TSI Instruments 8455 Operation manual

Air Velocity Transducer
Model 8455/8465/8475
Operation and Service Manual
1980239, Revision
K
July 2022
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

ii
Start Seeing the Benefits
of Registering Today!
Thank you for your TSI®instrument purchase. Occasionally, TSI®releases
information on software updates, product enhancements and new products.
By registering your instrument, TSI®will be able to send this important
information to you.
As part of the registration process, you will be asked for your comments on
TSI products and services. TSI’s customer feedback program gives
customers like you a way to tell us how we are doing.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

v
Copyright
TSI Incorporated / 2002-2022 / All rights reserved.
LIMITATION OF WARRANTY AND LIABILITY (effective February 2015)
Seller warrants the goods, excluding software, sold hereunder,under normal use and service
as described inthe operator's manual, to be free from defects in workmanship and material
for 24 months, or if less, the length of time specified in the operator's manual, from the date
of shipment to the customer. This warranty period is inclusive of any statutory warranty. This
limited warranty is subject to the following exclusions and exceptions:
a. Hot-wire or hot-film sensors used with research anemometers, and certain other
components when indicated in specifications, are warranted for 90 days from the date
of shipment;
b. Pumps are warranted for hours of operation as set forth in product or operator’s
manuals;
c. Parts repaired or replaced as a result of repair services are warranted to be free from
defects in workmanship and material, under normal use, for 90 days from the date of
shipment;
d. Seller does not provide any warranty on finished goods manufactured by others or on
any fuses, batteries or other consumable materials. Only the original manufacturer's
warranty applies;
e. This warranty does not cover calibration requirements, and seller warrants only that the
instrument or product is properly calibrated at the time of its manufacture. Instruments
returned for calibration are not covered by this warranty;
f. This warranty is VOID if the instrument is opened by anyone other than a factory
authorized service center with the one exception where requirements set forth in the
manual allow an operator to replace consumables or perform recommended cleaning;
g. This warranty is VOID if the product has been misused, neglected, subjected to
accidental or intentional damage, or is not properly installed, maintained, or cleaned
according to the requirements of the manual. Unless specifically authorized in a
separate writing by Seller, Seller makes no warranty with respect to, and shall have no
liability in connection with, goods which are incorporated into other products or
equipment, or which are modified by any person other than Seller.
The foregoing is IN LIEU OF all other warranties and is subject to the LIMITATIONS stated
herein. NO OTHER EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE OR MERCHANTABILITY IS MADE. WITH RESPECT TO
SELLER’S BREACH OF THE IMPLIED WARRANTY AGAINST INFRINGEMENT, SAID
WARRANTY IS LIMITED TO CLAIMS OF DIRECT INFRINGEMENT AND EXCLUDES
CLAIMS OF CONTRIBUTORY OR INDUCED INFRINGEMENTS. BUYER’S EXCLUSIVE
REMEDY SHALL BE THE RETURN OF THE PURCHASE PRICE DISCOUNTED FOR
REASONABLE WEAR AND TEAR OR AT SELLER’S OPTION REPLACEMENT OF THE
GOODS WITH NON-INFRINGING GOODS.
TOTHE EXTENT PERMITTED BY LAW,THE EXCLUSIVE REMEDY OFTHE USER OR
BUYER, AND THE LIMIT OF SELLER'S LIABILITY FOR ANY AND ALL LOSSES,
INJURIES,OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED
ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE)SHALL BE
THE RETURN OF GOODS TO SELLERAND THE REFUND OFTHE PURCHASE PRICE,
OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE GOODS.
IN THE CASE OF SOFTWARE, SELLER WILLREPAIR OR REPLACE DEFECTIVE
SOFTWARE OR IF UNABLE TO DO SO, WILL REFUND THE PURCHASE PRICE OF
THE SOFTWARE. IN NO EVENT SHALL SELLER BE LIABLE FOR LOST PROFITS,
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

vi
BUSINESS INTERRUPTION, OR ANY SPECIAL, INDIRECT, CONSEQUENTIAL OR
INCIDENTAL DAMAGES. SELLER SHALL NOT BE RESPONSIBLE FOR INSTALLATION,
DISMANTLING OR REINSTALLATION COSTS OR CHARGES. No Action, regardless of
form, may be brought against Seller more than 12 months after a cause of action has
accrued. The goods returned under warranty to Seller's factory shall be at Buyer's risk of
loss, and will be returned, if at all, at Seller's risk of loss.
Buyer and all users are deemed to have accepted this LIMITATION OF WARRANTY AND
LIABILITY, which contains the complete and exclusive limited warranty of Seller. This
LIMITATION OF WARRANTY AND LIABILITY may not be amended, modified or its terms
waived, except by writing signed by an Officerof Seller.
Service Policy
Knowing that inoperative or defective instruments are as detrimental to TSI as they are
to our customers, our service policy is designed to give prompt attention to any
problems. If any malfunction is discovered, please contact your nearest sales office or
Trademarks
TSI and TSI logo are registered trademarks of TSI Incorporated in the United States
and may be protected under other country’s trademark registrations.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

