Trycom Technology TRP-C07 User manual

TRP-C07
User’s Manual
RS-422/485 Isolated Repeater
Printed Feb. 2007 Rev 1.1
Trycom Technology Co.,Ltd
1F, No.2-11,Sihu street ,Yingge Township, Taipei, Taiwan ROC
Tel: [phone] , Fax: [phone]
Web: www.trycom.com.tw
Copyright
Copyright Notice: The information in this manual is subject to change without prior notice in order to improve
reliability, design and function and dosed not represent a commitment on the part of the manufacturer. No part of this
manual may be reproduced, copied, or transmitted in any form without the prior written permission of manufacturer.
Acknowledgment Products mentioned in this manual are mentioned for identification purpose only. Products manes
appearing in this manual may or may not be registered trademarks or copyright of their respective companies.

1. Introduction
TRP-C07 is designed to extend the RS-422 and RS-485 signals to another 4000ft (1200m)
distance and increase the maximum number of connected nodes up to 32 sets. Aside from
extension function TRP-C07 provides with auto configuration features in data format detecting,
baud rate setting and RS-485 data direction flow control. TRP-C07 is equipped with
photo-couplers and internal surge protection to protect the module and all data lines against high
voltage spikes, as well as ground potential differences. The industry standard DIN rail and panel
mounting design enable user a fast and professional installation. TRP-C07 is the ideal solution
for the user who wants to automate their application quickly, safely and cost-effectively.
1-1. Features
¾Wide input range DC power supply.
¾Automatic data format configuration.
¾Auto direction flow control on RS-485.
¾Auto baud rate switching from 300bps to 115.2Kbps.
¾RS-485 bi-directionally communication.
¾3000 DC isolated protection.
¾Surge protection on RS-422/485 data lines.
¾Power/TX/RX mode LED indicator.
¾Support screw terminal and external DC adapter.
¾DIN rail or panel mount support.
1-2. Specification
¾Power input voltage: DC +10V to +30V.
¾Power input type: Support screw terminal or external DC adaptor.
¾Interface: Industrial plug-in screw terminal.
¾RS-485 signal: differential 2 half-duplex wires. (D+,D-).
¾RS-422 signal: differential 4 full-duplex wires. (TX+,RX+,TX-,RX-).
¾Plug-in screw terminal wiring: Accepts AWG -#12~30 wire.
¾Distance: extend RS-422/485 signal up to 4000ft. (1200M).
¾Isolation voltage: 3000V DC.
¾LED indicator: Power, TX, and RX.
¾Power consumption: 1.2 watt.
¾Operating Temperature: 0 to 60℃.
¾Storage Temperature: -20 to 70℃
¾Humidity: 10-90% Non-condensing.
¾Dimension: 151mm X 75mm X 26mm
¾Weight: 380g.

2. TRP-C07 Hardware description
2-1. Panel Layout
2-2. TRP-C07 block diagram
2-3. LED indicators
PWR LED: System is ready.
RX LED: RS-422/485 receiving.
TX LED: RS-422/485 transmitting.

3. Install TRP-C07
3-1. Connect power source with TRP-C07
The TRP-C07 has a two pins terminal block and power jack. Power can be supplied from
terminal block or external power adapter and supports wide input range from +10~30V. When
power is correctly supplied the PWR LED will lighting and indicate the system is up and running.
It is highly recommended use the power jack specification 5.5*2.1*12mm if the power supply is
from external DC plug.
Warning: User can only choose one of following 2 power sources.
1. External DC adapter. 2. Screw terminal DC input
Do not use both power input simultaneously.
3-2. Connect TRP-C07 with RS-422 or RS-485 devices
RS-422 wiring Connection .
RS-485 wiring connection.
RS-422 to RS-485 conversion wiring connection.
System protection wiring connection.
** TRP-C06: RS-232 to RS-422/485 Isolated Converter

4. How to test TRP-C07
Trycom Technology Co., Ltd offers demo and test utility, these utilities may help user to demo
and test TRP-C07 fast and easily. User may find the utilities in Trycom support CD or download
from Trycom web www.trycom.com.tw. The testing utility includes.
RS-422 test utility
Test422.exe for DOS
DEMO.exe for Windows
and RS-485 utility.
Test485.exe for DOS
TRPCOM for Windows.
4-1. RS-422 Loop Back Test
Refer to wire connection as below
STEP1:Run the “DEMO.EXE” utility (See the Figure 1).
Fig.1
STEP2: Click the “Setting” to set the RS-422 loop counter (See the Figure 2); the demo setting
screen will shown as Fig.2.
Fig.2

*Please note: “COM3” is an example of COM port number; the real COM number is assigned by
your PC.
STEP3:.Click the “OK” the utility will show the input and output status.
4-2. RS485 test
The wiring connection is as below.
Step1. Install TRPCOM utility.
TRPCOM is a test utility which may help user to test TRP-C07 with RS485 device easily. Double
click “Setup.exe”, the install Wizard will guide you to complete the installation.
Step2. Configure COM port and baud rate, after configuration press “OK” to the next screen.

Step3.Send command “$01M” and press “Send”.
Step4. Data response received.
Test complete.
