Tunturi C 900 User manual

GB OWNER'S MANUAL P. 2-7
DBETRIEBSANLEITUNG S. 8-13
FMODE D'EMPLOI P. 14-19
NL HANDLEIDING P. 20-25
IMANUALE D'USO P. 26-31
EMANUAL DEL USUARIO P. 32-37
SBRUKSANVISNING S. 38-43
FIN KÄYTTÖOHJE S. 44-49
PULSE CONTROLLED
TRISTEPPER C 900
5837007C
SERIAL NUMBER
SERIENNUMMER
NUMERO DE SERIE
SERIENUMMER
NUMERO DI SERIE
NUMERO DE SERIE
SERIENNUMMER
SARJANUMERO

2
GB
REMARKS AND WARNINGS
PLEASEREADTHISOWNER’SMANUALTHROUGHCAREFULLYBEFOREASSEMBLING,USING
ANDSERVICINGTHEDEVICE!FOLLOWTHEINSTRUCTIONSDESCRIBEDINTHISMANUAL
CAREFULLY.
THEEQUIPMENT HASBEENDESIGNEDFORHOMEUSE.THETUNTURIWARRANTY APPLIES
ONLYFORFAULTS AND MALFUNCTIONSINHOME USE.
Before connecting the device to a power source make sure the voltage is correct. The voltage is marked on
the step-down transformer (either 230 V or 115 V). Do not connect the device directly to the mains supply.
NOTE ABOUT THE EQUIPMENT
* The device must always be unplugged during any assembly or service work.
* Check the transformer for the correct voltage.
* Always unplug the device from the power source after you have finished your workout.
* Although the device operates with a 12 V protective voltage all service and repair work are recommended to be
carried out by a person qualified to service electromechanical appliances according to the legislation of your
country.
* The magnet caliper of the magnetic brake forms an extremely powerful magnetic field which may damage the
mechanism of a watch or the magnetic identification tape of a credit or cash card if they come into immediate
contact with the magnets. Never attempt to detach or remove the magnet caliper of the magnetic brake.
NOTE ABOUT YOUR HEALTH
* Before you start any training, consult a physician to check your state of health.
* If you experience nausea, dizziness or other abnormal symptoms while exercising, stop your workout at once
and consult a physician.
* Warm up slowly by stepping at a slow pace. Increase gradually until you reach the desired workout pace.
Before completing a workout session, slow your pace gradually to a slow step, allowing your heart rate to
decrease to normal before stopping and stepping off the device. To avoid muscular pain, begin and end each
workout by stretching and warming up and cooling down.
* The TARGET PULSE -programme is based on pulse measurement, i.e. the device regulates the resistance
according to the measured pulse. Since an erratic measurement can cause a risk to the user it is most
important to follow the instructions and warnings described in this manual about pulse measurement. Follow
your pulse also during the training. If you notice interference in the measurement, stop your workout at once.
NOTE ABOUT THE EXERCISING ENVIRONMENT
* Place the device on a firm, level surface.
* Make sure that the exercising environment has adequate ventilation. To avoid catching cold, do not exercise in
a draughty place.
NOTE ABOUT USING THE EQUIPMENT
* Parents or others responsible for children should note that children’s natural playfulness and curiosity may lead
to situations and behaviour for which the device is not designed. If children are allowed to use the device, they
should be supervised and taught to use the device properly, keeping in mind the child’s physical and mental
development and their personality.
* Before you start using the device, make sure that it functions correctly in every way. Do not use a faulty device.
* As the stepper is not covered from below, make sure that there are no small metal objects such as screws,
coins etc. near or under the stepper. The magnetic brake mechanism might draw small metal objects into the
mechanism, thus causing possible danger.
* In heavy or long-term use, the device may shed dust or oil. It is therefore advised to place the device on a
protective base.
* Only one person may use the device at a time.
* Place the device on a firm, level surface.
* Hold the handlebar for support when getting on or off the device. Keep at least one hand on the handlebar
when exercising.
* Always keep your hands well away from moving parts.
* Wear appropriate clothing and shoes when exercising.
* Never operate the device with sidecovers removed.
