Tuff stuff Apollo 7000 Series User manual

LEG PRESS STATION
OWNER’S MANUAL
AMERICA’S PREMIER EXERCISE EQUIPMENT
AP-71LP Rev0
Revision Date 8-14-09

About the LEG PRESS STATION. Congratulations on your
new purchase of the LEG PRESS STATION. We hope you are
completely satised with this product and wish you many years of
enjoyment.
Tuff Stuff Equipment
This Tuffstuff product has been built to precise quality standards
and has been carefully packaged to ensure that damage will not
occur during shipment. The Home Lifetime Warranty and signature
indicating nal inspection has been conducted by our line foreman,
is an expression of our condence in the completeness, the
materials, and workmanship of this product.
Warranty
SEE A COPY OF WARRANTY ON BACK PAGE.
Registration Card
To avoid unnecessary delays in warranty service and to insure that
a permanent record of your purchase is on le with our factory,
be sure to complete the warranty registration card and send it to
TuffStuff Fitness Equipment today.
Safety First
Regardless of how enthusiastic you may be about getting on
your equipment and exercising, take the time to ensure that your
safety is not jeopardized. A moment’s lack of attention can result
in an accident, as can failure to observe certain simple safety
precautions.
1. Read, study and understand the Assembly Instructions and all the
warning labels on this product. Furthermore, it is recommended
to familiarize yourself and others with the proper operation and
workout recommendations for this Tuff Stuff product prior to
use.
2. It is imperative that you retain this Assembly Instructions and
be sure all warning labels are legible and intact. Replacement
Assembly Instructions and labels are available from your local
Tuff Stuff retailer.
3. Consult with your physician before beginning any exercise
program.
4. Frayed or worn cables can be dangerous and may cause injury.
Periodically check the cable for any indication of wear.
5. Use proper discretion when children are present.
6. Keep hands, limbs, loose clothing and long hair well out of the
way of moving parts.
7. Do not attempt to lift more weight than you can control safely.
8. Inspect the Unit for any sign of wear on parts, hardware becoming
loose or cracks on welds. If a problem is found do not use or
allow the machine to be used until the defective part is repaired
or replaced.
Safety Precautions
Note: Due to continuing product improvements, specications and designs are subject to change
without notice.
Specications
1. Maximum Wt. Capacity - 200 lbs.
2. Total Machine Weight - 490 lbs.
3. Footprint (LWH) - Height is 77”. For footprints refer to
the Center Post/Rear Post Assembly
Manuals.
Introduction
2AP-7000 SERIES LEG PRESS STATION
Prior to the Assembly of the LEG PRESS STATION
1. We advise you to consult your local Tuff Stuff retailer if you should
have a question or problem regarding the proper assembly of
this unit.
Tool Requirements
1. One 7/8” combination wrench
2. Two 3/4” combination wrench
3. One 9/16” combination wrench
4. One 1/2” combination wrench
5. One 7/16” combination wrench
6. One adjustable wrench
7. One ratchet
8. One 3/4” socket
9. One 9/16” socket
10. One rubber mallet
11. Windex or household glass cleaner
12. Measuring tape
13. Utility knife
14. The hex key alloy set included in the Center Post/Rear Post
box.
Hardware Measurement Diagram

INDEX
IMPORTANT ASSEMBLY INSTRUCTION NOTE..................4
FIRST STEPS FOR A SINGLE STATION...................................5
MULTIPLE STATION ASSEMBLY STEPS.................................7
LEG PRESS CABLE......................................................................14
EXPLODED VIEW.......................................................................19
PARTS LIST...................................................................................20
MAINTENANCE.........................................................................21
AP-7000 SERIES LEG PRESS STATION 3
