TUFLOC Vertical Mount User manual

INSTALLATION INSTRUCTIONS
Vertical Mount Gun Rack
Congratulations and thank you for your recent purchase of the TUFLOC gun rack system. Esmet has designed
and manufactured the highest quality products for over sixty-five years and we are confident that you will
be a satisfied Tufloc product owner.
This manual includes simple step by step instructions to install, operate and maintain your gun rack. Please
contact the factory if you have any installation or operation questions.
9/20
1406 Fifth Street, SW • Canton, Ohio 44702 • USA1-800-321-0870 • 330-452-9132 • Fax [phone]
[email protected] • Tufloc.com

Adjust Rack to Fit Gun
1. Gun Racks are shipped with the components already attached. However, it may be necessary to move
these components to fit a specific make/model of gun. All gun rack components are necessary to properly
secure the gun. Do not remove components.
2. If your gun rack uses a Large Lock head. It can be adjusted to fit different guns. Simply raise or lower the
adjustment plate inside the lock by loosening or tightening the screw.
3. To reposition the Gun Lock, open the lock and use a 3/16” Allen-Head wrench to loosen the screws (do not
fully remove the screws). Slide the Gun Lock along the Channel to a position where it will securely hold the
gun. The proper position of the Gun Lock will keep the gun from being lifted out of the Butt Pocket. The
Trigger Guard and Butt Pocket can also be adjusted by loosening the fasteners. The proper position of the
Trigger Guard will protect the trigger and will keep ammunition from being chambered.
4. Once all adjustments are made, verify that the gun fits securely by locking it in the Gun Rack.
Examples: Mounting Configurations
1406 Fifth Street, SW • Canton, Ohio 44702 • USA1-800-321-0870 • 330-452-9132 • Fax [phone]
[email protected] • Tufloc.com
Hardware Kit

Mount to Partition
1. Before placing the Gun Rack into vehicle, assemble the brackets onto the Channel of the Gun Rack as shown
in Bracket Assembly Diagram. (See Bracket Assemblies diagram below.)
2. Two U-Brackets will be used to secure the Gun Rack to the Partition. When positioning the U-Brackets
along the Channel, try to create the largest possible spacing between the two Brackets.
3. Place the U-Bracket over the Channel. Using two washers, two 5/8” bolts and one nut plate, attach the U-
Bracket to the gun rack and tighten completely. Place the spacer inside the U-Bracket and attach the two
L-Brackets with legs facing outward using a washer, 2-1/2” bolt and nut. Do not fully tighten. Repeat for
the other mounting Bracket Assembly.
Electrical
• Attach and insulate the wires following the enclosed wiring diagram. Ensure that the wires are not pinched
as they are routed towards the most convenient power and grounding source.
1406 Fifth Street, SW • Canton, Ohio 44702 • USA1-800-321-0870 • 330-452-9132 • Fax [phone]
[email protected] • Tufloc.com
4. Place the Gun Rack with gun into the vehicle and
determine the best location on the partition for the
Bracket Assemblies.
5. Mark the four locations where the pre-welded nuts
on the L-Brackets will attach to the partition.
6. Remove the Gun Rack from the vehicle. Making
sure the four marks from Step 5 are aligned
vertically and horizontally, center punch the marks.
7. Using a 5/16” drill bit, drill through the partition.
Use the 5/8” Bolts and Washers to secure the L-
Bracket assemblies to the partition. (See Mounting
Bracket diagram above.)
8. Place the gun into the Gun Rack and adjust the Gun
Rack to its desired distance from the partition.
Tighten the two 2-1/4” bolts on the upper and
lower mounting Bracket Assemblies.
