Illustrated Parts List
Printed in USA Manual No. 192258A Revision 0 (09/17/2004)
Portable Generator
Model 01919
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON,WISCONSIN, U.S.A.
Troy-Bilt® is a registered trademark of Troy-Bilt, LLC and is used under license to Briggs & Stratton Power Products.
Troy-Bilt® es una marca registrada de Troy-Bilt, LLC y se usa abajo licencia a Briggs & Stratton Power Products.

2
1
Section Exploded Views and Parts Lists
EXPLODED VIEW - MAIN UNIT

3
Section 1: Exploded Views and Parts Lists
Item Part # Description
1 P194766GS CRADLE
2 194150GS KIT,Vibration, Mount, 45°
4 190220GS HOUSING, Engine Adapter
5 NSP ASSY,Alternator (see page 5)
6 194151GS KIT, Hrdwr Mounting Adapter
8 96796GS WASHER, M8 Flat
10 * SBHCS, 3/8-16 x 1.0 Lg.
11 187365FGS HHCS, 5/16-24 x 7.44
14 194729GS KIT, Muffler Bracket w/ Hardware
15 695398 GASKET, Exhaust
17 189008GS MUFFLER
18 * SCREW, 5/16 - 18 x 3/4"
19 83083GS SCREEN, Spark Arrest
20 B4986GS DECAL, Ground, Green
21 194153GS KIT,Vibration Mount
23 193646GS KIT, Grounding Hardware
24 192794GS SHIELD, Heat
26 74908GS SCREW, M5-0.8 x 10,Taptite
31 191436GS DECAL, Hot Muffler
34 186347GS COVER, Bearing Carrier
35 194397GS KIT, Fuel Hose, Formed w/ Clamps
37 192376GS SCREW, 12-24 x 1/2 Thrd forming
38 56893GS CRIMPTITE, 10 - 24 x 1/2
40 194398GS KIT, Fuel Tank Hardware
41 192980GS KIT,Valve, Fuel Tank
44 193668GS ASSY,Tank, Fuel (Includes Items 41, 50, 51 & 52)
45 B4363GS CAP, Fuel Gauge
48 14353621GS WIRE, Ground
50 188333GS DECAL, Gas Fill
51 194799GS DECAL, Danger
52 189235GS DECAL, Start Instructions
55 191435GS DECAL, Shut-Off, Fuel
58 190355GS ASSY, Control Panel (see page 4)
59 * NUT, Palnut, 3/16"
900 NSP ENGINE
Parts Not Illustrated
MS5242 MANUAL, Engine
192258GS MANUAL, Owners
BB3061GS BOTTLE, Oil
188971GS CORD, Extension, 120/240V, 30A
193667GS KIT, Decals
* - Items shown without part numbers are common fasteners found at your local hardware store.
PARTS LIST - MAIN UNIT

4
Item Part # Description
1 195112GS KIT, Control Panel Lid
2 188889GS CONTROL PANEL, Compact
6 68759GS OUTLET, 120V, 20Amp, Duplex
7 * NUT, Palnut, Pushnut, 5/32
8 84198GS CAP, Circuit Breaker
9 75207GS BREAKER, Circuit
10 43437GS OUTLET, 120/240V Locking, 30A
11 * NUT, Palnut, Pushnut, 3/16
12 * SCREW, Phillips, Head 3.5 x 18
13 93857GS BAR, Retaining
14 188890GS COVER, Back, Control Panel
15 82308GS SCREW, Self Tapping, STC 3 x 18
16 22694GS HOUSING, Receptacle
17 * SCREW, Phillips, 3.5 x 14
* - Items shown without part numbers are common
fasteners found at your local hardware store.
Section 1: Exploded Views and Parts Lists
CONTROL PANEL EXPLODED VIEW & PARTS LIST

5
Section 1: Exploded Views and Parts Lists
ALTERNATOR EXPLODED VIEW AND PARTS LIST
Item Part # Description
1 186059GS ADAPTER, Mounting,Alternator
2 190032GS ROTOR
3 190079AGS STATOR
4 186060GS RBC, with O-Ring (p/n 189197GS)
5 86308HGS SCREW
6 91825GS ASSY, Holder, Rectifier/Brush
7 66849GS SCREW
8 22694GS RECEPTACLE, 6 pin
9 81917GS PIN, Roll
10 193428AGS ASSY,Wire, Ground
13 190356GS HARNESS,Wire, Power

6
Section 1: Exploded Views and Parts Lists
WHEEL KIT EXPLODED VIEW AND PARTS LIST
Item Part # Description
1 189715GS ASSY, Handle
2 B1764GS LEG, Mounting
3 52858GS NUT, Lock
4 39287GS SCREW
5 191267HGS AXLE
6 B4966GS WHEEL
7 191265GS E-RING
8 22247GS WASHER
9 42907GS SCREW
