Trust 340 User manual

TRUST 340 SPEEDSHARE WEB STATION
1
UK
1 Introduction
Thank you for buying this Trust 340 SPEEDSHARE WEB STATION. This
SPEEDSHARE WEB STATION allows you to create a flexible high performance
Ethernet network desktop system. This SPEEDSHARE WEB STATION allows you to
share a high speed broadband internet connection with one or more computers.
1.1 Accessing the Internet
Your Trust 340 SPEEDSHARE WEB STATION gives you direct access to a
broadband connection allowing you to surf the web, send and receive files and email
from other computers and/or share a printer which is connected to your network.
Your Trust 340 SPEEDSHARE WEB STATION can automatically acquire the
necessary IP address when a connection is made with the Internet, removing the
need to configure each computer individually on your network. It is possible however
to individually configure each computer with your Trust 340 SPEEDSHARE WEB
STATION.
2 Safety
Please read the following directions before first use.
1. Always disconnect the power supply and remove the power supply cable before
connecting or installing any devices including network adapters.
2. Never attempt to repair your Trust 340 SPEEDSHARE WEB STATION yourself.
All repairs should be done by a qualified individual.
This product conforms to relevant European directives and standards. The
Declaration of Conformity (DoC) can be found at www.trust.com/13602/CE.
3 Indicators
This chapter explains the features of your Trust 340 SPEEDSHARE WEB STATION.
3.1 The Front Panel
Power LED Green; This shows when the WEB STATION is powered on.
10M Link/ACT Orange; When these LEDs are continuously lit the SPEEDSHARE
WEB STATION is connected successfully to the Internet through a ADSL/Cable
modem. If these LEDs are flashing it indicates that data is being sent or received.
100M Link/ACT Green; When these are lit a successful 100M connection is made.
Wan; This shows when a successful connection is made with the Internet.
LED 1-4; These correspond to each PC, workstation or hub connected to your Trust
340 SPEEDSHARE WEB STATION.
3.2 The Rear Panel
See Figure 1
1. Four RJ-45 10/100 SPEEDSHARE WEB STATION connectors to connect to
PCs and Workstations.

TRUST 340 SPEEDSHARE WEB STATION
2
2. One RJ-45 WAN connector to connect the Trust 340 SPEEDSHARE WEB
STATION to the Internet via a broadband connection such as ADSL or Cable.
3. One DC power connector for connecting a DC power adapter
4. Reset button to reset to the original factory settings
3.2.1 Reset
To reset your Trust 340 SPEEDSHARE WEB STATION use a paper clip or pen tip,
press the reset button and hold it for 2 seconds. This will restore all of the Trust 340
SPEEDSHARE WEB STATION settings to the factory settings.
Note: This will remove all IP addresses and other individual settings you may have
setup.
4 Connecting Your Trust 340 SPEEDSHARE
WEB STATION
Before installing your Trust 340 SPEEDSHARE WEB STATION in your network
please ensure that your xDSL modem and Broadband connect are functioning
properly. You can do this by connecting your xDSL modem and Broadband
connection directly to a PC or workstation. If the system functions correctly and you
have full access to the Internet then proceed with the Trust 340 SPEEDSHARE WEB
STATION installation. If this fails please refer to either the xDSL modem reference
material or the documentation form your ISP (Internet service Provider).
Connecting your Trust 340 SPEEDSHARE WEB STATION is extremely easy when
following these steps:
1. Connect your Trust 340 SPEEDSHARE WEB STATION through the Trust 340
SPEEDSHARE WEB STATION’s WAN port to an ADSL/Cable modem using a
crossover CAT5 UTP LAN cable.
2. Connect your PC or Workstation to one of the four Trust 340 SPEEDSHARE
WEB STATION LAN ports using a standard RJ-45 network cable.
3. Connect the DC power adapter to the Trust 340 SPEEDSHARE WEB
STATION and to a power outlet.
5 Configuring Your Windows Network
This chapter explains how to configure each computer or workstation in your network
so that they can communicate with your Trust 340 SPEEDSHARE WEB STATION.
Each computer or workstation needs to have an Ethernet card installed and also be
connected to your Trust 340 SPEEDSHARE WEB STATION. This connection could
be either direct or indirect through and external hub or switch. Each computer should
have TCP/IP installed and be setup to automatically obtain an IP address. For
advanced settings please refer to chapter 7. To install TCP/IP and set it to
automatically obtain an IP address, please refer to the following sections 5.1 for
Windows 98/ME and 5.2 for Windows 2000/XP.
5.1 Windows 98/ME
1. From the windows desktop select the Start button and then open the Control
Panel and select the Network icon.
2. In the Network window select the Configuration tab.
See Figure 2