* Do not attempt any servicing or adjustment other than those described in this manual.
* The device is not recommended for persons weighing over 110 kg.
THE FIGURES REFERRED TO IN THE TEXT ARE IN THE BACK FOLD.

3
GB
1.5. ATTACH THE METER
Feed the wires from the meter through the meter mount and
pushthemeterintoplaceonthemetermount(fig.6).Connect
the wires and snap the meter mount over the handlebars,
making sure the tongue on the handlebar mount fits into the
corresponding groove on the meter mount (fig 7). N.B. Be
careful not to damage the wire.
To secure the meter, remove carefully the meter and the
protective paper from the two-sided adhesive tape on the
meter mount. Push the meter back into place. N.B. Be
careful not to damage the wire.
1.6. PLUG IN THE TRANSFORMER
Plugthetransformer intotheconnectorinthelowerlefthand
corner of the side of the pulley cover and then to the wall
socket(fig.8).N.B.Makesurethewiredoesnotrununder
thedevice.
2. USE
Working out using a stepper is excellent aerobic exercise,
theprinciplebeingthattheexerciseshouldbesuitablylight,
butoflongduration.Aerobicexerciseisbasedonimproving
thebody’smaximumoxygenuptake,whichinturnimproves
enduranceandfitness. Theabilityofthebodytoburnfatas
a fuel is directly dependent on its oxygen-uptake capacity.
Aerobicexerciseshouldaboveallbepleasant.Youshould
perspire, but you should not get out of breath during the
workout. You must, for example, be able to speak and not
justpantwhilepedalling.
You should exercise at least three times a week, 30
minutesatatime,toreachabasicfitnesslevel.Maintaining
thislevelrequiresafewexercisesessionseachweek.Once
thebasicconditionhas beenreached,itiseasily improved,
simply by increasing the number of exercise sessions.
Exercise efficiency can be measured by monitoring the
pulse.
Exerciseisalwaysrewardingforweightloss,becauseitisthe
onlywayofincreasingtheenergyspentbythebody.Thisis
whyitisalwaysworthwhiletocombineregularexercisewith
ahealthydiet.
ThefeetoftheTriStepper900moveindependentlyofeach
other. This means that as the resistance is decreased,
thetempo willneed tobe increasedand thestep length
shortened, in order to exercise and avoid the pedals
descending too far with the users weight. With fast
tempo and small steps the work out is more efficient: the
pulse is faster and energy consumption increases. The
higher the colums of dots on the display, the more efficient
the work out is.
N.B. Keepyourheadup and neck straight in order to avoid
strain on your neck, shoulders and back. Keep also your
back straight. Make sure that your feet are centered onthe
foot pedals and that your hips, knees, ankles and toes are
facing forward. Keep your body weight centered over your
lowerbodyregardlesstowhetheryouleanforwardorstand
upright.
1.ASSEMBLY
Beforeassemblingthedevice,insureallpartsarepresent(fig.
1):
AMain mast assembly
BSupportlegs(2)
CTie rods (2)
DFeet (2)
EHandlebarsupporttube
FMeter mount
GMeter
HTransmitter belt
ITransformer (12 V)
JHardwarekit
Ifyounoticethatapartismissing,contactthedealerandgive
the model (TriStepper 900), serial number and spare part
number from the spare part list in the back of the manual.
The package includes a silicate bag for absorbing moisture
duringstorageandtransportation.
Once the device and all its parts have been unpacked,
assemble as follows (left, right, front and rear are seen from
theexercisingposition):
1.1. ATTACH THE SUPPORT LEGS
Position the main mast assembly on the floor so that the
TriStepper label is facing up. Screw the left leg tube into the
mainmastasshown(fig.2),beingcarefultokeepthelegtube
inline.N.B.Donotforce.Ifresistanceisfeltinitially,unscrew
andstartagain.Handtightenthelegfirmly.Installtherightleg
in the same manner.
1.2. ATTACH THE TIE RODS
Place the hooked end of a tie rod into the left hole at the
bottom of the main mast (fig. 3). Gently slide the tie rod
bracket into the end of the left tube while simultaneously
inserting the threaded end of the tie rod into the tie rod
bracket.Slidethebracketwiththerodintothetubeasfaras
possible, making sure the bracket is at the correct angle to
thetierod.
