Trust 100 Series User manual

TRUST 100X OUTDOOR WIRELESS SECURITY CAM
1
UK
Instructions when using for the first time Chapter
1. Positioning the camera (3.1)
2. Setting the channel (3.2)
3. Directing the camera (3.3)
1 Introduction
This instruction manual is for users of the TRUST 100X OUTDOOR WIRELESS
SECURITY CAM. This camera makes it possible to extend your existing 2.4 GHz
wireless system (TRUST WIRELESS OBSERVATION SYSTEM 100M / 100S or
100V) with a splash resistant camera for outside use. The TRUST 100X OUTDOOR
WIRELESS SECURITY CAM can be used to protect your property. This wireless
camera works via radio frequencies. The camera can be connected to receivers of
the Trust 100 series of wireless products. The camera can also be used with other
2.4 GHz wireless systems, provided they use the same technology. We cannot,
however, guarantee that it will always work.
2 Safety
Carefully read the following instructions before use:
- ALWAYS locate the adapter indoors and have the cable run outside.
- The TRUST 100X OUTDOOR WIRELESS SECURITY CAM does not require
any special maintenance. Use a slightly damp, soft cloth to clean the camera.
- Do not use aggressive substances, such as petrol or white spirit, to clean the
device. These may harm the material.
- This device is SPLASH RESISTANT. Do not submerge the device in liquid.
This may be dangerous and will damage the device.
- Make sure nothing is placed on the cable. Do not use this device in an area
where the cable can become worn or damaged as a result of people walking
over it.
- Do not repair this device yourself. If you open this device, you may touch live
components. The device may then also no longer be watertight.
- Under the following circumstances, have the device repaired by qualified
personnel:
- The cable or adapter is damaged or worn.
- The device has come into contact with rain, water or another liquid.
- This product works at a frequency of 2.4835 GHz. It is approved according to
the European R&TEE guidelines and, therefore, meets the harmonized
requirements for use within the EU. There may be limitations for the use of
this device outside of the EU. In that case, check whether this device meets
local regulations. Frequency(s): 2.4835 GHz, Bandwidth: 20 MHz, Power: 10
mW.
- Nowadays, there are an increasing number of wireless products (video,
audio, convenience, computer, etc.) which work in the same frequency range
as this device. It may, therefore, be possible that the functionality of this
product is limited by or is limiting for other wireless products. This can only be
avoided by paying attention to the distance between products and, where
possible, by changing channels.
- Be careful when using wireless devices if you have a pacemaker or are
dependent on other life-saving, sensitive electronic equipment, because this
product transmits radio signals!
!

TRUST 100X OUTDOOR WIRELESS SECURITY CAM
2
3 Positioning and adjusting the camera
3.1 Positioning the camera
1. If necessary, drill a 14 mm hole from inside to outside to feed the adapter
cable outside.
Advice: To prevent damaging the cable, feed the cable through a piece of
PVC tubing. This can be purchased from your local DIY store.
2. Feed the adapter cable through the hole outside.
3. Determine the position where the camera will be hung. Preferably hang it in a
sheltered location, for example, under a lean-to.
Note: Do not hang the camera in direct sunlight. This will affect the quality of
the image.
Note: If you wish to fix the camera against a stone or concrete surface, we
recommend using the plugs provided to ensure that the camera is
firmly fixed in position.
4. Bring the connections for the camera and the adapter together and connect
them by pushing them firmly into each other. If desired, use a PVC tube to
provide optimal protection for the cable.
5. Insert the adapter into the plug socket.
Note: NEVER insert the adapter into an outdoor plug socket. Always use an
indoor plug socket.
3.2 Setting the channel
1. Remove the protective rubber cover on the rear of the camera.
2. Select the camera channel using the switch Swhich is now visible (see figure
1).
3. Select channel 1, 2, 3 or 4 by sliding the switch to the left or right.
4. Check on the receiver of, for example, your TRUST WIRELESS
OBSERVATION SYSTEM 100M whether you receive a picture.
5. Place the protective rubber cover back on the rear of the camera.
Note: For more information about your receiver, see the instruction manual
for the TRUST 100 series receiver.
3.3 Directing the camera
The lens of the camera can be rotated upwards and downwards. The camera can be
rotated through 360 degrees when on the stand. Once you have found the desired
position, you can secure it in position using the locking screw (A in figure 2).

TRUST 100X OUTDOOR WIRELESS SECURITY CAM
3
UK
4 Technical specifications
Description Response
Wireless technology Radio frequency, 2.4 ~ 2.473 GHz
Frequency per channel [GHz] [ 1 / 2 / 3 / 4] 2.434 / 2.453 / 2.473 / 2.411
Wireless power (mW) 10 mWatt
Bandwidth 20 MHz
Optical module CMOS 1/3”
Lens f3.6mm / F2.0
Microphone Yes
A/V mod/demod. method FM
Night vision Yes, via 7 infrared sensors
Wireless signal range (metres) 100 m free space
Resolution 500 x 582
PAL (EU) Yes
PAL I (UK) Yes
SECAM (FR) No
Video output signal
NTSC (USA) No
Power adapter DC 9 V – 500 mA
Camera: 10 metres
Cable length (m)
Adapter: 10 metres
Product size [HxWxD] (mm) 108 x 135 x 117
Weight (kg) 1.86

TRUST 100X OUTDOOR WIRELESS SECURITY CAM
4
5 Troubleshooting
Method
1. Read the solutions given below.
2. Check for up-to-date FAQ’s, drivers and instruction
manuals on the Internet (www.trust.com/12955).
Problem Cause Possible solution
The camera is turned off. Turn the camera on.
The adapter has not been
connected.
Connect the adapter to the
camera.
The channel which has been
selected has not been
selected on your receiver.
Select the correct channel
on the camera or the
receiver.
The camera does
not give an image
or gives a poor
quality image.
The receiver’s aerial is not in
the correct position.
Direct the aerial so that the
image becomes clear. Also
see the instruction manual
provided with the receiver.
The camera
suddenly stops
working.
The adapter is not securely
connected.
Firmly insert the plug in the
socket between the camera
and the adapter connection.
A high-pitched
whistle can be
heard on the
receiver.
The camera and the
receiver are positioned too
close to each other.
Increase the distance
between the camera and the
receiver.
I do not have a
receiver.
Visit your dealer and ask for
the TRUST WIRELESS
OBSERVATION SYSTEM
100M, 100S or 100V
models.
The problem is not
listed here.
The latest FAQ update is
available on the Internet.
Visit www.trust.com/12955
for FAQ’s and other product
information.
If you still have problems after trying these solutions, please contact one of the Trust
Customer Care Centers. You can find more information at the back of this instruction
manual. Please have the following information available:
• The article number. This is 12955.
• A good description of what does not work.
• A good description of when the problem occurs.
!