1
Introduction
The TSI®air velocity transducer is a precision instrument designed to
measure air velocity in fixed installations or test applications. TSI
Transducers indicate velocity at standard conditions of 21.1°C (70°F)
and 101.4 kPa (14.7 psia). Each transducer must be setup in the field for the
desired velocity units, full-scale velocity, output signal and time constant.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

2
Parts Identification
Carefully unpack the instrument and accessories. Check the parts against
Figure 1. If any are missing or damaged notify your local distributor or TSI®
immediately.
Figure 1/F
8455/65/75
Transducer
-w
1980239
Manual
1309091
Probe mounting
clips
5000285
#6 Sheet Metal
Screws
5000286
#10 Sheet
Metal Screws
2919020
Compression
Fitting
2404624
Instruction
Labels
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

3
Figure 2: Inside of Electronic Enclosure
1. Setup/Troubleshooting Display
5. Programming Instructions (foldout)
2. Push-Buttons (SET, , )
6. Compression Fitting (Power)
3. Terminal Block
7. Calibration Connector, Factory use
4. Mounting Holes
only
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

4
Mounting the Transducer Electronics Enclosure
The electronics enclosure should be mounted to a secure surface.
W A R N I N G
DO NOT change the length of the transducer probe cable. Changing the
cable length will alter the performance and calibration of the Transducer.
5000285
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

5
Mounting the Transducer Probe
The probe should be securely mounted before use. If mounted in a duct or
pipe the probe should be at least 7.5 duct diameters downstream and 3 duct
diameters upstream of anything that could cause flow turbulence. The
orientation dot on the probe should face upstream.
5000286
2919020
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

6
Wiring the Transducer
Position the wires away from the SET - - push-buttons
Power
Requirements
11-30 VDC or 18-28 VAC 50/60 Hz, 350 mA
Recommended
Wire
18 gauge shielded cable. To avoid electrical
interference, connect shield to ground on transducer
and ground or minus(-) terminal on power supply.
Recommended
Transformer
24 VAC, 20 VA. Each transducer should have a
separate AC transformer to avoid shorting through
the ground circuit.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

7
Wiring for AC-Powered Operation
Wiring for DC-Powered Operation
Output Measuring
Device:
Use a fully differential input device (no ground
connection, plus (+) and minus (-) terminals are
independent), so the signal can float at the
measuring device. If fully differential input is not
available, current (mA) output should be selected.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

8
Setting Up the Transducer
1. Turn the transducer power supply on. The instrument will go through a
preprogrammed power-up sequence. The internal display will
sequence through the current settings: Calibration date “CALdAtE”,
“=“, month and year “03.2013”(March 2013), measurement units
“mEtErS”(m/s) or “FEET”(ft/min), “=“, selected output type and range
“0-5V” and the time constant “tc = 1.00” in seconds. The display will
then show velocity readings.
2. Push the SET button to enter setup mode. When setup mode is entered,
the transducer voltage/current output will drop below zero.
3. Use the and buttons to select the desired setting.
4. Use the SET button to advance to the next setup message.
N O T I C E
The output signal is disabled during the 15 second warm-up period and
when the transducer is in setup mode.
Setup Message
Available Settings
SELECt UnitS
FEEt (ft/min) or mEtErS (m/s)
SELECt FULL
SCALE
Select full scale of the velocity range
SELECt OUtPUt
Select Output Type: 0-5V, 0-10V, 1-5V, 2-10V, 4-20 mA,
0-20 mA
SELECt tc
Select Time Constant: 0.05 to 10 seconds
(see page 12)
AdJUSt ZErO
Adjusts voltage/current output signal at zero velocity
(see page 14)
AdJUSt SPAn
Adjusts the voltage/current output by ±15%
(see page 13)
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

12
More Detail on the Time Constant
In order to make a fluctuating display easier to read, the output time constant
can be set between 0.05 and 10 seconds. The time constant is actually an
averaging period. The output is the average of readings taken over the last
time-constant period. Readings are taken 20 times per time constant period
for a time constant greater than one second and 20 times per second for a
time constants of one second or less.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

13
More Detail on Span Adjustment
A span factor can be entered to adjust the output signal up or down by
fifteen percent. While the span factor is shown on the display, the
transducer will measure velocity and output the appropriate voltage or
current for that velocity. (The time constant will not be active). By changing
the span factor, the transducer’s output signal can be adjusted up or down
by up to fifteen percent.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