TRUST 340 SPEEDSHARE WEB STATION
3
UK
3. Check to see if the TCP/IP is installed in the Network component list. If it is
installed proceed to step 6. Otherwise click the Add button now.
4. A new window will appear.
See Figure 3
5. Select Protocol and click Add.
6. After you have TCP/IP installed select it form the Network Component list and
click Properties.
See Figure 4
7 Select the Obtain an IP address automatically option.
8. Click OK.
5.2 Windows 2000/XP
1. From the windows desktop select the Start button and then open the Control
Panel and select the Network icon.
2. Right Click on Local Area Connection and select properties.
3. In the Network window select the General tab.
See Figure 5
4. Select the Internet Protocol (TCP/IP) option and press Properties.
See Figure 6
5. Select Obtain an IP address automatically and Obtain DNS server automatically.
6. Click OK.
6 Configuring your Trust 340 SPEEDSHARE
WEB STATION
Your Trust 340 SPEEDSHARE WEB STATION is equipped with a web based user
interface to configure and set up all functions of the station. This easy to use
interface makes configuring your station easy.
To access the web based interface open your browser and enter http://192.168.1.1
in the browser’s address bar and click Enter. This is the default address of your Trust
340 SPEEDSHARE WEB STATION.
6.1 Login
Once you have access to the web based set up interface you will need to enter a
password. The first time you log in there is no password required.
To set your own password, enter the new password now. This password will be
needed for future access to the web based interface.
Note: To change an existing password please refer to the Advanced Settings in
chapter 7.
See Figure 7

TRUST 340 SPEEDSHARE WEB STATION
4
Note: If you forget your password you need to rest the SPEEDSHARE WEB
STATION to the factory settings. Please refer to chapter 2.1
6.2 Setup
The setup screen gives you two options:
The setup wizard which gives you access to the different WAN types or Advanced
settings. For further details about the Advanced settings please see chapter 7.5.
See Figure 8
6.3 Setup Wizard
6.3.1 Time Zone
The time zone is used for all log entries and client filtering. Click on the drop down
box and selected the desired time zone (normally the time zone in which you are
located). Also you can select Daylight Savings if required in the region where you
are located.
See Figure 9
6.3.2 WAN Type
Your Trust 340 SPEEDSHARE WEB STATION is enabled to handle four WAN Types:
Dial-UpxDSL (PPPoE), PPTP, Fixed IP xDSL, and Cable Modem.
Your ISP (Internet service Provider) will provide the necessary information about
which WAN type to select. Your ISP will provide all the needed information. Please
refer to your ISP’s documentation for the proper settings.
See figure 10
6.3.2.1 Dial-Up xDSL(PPPoE)
Select this option if your ISP uses PPPoE. Enter the user name and password
supplied by your ISP. If your ISP does not supply you with any of the information
listed in this window then these boxes can be left blank.
See Figure 11
MTU: Maximum Transmission Unit this is the largest frame size that can be
transmitted over your network. If a message exceeds the MTU then it will be divided
into smaller frames.
Maximum Idle Time: This represents the number of seconds of inactivity through the
connection. When the Maximum Idle Time is exceeded the Internet Connection will
be disconnected.
Auto Reconnect: The Auto reconnect option will automatically try to connect to your
ISP if your system is restarted.
6.3.2.2 PPTP
Select this option if your ISP requires you to use the PPTP protocol.
See Figure 12