Securethetierodwithaflatwasherandlockingnut.Tighten
thenut with theflatwrenchsupplied. Repeat for therighttie
rod.
1.3. ATTACH THE FEET
Thefeetarelabeled"L"and"R"(forleftandright).Slideeach
footontoitsrespectiveleg,makingsurethetierodfitsintothe
bottom of the slot (fig. 4). Tilt the TriStepper back into the
uprightposition.
1.4.ATTACHTHE HANDLEBAR
Aligntheholesonthebaseofthehandlebartothoseonthetop
ofthemast,makingsurethehandlebarendcapsarepointing
forward. Secure the handlebars with four Allen screws and
splitlockwashers.Tightenscrewswiththehexwrench(fig.5).

GB
4
connectedtothepowersource.Thedisplaygivesoutashort
beepafter which all the functions are atzero.
Ifyoudonotusethedeviceformorethan5minutes,themeter
automaticallyswitchesoff.
3.2.1. MANUAL FUNCTION
1. Select the manual function by pressing the
MANUAL key after the meter has been switched
on or after pressing the RESET key. Press the
ENTER key. You can change your programme
selection any time before you press ENTER.
2. The TIMEdisplay inthe upperright-handcorner
of the display will start to flash. Choose the
desired duration of workout (1-90 minutes in
steps of 5 minutes) by using the arrow keys.
However, you can also exercise for a shorter or
longer periodthan you have chosen. Afterhaving
set duration, press the ENTER key.
3. Theweightdisplayinthelowerright-hand
corner starts to flash. The left-hand side display
reads KG ->. Enter your weight (default value
70 kg).The meter counts your approximate
energyconsumptionduringtheworkout
accordingtoyourweight.Afterhavingentered
yourweight,pressthe ENTER keyagain.
4. Begin your workout. You can adjust the effort
level with the arrow keys, and the column of
dotsin the left-hand displayindicatethechosen
effortlevel.
By pressing the SCAN key the right-hand side displays
automaticallyscandifferentvaluesevery6seconds.Youcan
also switch off the scan function by pressing the SCAN key,
if you want to follow only the effort, steps/minute and pulse
displays, for example.
Thetopmostdisplayshowseithertimecountdownoreffort
inwatts.Themiddledisplayshowseithertotalstepsorrate
in steps/minute. The lowest display indicates either
approximateenergyconsumptioninkilocaloriesorpulse.
When the chosen workout time has elapsed, the meter will
maintain the effort level and continues counting the training
values,soyoucancontinueyourworkoutwithoutstoppingif
yousowish.
Manuallymadeprogrammescan besavedinthememory of
the meter (see 3.3. MEMORY FUNCTION).
3.2.2. INTERVAL PROGRAMME
1.Select the INTERVAL programme by
pressing the INTERVAL key after the meter
hasbeenswitched on or after pressing the
RESET key. Press ENTER key. You can
change your programme selection any time
before you press ENTER. The various effort
levelsare indicated by green dots onthe
display on the left. By pressing the INTERVAL
1.MANUAL
Allowsyoutosetyoureffortlevelwiththearrowkeysduringthe
workout.Thesemanuallymadeprogrammescanbesavedin
the memory of the meter (see 3.3. MEMORY FUNCTION).
2.INTERVAL
Thisprogrammechangestheeffortlevelsduringyourworkout.
Thedisplayshowstheprogrammeandthechangesineffort.
You can choose a profile to your liking by pushing the
INTERVALbuttonrepeatedly.
3. TARGET PULSE
Thisprogrammeallowsyoutopresetyourpulselevel,i.e.the
resistance is regulated so that your pulse remains at the
requestedlevel.Thesetvaluecanbechangedalsoduringthe
workout.
4. HILL
This programme increases resistance gradually during the
wholeworkout.
5. RESET
Resets all values.
6. ENTER
Approves set values and user parameters.
7. MEMORY
Saves and opens manual programmes (user 1-4).
