Trycom Technology TRP-C07 User manual

TRP-C07
User’s Manual
RS422/485 Optical Isolated Repeater
Printed Aug. 2005 Rev 1.0

1. Introduction
The TRP-C07 repeater boosts the RS-422/485 signals to extend the distance up to 4000 ft
(1200M) and increase the maximum number of connected nodes up to 128. With data format
auto detecting and baud rate auto switching function TRP-C07 is able to automatically detect the
data flow and switch the direction of the data lines accordingly as well as to automatically
configure RS-422/485 signals to any baud rate without external switch setting. The optical
isolation provides 3000VDC of isolation to protect the host computer from ground loops and
destructive voltage spikes on the RS422/485 data lines. The internal surge-protection on each
data line protects the module from dangerous voltages.
1-1. Features
¾Automatic internal RS-422/485 bus supervision.
¾Auto direction flow control on RS-485.
¾Supported baud rate up to 115.2 Kbps.
¾Support 3000 V DC isolation protection.
¾Over current protection.
¾All RS422/485 signals provide surge protection.
¾Power/TX/RX mode LED indicator.
¾Power supply :Support screw terminal and standard external DC adaptor.
¾Power input requirement from DC +10V to +30V.
1-2. Specification.
¾Power Input Voltage: DC +10V to +30V
¾Input: RS422/485 protocol.
¾Output: RS422 signal: Differential 4 full-duplex wires
¾RS485 signal: Differential 2 half-duplex wires.
¾Electromagnetic Compatibility: CE.
¾Communication speed: form 1.2 to 115.2Kbps auto-switching.
¾RS422/485 line protection: Against surge, short circuit, voltage peak.
¾Distance: Extend RS422/485 signal up to 4000ft (1250M).
¾Connection type: Screw terminal for maximum AWG 12 wire.
¾Signal LED: Power on , TX , RX.
¾Din-Rail mountable: Yes.
¾Power supply: Screw terminal , or standard external DC adapter.
¾Power consumption:1.2W..
¾Isolation Voltage3000V DC.
¾Operating environment:-20 to 65C.
¾Storage temperature: -20 to 65C.
¾Dimension:151mm X 111mm X 26mm.
¾Weight: 375g.

2. TRP-C07 panel layout
3. TRP-C07 Hardware Structure
4. Install TRP-C07
4-1. Connect power source with TRP-C07.
Warning: User can only choose one of 2 power source
External DC-Jack or Screw terminal DC input
Do not use external DC-Jack and screw terminal DC input simultaneously.
RS485 Signal from host
RS422 Signal from the host
Power LED
RX LED( When the signal is receiving will flash)
TX LED(When the signal is transecting will flash)
Power DC input from +10V to+ 30V
RS422 Signal to target device
RS485 Signal to target device
DC Jack Input from +10V to +30V. (Pleas use the 5.5*2.1mm DC JACK)
W
Wa ar rn ni in ng g: : D Do on n’ ’t t c co on nn ne ec ct t e ex xt te er rn na al l D DC C- -J Ja ac ck k a an nd d
s
sc cr re ew w t
te er rm mi in na al l D DC C i in np pu ut t s si im mu ul lt ta an ne eo ou us sl ly y. .

4-2. Connect TRP-C07 with RS422 or RS485 devices
4-2-1. RS422 wiring Connection
** TRP-C06 : RS232 to RS422/485 Isolated Conserver
4-2-2. RS485 wiring connection.

4-2-3. RS422 to RS485 wiring connection.
TRP-C07 may bi-directionally communicate between RS422 and RS485 devices
5. RS422 loop back test
Wiring connection.