TRUST 340 SPEEDSHARE WEB STATION
5
UK
MTU: Maximum Transmission Unit this is the largest frame size that can be
transmitted over your network. If a message exceeds the MTU then it will be divided
into smaller frames.
Maximum Idle Time: This represents the number of seconds of inactivity through the
connection. When the Maximum Idle Time is exceeded the Internet Connection will
be disconnected.
6.3.2.3 Fixed IP xDSL
Select this option to manually enter the IP address provided by your ISP.
Enter the assigned IP address, subnet mask and gateway. The assigned IP address,
subnet mask and gateway should all be provided by you ISP.
See Figure 13
6.3.2.4 Cable Modem
If you are using a Cable modem, enter the modem host name and a MAC address (if
required). Some ISPs require a specific MAC address to be entered before a
connection to the Internet can be established.
See Figure 14
6.4 DNS
The DNS or Domain Name Server is a list of names and web addresses. Your ISP
should provide you with the IP address of one or more domain name servers. Enter
those addresses in the corresponding boxes.
See Figure 15
7 Advanced Settings
Your Trust 340 SPEEDSHARE WEB STATION comes with a comprehensive list of
advanced options. Please the following sections to learn about the key Advanced
Settings.
Note: If you are unsure of any of the following settings please use the factory default
settings.
To access these functions select the Advance Setup from the home page of the user
interface.
See Figure 16
7.1 System Settings
This section covers all the basic configuration tools for your Trust 340 SPEEDSHARE
WEB STATION. In this section you will find: System Time, Administrator Settings,
Firmware Upgrade, Configuration Tools, System Log, Reset. These tools will be
briefly described below.

TRUST 340 SPEEDSHARE WEB STATION
6
If you are unsure of any of the following settings please use the factory default
settings. For further Networking Information please read the “Networking Sharing
Manual”. You can find this manual on the Trust installer CD that came with this
product. To open this manual click on “Read manual” on the Trust installer CD menu,
or see the file named “Read Internet Sharing Manual” on the same CD
7.1.1 System Time
The system time function allows you to set any time zone you require for your
network.
7.1.2 Administrator Settings
The administrator setting allows you to restrict access to the Trust 340
SPEEDSHARE WEB STATION. The administrator can have access from a remote
location by using the Remote Management option. You will need to specify the IP
address of the remote computer however.
To set an Administrator password enter the current (existing) password, the new
password and then retype the new password.
7.1.3 Firmware Upgrade
To check for a Firmware upgrade use the hyperlink provided in this window, or
manually enter the following URL in your browser. Only upgrade your Trust 340
SPEEDSHARE WEB STATION if you are familiar with firmware upgrading. Improper
firmware installation can damage your web station.
Please note that if you are unfamiliar with firmware upgrades DO NOT attempt to
proceed as you can damage your SPEEDSHARE WEB STATION.
7.1.4 Configuration Tools
The configuration tools allow you make a back-up of all your current 340
SPEEDSHARE WEB STATION settings. This back-up file will be saved on your
computer or workstation as a “config.bin” file.
To restore the original factory settings use the “Restore Factory Default
Configuration” function.
7.1.5 System Log
This function gives you the chance to review all attempts that were made to gain
access to your network by all users and potential hackers.
7.1.6 Reset
If your 340 SPEEDSHARE WEB STATION does not respond or is functioning
incorrectly then you can use the reset function to reset the web station. When
resetting your web station the power LED will start flashing. The reset process is
completed when the power LED stops flashing. Please note you will not lose your
settings when using this function.

TRUST 340 SPEEDSHARE WEB STATION
7
UK
7.2 Wan
This option lets you select the correct WAN type as required by your ISP. There are
four WAN types:
1. PPPoE; PPP over the Ethernet is the most common connection method used
for xDSL internet connections
2. PPTP; This method uses the PPP Tunnelling Protocol which supports multi-
protocol Virtual Private Networks (VPN)
3. Static IP Address; This method uses a static IP address that will be provided
by your ISP if needed.
4. Dynamic IP Address; This method automatically obtains an IP address from
your ISP every time your web station connects to the Internet.
7.3 LAN
It is necessary for your Trust 340 SPEEDSHARE WEB STATION to have an IP
address to access your LAN (Local Access Network). It is possible to enable the
DHCP (Dynamic Host Configuration Protocol) service which allows for dynamic IP
addresses for each of your network clients. You can also configure your web station
with filtering functions based on specific clients or protocols.
7.4 NAT
NAT (Network Address Translation) gives permission for multiple users to access the
Internet from your network using a single public IP address or with the use of multiple
public IP addresses. NAT also prevents the threat of hacker attacks by the mapping
of local addresses of public addresses for important applications like accessing the
Internet or using an ftp (File Transfer Protocol) site.
7.5 Firewall
Your Trust 340 SPEEDSHARE WEB STATION offers extensive firewall protection
and security. This is accomplished by restricting connection parameters limiting the
risk of intrusion; this defends your network against a wide variety of the more
common hacker attacks. For applications that require unrestricted access to the
Internet and possibly your network you can configure individual clients or servers as
DMZ (Demilitarized Zone).
7.6 Routing
In the case that you use multiple routers in your network it is necessary to configure
each router’s routing functions.
Please take note that if you are unfamiliar with any setting, please use the default
setting. This will eliminate the possibility of lost data or damage to your Trust 340
SPEEDSHARE WEB STATION or workstation.
Note: To learn more about these options please refer to the “Networking Sharing
Manual”. You can find this manual on the Trust installer CD that came with this
product. To open this manual click on “Read manual” on the Trust installer CD menu,
or see the file named “Read Internet Sharing Manual” on the same CD

