
measuring mode.
Info
It is not possible to save and call up measuring values
when performing the pin dimension measuring mode.
Carrying out measurements
Warning of laser radiation
Laser class2, Pmax.: <1mW, λ: 400-700nm,
EN60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
By pressing the button(13) you can call up the following
measuring modes one after the other:
• Single distance measurement:
- you can add or subtract measured values
- you can perform a non-stop measurement with
MAX- /MIN-/current value
• Area measurement
• Volume measurement
• Indirect height measurement
• Twofold indirect height measurement
• Indirect measurement of a partial height
• Trapezoidal measurement
• Delayed measurement (starting after10seconds)
- Use the+(12) and–buttons(9) to set the delay time
between5 and60s.
Carrying out single distance measurement
1. Briefly press the button(7) to activate the laser.
2. Point the laser at the target area.
3. Briefly press the button(7) again to perform a distance
measurement.
ðThe measured value is indicated on the display.
a

EN 7
laser distance measuring device BD22
Adding/ subtracting measured values
1. Carry out a single distance measurement.
2. Press the+button(12) to add the next measured value to
the previous one.
Press the−button(9) to subtract the next measured value
from the previous one.
3. Press the button(7) to determine the next measured
value.
ðThe overall result will be indicated in the lower
measurement value display. The individual measured
values will be indicated in the upper measurement value
displays.
Performing a non-stop/ min and max measurement
With this measurement method the device can be moved with
the measured value being recalculated roughly
every0.5seconds. You can use the non-stop measurement
function with MAX/MIN/current value display for performing the
following measurements, for example:
•MAX value: measuring a diagonal
•MIN value: determining the perpendicular length to a wall/
floor area
•Actual value: marking a defined value for a distance (e.g.
a measurement from a ground plan)
A=1,531m
1. Press the button(7) for a long time.
ðWith activated signal indication function, a recurring
acoustic signal is emitted.
ðThe maximum, minimum and current value are
indicated on the display.
2. Depending on the desired measurement, move the device
slowly back and forth or up and down (e.g. in the corner of
a room).
3. Briefly press the button to terminate the non-stop
measurement.
ðThe maximum, minimum and last measured value are
indicated on the display.
Performing an area measurement
1. Press the button(13) until the symbol for the area
measurement appears on the display.
2. Briefly press the button(7) to carry out the first
measurement (e.g.length).
ðThe length of the line segment is displayed in the
"Indication of the measured value1"(17).
3. Briefly press the button(7) again to carry out the
second measurement (e.g.width).
ðThe second measured value is displayed in the
"Indication of measured value2"(18).
ðUpon pressing the button for the second time the
device independently calculates the area and displays
this value in the lower measured value indication(20).
b
a

8 EN
laser distance measuring device BD22
Performing a volume measurement
1. Press the button(13) until the symbol for the
volume measurement appears on the display.
ðThe side to be measured in each case is indicated on
the display by flashing.
2. Briefly press the button(7) to carry out the first
measurement (e.g.length).
ðThe length of the line segment is displayed in the
"Indication of the measured value1"(17).
3. Briefly press the button again to carry out the second
measurement (e.g.width).
ðThe second measured value is displayed in the
"Indication of measured value2"(18).
4. Briefly press the button again to carry out the third
measurement (e.g.height).
ðThe third measured value is displayed in the "Indication
of measured value3"(19).
ðUpon pressing the button(7) for the third time the device
independently calculates the volume and displays this value
in the lower measurement value display(20).
a
b
c
Indirect height measurement (Pythagoras)
Using this method the length of an unknown straight-line
segment can be determined via the Pythagorean Theorem. This
method is suitable for e.g. height measurements.
The measurement result is calculated by determining the
distancesA andB.
A
B
1. Press the button(13) until the symbol for the
indirect measurement appears on the display.
ðThe upper bar (hypotenuse) flashes.
2. First, aim the device at the highest point(A) and briefly
press the button(7) once to perform a measurement.
Make sure to hold the device as steady as possible and
place it level on the ground with the two rear edges. The
position at the two rear edges must not be changed
during the measurements!
ðThe length of the line segment is displayed in the
"Indication of the measured value1"(17).
3. Using the spirit level, align the device horizontally at the
lower measuring point(B) and briefly press the button
once to measure the horizontal distance.
ðThe second measured value is displayed in the
"Indication of measured value2"(18).
ðThe line segment to be determined is displayed as
result in the lower measurement value display(20).

