TRUE REACH-IN’S
Delivering Solutions for the Foodservice Industry
THE DEFINITION OF PRODUCT INTEGRITY
230–240v/50Hz CE
®

·Oversized and balanced, environmentally friendly
refrigeration system. Refrigerators hold .5˚C to 3.3˚C
(33˚to 38˚F), and Freezers hold -23.3˚C (-10˚F ).
·Foamed-in-place polyurethane high density cell
insulation (CFC free).
·Energy efficient “Low-E” thermal glass on glass
door refrigerator models.
·Energy efficient triple pane, thermal insulated glass
door freezer models.
·Positive seal self-closing doors with factory tested
(over 1,000,000 times) lifetime guaranteed door
hinges and torsion type closure system.
·Adjustable heavy duty, PVC coated wire shelves.
·White aluminium interior, 300 series stainless steel
floor and front, and anodized aluminium ends.
(TS models have 300 series stainless steel interior
and exterior).
·Recessed door handles standard (except on glass
door models).
Reach In
Features and Benefits
®

Signature Series
T-23
300 series stainless steel front, anodized quality
aluminium finished sides, back, and top.
Available in single, double, and triple door with several
door combinations.
Gastronorm Compatible
·
·
·
300 Series Stainless Steel
300 series stainless steel interior and exterior front and
sides, with matching aluminium back.
Available in single, double, and triple door with several
door combinations.
Gastronorm Compatible.
·
·
·
TS-49
Also available with the following options:
Glass Doors Top Mount Slide Doors
...distinctively the best for food preservation
and storage.
Specifications are subject to change without notice.

T-23
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS
CRATED
WEIGHT
KG
L x D†x H
MM
REFRIGERATORS
T-23 ★1 STAINLESS ✓4 651 1/34.0 118 686 X 750 X 2074
T-23 (S/S INT) ★1 STAINLESS ✓4 651 1/34.0 127 686 X 750 X 2074
T-23G†1 GLASS 4 651 1/34.0 132 686 X 756 X 2074
T-23G†(S/S INT) 1 GLASS 4 651 1/34.0 127 686 X 756 X 2074
T-23-PT 1 FR/1 BK 3 651 1/33.7 148 686 X 816 X 2074
T-23-2 2 SS HALF ✓4 651 1/34.0 125 686 X 750 X 2074
T-23G-2†2 GLASS HALF 4 651 1/34.0 137 686 X 756 X 2074
T-23-1-G-1†1 GLASS / 1 SS HALF 4 651 1/34.0 130 686 X 756 X 2074
FREEZERS
T-23F ★1 STAINLESS ✓4 651 1/25.5 132 686 X 750 X 2074
T-23F (S/S INT) ★1 STAINLESS ✓4 651 1/25.5 143 686 X 750 X 2074
T-23FZ✫★1 STAINLESS ✓4 651 1/25.5 132 686 X 750 X 2074
T-23FZ✫(S/S INT) 1 STAINLESS ✓4 651 1/25.5 132 686 X 750 X 2074
T-23F-2 2 SS HALF ✓4 651 1/25.5 137 686 X 750 X 2074
GLASS DOOR FREEZERS
T-23FG 1 GLASS ✓4 651 3/44.7 184 686 X 756 X 2074
ALL STAINLESS STEEL REFRIGERATORS
TS-23 1 STAINLESS ✓4 651 1/34.0 134 686 X 750 X 2074
TS-23G†1 GLASS 4 651 1/34.0 146 686 X 756 X 2074
TS-23-2 2 SS HALF ✓4 651 1/34.0 139 686 X 750 X 2074
TS-23G-2†2 GLASS HALF 4 651 1/34.0 142 686 X 756 X 2074
TS-23-1-G-1†1 GLASS / 1 SS HALF 4 651 1/34.0 146 686 X 756 X 2074
ALL STAINLESS STEEL FREEZERS
TS-23F 1 STAINLESS ✓4 651 1/25.5 146 686 X 750 X 2074
TS-23F-2 2 SS HALF ✓4 651 1/25.5 150 686 X 750 X 2074
DUAL TEMPERATURE REF/FRZR TOTAL
T-23DT 2 SS HALF 4 651 1/5/ 1/36.5 146 686 X 750 X 2074
T-23DT-G 2 GLASS HALF 4 651 1/5/ 1/27.3 168 686 X 756 X 2074
✫HOLDS -18˚C AVERAGE. ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
†DEPTH DOES NOT INCLUDE 35MM FOR DOOR HANDLE ON GLASS DOOR MODELS.
T-12
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS
CRATED
WEIGHT
KG
L x D†x H
MM
REFRIGERATORS
T-12 1 STAINLESS 4 340 1/43.0 87 632 X 588 X 1630
T-12G†1 GLASS 4 340 1/43.0 98 632 X 594 X 1630
FREEZER
T-12F 1 STAINLESS 4 340 1/32.5 87 632 X 588 X 1630
† DEPTH DOES NOT INCLUDE 35MM FOR DOOR HANDLE ON GLASS DOOR MODELS.
ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
T-19FZ
‡ GC= Gastronorm Compatible
T-23G-2
T-12
Traditional Reach-In Models
T-19
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS
CRATED
WEIGHT
KG
L x D†x H
MM
REFRIGERATORS
T-19 ★1 STAINLESS 4 538 1/33.0 100 686 X 623 X 1995
T-19E ★1 STAINLESS 4 538 1/42.4 109 686 X 623 X 1995
FREEZERS
T-19F ★1 STAINLESS 4 538 1/32.6 130 686 X 623 X 1995
T-19FZ✫★1 STAINLESS 4 538 1/32.6 112 686 X 623 X 1995
✫HOLDS -18˚C AVERAGE. ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.

