Tunturi 17TBE80000 User manual

www�tunturi�com
- Please read this assembly manual carefully prior to assembling this product.
- Lesen Sie sich vor der Montage des Produkts diese Montageanleitung sorgfältig durch.
- Veuillez lire attentivement le présent manuel d’assemblage avant de monter ce produit.
- Lees deze montagehandleiding zorgvuldig voordat u dit product in elkaar gaat zetten.
- Leggere attentamente questo manuale di montaggio prima di montare il prodotto.
- Antes de montar este producto, lea atentamente este manual de montaje.
- Läs den här monteringshandboken noggrant före användning av den här produkten.
- Lue tämä asennusohje huolellisesti ennen tämän tuotteen asennusta.
Attention, Achtung, Attention, Attentie, Attenzione, Atención, Giv akt, Huomio
GB Assembly manual
DE Montageanleitung
FR Manuel d’assemblage
NL Montagehandleiding
IT Manuale di montaggio
ES Manual de montaje
SV Monteringshandbok
SU Asennusohje
E80 Bike Endurance
SU Asennusohje
EN957
Class HA
Made in China
RoHS
2011/65/EU
i
SN:
MAX USER WEIGHT: 135 KGS
300 LBS
HOME & OFFICE USE
INPUT: 26 V-DC / 2.3 Amp.
SKU: 17TBE80000
Upright bike E80
ROUTES
Tunturi Routes
iOS & Android
GET YOUR
USER MANUAL
ONLINE
http://manuals.tunturi.com
WWW
IMPORTANT
15 - 19
20 - 24
25 - 29
30 - 34
35 - 39
40 - 44
45 - 49
50 - 51

3
E80 Bike
A

NO.92 flat Washer φ8*φ19*2t (4) NO.94 knob M8 (1)
Screwdriver (1)
NO.91 SCREW M8*P1.25*60MM (4)
NO.96 Screws M5x14mm (2)
NO.93 Bushing φ8.2*φ14.8*25L(1)
NO.95 Carriage Bolt M8*P1.25*75MM (1)
Allen Key(1)
Allen Key(1)
Box Spanner(1)
E50B/E60B/E80B
i
4
E80 Bike
B

100 cm
100 cm
100 cm
100 cm
NO.92 flat Washer φ8*φ19*2t (4) NO.94 knob M8 (1)
Screwdriver (1)
NO.91 SCREW M8*P1.25*60MM (4)
NO.96 Screws M5x14mm (2)
NO.93 Bushing φ8.2 *φ14.8*25L(1)
NO.95 Carriage Bolt M8*P1.25*75MM (1)
Allen Key(1)
Allen Key(1)
Box Spanner(1)
5
E80 Bike
C
D

NO.95 Carriage Bolt M8*P1.25*75MM (1)
NO.91 SCREW M8*P1.25*60MM (4)
NO.92 flat Washer φ8*φ19*2t (4)
NO.94 knob M8 (1)
NO.96 Screws M5x14mm (2)
NO.93 Bushing φ8.2 *φ14.8*25L(1)
Box Spanner(1)
Allen Key(1)
Allen Key(1)
Screwdriver (1)
6
E80 Bike
D-1

NO.95 Carriage Bolt M8*P1.25*75MM (1)
NO.91 SCREW M8*P1.25*60MM (4)
NO.92 flat Washer φ8*φ19*2t (4)
NO.94 knob M8 (1)
NO.96 Screws M5x14mm (2)
NO.93 Bushing φ8.2 *φ14.8*25L(1)
Box Spanner(1)
Allen Key(1)
Allen Key(1)
Screwdriver (1)
7
E80 Bike
D-2

LLeft hand crank
Make sure to use Left hand pedal
L
RRight hand crank
Make sure to use Right hand pedal
R
NO.95 Carriage Bolt M8*P1.25*75MM (1)
NO.94 knob M8 (1)
NO.96 Screws M5x14mm (2)
NO.93 Bushing φ8.2 *φ14.8*25L(1)
Box Spanner(1)
Allen Key(1)
Allen Key(1)
Screwdriver (1)
8
E80 Bike
D-3

77
NO.95 Carriage Bolt M8*P1.25*75MM (1)
NO.94 knob M8 (1)
NO.96 Screws M5x14mm (2)
NO.93 Bushing φ8.2 *φ14.8*25L(1)
Box Spanner(1)
Allen Key(1)
Allen Key(1)
Screwdriver (1)
9
E80 Bike
D-4

A-2A-1
A-2
A-1
A-2
A-1
A-1 A-2
NO.95 Carriage Bolt M8*P1.25*75MM (1)
NO.94 knob M8 (1)
NO.96 Screws M5x14mm (2)
NO.93 Bushing φ8.2 *φ14.8*25L(1)
Box Spanner(1)
Allen Key(1)
Allen Key(1)
Screwdriver (1)
10
E80 Bike
D-5
