Trust OCTOPUS Setup guide

ICS-2000
OCTOPUS CONTROL STATION
ONLINE MANUAL
www.trust.com
Item 71110 Version 1.0
Visit www.trust.com
for the latest instructions

3 4
ICS-2000 OCTOPUS CONTROL STATIONICS-2000 OCTOPUS CONTROL STATION
Index
1.1 Add a room 5
1.2 Edit/Delete room 6
2.1 Connect a new device 7
2.2 Connect a ZigBee bulb 10
2.3 Connect a ZigBee remote 14
2.4 Edit/delete device 16
3.1 Add scenes 17
3.2 Add/delete actions 18
3.3 Add/delete delays 19
4.1 Configure timers 20
4.2 Edit/delete timer 23
5.1 Configure rules 24
5.2 Edit/delete rule 27
6.0 Connect manually 28
7.0 Connect an existing device (Clone) 29

5 6
ICS-2000 OCTOPUS CONTROL STATIONICS-2000 OCTOPUS CONTROL STATION
1.1 1.2
1.2 Edit/Delete room1.1 Add a room
APress the + button at the top of the screen to add a new room
BFill in a name for the room you want to add.
CPress the ADD button to save the new room
ATo edit the name of a room press the pencil button at the top of the screen
BPress on the room name to begin editing.
CWhen you are done editing the name press the CONFIRM button.
DTo delete a room press the DELETE button in front of the room when in editing mode. Press the
CONFIRM button to go back to the room overview.
A
B
C
A
BD
C

7 8
ICS-2000 OCTOPUS CONTROL STATIONICS-2000 OCTOPUS CONTROL STATION
2.1 Connect a new device
APress on a room name to open it.
BPress the + button at the top of the screen to add a new device.
CEnter a name for the device you want to add
DPress ADD
EPress the desired Product Line.
FSelect the type of device you want to add to your room.
If you already control your Trust Smart Home receiver with a remote control or wall switch
continue to step 7. (Only for Startline products)
GPut your receiver in connect/learn mode. (Read the manual of the receiver on how to put it in connect/
learn mode).
2.1
AB
C
D
EF

ICS-2000 INTERNET CONTROL STATION
910
ICS-2000 OCTOPUS CONTROL STATION
HWhen the receiver is in connect/learn mode press CONNECT.
IThe device is now added to your room. You can now control the device with the App.
JUse the buttons to control the device.
H
IJ
2.2 Connect a ZigBee bulb
Make sure the ZigBee bulb is close to the Control Station (Within 4 metres)
APress on a room name to open it.
BPress the + button at the top of the screen to add a new device.
CEnter a name for the device you want to add
DPress ADD
2.2
AB
C
D

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
11 12
ESelect Trust Smart Home ZigBee Line
FChoose for ZigBee light
GPut the bulb in connect mode. (Check the manual of the bulb on how to put it in connect mode)
E
F
HWhen the ZigBee bulb is in connect mode press CONNECT.
IThe bulb is now added to your room. You can now control the device with the App.
JUse the buttons to control the device.
H
IJ

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
13 14
ICS-2000 OCTOPUS CONTROL STATION
KTo change the color of a ZigBee bulb press on the color circle to open the color palette (Only for
RGB or Cold/Warm bulb)
LChoose the desired color.
MPress the BACK button to go back to the room.
KL
M
14
2.3 Connect a ZigBee remote
2.3
A
B
First reset your ZYCT-202 ZigBee remote before you connect it to the ICS-2000. (Check the manual of
the ZigBee remote on how to reset it). Keep the remote within 2 meters from the ICS-2000.
AAdd a new device (See chapter 2.2) and choose for ZigBee Remote control
BPress CONNECT in the App and wait for confirmation from the App
CPress and hold the Smart Group button on the remote and wait untill the LEDs under the channels start
to blink. Wait for confirmation from the App that the connection succeeded.
Arm
5
C

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
15 1615
D
DThe ZigBee Remote is now connected
To control a bulb which is already connected with the Control station it also needs to be connected
to the ZigBee Remote. (Check the manual of the ZigBee remote on how to connect it with a bulb)
Notice: With the ZYCT-202 ZigBee Remote control RGB and Cold/Warm bulbs can only be turned ON
and OFF and can be dimmed.
16
2.4
ATo edit the name of a device first open the room which contains the device.
BPress the pencil button the enter edit mode.
CPress on the device name to begin editing.
DWhen you are done editing the name press the confirm button.
ETo delete a device press the DELETE button in front of the device when in editing mode. Press the
CONFIRM button to go back to the device overview.
2.4 Edit/delete device
ABC
E
D