T-49
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS
CRATED
WEIGHT
KG
L x D†x H
MM
REFRIGERATORS
T-49 ★2 STAINLESS ✓8 1388 1/25.4 191 1375 X 750 X 2074
T-49 (S/S INT) ★2 STAINLESS ✓8 1388 1/25.4 196 1375 X 750 X 2074
T-49G†2 GLASS 8 1388 1/25.4 202 1375 X 756 X 2074
T-49G†(S/S INT) 2 GLASS 8 1388 1/25.4 228 1375 X 756 X 2074
T-49-PT 2 FRONT / 2 BACK ✓8 1388 1/25.4 236 1375 X 816 X 2074
T-49-4 4 SS HALF ✓8 1388 1/25.4 196 1375 X 750 X 2074
T-49G-4†4 GLASS HALF 8 1388 1/25.4 223 1375 X 756 X 2074
T-49-4-PT 4 FRONT / 4 BACK 8 1388 1/25.4 233 1375 X 816 X 2074
T-49-2-G-2†2 GLASS / 2 SS HALF 8 1388 1/25.4 207 1375 X 756 X 2074
FREEZERS
T-49F ★2 STAINLESS ✓8 1388 1 6.4 232 1375 X 750 X 2074
T-49F (S/S INT) ★2 STAINLESS ✓8 1388 1 6.4 237 1375 X 750 X 2074
T-49FZ✫★2 STAINLESS ✓8 1388 1/25.6 211 1375 X 750 X 2074
T-49FZ✫ (S/S INT) 2 STAINLESS ✓8 1388 1/25.6 216 1375 X 750 X 2074
T-49F-4 4 SS HALF ✓8 1388 1 6.4 241 1375 X 750 X 2074
ALL STAINLESS STEEL REFRIGERATORS
TS-49 2 STAINLESS ✓8 1388 1/25.4 200 1375 X 750 X 2074
TS-49G†2 GLASS 8 1388 1/25.4 234 1375 X 756 X 2074
TS-49-4 4 SS HALF ✓8 1388 1/25.4 207 1375 X 750 X 2074
TS-49G-4†4 GLASS HALF 8 1388 1/25.4 225 1375 X 756 X 2074
TS-49-2-G-2†2 GLASS / 2 SS HALF 8 1388 1/25.4 218 1375 X 756 X 2074
ALL STAINLESS STEEL FREEZERS
TS-49F 2 STAINLESS ✓8 1388 1 6.4 232 1375 X 750 X 2074
TS-49F-4 4 SS HALF ✓8 1388 1 6.4 241 1375 X 750 X 2074
DUAL TEMPERATURE REF/FRZR TOTAL
T-49DT 2 STAINLESS 8 1388 1/3/ 1/25.5 225 1375 X 750 X 2074
✫HOLDS -18˚C AVERAGE. ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
†DEPTH DOES NOT INCLUDE 35MM FOR DOOR HANDLE ON GLASS DOOR MODELS.
‡GC= Gastronorm Compatible
T-35
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS
CRATED
WEIGHT
KG
L x D†x H
MM
REFRIGERATORS
T-35 ★2 STAINLESS 8991
1/32.6 155 1004 X 750 X 2074
T-35G†2 GLASS 8991
1/32.6 168 1004 X 756 X 2074
FREEZERS
T-35F ★2 STAINLESS 8991
3/45.5 205 1004 X 750 X 2074
T-35FZ✫2 STAINLESS 8991
3/44.2 175 1004 X 750 X 2074
ALL STAINLESS STEEL REFRIGERATOR
TS-35 2 STAINLESS 8991
1/32.6 175 1004 X 750 X 2074
ALL STAINLESS STEEL FREEZER
TS-35F 2 STAINLESS 8991
3/45.5 193 1004 X 750 X 2074
✫HOLDS -18˚C AVERAGE. ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
†DEPTH DOES NOT INCLUDE 35MM FOR DOOR HANDLE ON GLASS DOOR MODELS.
T-35
T-49F-4
®