8.SCAN
Allowsselection of Scan function oracertain display.
9. ARROW KEYS
Used for setting values. In the manual function used for in-
creasingordecreasing resistance.
10. TIME / EFFORT
This display alternates between elapsed time (countdown)
and effort in watts (or effort level in INTERVAL programme).
11. TOTAL STEPS / STEPS/MIN
This display alternates between the total number of steps
takenand the rate.
12. KCAL / PULSE
This display alternates between approximate energy con-
sumptioninkilocaloriesandpulse.
3.2. OPERATING THE METER
N.B. Protect the meter from direct sunlight, as it may
damage the liquid crystal display. Do not expose the
meter to water or severe impacts, as these may also
damage the meter.
The meter switches on automatically when the device is
3. METER
3.1. METER KEYS AND FUNCTIONS

keyrepeatedly you get the display toshow
differenteffortprofilesandyou can choose the
one best suited for you by pressing the ENTER
key.
2. TheTIME displayintheupperright-hand
corner of the display will start to flash.
Choose the desired duration of workout
(1-90 minutes in steps of 5 minutes) by using
the arrow keys. The device uses this value to
calculatethedurationof thedifferenteffort
levelsduring the programme. However,you
can also exercise for a shorter or longer
periodthan you have chosen. Afterhaving
setduration,press ENTER key.
3. The EFFORT display in the meter’s upper
right-hand corner starts to flash. Select the
desired effort level, from 1 up to 9 (default
value 5). If you are just beginning, choose a
low effort level from 1 to 5. If you are very fit,
select a high effort level from 6 to 9. N.B.
Youcanchangeyoureffort level during the
workoutwiththe arrow keys. After having set
the effort level, press ENTER key.
4. Theweightdisplayinthelowerright-hand
corner starts to flash. The left-hand side
display reads KG ->. Enter your weight
(default value 70 kg). The meter counts your
approximateenergyconsumptionduringthe
workoutaccordingtoyourweight.After
havingenteredyourweight,pressthe
ENTERkeyagain.
5. Begin your workout.
By pressing the SCAN key the right-hand side displays
automaticallyscandifferentvaluesevery6seconds.Youcan
also switch off the scan function by pressing the SCAN key,
if you want to follow only the effort, steps/minute and pulse
displays, for example.
Thetopmostdisplayshowseithertimecountdownoreffort
inwatts.Themiddledisplayshowseithertotalstepsorrate
in steps/minute. The lowest display indicates either
approximateenergyconsumptioninkilocaloriesorpulse.
The flashing dot in the left-hand display shows the present
effortlevel in the workoutprogramme.
When the chosen workout time has elapsed, the meter will
maintain the effort level and continues counting the training
values,soyoucancontinueyourworkoutwithoutstoppingif
yousowish.
3.2.3. TARGET PULSE PROGRAMME
Exerciseindifferentpulserangesaffectsthebodyindifferent
ways. For example, exercise of long duration within a
pulserange that is about50-60 % of themaximum pulse
burns fat, or helps you lose weight, whereas exercise in a
rangethatisabout70-80%ofthemaximumdevelopsthe
heartandrespiratorysystem,andoverallendurance,i.e.
itimprovesyourcondition.Ifyoudon’tknowyourownmaximum
pulserateyoucanusethefollowingformulasasaguideline:
GB
5
WOMEN: APPROX. MAXIMUM PULSE = 226 - AGE
MEN: APPROX. MAXIMUM PULSE = 220 - AGE
However, it is advisable to make sure by consulting your
doctor.
TheTARGET PULSEprogramme enables trainingat the
requested pulse level. Theprogramme requires measure-
ment of pulse.
1. Select the TARGET PULSE programme by
pressing the TARGET key after the meter
hasbeenswitched on or after pressing the
RESET key.
2. ThePULSEdisplayinthelowerright-hand
corner of the display will start to flash. Set
the desired pulse value (beats/min) by
using the arrow keys. N.B. The preset value can
bechangedduringthetraining. Youcan e.g.
beginyourtrainingwithalower,warmup
level and increase your effort level after a
whileby increasingthepulsevalue. After
having set the pulse value, press the ENTER
key.
