TTL-TECHNICS S-1+ User manual

TTL-TECHNICS V1.3 9APR2019
Page 1 of 9
S-1+ English Manual
Thank you for purchasing the motorcycle DVR S-1+. This manual will go over how to
properly use the dashboard camera and provide you with detailed product
information regarding operation, precautions, and technical data. Please read this
manual carefully.
Disclaimer
The dashcam is provided as is and the recording videos is only for reference, the
final adjudication will be judged by the police officer.
 In order to ensure the integrity of the video, please use a genuine high-speed
Class 10 memory card and format it regularly.
 The terms and conditions are subject to change at any time without prior notice.
 TTL-TECHNICS can’t be held responsible for accidents or malfunction of this
tool.

TTL-TECHNICS V1.3 9APR2019
Page 2 of 9
1. Power Button
2. OK Button
3. Mode Button
4. Menu Button
5. Up Button
6. Down Button
7. Recording Indicator
8. Lens Connector
9. Power Connector
10. Reset Button
11. Battery Cover
12. Build-in Battery
13. TF Card Slot
14. Bracket fixed position
15.MIC
＊5. Up Button: Turn on/off WIFI
＊6. Down Button：Switch camera display (Turn off the WIFI first)

TTL-TECHNICS V1.3 9APR2019
Page 3 of 9
Wired controller
GPS module (this can only be seen in playback mode on your phone)

TTL-TECHNICS V1.3 9APR2019
Page 4 of 9
Product Features
1. Dual Channel: FHD 1920x1080
2. Auto white Balance adjustment
3. Lens angle 140 degree
4. 2.7inch TFT display (16:9)
5. Supports max. 128G micro SD card
6. Lean-angle auto lock function.
7. Wired controller to lock the current file and take photo easily.
8. GPS function to record the speed and route, the data can be viewed when
playback by using APP.
Key Operation
1. Power button: Long press to turn on/off the machine
2. OK button:
In video mode, press to start/stop recording
In photo mode, press to take pictures
In playback mode, press to start/stop playback
In the menu settings, press to confirm selection or enter selected menu
3. Mode button: With recording paused, short press to switch between video, photo,
or playback modes.
4. Menu button: With recording paused, short press to enter the settings menu.
5. Up button: (1) Turn on/off WIFI. 2) Scrolls through menu items.
6. Down button: Scrolls through menu items

TTL-TECHNICS V1.3 9APR2019
Page 5 of 9
Installation
1. Hidden installation of the display and lens.
2. Connect the red cable to ACC Key-on (+), and black to GND.
3. Please use the full set of the cable and machine, the car charger transforms the
voltage from 12V-24V to 5V.
4. Adjust the lens angle when the installation is done.
5. The controller has build-in MIC, don’t cover it when installation.
6. The position of the GPS module must be put on the exterior, can not be covered
by any plastic or metal. The wire of the GPS module must be tied up independent to
avoid any signal interference.
Insert SD card
1. Insert the SD card according the indicated direction
2. To remove the memory card, push the card in and the card should automatically
pop out.
Note:
1. Please format the memory card when using a new card in this device for the first
time.
2. Please use the Class 10 micro SD card. (80MB/S above)
Power on/off and Auto shut-off
1. Long press to turn on/off the machine.
2. The machine can be programmed to shut down automatically to save power; if the
machine is not recording, it will automatically shut off.

TTL-TECHNICS V1.3 9APR2019
Page 6 of 9
Recording mode
1. Recording mode is the default mode for this device. When in recording mode, you
will see the icon in the upper left-hand corner and a flashing icon.
2. In recording mode, short press to start/stop recording.
3. Press menu button to enter the video settings menu, up and down buttons can
scroll through menu items. Under the video settings menu, you can choose the
resolution, segment of recording, audio on/off…etc.
4. Use controller: Press the lock button to save the current recording file; press the
camera button to take a photo.
Note:
The machine will be powered automatically when turn the key on, please don’t
remove the TF card when the machine is recording.
Camera mode
1. Short press to start/stop recording and enter the camera mode by using the mode
button. When in camera mode, you will see the icon in the upper left-hand
corner
2. Press menu button to enter the camera settings menu, up and down buttons can
scroll through menu items. Under the camera settings menu, you can choose the
resolution, color, contrast…etc.
Playback mode
1. Short press to start/stop recording and enter the playback mode by using the
mode button. When in playback mode, you will see the icon in the upper left-
hand corner
2. Press menu button to enter the playback settings menu, up and down buttons can
scroll through menu items. Under the playback settings menu, you can delete or save
the recordings.

TTL-TECHNICS V1.3 9APR2019
Page 7 of 9
General Settings
Press menu button to enter the settings menu, press twice the menu button to enter
the general settings menu.
 Date/Time: Use the Up and Down buttons to set the correct values and press
Ok to confirm.
 Auto shut-off: The machine can be programmed to shut down automatically to
save power.
 Languages: Multiple languages supported.
 Key tone: Turn on/off the key tone.
 Format: Format the micro SD card.
 Screen saver: Once the machine has started recording, the screen can be set to
turn off
 Version: To view the current software version for the machine.

TTL-TECHNICS V1.3 9APR2019
Page 8 of 9
WIFI APP
1. Scan the QR code to download the app
2. Switch on the motorcycle DVR and WIFI function (the WIFI default setting is on)
3. The WIFI name & password will show on the display. Password: 12345678
4. After the device is linked, you may now use the APP
5. Only when connecting the GPS, you will find the route & speed when playback.
PS. When the device is on, short press you can turn off the wifi function, and
press the to turn on the wifi function.

TTL-TECHNICS V1.3 9APR2019
Page 9 of 9
Product Specification
Sensor Dual channel 1920x1080 SONY IMX323
Lens F=3.65mm F/NO 1.9
Display 2.7” LCD TFT 16:9
Resolution Dual channel FHD1080P 30fps
Audio Build-in MIC/Speaker
Memory card Max. 128G micro SDHC (class 10)
White balance Auto
Power supply Multi-pin connector
Input: 12V-24V 2A
Output: 5V 2A
Battery 3.7V 500m/A Lithium battery
Size 74 x 55 x 20 mm
Working humidity 10%-80%
Working Temperature -10 oC ~ +65oC
Problem Shooting
 Can’t record: Check the SD card if there is enough space.
 Stop recording while riding: (1) Check the SD card if is Class 10 and with
80MB/S above. The SD card writing & reading speed is required to this device.
(2) Check the loop recording is on or not.
 “Wrong file” or “damaged file” showed: Check the SD card and format it (please
use the device to format the SD card not by PC). If the SD card has problem the
file can’t be saved properly.
 Fuzzy image: Check the camera lens and clean it.
 The image is shaking: (1) Check the lens bracket is fixed tightly. (2) Check the
installation of the device, if it’s too closed to the coil and spark plug, it will have
signal interference.
 Buttons no work: Turn off the WIFI first, if the WIFI function is on, the buttons
can’t work.