TRUST 340 SPEEDSHARE WEB STATION
8
8 Troubleshooting
Problem Cause Possible Solution
Forgotten
Password
Reset your WEB STATION.
See chapter 3.2.1.
Cable is not connected or not
connected correctly.
Check if the cable is
connected to the router
correctly.
PCs or printers are not
shared with other computers
on the network.
Share a minimum of 1 PC or 1
printer to make the printer
visible on the network.
User group name of your PC
is different from the others of
the network.
Change the work group in the
“Network Properties”. Please
refer to the “Internet Sharing”
manual, chapter 6 on the
Trust installation CD-ROM.
Other
computers
connected to
the network are
not visible. /
Router does not
work.
Incorrect Network settings Please refer to the “Internet
Sharing” manual on the Trust
installation CD-ROM.
Any of the LEDs
do not light up
Incorrect or faulty cable. Check that all cables are the
proper type or change them if
needed.
Incorrect network cable. Ensure that you are using
the3 correct cable.
The Dial-up mode is still
enabled on that computer.
Disable the dial-up mode in
your browser.
The Internet
cannot be
shared with
PCs on in your
network
Network settings are not set
to DHCP for this computer.
Set the computer to DHCP.
Latest FAQ update is
available on the internet.
Please go to
www.trust.com/13602/CE for
FAQ and other product
information.
Problem is not
listed here.
Other network problems. Please go to the
Troubleshooter:
www.trust.com/customercare/
help/network
For further Networking troubleshooting information please go to:
http://www.trust.com/customercare/help/network/
9 Further Information
For further Networking Information please read the “Networking Sharing Manual”.
You can find this manual on the Trust installer CD that came with the product. To
open this manual click on “Read manual” on the Trust installer CD menu, or see the
file named “Read Internet Sharing Manual” on the same CD

TRUST 340 SPEEDSHARE WEB STATION
9
UK
For further Networking troubleshooting information please go to:
http://www.trust.com/customercare/help/network/
For ADSL troubleshooting please refer to:
www.trust.com/customercare/help/ADSL
For Windows XP troubleshooting please refer to:
www:.trust.com/customercare/help/XP
Check the FAQ's on the Internet (www.trust.com). You can also register your product
at www.trust.com, so that you can receive optimal guarantee and service support.
You will be automatically informed of developments to your product and other Trust
products. You will also have the chance to win some spectacular prizes.
If you still have problems after trying these solutions, please contact one of the Trust
Customer Care Centres. You can find more information at the back of this instruction
manual. Please have the following information available:
•The product number (in this case, 13602 and for the UK 13611).
•Your workstation specifications.
•A complete description of the problem.
•In which situations the problem occurs.
10 Warranty Information
-TRUST guarantees its products against any defect in material and
workmanship, for a period of 2 years from the date of purchase.
-In the event a product is found to be defective within the warranty period,
please return the product to the dealer. Make sure to include a description of
the problem, proof of purchase and all accessories.
-During the warranty period, the dealer will exchange the defective product for a
comparable product if available. If a comparable product is not available, the
defective product will be repaired.
-For missing items, such as user’ guide, software or other parts, please contact
our helpdesk.
-If the product is repaired, modified or altered by a third party, or has been
exposed to abuse or neglect, or has been used in other ways than its intended
use.
-This warranty is void if:
•The damage was caused by accidents or disasters, such as fire, flooding,
earthquakes, acts of war, vandalism or theft
•Incompatibility with other hardware/software not stated in the minimum
system requirements
•Accessories such as batteries and fuses are excluded from the warranty (if
applicable)
-TRUST will not, under any circumstances, be liable for direct or consequential
damages such as, but not limited to, damage or loss of profits or revenues, or
other commercial losses, or inconvenience caused by service interruptions
