True TA1RRI-1S User manual

FEATURES/BENEFITS
Roll-thru models feature
front and rear swing doors,
each with a heavy duty
stainless steel ramp for
roll-thru service.
Toll Free Number • 1-800-325-6152
True Website: www.truemfg.com Parts Department • 1-800-424-TRUE
TA Series
TA1RRI-1S
TA1RRI89-1S
TA2RRT-2S-2S
The new
consultant
choice
for roll-in &
roll-thru
rack
applications.
•Oversized and balanced, environmen-
tally friendly, refrigeration system,
factory sealed and pre-lubricated for
long life.
•Food safe refrigerators hold 33°F to
38°F.
•Accepts roll-in rack (inboard castor) with
maximum dimensions of
27”W x 29”D x 66”H.
89” high models accept roll-in/thru rack
(inboard castor) with maximum dimen-
sions of 27”W x 29”D x 72”H.
(supplied by others)
•Exterior - 300 series stainless steel
doors, front, back & bottom.
Stainless steel sides.
•Heavy gauge doors.
•Interior - attractive, NSF approved,
white aluminum sides and back. 300
series stainless floor and door liner.
•Three rugged cam-lift hinges per door-
lifetime guaranteed. Designed for easy
product access with a full 180 degree
open capability and stay open feature at
120 degrees.
•Heavy gauge stainless steel ramp
standard for each door.
•Exterior mounted digital electronic ther-
mometer features manual defogger.
•Interior bumpers protect cabinet.
•Foamed-in-place polyurethane high
density cell insulation (CFC Free).
•Incandescent interior lighting.
•Energy saver switch.
•Lifetime guaranteed recessed door
handles.
•Door locks standard.
•Top mounted unit positioned out of
food zone to maximize storage capacity.
•Glass condensate pan to prevent elec-
trolysis.
•Hot gas condensate for energy
efficiency.
•Self-contained system.
•Reversible wiper gaskets for positive seal.
•Field reversible door swing.
* Height does not include 1” for system mechanical components.
* Height does not include 1” for system mechanical components.
Roll-In Refrigerators
Model Swing Doors Cu. Ft. HP Amps Crated Weight
Cabinet Dimensions
L D H*
SOLID DOORS
TA1RRI-1S 1 37 1/38.9 400 35 x 341 / 2x 833 / 4
TA2RRI-2S 2 75 1/211.8 706 68 x 341 / 2x 833 / 4
SOLID DOORS 89" HIGH
TA1RRI89-1S 1 38 1/38.9 485 35 x 341 / 2x 89
TA2RRI89-2S 2 80 1/211.8 786 68 x 341 / 2x 89
All dimensions rounded up to the nearest 1/8”.
Roll-Thru Refrigerators
Model Swing Doors Cu. Ft. HP Amps Crated Weight
Cabinet Dimensions
L D H*
SOLID DOORS
TA1RRT-1S-1S 2 37 1/38.9 475 35 x 367 / 8x 833 / 4
TA2RRT-2S-2S 4 75 1/29.5 781 68 x 367 / 8x 833 / 4
SOLID DOORS 89" HIGH
TA1RRT89-1S-1S 2 38 1/38.9 495 35 x 367 / 8x 89
TA2RRT89-2S-2S 4 80 1/29.5 821 68 x 367 / 8x 89
All dimensions rounded up to the nearest 1/8”.
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
