Trust 13814 User manual

TRUST 120V WIRELESS DVD & VIDEO VIEWER
Instructions when using for the first time Chapter
1. Connecting (4.2)
2. Using Remote Control Extender (4.3)
UK
3. Checking after the installation (5)
1 Introduction
!
This instruction manual is for users of the TRUST 120V WIRELESS DVD & VIDEO
VIEWER. The product can be used to transmit video and audio flexibly from your
DVD/VCR player or PC or camcorder to anywhere your TV is in your house. And it
can work with other TRUST wireless video security products.
VIEWER. The product can be used to transmit video and audio flexibly from your
DVD/VCR player or PC or camcorder to anywhere your TV is in your house. And it
can work with other TRUST wireless video security products.
2 Safety2 Safety
Carefully read the following instructions before use.Carefully read the following instructions before use.
- The TRUST 120V WIRELESS DVD & VIDEO VIEWER does not require any
special maintenance. Use a slightly damp, soft cloth to clean the cover when it
gets dusty.
- The TRUST 120V WIRELESS DVD & VIDEO VIEWER does not require any
special maintenance. Use a slightly damp, soft cloth to clean the cover when it
gets dusty.
- Do not use aggressive substances, such as white spirit, to clean the device.
These may harm the material.
- Do not use aggressive substances, such as white spirit, to clean the device.
These may harm the material.
- Do not submerge the device in liquid. This may be dangerous and will
damage the device. Do not use this device near water.
- Do not submerge the device in liquid. This may be dangerous and will
damage the device. Do not use this device near water.
- Make sure nothing is placed on the cable. Do not use this device where the
cable can become worn or damaged as a result of people walking over it.
- Make sure nothing is placed on the cable. Do not use this device where the
cable can become worn or damaged as a result of people walking over it.
- Do not repair this device yourself. If you open this device, you may touch live
components.
- Do not repair this device yourself. If you open this device, you may touch live
components.
- Under the following circumstances, have the device repaired by qualified
personnel:
- The cable or plug is damaged or worn.
- The device has come into contact with rain, water or another liquid.
- Under the following circumstances, have the device repaired by qualified
personnel:
- The cable or plug is damaged or worn.
- The device has come into contact with rain, water or another liquid.
- Nowadays, there are an increasing number of wireless products (video, audio,
convenience, computer, etc.) which work in the same frequency range as this
device. It may, therefore, be possible that the functionality of this product is
limited by or is limiting for other wireless products. This can only be avoided
by paying attention to the distance between products and, where possible, by
changing channels.
- Nowadays, there are an increasing number of wireless products (video, audio,
convenience, computer, etc.) which work in the same frequency range as this
device. It may, therefore, be possible that the functionality of this product is
limited by or is limiting for other wireless products. This can only be avoided
by paying attention to the distance between products and, where possible, by
changing channels.
- Be careful when using wireless devices if you have a pacemaker or are
dependent on other life-saving, sensitive electronic equipment, because this
product transmits radio signals.
- Be careful when using wireless devices if you have a pacemaker or are
dependent on other life-saving, sensitive electronic equipment, because this
product transmits radio signals.
1