3. TheTIME displayintheupperright-hand
corner of the display will start to flash.
Choose the desired duration of workout
(1-90 minutes in steps of 5 minutes) by using
thearrow keys. After havingset duration,
press the ENTER key.
4. Theweightdisplayinthelowerright-hand
corner starts to flash. The left-hand side
display reads KG ->. Enter your weight
(default value 70 kg). The meter counts your
approximateenergyconsumptionduringthe
workoutaccordingtoyourweight.After
havingenteredyourweight,pressthe
ENTERkeyagain.
5. Begin your workout.
Followyour pulseduring thetraining andespecially the
small light, the so called heart indicator next to the
PULSEtext.Thelightshouldflashintimewithyourheartbeat.
Iftheindicatorbeginstofunctioninadisturbingfashion(e.g.
additional beats or unnormal fluctuations), the pulse
measurementis notfunctioningproperly. Stopyourworkout
and make sure that you have followed all the instructions
describedinthismanualaboutpulsemeasu-rement(see3.4.
MEASURING PULSE).
Ifthesteppingeffortseemstoostrenuousoreasy,changethe
preset pulse value by using the arrow keys.
By pressing the SCAN key the right-hand side displays
automaticallyscandifferentvaluesevery6seconds.Youcan
also switch off the scan function by pressing the SCAN key,
if you want to follow only the effort, steps/minute and pulse
displays, for example.
Thetopmostdisplayshowseithertimecountdownoreffort
inwatts.Themiddledisplayshowseithertotalstepsorrate
in steps/minute. The lowest display indicates either
approximateenergyconsumptioninkilocaloriesorpulse.

the chest transmit the pulses from the heart to the meter by
means of an electromagnetic field.
If you want to measure your pulse this way during your
workout,moistenthegroovedelectrodesonthetransmitter
beltwithsalivaorwater.
Fastenthetransmitterjustbelowthechestwiththeelastic
belt, firmly enough so that the electrodes remain in contact
withtheskin,butnotsotightthatnormalbreathingisprevented.
GB
The flashing dot in the left-hand display shows the present
effortlevel.
When the chosen workout time has elapsed, the meter will
maintain the pulse level and continues counting the training
values,soyoucancontinueyourworkoutwithoutstoppingif
yousowish.
3.3. MEMORY FUNCTION
Themeterenablessavingof4manuallymadeprogramm-
es to its memory (see 3.2.1. MANUAL FUNCTION).
Themeterhasfourpreprogrammedtrainingprogrammesof
different length and effort levels. If you wish to use one of
these programmes, move to RUNNING THE
PROGRAMMES.
3.3.1. SAVING THE PROGRAMMES
When you wish to save a manually made programme in the
memory of the meter, press the MEMORY key after your
workout session. The display in the lower right-hand corner
reads USr 1 (= user 1). Choose the desired memory
location(USr1,USr2,USr3,USr4)byusingthearrowkeys.
After having chosen the location, press the ENTER key.
Your programme is now saved in the memory of the meter.
3.3.2. RUNNING THE PROGRAMMES
1. When you want to use an earlier saved
programme, press the MEMORY key after
the meter has been switched on or after
pressing the RESET key.
2. Choose the desired programme with the
arrow keys. Press the ENTER key.
3. Thetime display in the upperright-hand
corner of the display will start to flash.
Choose the desired duration of workout (1-90
minutes in steps of 5 minutes) by using the
arrow keys. Press the ENTER key.
4. Theweightdisplay inthelowerright-hand
corner starts to flash The left-hand side
display reads KG ->. Enter your weight
(default value 70 kg). Press the ENTER key.
5. Begin your workout.
N.B.Ifyouwish,youcanadjusttheeffortlevelwiththearrow
keysduringthetraining.Ifyouwanttosavethesechangesin
thememory,presstheMEMORYkeyafteryourworkoutand
choose the desired memory location. Press ENTER after
making your selection.
3.4. MEASURING PULSE
Thisdevicehasabuiltinpulsereceiverwhichiscompatible
withaPOLARtelemetricpulsetransmitter.Thetransmitter
isautomaticallyincluded.
