Truly 300W Manual

450W300W
Modular LED Light Fixture
(2014)
Installation and Maintenance Manual
TRULY GREEN SOLUTIONS

1/9
Warning
Wiring
B. Surface Mount
A. Hanging Ring Mount
C. Universal Hanging Bracket
Content

2/9
Using only the highest quality components, the Modular LED Light Fixture is designed for industrial
applications where reliability and performance are critical as the bulb maintenance is difficult or
impossible, not to mention the high cost.
Every component of the Modular LED Light Fixture has been carefully engineered to provide the
most reliable performance and bring across many benefits of utilizing solid state lighting
technology in industrial applications.
Modular LED Light Fixture is rated IP65 with further option to upgrade to IP67, suitable for both
indoor and outdoor use.
Product Features:
· Individual high performance LED light engine with Cree XT-E LED delivering 100 lumen per watt.
· Patented thermal management allows -30oC to 55oC ambient working temperature.
· Easiest installation and maintenance experiences guaranteed:
Easiest one-man operation;
Hinged LED light engine holder;
Quick connector between LED light engine and driver.
· 5 years warranty, up to 50,000 hours long life.
· Dimmable and motion sensor control compatible.

Warning
3/9
To avoid the risk of fire, explosion, or electric shock, this product should be installed, inspected,
and maintained by a qualified electrician only, in accordance with all applicable electrical codes.
To avoid electric shock:
-- Be certain electrical power is OFF before and during installation and maintenance.
-- Luminaire must be connected to a wiring system with an equipment-grounding conductor.
-- Make sure the supply voltage is the same as the rated luminaire voltage.
-- Do not operate in ambient temperatures above those indicated on the luminaire nameplate.
-- Avoid to use in environments containing sulfur, chlorine, or other halides, methyl acetate or ethyl
acetate, cyanoacrylates, glycol ethers, formaldehyde or butadiene.

4/9
A: Hanging Ring
B: Safety Rope
C: Power Cable
1. Hang the ring to the field supplied by the mounting hook or chain.
2. Secure the safety rope hook to the field supplied by the second mounting point or to the main
mounting point in case the second point is not provided.
3. Wiring.(Connect supply wires to luminaire wire leads per the wiring diagram using methods that
comply with all applicable codes.)
A. Hanging Ring Mount
For high performance and long term reliability, the light should be installed in free air.

5/9
A: Double Hook
B: Safety Rope
C: Anchor Plate
D: Power Cable
1. Bolt the anchor plate to the ceiling securely.
2. Hook the fixture to the anchor plate.
3. Insert the screw to secure the hook
to the anchor plate.
4. Secure the safety rope hook to the
field supplied by the second mounting point.
5. Wiring.(Connect supply wires to
luminaire wire leads per the wiring
diagram using methods that comply
with all applicable codes.)
B. Surface Mount
For high performance and long term reliability, the light should be installed in free air.

6/9
A: Angle Plate
B: Universal
C: Safety Rope
D: Power Cable
1. The angle plate allows 360ºrotation and 10ºper move.
2. Rotate the bracket to the desired angle and insert 2 screws to lock it.
3. Bolt the universal mounting bracket to the field mounting point.
Bolt the center point before the two side points. Tighten the bolts
to wrench tight.
4. Secure the safety rope hook to the field supplied by the
second mounting point.
5. Wiring.(Connect supply wires to luminaire wire
leads per the wiring diagram using methods that
comply with all applicable codes.)
C. Universal Hanging Bracket
Secure the center
bolt before the two
side ones
Note: The angle plate allows 360º
rotation and 10ºper move.
For high performance and long term reliability, the light should be installed in free air.

7/9
c/w Clapping Ring
A: Angle Plate
C: Safety Rope
D: Power Cable
1. The angle plate allows 360ºrotation and 10ºper move.
2. Rotate the bracket to the desired angle and insert 2 screws to lock it.
3. Insert bolts to lock the bracket with clapping ring to the pole arm, tighten the bolts to wrench
tight.
4. Secure the safety rope hook to the field supplied by the second mounting point.
5. Wiring.(Connect supply wires to luminaire wire
leads per the wiring diagram using methods that
comply with all applicable codes.)
For high performance and long term reliability, the light should be installed in free air.
Note: The angle plate allows 360º
rotation and 10ºper move.

Wiring
8/9
1. Connect supply wires to luminaire wire leads per the wiring diagram using methods that comply
with all applicable codes.
2. Turn power on.
LIGHT
Ground
Neutral
Live
White Green
Black
A. American Standard Power Cable
B. European Standard Power Cable
C. Australian Standard Power Cable
LIGHT
Ground
Neutral
Live
Blue Yellow & Green
Brown
LIGHT
Ground
Neutral
Live
Blue Yellow & Green
Brown

9/9
All statements, technical information and recommendations contained herein are
based on information and tests we believe to be reliable. The accuracy or complete-
ness thereof is not guaranteed.
AC Voltage 100~277V/200~480V
Working Temp. -30~+55
Storing Temp. -40~+70
300W Light Dimensions L560×W375×H180mm
450W Light Dimensions L560×W560×H180mm
Power Frequency 50/60Hz
Working Humidity 15%~90%RH
IP Rating IP65/IP67
Fixture Size & Net Weight
300W Light Net Weight 16.8kg±0.4kg
450W Light Net Weight 21.7kg±0.5kg