TRUST 120V WIRELESS DVD & VIDEO VIEWER
3 Approval
0678
- This device meets the essential requirements and other relevant conditions of
the applicable European directives. The Declaration of Conformity (DoC) is
available at www.trust.com/13814.
- This wireless device works at a frequency of 2.4GHz(AV) and 433.92MHz(IR
extender). It meets the essential requirements and other relevant conditions of
R&TTE Directive 1999/5/EC. It can be used in all EU countries and in
NO/CH/CZ/SK/HU/PL. The following limitations are applicable for certain
countries: (a) only channel 2 is allowed using outside in France.
- There may be limitations for the use of this device outside of the EU. If this
device is used outside of the EU, check whether this device meets local
regulations. Frequency: 2.4GHz, Bandwidth: 20MHz, Power: 10mW.
4 Installation
4.1 Product layout
1 Power indication/IR window 5 Channel selection switch
2 Adjustable IR antenna 6 AV in jack
3 On/Off button 7 AV out jack
4 Power adapter jack 8 IR sensor jack
Table 1. Product layout (Refer on Fig. 1 for the specific part)
** Refer on the product label to identify Transmitter(A) and Receiver(B)!
** Antenna for audio and video signal is built in.
4.2 Connecting
Before you make connection:
a. Set the channel switch of the transmitter(A) and receiver(B) on the same channel!
To set up your transmitter(A)
1. Take the SCART cable which
labelled with “TRANSMITTER(A)”
on its connector
2. Connect the mini plug of the
cable to the AV jack at the rear
side of the unit(see Fig. 2)
3. Connect the other end of the
cable to the SCART connector
on the AV equipment(see Fig. 2)
4. Plug one end of the provided
power adapter into a wall outlet
and the other end to the
transmitter(see Fig. 4, step 1, 2)
5. Turn on the transmitter by
pressing the power button in front
of the unit(see Fig. 4, step 3)
To set up your receiver(B)
1. Take the SCART cable which
labelled with “RECEIVER(B)” on
its connector
2. Connect the mini plug of the
cable to the AV jack at the rear
side of the unit(see Fig. 3)
3. Connect the other end of the
cable to the SCART connector
on the TV(see Fig. 3)
4. Plug one end of the provided
power adapter into a wall outlet
and the other end to the
receiver(see Fig. 4, step 1, 2)
5. Turn on the receiver by pressing
the power button in front of the
unit(see Fig. 4, step 3)
2

TRUST 120V WIRELESS DVD & VIDEO VIEWER
4.3 Using remote control extender
The TRUST 120V WIRELESS DVD & VIDEO VIEWER gives you the ability to control
AV source equipment from another room with your existing remote control. To use
this function, follow the steps below: (prefer to be done by two people) UK
a. Place the transmitter(A) on top of the AV source equipment and make
sure the front of the transmitter(A) is aligned with the IR panel of the AV
equipment. See Fig.5.
Or
Place the transmitter(A) close to the AV source equipment and plug the
IR sensor into the jack on the transmitter(A). Stick the IR sensor directly
on the IR window of the AV source equipment. See Fig. 6(a)
Or
Place the transmitter(A) in front of your AV source equipment and make
sure the front of the transmitter(A) is aimed to the IR panel of the AV
equipment. See Fig. 6(b)
b. Position your receiver(B) so that your remote control signal can strike the
IR window on the front of the receiver(B)
c. To use your remote control to point at the front of the receiver(B) and
operate it as you normally would
4.4 Other applications
a. To use with camcorder
Connect the mini plug of an A/V cable to the AV in jack on the transmitter(A)
and the other end to the output cinches of the camcorder, matching the
plugs colours with the cinches on the camcorder.
b. To use with your PC
(1) Transmit from a PC with composite video output
1-a. Connect the mini plug of an A/V cable to the AV in jack on
transmitter(A)
1-b. Connect the yellow plug on the A/V cable to the TV-OUT cinch on
your VGA card
1-c. Connect a “Y” adapter into the line out jack on your sound card
and connect the red and white audio cinches with the red and white
plugs of the A/V cable from the transmitter(A)
(2) Transmit from a PC with S-video output
Please first get a S-Video to composite converter/cable, which you can
find at electronics stores. Connect the S-Video converter/cable to your
S-Video output on your VGA card. And then follow the steps as in (1)
to finish the installation.
c. To use with other Trust wireless video product
(1) Connect the products as the way as instructed in the manuals
(2) Set different Trust products on the same channel
(3) Do not mix the role of which is transmitting signal and which is
receiving signal, for example, a security cam is transmitting the signal
while your TV, where you place the receiver(B), is receiving the signal.
(4) Operate the wireless products as you normally would do.
3