Reliable pulse measurement is achieved with a telemetric
device,inwhichtheelectrodesofthetransmitterfastenedto
6

GB
7
The transmitter automatically transmits the pulse reading to
the meter up to a distance of about 1 m.
Ifyouwearthetransmitterandbeltoveralightshirt,moisten
theshirtslightlyatthepointswheretheelectrodestouch
the shirt.
Thepulsevalueisdisplayedinthelowerright-handdisplayof
the meter.
Followyour pulseduring thetraining andespecially the
heart indicator light next to the PULSE text. The light
shouldflashintimewithyourheartbeat.Iftheindicatorbegins
to function in a disturbing fashion (e.g. additional beats or
abnormal fluctuations), the pulse measurement is not
functioningproperly.
REMARKS ON
TELEMETRIC PULSE MEASUREMENT
N.B. IF YOU HAVE A HEART PACEMAKER, YOU MAY
USETHEPULSEMEASUREMENTTRANSMITTERONLY
ON A PHYSICIAN'S APPROVAL!
Ifthe electrode surfaces arenotmoist,the pulse reading will
not appear on the display. If the electrodes are dry, they
must be moistened again. Allow the electrodes to warm
up properly to ensure accurate pulse measurement.
Ifthereareseveraltelemetricpulsemeasurementdevices
nexttoeachother,thedistancebetweenthemshouldbeat
least 1.5 m. Similarily, if there is only one receiver and
several transmitters in use, only one person with a
transmitter should be within transmission range.
The transmitter is switched to an active state only when it is
beingusedformeasurement. Sweatandothermoisturecan,
however, keep the transmitter in an active state and waste
batteryenergy.Thereforeitisimportanttodrytheelectrodes
carefully after use.
4. MAINTENANCE
TheTriStepper 900requiresverylittlemaintenance.Check,
however,fromtimetotimetheconditionoftherubberretraction
bands.Tiltthestepperonitssidetoinspecttherubberbands
atthebottom of the stepper. If thebandsareworn or frayed,
contact your local TUNTURI representative to have the
bandsreplaced.
To avoid premature wear on the chain mechanism and to
lower the noise level of the stepper, it is recommended to
lubricatethepedalchainswithvaseline.
Checkfromtimetotimethatallfasteningscrewsandnutsare
tight. Clean the stepper with a damp cloth. Do not use
solvents.
Although the device operates with a 12 V protective
voltage we recommend the following adjustment to be
carriedout onlyby aperson qualifiedto serviceelectro-
mechanical appliances according to the legislation of
yourcountry.
In spite of continuous quality control, individual defects and
malfunctionsmayoccurduetoindividualcomponents.Itisin
mostcasesunnecessarytotakethewholedeviceforrepair,
as it is usually sufficient to replace the defective part.
If you notice any defects or malfunctions in the device
during use, contact your dealer immediately. Always
give the serial number of your device!
5. TRANSPORT AND STORAGE
Thestepperiseasytomovebypushingalongonthebuilt-in
transportationwheels.Unplugthetransformerfromthepower
sourceandfromtheconnectorinthelowerlefthandcornerof
theside of thepulleycover.Take hold of thehandlebarfrom
theback, tilt the stepper forward andpushalongthefloor on
the wheels at the bottom of the main mast.
Topreventmalfunctioningofthestepper,storeitinadryplace
with as little temperature variation as possible, protected
againstdust.
6.DIMENSIONS
Length 87 cm
Height 141 cm
Width 86 cm
Weight 41 kg
All TUNTURI models are designed to meet the electro-
magnetic compatibility directive, EMC, and are affixed with
the CE conformity marking.
Theinformationpresentedinthismanualisgiveningoodfaith
and as accurately as possible. However, anyone who uses
this information in installing, using or servicing the device
does so at their own risk.
Due to continuous programme of product development
we reserve the right to change specifications without
notice.

