Tuff stuff Rdm-400 User manual

RDM-400

L 57” W 27” H 50”

OWNER’S MANUAL

DO NOT DISCARD THIS MANUAL

HOME LIFETIME WARRANTY

TuffStuff products are warranted to the retail purchaser to be free from defects in materials and workmanship.

TuffStuff exclusive Home Lifetime Warranty coverage extends for the life of the product while owned by the

original retail purchaser, and used only in a home or residential setting unless otherwise noted in the owner’s

manual.

This warranty does not cover:

1. TuffStuff products sold for and used in a commercial or institutional setting.

2. Any damage, failure or loss caused by accident, misuse, neglect, abuse, improper assembly, improper

maintenance, or failure to follow instructions or warnings in the owner’s manual and warning labels

posted on the machine.

3. Use of products in a manner for which they were not designed.

4. Original product that is altered, or the use of replacement parts and components of another manufac-

turer other than TuffStuff.

Limitations:

The foregoing shall constitute the sole remedy of the purchaser and the sole liability of TuffStuff with regard to

warranty, whether express or implied by operation of law or otherwise, including but not limited to any implied

warranties of merchantability or fitness. TuffStuff shall in no event be liable for incidental or consequential

losses, damages or expenses in connection with exercise products. TuffStuff’s liability hereunder is expressly

limited to the repairs or replacements of warranted defective parts.

Procedures:

Warranty service will be performed at TuffStuff’s facility in Pomona, California. TuffStuff will have the option of

either repair or replacement at no charge for any defective product. Purchaser is responsible for installation of

repaired or replaced parts and all transportation and insurance costs on returned or replaced equipment to and

from TuffStuff’s facility in Pomona.

This warranty gives you specific legal rights and you may also have other rights, which may vary from state to

state. Effective July 1, 2004.

This warranty is the final, complete and exclusive agreement of the parties with respect to the quality or performance of the equipment

and no action for breach of this written warranty or any implied warranty shall be commenced more than one (1) year after the accrual

of the cause of action. No modification of this warranty or waiver of its terms shall be binding on either party unless approved in

writing by an authorized representative of the party. Contact TuffStuff at 1325 E. Franklin Avenue, Pomona, California 91766, before

returning any defective equipment.

Note: Retain your sales receipt and be sure to mail in the warranty registration card to insure that a

permanent record of your purchase is on file with the factory and to avoid unnecessary delays in

warranty service.

TuffStuff Fitness Equipment, Inc.

1325 E. Franklin Avenue

Pomona, CA 91766, USA

Ph: 909-629-1600 Fax: 909-629-4967

E-mail: [email protected] Net: www.tuffstuff.net

RDM-400 Rev0

Revision Date 9-15-06

AMERICA’S PREMIER EXERCISE EQUIPMENT

RDM-400

DELUXE MULTI-PURPOSE BENCH

Part Three: Lubrication

Bearing and linear bearings systems have advanced over the years but they must be maintained on a regu-

lar basis if you expect them to last and perform efﬁciently. TuffStuff uses only the highest quality bearings

and linear motion components that are virtually trouble-free but requires the regular preventive maintenance

to insure long-lasting performance.

1. Bronze and nylon bushings, we recommend on a weekly basis to spray a teﬂon-base lubricant

(silicone-free) directly onto the shaft as it passes through these bushings. Spray a small amount

onto the shaft and rotate it through its complete movement and wipe off any excess.

2. Weight stack guide rods and bushings, again use teﬂon spray lubricant and this time spray onto

a rag and wipe the guide rods down with this rag on a weekly basis. Do not use WD-40 or other

lubricants as they attract dirt and will crate a mess between the weight plates and bushings.

3. Sealed bearings pivot points, as the name implies are protected from the outside environment

and require no lubrication. During the machine wipe down, wipe the external bearing surfaces

with the damp rag and dried to prevent the build up of dust and sweat.

4. Linear bearing systems are precision, high load components that require regular maintenance.

Dirt and corrosion are the major culprits in linear bearing failure. The hardened shafts must be

wiped down weekly and lubricated with a light layer of teﬂon grease. We recommend a teﬂon-

base (silicone-free) gel/grease for this purpose. Lack of care and maintenance will result in cor-

rosion of the linear shaft causing the bearings to clogged and jammed.

If you religiously perform the daily and weekly maintenance procedures, you will increase the life of the ma-

chine and ultimately lower your maintenance costs with fewer replaced components and downtime.

Any doubts, equipment with mechanical problems should be placed “Out-of-Service” until all problems are

corrected. If replacement parts are required or maintenance questions, please contact:

TUFFSTUFF FITNESS EQUIPMENT INC.

