Turbo TBS-201 User manual
TBS-201 Wireless Vehicle detector
TBS-201 Wireless Vehicle Detector
User Manual
TBS-201 Wireless Vehicle detector
Content
1. Overview .......................................................................................................................................... 1
2. Product Model ............................................................................................................................... 1
3. Key Features .................................................................................................................................... 1
4. Main Function................................................................................................................................. 1
5. Application Scenarios .................................................................................................................. 2
6. Production Specification............................................................................................................. 2
7. Structure Size .................................................................................................................................. 3
8. Working Principle .......................................................................................................................... 4
8.1. Working Principle .............................................................................................................. 4
8.2. Wireless Communication Working Principle ........................................................... 5
TBS-201 Wireless Vehicle detector
9. Installation ....................................................................................................................................... 5
9.1. Installation requirements ................................................................................................ 5
9.2. Installation Steps ............................................................................................................... 5
10. WeChat Applet Introduction................................................................................................... 8
10.1. Add WeChat Applet ....................................................................................................... 8
10.2. Enable Bluetooth connection ..................................................................................... 9
11. Notes ............................................................................................................................................ 10
TBS-201 Wireless Vehicle detector
1
1. Overview
TBS-201 wireless vehicle detector is a wireless geomagnetic sensor integrated with LoRa
and microwave technology. Using effective dual-mode joint algorithm, the detector realize
precise parking spot detecting function and can be widely used in intelligent traffic, smart
community, smart parking and other applications.
TBS-201, LoRa gateway and smart parking application management platform form smart
parking management system, which works as a whole smart parking solution. TBS-201 is
compatible with LoRaWAN protocol , can communicate with gateway which compatible
with LoRaWAN protocol.
The data collected by the detector and transferred to application platform can be
explained, detailed information please refer to < TBS-201 application protocol>.
2. ProductModel
TBS-201: Wireless vehicle detector (dual mode, with geomagnetic and microwave
sensor)
3. KeyFeatures
High detection precision, adjustable detection threshold
Build-in intelligent procession, Automatic drift compensation, stable and reliable
performance
Long wireless transmission distance
Transmission parameters can be set optionally
Parameters can be configured via Bluetooth
Low power consumption, long battery life
Compact size, easy to install
4. MainFunction
Report parking state timely
Low power alarm
Detector failure alarm
Report working states regularly
Support reset and calibration automatically or manually
TBS-201 Wireless Vehicle detector
2
5. ApplicationScenarios
Industrial parks
On road parking space
Commercial parking slot
Other public parking slot
Note: The strong magnetic field or the field where magnetic varies greatly are not suitable
for the detector use.
6. ProductionSpecification
Basic Specification
Working Frequency AU915, AS923
Communication Standard LoRaWANTM, Class A
Transmitting Power Maximum 20dBm
Receiving Sensitivity -135 dBm ( SF12,125KHz)
Detection Rate >99%
Bluetooth Calibration Auto calibration after device wake-up via Bluetooth
Downlink Configuration Calibration, detection threshold, heartbeat interval
Uplink Alarm Low power alarm, failure alarm
Software Upgrade Wireless upgrade
Power Supply Build-in battery, 3.6V, 38000mAh
Power Switch Strong magnetic switch
Battery Life >10 yrs, in typical working state[1]
Bearing Weight >10 tonnes
IP Grade IP68
Working Temperature -40℃~85℃
Storage Temperature -50℃~85℃
Working Humidity 10%~95%
Environment Requirement There are no ferromagnetic materials, no strong magnetic
TBS-201 Wireless Vehicle detector
3
field nearby. no Metal shield cover the detector.
Size Φ: 130mm, H: 87mm
Weight 800g
Note[1]：Typical working state means the device report information every 12 hours, there
are 5 times for vehicles come in and go out to a parking space a day.
Microwave Antenna Specification (TBS-201 only)
Item Receiving antenna Transmitting antenna
Vertical 3dB main lobe width 38° 38°
Horizontal 3dB main lobe width 38° 38°
Minor lobe level ≥15dB ≥15dB
7. StructureSize
Figure 1. TBS-201 dimensions
TBS-201 Wireless Vehicle detector
4
8. WorkingPrinciple
8.1. Working Principle
The frame and shell of a car are made of ferromagnetic material (various types of steel),
which make disturbance to surrounding magnetic field. According to this characteristic,
the parking sensor determines whether there is a car in the parking space by sensing the
magnetic field change. With build-in dual-sensors (geomagnetic sensor and microwave
sensor), powerful signal analysis and processing algorithm, the detector offers enhanced
information, especially acquire complementary and optimization to the reverse sensitivity
characteristics of chassis with different height.
Compared with traditional device with single sensor, TBS-201 can greatly improve the
detection accuracy and reduce information loss. The detection mechanism is show as
below.
1) Geomagnetic sensor detects the magnetic field lines which distorted by ferrous
metal of the vehicle, magnetic field strength obtained as the vehicle presence and
movement with the magnetic sensor.