EN 9
laser distance measuring device BD22
Twofold indirect height measurement
This method is suitable for e.g. height measurements when you
are not at the same height as the base point.
The measurement result is calculated by determining the
distancesA, B andC.
A
B
C
1. Press the button(13) until the symbol for the
twofold indirect measurement appears on the display.
2. First, aim the device at the highest point(C) and briefly
press the Switch-on/measurement button(7) once to
perform a measurement. In doing so, hold the device as
steady as possible. The alignment of the device in
relation to the reference point must not be changed
during the measurements!
ðThe length of the line segment is displayed in the
"Indication of the measured value1"(17).
3. Align the device horizontally (pointB) and briefly press
the button(7) one time to measure the horizontal
distance.
ðThe second measured value is displayed in the
"Indication of measured value2"(18).
4. First, aim the device at the highest point(A) and briefly
press the button once to perform a measurement.
ðThe third measured value is displayed in the "Indication
of measured value3"(19).
ðThe line segment to be determined is displayed as result in
the lower measurement value display(20).
Indirect measurement of a partial height
This method is suitable for measuring partial heights (e.g. storey
heights, window heights, etc.).
The measurement result is calculated by determining the
distancesA, B andC.
C
B
A
1. Press the button(13) until the symbol for the
indirect measurement of a partial height appears on the
display.
2. First, aim the device at the upper point(A) of the partial
height to be measured and briefly press the button(7)
once to perform a measurement. Make sure to hold the
device as steady as possible. The alignment of the
device in relation to the reference point must not be
changed during the measurements!
ðThe length of the line segment is displayed in the
"Indication of the measured value1"(17).
3. Now aim the device at the lowest point(B) of the partial
height to be measured and briefly press the button(7)
once to perform a measurement.
ðThe second measured value is displayed in the
"Indication of measured value2"(18).
4. Using the spirit level, align the device horizontally at the
lower measuring point(C) and briefly press the button
once to measure the horizontal distance.
ðThe third measured value is displayed in the "Indication
of measured value3"(19).
ðThe partial height to be determined is displayed as result in
the lower measurement value display(20).

10 EN
laser distance measuring device BD22
Trapezoidal measurement
The trapezoidal measurement allows you to determine the
length of a roof slope from the ground, for example. To do so,
please proceed as follows:
1. Press the button(13) until the symbol for the
trapezoidal measurement appears on the display.
ðThe side to be measured in each case is indicated on
the display by flashing.
2. Briefly press the button(7) to carry out the first
measurementA (e.g.the height at the eaves).
ðThe length of the line segment is displayed in the
"Indication of the measured value1"(17).
3. Briefly press the button again to carry out the second
measurementB (e.g.the horizontal section under the slope
of the roof).
ðThe second measured value is displayed in the
"Indication of measured value2"(18).
4. Briefly press the button again to carry out the third
measurementC (e.g.the height to the roof ridge).
ðThe line segment to be determined is displayed as result in
the lower measurement value display(20).
c
b
a
d=?
c
1.
2.
3.
?
Delayed measurement
With the delayed measurement you can e.g. determine the
length up to a point if there is no obstacle for the laser to be
aimed at (e.g. an outside corner of a building). To do so, please
proceed as follows:
1. Press the button(13) until the number"10" and the
symbol for the timer(27) appear on the display.
2. Use the+(12) and–buttons(9) to set the delay time
between5 and60s.
3. Position the device in a way that it is firmly placed on the
ground and that measurements up to the desired point
(e.g. horizontally) can be performed.
4. Briefly press the button(7) to activate the delayed
measurement function.
ðThe countdown has started to slowly run down from the
set time value.
5. Quickly move away from the device and place the obstacle
at the target point. Make sure that the laser is visible on
the obstacle.
ðAfter the set time has elapsed, the device carries out
the measurement.
ðThe measured line segment is displayed as result in the
lower measurement value display(20).
Pin dimension measurement
The measuring wheel(2) enables the measurement of curved
lines, curve lengths or circle circumferences. To do so, please
proceed as follows:
1. Briefly press the Unit/ button(11).
ðThe symbol for the pin dimension measurement (29)
appears on the display.
2. Trace the contour to be measured (max.10m) with the pin
dimension.
ðThe measured line segment is displayed as result in the
lower measurement value display(20).
Max.10m
Info
Note down the result. The result will not be saved in
the history.
3. Press the C/Offbutton(10) to return to the laser measuring
mode.

EN 11
laser distance measuring device BD22
Switch-off
1. Press the C/Off button(10) for a long time.
ðThe display is switched off.
Maintenance and repair
Battery change
Note
Make sure that the surface of the device is dry and the
device is switched off.
A battery change is required when the error message 220
appears on the display or when the device can no longer be
switched on (see chapter Inserting the batteries).
Cleaning
Clean the device with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Do not use any
sprays, solvents, alcohol-based cleaning agents or abrasive
cleaners, but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The following fault indications can appear in the lower
measurement value display:
Display Cause Remedy
203 The temperature is
too high.
Allow the device to cool down.
Observe the permissible
operating temperature
according to the Technical data
chapter.
220 The batteries are
almost empty.
Change the batteries, see
chapter Battery change.
254 Calculation error Repeat the measurement. Pay
attention to the measurement
sequence and position of the
device.
255 The reception of the
reflected signal is too
weak.
Repeat measurement on
another surface with better
reflective properties or use a
target plate.
256 The reception of the
reflected signal is too
strong.
258 Range exceeded Observe the range values
specified in the Technical data
chapter.
301 Hardware fault Repeatedly switch the device
on and off. If the indication
continues to appear, please
contact the Trotec customer
service.

12 EN
laser distance measuring device BD22
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. You can also find out about other return options
that apply for many EU countries on the website
https://hub.trotec.com/?id=45090. Otherwise, please contact an
official recycling centre for electronic and electrical equipment
authorised for your country.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
In the European Union, batteries and accumulators must
not be treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