TRUST 120V WIRELESS DVD & VIDEO VIEWER
5 Checking after installation.
a. Check if transmitter(A) is at AV source and receiver(B) is at your TV.
b. Check if all connectors are well connected.
c. Check if all power are plugged.
d. Check if cables used are correct on the transmitter(A) and receiver(B).
e. Remote control extender performance depends on the IR sensor on your
AV source component as well. There are three ways to implement the
remote control extender, please find one which is most suitable. When
using IR sensor, please try with two people to find the best position to
stick the IR sensor. See Fig. 7 for example.
6 Troubleshooting
Method
1. Read the solutions given below.
2. Check for up-to-date FAQ’s and instruction
manuals on the Internet www.trust.com/13814
!
Problem Cause Possible solution
Connectors are not well
connected.
Connect the connectors
firmly.
Power is not turned on. Turn on the power.
Misplaced transmitter(A) and
receiver(B).
Refer on the product label at
the bottom of the product
and connect transmitter(A)
with AV source component
and receiver(B) with TV.
Not getting any
video or audio
signal on TV.
The AV source is not
playing.
Start playing the AV source
Channel switch is not set on
the same channel.
Set the channel switch on
transmitter(A) and
receiver(B) to the same
channel.
Signal transmitted is not
reaching receiver(B).
Adjust the transmitter(A) or
receiver(B) by rotating its
orientation until you get
better signal. Or relocate
them into a working range.
There is data transmitted on
the 2.4GHz band from a
wireless network as well.
Switch both transmitter(A)
and receiver(B) to another
channel. Or adjust wireless
network to another channel.
Certain channel does not
work properly.
Switch both transmitter(A)
and receiver(B) to another
channel.
The audio or video
signal is poor, or
interfered.
There is a microwave in the
path between the
transmitter(A) and
receiver(B).
Turn off the microwave.
4

TRUST 120V WIRELESS DVD & VIDEO VIEWER
UK
The audio or video output
settings on AV source
(DVD/VCR/etc.) has not
been adjusted.
Check if the audio or video
output settings are proper on
the AV source component.
The cables are not
connected properly.
Please check if the A/V
cable plugs as well as the
audio plug is connected
correctly.
Not getting proper
video or audio
signal from your
DVD-ROM player on
your PC. The settings of the software
media player, VGA card,
sound card in your PC is not
adjusted.
Please refer on the manual
of your software media
player, VGA card to adjust
the settings of how to output
to TV. Transmitter(A) only
transmits video and audio
signal from your VGA and
sound card in your system.
Cannot play DIVX or
AVI or MPEG files
from PC to TV.
The settings of your VGA
card in your PC is not
adjusted.
Please check the settings of
your VGA card, e.g. output
to TV, PAL and etc.. Or try
to play the file from your PC
to TV through cable
connection and make sure it
works first then connect the
transmitter(A) onto your PC.
I cannot use my
wireless
mouse/keyboard
with this product.
The working frequency of
these devices are different.
This wireless video
transmitter works at 2.4GHz.
The wireless mouse or
keyboard works at 27MHz
range.
The batteries in remote
control is low.
Replace the batteries in the
remote control.
The IR sensor is not
attached at a proper
position.
Try to attach the IR sensor
at the best location on the IR
window of the AV source.
See Fig. 7 for example.
Remote control is
not working
properly.
The antenna is not extended
or not in right direction.
Extend the antenna and
adjust the direction of the
antenna.
If you still have problems after trying these solutions, please contact one of the Trust
Customer Care Centers. You can find more information at the back of this instruction
manual. Please have the following information available:
• The item number is 13814 or 13815 of UK model.
• A good description of what does not work.
• A good description of when the problem occurs.
7 Warranty conditions
- Our products have a two-year manufacturer's warranty which is effective from
the date of purchase.
5

TRUST 120V WIRELESS DVD & VIDEO VIEWER
- If there is a fault, return the product to your dealer and include an explanation
of the fault, the proof of purchase and all the accessories.
- During the warranty period, you will receive a similar model, if one is available.
If no similar product is available, your product will be repaired.
- Please contact our help desk for missing components, such as the instruction
manual, software or other components.
- The warranty becomes invalid if the product has been opened, if there is
mechanical damage, if the product has been misused, if alterations have been
made to the product, if the product has been repaired by a third party, in the
case of negligence or if the product has been used for a purpose other than
that originally intended.
- Excluded from the warranty:
• Damage caused by accidents or disasters, such as fire, flood,
earthquakes, war, vandalism or theft.
• Incompatibility with other hardware/software which is not stated in the
minimum system requirements.
• Accessories, such as batteries, fuses (if applicable).
- Under no circumstances will the manufacturer be held responsible for any
incidental or consequential damage, including the loss of income or other
commercial losses resulting from the use of this product.
6