2) Microwave Radar module emits wireless modulation wave and receives the
reflective signals to determine if the parking spot is occupied and vacant
TBS-201 Wireless Vehicle detector
5
8.2. Wireless Communication Working Principle
With build-in wireless transmission module, TBS-201 can communicate with LoRaWAN
gateway and smart parking application server located in cloud or in local.
Vehicle detector, LoRaWAN gateway, application server and smart parking application
(APP) composite of the Smart Parking system. Shown as figure 2.
Figure 2. Smart Parking System
9. Installation
9.1. Installation requirements
1. Please try to install in the daytime and finish the installation as soon as possible.
2. Please pay attention to road safety and wear orange or other color clothes.
3. Tool:
a. Ruler: Measure the installation position and the hole depth.
b. Marking pen: mark the installation position.
c. Drill: Drill holes on the ground at the installation position.
d. Cleaning brush: clear sundries in holes.
e. Scoop: mixing cement, marble glue and curing agent.
9.2. Installation Steps
1. Product Check
Take out the product and make sure appearance is not damaged. Check if the label
pastes tight on the product and label information (include the DevEUI and other
parameters which used to device registration) is clear. As shown in figure 3.
TBS-201 Wireless Vehicle detector
6
Figure 3. Product appearance and label
Note: To restart or calibrate TBS-201, place the magnet in the groove at the top of the
device and stay for 1~5 seconds, then move away.
2. Drill hole
a. Mark the installation position
According to the design of parking space, select the installation position and mark the
position, provide a code for the parking space. Usually the device is installed in the middle
of the parking space. Shown as figure 4.
Figure 4. TBS-201 installation position
b. Drill a hole
Drill a hole at the marked position, pay attention to measure the hole depth so that
TBS-201 surface will be placed a bit lower low road surface. Shown as figure 5.
TBS-201 Wireless Vehicle detector
7
Figure 5. drill a hole
c. Clear the sundries and fill the hole with cement
Clear the sundries in the hole, put water, quick dry cement to the hole and stir evenly.
d. Place device.
Put the device into the hole, compact the cement, make sure the device surface is aligned
to or a bit lower than the road surface, finally remove the extra cement.
Note:
Make sure cement do not cover the TBS-201 surface and the spiral slit. the spiral slit
is shown as the figure 6. Once the spiral slit is sealed with cement, the device will be
hard to remove for device maintenance or replacement.
Figure 6. the spiral slit is marked in red circle
Keep device is placed in horizontal position, cement is compacted tightly to avoid the
device cause inclination or subsidence once tires rolling over the device.
TBS-201 Wireless Vehicle detector
8
Make sure the triangle mark on the device surface point to the direction of vehicle
leaving or entering. The triangle mark is shown as figure 7.
Figure 7. Triangle mark located on the device surface
10. WeChatAppletIntroduction
The Applet is designed to finish the registration to LoRaWAN network and wake up the
device via Blue-tooth.
10.1. Add WeChat Applet
There are two ways to add Wechat Applet.
1. Scan code.
Open Wechat, scan following code, then enter the applet. The code is shown as figure 8.
then select “Geomagnetic vehicle detector".
Figure 8. Scan code
2. Search in WeChat
Search “ 快捷设备安装” in WeChat.
TBS-201 Wireless Vehicle detector
9
10.2. Enable Bluetooth connection
a. Turn on phone’s Blue-tooth.
b. Place the magnet stripe in the groove at the top of the device and stay for 1~5
seconds, then move away. The groove is shown as figure 9.
Figure 9. groove in the device surface
c. Click “Connected device” in applet. If success, the device basic information will be
displayed in applet. As shown in figure 10.
TBS-201 Wireless Vehicle detector
1
Figure 10. applet page
d. Select “Auto Install”, the device will be wakened up and perform the calibration
automatically, the system time will be synchronized. as shown in figure 11.
Figure11.Autoinstall
11. Notes
1. Battery life: The battery life refers to the service life under normal conditions. When
the device is used in poor LoRa network (SNR≤-12), the device function will be affected
and the battery life will be shortened.
TBS-201 Wireless Vehicle detector
1
Normal conditions mean the device can work normally in most time. The wireless
communication is stable.
2. During the calibration, make sure there is no vehicle and other metal material within 1
meter around the device. or calibration will make error.
3. When the server sends calibration command to device, make sure there is no vehicle
in the parking space or calibration will make error.
4. When the device work abnormally, the device can be reset through calibration
command. If this method doesn’t work, please try to do manual calibration. (refers to
chapter 9.2)
5. For manual calibration, if device cannot connect by Bluetooth, please try to change a
magnetic stripe.
6. Re-calibration is needed once the device is moved during detecting.
7. Make sure the triangle mark on the device surface point to the direction of vehicle
leaving or entering.
8. When command to modify parameter is sent to device from server, while the device is
in dormant state and cannot receive the command until waiting for the detector sending
state. Detailed information please refer to < TBS-201 application protocol>.
9. iPhone is recommended to be used. The device can be connected and operated
through applet via Bluetooth. Because there are many android phones, some of phones
may have compatibility problem.