28
67
88
89 58c
58d
57
90
91
97 98 48
28 6
94 53 96 46
57 92
1
58b
58a
100 2
99
43
12 11 17 18 65 19 20
9 10 16 12 13 14 15 13 12 26 27 16
11 12 41
40 43
39 38 15
16
16
12
29
30
31
32
21
22
23
24
25
20 19 17 18 65 64 63
74 60
81 80 102 79
73 72 71 75
76
49
77
78
69
70
59 60 61
3
4
5
6
7
86b
86a
54
55
56
101
101 98
8c 8d
8a 8b
46
57 98
98
58a
TUNTURI PULSE CONTROLLED TRISTEPPER C 900
58 403 7011 D
(incl. 58b-d)
58a 403 7014 D
59 653 7015 C
60 533 8004 A
61 61 0810 N A/C
63 103 7029 C
64 103 7010 C
65 653 2002 A
67 533 7036 A
68 62 2535 05 C
69 533 7025 A
70 653 5003 C
71 62 0817 16 C
72 533 4002 A
73 343 7007 C
74 673 600 86 C
75 103 7009 C
76* 503 7002 C
77* 61 0501 C
78 533 7018 A
-533 7023 A
79 533 7017 A
80 653 7020 C
81 103 7025 C
-103 7026 C
82 533 7014 A
83 62 0824 20 C
84 60 08 016 03 C
85 533 7031 A
86 363 7002 A
(incl. 86a, 86b)
87 523 102 71 C
88 403 7010 D
USA 120V
-403 7009 D
GB 120 V
-403 7008 D
EUR 230V
89 653 0062 D
90 63 05 6798JP C
91 501017 C
92 373 1020 C
93 403 1040 C
94 403 1043 D
95 683 402 A
96 503 7008 C
97 652 1701 C
98 62 051515 C
99 403 0015 A/D
100 233 71010 F
-553 7002 A/C
Tool set
-553 7003 A/C
Hardware kit (incl. * )
1233 7011 (incl. 58) D
-173 7009
2533 7024 A
3203 7007 (incl. 2,7) C
4503 7003 A
5* 60 06 016 33 C
6* 62 0612 16 C
7213 7007 A
8423 7037 E
(incl. 8a-8d)
92537002 C
10 263 7005 (incl.13,15)
C
11 61 0601 C
12 63 06 6798AZ C
13 523 7011 C
14 72 0711 447 1 C
15 673 601 90 C
16 60 06 080 02 C
17 263 2004 C
18 373 8003 (incl. 17) C
19 653 7021 C
20 60 06 010 03 C
21 253 7003 C
22 533 7032 A
23 60 08 020 39 C
24 693 7001 C
25 443 7002 E
26 643 8001 C
Ref. no Part no
LIST FOR RECYCLING /
INDEX FÜR MATERIALENTSORGUNG
A = Plastic,Thermoplast
Kunststoff, Thermoplast
B = Paper,Carton
Papier,Pappe
C= Metal / Metall
D= Electronics / Elektronik
E = Batteries / Batterien
F= Other / Sonstiges
This list will help you to sort out the different
components for recycling purposes.
Dieser Index soll Ihnen die Zuordnung der
Rohstoffe bei einer späteren Entsorgung
erleichtern.
27 72 0711 670 1 C
28 61 0610 A/C
29 62 0624 10 C
30 523 1009 C
31 533 1010 A
32 373 7005 C
37 60 05 010 21 C
38 523 8001 A/C
39 303 7001 C
(incl. 15, 38, 40)
40 263 7003 A
41 373 7002 C
43 60 06 016 37 C
44 373 1019 C
45 60 03 006 21 C
46 503 7004 C
-403 1037 A/C
(incl. 41,45-47,51,53,
93-97)
47 403 7012 D
48 60 05 016 33 C
49* 62 0511 10 C
51 60 05 008 35 C
53 403 1039 D
54 173 7007 LH, RH A
55 653 1003 C
56 503 7006 C
57 60 05 012 21 C
50

FIG. 7
FIG. 1
FIG. 3
FIG. 2
FIG. 8
FIG. 6
FIG. 5
FIG. 4

TUNTURIPYÖRÄ OY
P.O. Box 44
FIN-20521 Turku FINLAND
Tel. [phone]
Fax [phone]
http://www.tunturi.com
email:[email protected]