14
More Detail on Adjusting Output Signal at Zero Velocity
In certain cases, the remote display will not read the same as the transducer
display output at zero velocity. To correct this discrepancy you will need to
adjust the output signal at zero velocity. Put the transducer into setup mode
and sequence through the setup messages until “AdJUSt ZErO” is shown on
the display. The transducer then displays and outputs the voltage or current
that has been set as the zero value. Adjust the transducer output voltage or
current using the and pushbuttons. Adjust the output signal until the
remote device displays the expected zero. The transducer displays the
voltage or current that corresponds to the factory calibration. The velocity
readings should now be the same on both the setup/troubleshooting display
and the remote display.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

18
Troubleshooting
Symptom
Possible Problem & Solutions
No output or low output
Incorrect input voltage
Sensor positioned incorrectly
Sensor not extended beyond protective shield
Wrong output type/range selected
Loose power or signal connections
Incorrect full scale velocity range selected
Displayed velocity is
hard to read
Internal display is for setup/troubleshooting
only
Accuracy of velocity
reading suspect
Dirty sensor, check for dirt or dust buildup.
Erratic readings
Turbulent flow, check positioning of sensor,
increase time constant to dampen reading.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

20
Cleaning the Sensor
Dust and dirt may build up on the sensor. If necessary, carefully clean the
sensor using a soft bristle brush dipped in a mild solvent like alcohol.
Recalibration
To maintain a high degree of accuracy in your velocity measurements, TSI®
recommends that you have your instrument recalibrated annually.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

21
Specifications
Models 8455, 8465, 8475
8455
8465
8475
Accuracy...........................
±2.0% of reading1
±2.0% of reading1
±3.0% of reading2
±0.5% of full scale
of selected range
±0.5% of selected
full scale range
±1.0% of selected
full scale range
Repeatability ....................
<±1.0% of
reading3
<±1.0% of
reading3
NA
Response Time to Flow...
0.2 sec4
0.2 sec4
5 sec5
Common specifications to all models
Field Selectable Velocity Ranges
Model 8455/8465 ...........0.125 m/s to 1.0, 1.25, 1.50, 2.0, 2.5, 3.0, 4.0, 5.0, 7.5, 10.0,
12.5, 15.0, 20.0, 25.0, 30.0, 40.0, 50.0 m/s (25 ft/min to 200,
250, 300, 400, 500, 750, 1000, 1250, 1500, 2000, 2500,
3000, 4000, 5000, 7500, 10000 ft/min)
Model 8475 ....................0.05 m/s to 0.5, 0.75, 1.00, 1.25, 1.50, 2.0, 2.5 m/s
(10 ft/min to 100, 125, 150, 200, 250, 300, 400, 500 ft/min)
Minimum Resolution ....0.07% of selected full scale
Input Power ...................11-30 VDC or 18-28 VAC, 350 mA max6
Output Impedance ........Voltage mode: less than 1 ohm, 20 mA max source current
Output Resistance........Current mode: 500 ohms maximum load resistance
Output Signal
(field selectable)..........0-5V, 0-10V, 1-5V, 2-10V, 0-20 mA, 4-20 mA
Output Time
Constant (field
selectable)................... 0.05 to 10 seconds.
Probe Length.................7.5 cm, 15 cm, 21.5 cm or 30 cm (3 in, 6 in, 9 in or 12 in)
Temperature..................Compensation Range: 0 to 60°C (32 to 140°F)
Sensor Operation: 0 to 93°C (32 to 200°F)
Electronics Operation: 0 to 93°C (32 to 200°F)
Storage: 0 to 93°C (32 to 200°F)
1from 18 to 28°C (64.4 to 82.4°F), outside this range add 0.2% per °C (0.11% per °F),
within temperature compensation range.
2from 20 to 26°C (68 to 78.8°F), outside this range add 0.5% per °C (0.28% per °F),
within temperature compensation range. Uncertainty increases in downward vertical
flow at velocities less than 0.25 m/s (50 ft/min). Directional sensitivity of the Model
8475 is +5%/-20% of reading +0/-0.05 m/s (+0/-10 ft/min) over 270° solid angle
regardless of flow direction.
3Standard deviation based on one minute average from 0.5 to 5.0 m/s (100 to 1000
ft/min).
4For 63% of final value, tested at 7.5 m/s (1000 ft/min).
5 For 63% of final value, tested at 2.5 m/s (500 ft/min).
6 Input voltage must be maintained within specifications at the transducer.
Calibration occurs with sensor oriented horizontally in a horizontal air flow.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30