Service Department

1325 E. Franklin Avenue

Pomona, CA 91766

1-800-961-9377

e-mail: service@tuffstuff.net

Maintenance

About the Delux Multi-Purpose Bench RDM-400

Congratulations on your new purchase of the Delux Multi-Purpose

Bench. We hope you are completely satisﬁed with this product and

wish you many years of enjoyment.

Tuff Stuff Equipment

This Tuffstuff product has been built to precise quality standards

and has been carefully packaged to ensure that damage will

not occur during shipment. The Limited Warranty and signature

indicating ﬁnal inspection has been conducted by our line foreman,

is an expression of our conﬁdence in the completeness, the

materials, and workmanship of this product.

Warranty

SEE ACOPY OF WARRANTY ON BACK PAGE.

Registration Card

To avoid unnecessary delays in warranty service and to insure that

a permanent record of your purchase is on ﬁle with our factory,

be sure to complete the warranty registration card and send it to

TuffStuff Fitness Equipment today.

Note: Due to continuing product improvements, speciﬁcations and designs are subject to change

without notice.

Speciﬁcations

1. Maximum Wt. Capacity - 350 lbs.

2. Total Machine Weight - 78 lbs.

3. Footprint (LWH) - See Front Cover.

RDM-400 Delux Multi-Purpose Bench 6

RDM-400 Delux Multi-Purpose Bench

Introduction

Prior to the Assembly of the Delux Multi-Purpose Bench

1. We advise you to consult your local Tuff Stuff retailer if you

should have a question or problem regarding the proper

assembly of this unit.

Tool Requirements

1.One 3/4” combination wrench

2.One 9/16” combination wrench

3.One ratchet

4.One 3/4” socket

5.One 9/16” socket

6.One rubber mallet

7.Windex or household glass cleaner

8.Measuring tape

9.Utility knife

SCREWW

IDTH

WASHERDIAMETER

NUTDIAMETE

SCREWLENGT

Hardware Measurement Diagram

TuffStuff Basic Strength Equipment Safety and General Maintenance

All TUFFSTUFF strength equipment is designed and manufactured to offer maximum, long-life service

with minimal maintenance. However, safety inspection and routine maintenance in your facility should be

the upmost importance in your daily operation. Information presented in these pages will serve as a basic

guideline to design your own inspection procedures.

Part One: General Inspection and Cleaning

Equipment should be wiped down with a damp cloth and dried on a daily basis. The powder coat ﬁnish

should be polished with a good car wax on a weekly basis. Adaily wipe down of the upholstery with a lano-

lin based hand cleaner or Naugahyde Cleaner. Do not use cleaners such as Lysol or Windex as they will

dry out and crack the vinyl. Lanolin hand cleaner dissolves the sweat and lubricates the vinyl, maintaining

its natural ﬂexibility. Sweat is corrosive and when left on the frame and components will eventually cause

corrosion or rust. When performing these cleaning sessions, it is the perfect time to inspect the equipment

and note any problems for the maintenance personnel to correct.

1. Check equipment if it is operating properly.

2. Check the cable for loose ﬁttings or frayed cable and is seating properly on the pulleys and

cams.

3. Make sure that the proper weight stack selector pin is with each machine and that the pin func-

tions properly.

4. If something appears loose be sure to have it tightened immediately.

5. If a piece of equipment appears damaged or not operation properly, place the piece out-of-ser-

vice immediately.

Part Two: Maintenance

In this paragraph, we will discuss the inspection of the cables, pulleys and their associated components. If

there exists the potential for injury to occur on a machine, it will most likely lie in the cable system. It is im-

portant to inspect the cables frequently and let it be known to all users that it is their responsibility to report

any worn-out cable to prevent a sudden failure that can result in an injury. Cables are moving parts, mean-

ing cable-wear will occur regardless of the type or size used. In the advent of the 3/16” mill-spec cable this

wear takes longer to become apparent and this is why frequent inspections are so important.

1. Check the cable termination at the weight stack. To perform any cable tension adjustment,

loosen the hex jam nut and thread the hex tap bolt in or out to give cable the proper tension.

Re-tightened the hex jam nut when adjustment is complete and make sure the hex tap bolt is

threaded 1/2” into the socket of the selector bar top plate.

2. Check the cable as it terminates at the cam. Check the end ﬁtting for any signs of fraying in this

area. Inspect the bolt and nut and/or screw holding the ﬁtting and be sure that it is tight.

3. Check the cables as it passes over all pulley wheels. Visually inspect the cables and pulleys. A

cable that is wearing will exhibit a ballooned surface that passes over the pulley. This is and early

warning sign to replace the cable.