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
17 18
3.1
With a scene you can trigger dierent devices at the same time or with an delay.
APress the scene button in the menu bar
BPress the + button at the top of the screen to add a new scene.
CFill in a desired name for the scene.
DPress OK.
3.1 Add scenes
A
B
C
D
3.2
APress the ADD ACTION button to add actions to the scene.
BAdd the desired actions for the devices by pressing the buttons.
CPress CONFIRM to add the actions to the scene.
DBy pressing the pencil button you enter edit mode.
EDelete an action by pressing the DELETE button.
FPress CONFIRM again to save the scene.
3.2 Add/delete actions
A
B
E
F
D
C

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
19 20
3.3
It is possible to add a delay between actions. First add an actions like described in step 3.2
APress the ADD DELAY button.
BChoose how long the delay must be by selecting a time period.
CPress the CONFIRM button to add the delay to the scene
DThe delay is now added to your scene.
EBy pressing the pencil button you enter edit mode.
FPress the DELETE button to delete a delay.
3.3 Add/delete delays
A
B
C
D
E
F
4.1
With a timer you can trigger one or multiple devices on a fixed time, Sunrise or Sunset.
APress the Rules button in the menu bar
BPress the + button at the top of the screen to add a new timer.
CPress on Timer wizard.
DFill in a name for your timer and press OK.
4.1 Configure timers
B
C
D

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
21 22
EChoose the kind of start time for the timer. (In this example a fixed time is used)
FSelect the desired start time for the timer and press NEXT.
GChoose which days and in which months the timer should be triggered. (By default all days and months
are selected). Press NEXT
EFG
HChoose the desired actions for when the timer is triggered. Press NEXT
IA message appears asking if you want to add a timer to turn the devices OFF. Press Yes
JSelect the time you want the devices to be turned OFF. Press NEXT
KThe timers have been added to the overview.
H
I
J

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
23 24
LPress the pencil button the enter edit mode.
MPress on the timer name to begin editing.
NWhen you are done editing the name press the confirm button.
OTo delete a timer press the DELETE button in front of the timer when in editing mode. Press the
CONFIRM button to go back to the timers/rules overview.
4.2 Edit/delete timer
4.2
K
M
N
O
L
With a rule you can execute an action by choosing a trigger and action.
APress the RULES button in the menu bar
BPress the + button at the top of the screen to add a new rule.
CPress on RULE.
DFill in a name for your rule and press OK.
5.1 Configure rules
5.1
B
C
D

ICS-2000 INTERNET CONTROL STATION ICS-2000 INTERNET CONTROL STATION
25 26
EAdd a trigger by pressing the + button next to triggers.
FSelect a trigger to use to execute an action. (In this example a motion sensor is used as trigger)
GChoose one of the linked devices
E
F
G
HAdd an action by pressing the + button next to actions.
IAn overview is shown of the available devices that have been linked. Choose an action for the
desired devices. Press the CONFIRM button.
JThe choosen triggers and actions are shown. Press the CONFIRM button again to save the rule.
KThe rule has been added to the rule overview. You can turn the rule ON or OFF by opening or
closing the toggle.
H
J
I

ICS-2000 INTERNET CONTROL STATION
28
ICS-2000 INTERNET CONTROL STATION
27
LPress the pencil button the enter edit mode.
MPress on the rule name to begin editing.
NWhen you are done editing the name press the confirm button.
OTo delete a rule press the DELETE button in front of the rule when in editing mode. Press the CONFIRM
button to go back to the rules overview.
5.2 Edit/delete rule
5.2
KL
O
M
AWhen there is no ICS-2000 found, it is possible to enter the MAC address manually during the
registration process. Press the MANUAL button
BLook at the bottom of the ICS-2000 for the MAC address.
CPress the “Enter manually” field and enter the MAC address for your ICS-2000. Then press NEXT
6 Connect manually
MAC: 00-00-A2-00-12-11
B
6
AC

ICS-2000 INTERNET CONTROL STATION
30
ICS-2000 INTERNET CONTROL STATION
29
ICS-2000 INTERNET CONTROL STATION
30
ICS-2000 INTERNET CONTROL STATION
29
7 Connect an existing device (Clone)
This step is recommended when you already control your Trust Smart Home receiver with a remote
control or wall switch. (Only for Startline products)
APress CLONE
BA dialogue is shown to clone the signal of the transmitter
CGive an ON signal on the transmitter that controls the device chosen in step 2.1f.
C
B
A