TSD
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS CRATED WEIGHT KG
L x D†x H
MM
REFRIGERATORS
TSD-33 2 STAINLESS 8 935 1/25.0 157 1004 X 753 X 2147
TSD-33G 2 GLASS 8 935 1/25.0 182 1004 X 753 X 2147
TSD-47 2 STAINLESS 8 1331 1/25.4 186 1375 X 753 X 2147
TSD-47G 2 GLASS 8 1331 1/25.4 200 1375 X 753 X 2147
TSD-69 3 STAINLESS 12 1954 1/26.9 272 1985 X 753 X 2166
†DEPTH DOES NOT INCLUDE 10MM FOR DOOR HANDLE ON GLASS DOOR MODELS.
ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
TM
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS CRATED WEIGHT KG
L x D†x H
MM
REFRIGERATORS
TM-24 1 STAINLESS ✓4 680 1/34.0 118 686 X 750 X 2071
TM-24-2 2 SS HALF ✓4 680 1/34.0 125 686 X 750 X 2071
TM-52 2 STAINLESS ✓8 1473 1/25.0 202 1375 X 750 X 2071
TM-52-4 4 SS HALF ✓8 1473 1/25.0 205 1375 X 750 X 2071
FREEZERS
TM-24F 1 STAINLESS ✓4 680 1/24.1 141 686 X 750 X 2071
TM-52F†2 STAINLESS ✓8 1473 1 6.4 239 1375 X 750 X 2071
†DEPTH DOES NOT INCLUDE 61 MM FOR UPPER REAR CONDENSATE ENCLOSURE.
ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
TS-28
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS
CRATED
WEIGHT
KG
L x D†x H
MM
SINGLE HALF-DOOR PASS THRU REFRIGERATOR
TS-28-2-G-2-PT†2 GLASS / 2 SS HALF 6 CHROME
SHELVES 793 1/25.0 196 737 X 896 X 2074
†DEPTH DOES NOT INCLUDE 35MM FOR DOOR HANDLE ON GLASS DOOR MODELS.
ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
T-72
MODEL STOCKED
IN UK DOORS ‡GC SHELVES LITRES HP AMPS
CRATED
WEIGHT
KG
L x D†x H
MM
REFRIGERATORS
T-72 ★3 STAINLESS ✓12 2039 1/26.9 264 1985 X 750 X 2093
T-72G†3 GLASS 12 2039 1/26.9 304 1985 X 756 X 2093
T-72-6 6 SS HALF ✓12 2039 1/26.9 279 1985 X 750 X 2093
T-72G-6†6 GLASS HALF 12 2039 1/26.9 318 1985 X 756 X 2093
T-72-3-G-3†3 GLASS/3 SS HALF 12 2039 1/26.9 295 1985 X 756 X 2093
FREEZER
T-72F‡★3 STAINLESS ✓12 2039 11/29.0 302 1985 X 750 X 2093
ALL STAINLESS STEEL REFRIGERATORS
TS-72 3 STAINLESS ✓12 2039 1/26.9 284 1985 X 750 X 2093
TS-72G†3 GLASS 12 2039 1/26.9 300 1985 X 756 X 2093
TS-72-6 6 SS HALF ✓12 2039 1/26.9 289 1985 X 750 X 2093
TS-72G-6†6 GLASS HALF 12 2039 1/26.9 316 1985 X 756 X 2093
TS-72-3-G-3†3 GLASS/3 SS HALF 12 2039 1/26.9 315 1985 X 756 X 2093
ALL STAINLESS STEEL FREEZER
TS-72F‡3 STAINLESS ✓12 2039 11/29.0 323 1985 X 750 X 2093
ALL MILLIMETERS ARE ROUNDED TO NEXT WHOLE NUMBER.
†DEPTH DOES NOT INCLUDE 35MM FOR DOOR HANDLE ON GLASS DOOR MODELS.
‡THIS PRODUCT REQUIRES A 20 AMP HARD WIRE CONNECTION.
T-72
TS-28-2-G-2-PT
TSD-47
TM-24F
‡GC= Gastronorm Compatible

Product Lines Available
·Glass Door Merchandisers
·Glass Door Freezers
·Upright Reach-Ins
·Prep Tables (Drawer or Doors)
·Undercounter / Worktop Units
·Pizza Prep Stations
·Chef Bases
·Milk Coolers
·Back Bar Refrigerators
·Beer Dispense Direct Draw Units
·Glass & Plate Chillers/Frosters
·Horizontal Bottle Coolers
·Horizontal Convenience Merchandisers
300
Glass Door—Solid Door
Sliding Door—Single Door
Double Door—Triple Door
Drawer Units
Over
Model Variations
®
M
*All units displayed 230–240v/50Hz CE