Maintenance

5RDM-400 Delux Multi-Purpose Bench 2

Safety First

Regardless of how enthusiastic you may be about getting on

your equipment and exercising, take the time to ensure that your

safety is not jeopardized. A moment’s lack of attention can result

in an accident, as can failure to observe certain simple safety

precautions.

1. Read, study and understand the Owner’s Manual and all the

warning labels on this product. Furthermore, it is recommended

to familiarize yourself and others with the proper operation and

workout recommendations for this TuffStuff product prior to use.

2. It is imperative that you retain this Owner’s Manual and be sure

all warning labels are legible and intact. Replacement Owner’s

Manual and labels are available from your local TuffStuff

retailer.

3. Consult with your physician before beginning any exercise

program.

4. Use proper discretion when children are present.

5. Keep hands, limbs, loose clothing and long hair well out of the

way of moving parts.

6. Do not attempt to lift more weight than you can control safely.

7. Inspect the Unit for any sign of wear on parts, hardware

becoming loose or cracks on welds. If a problem is found do

not use or allow the machine to be used until the defective

part is repaired or replaced.

Safety Precautions

NOTES

RDM-400 Delux Multi-Purpose Bench

13 30 3

112

32 14 19

14 22 14 20 22 14 11

14 18

13 30 3

112

32 14 19

14 22 14 20 22 14 11

14 18

3RDM-400 DELUXE MULTI-PURPOSE BENCH

RDM-400 Rev0

Item No. Description Rev. Part No. Qty. Item No. Description Part No. Qty.

1BACK PAD 0 UP3862 1 20 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 5 1/4 BNH0690 2

2BACK PAD BRACKET 0 UP3677 1 21 NYLON INSERT LOCK NUT B/O 3/8-16 BNH0214 2

3CHROME WASHER 3/8 X 1 1/8 0 UP3863 2 22 NYLON INSERT THIN PATTERN LOCK NUT B/O 3/8-16 BNH0365 6

4FRONT STABILIZER 0 UP3845 1 23 NYLON SPACER 3/8 X 3/4 X 3/8 BNH0392 2

5MAIN FRAME 0 UP3676 1 24 PLASTIC HORIZONTAL ELLIPTICAL SHOE BNH1847 4

6PIVOT AXLE (3/4 RD X 6 1/2) 0 UP3844 1 25 PULL PIN 1/2 X 5 5/8 LIGHT SPRING (YELLOW KNOB) BNH0701 2

7REAR STABILIZER 0 UP3846 1 26 RUBBER BUMPER 3/8 X 2 1/2 BNH0511 1

8SEAT PAD 0 UP3861 1 27 RUBBER GRIP 1 ID X .125 X 4 1/2 BNH1062 1

9SEAT PAD BRACKET 0 UP3678 1 28 SOCKET SET SCREW ALLOY 10-32 X 1/8 BNH0473 2

10 BNH0537 1 29 SOCKET SET SCREW ALLOY 1/4-20 X 1/4 BNH0790 2

11 BNH0300 2 30 SPLIT LOCK WASHER B/O 3/8" BNH0658 2

12 BNH0243 8 31 STEEL BUMPER WASHER Z/P 3/8" BNH0498 1

13 BNH0115 2 32 URETHANE BUMPER 1 3/4 BNH0229 1

14 BNH0239 16 33 WHITE NYLON STEM BUTTON BNH1882 4

15 BNH1895 1 34 DECAL-CAUTION WEIGHT TRAINING SAFETY… BNH0126 1

16 BNH0273 6 35 DECAL-DANGER TIGHTEN THIS RETAINING... BNH0142 2

17 BNH0274 1 36 DECAL-IMPORTANT FOR BEST PERFORMANCE... BNH1894 1

18 BNH0276 2 37 TUFFSTUFF LOGO ALUMINUM SMALL BNH1323 1

19 BNH0277 2 38 FLAT PHILLIPS SCREW ZINC # 5 X 1/2 BNH1481 2

FLAT WASHER SAE B/O 3/8"

HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/4

DECAL-WARNING ATTENTION USERS! MOVING PARTS..

HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/2

RDM-400

Parts List

HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4

HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4

BLACK WHEEL 3/8 X 3 X 1 1/4 W/BEARING

BRONZE BUSHING W/FLANGE 3/4"

BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1

ALUMINUM CAP 1.020" RD (CAP-100)

COLOR CHART

GRAY= SUB-ASSEMBLY PARTS

BLACK= HARDWARE

RDM-400 DELUXE MULTI-PURPOSE BENCH 4

23 16
