ESYLUX COMPACT APC10 DALI-2 User manual

User manual
| MA01994300 | V1.00 | 20220812 | EN |
page
COMPACT APC10 DALI-2
Ceiling-mounted presence detector
with integrated control unit
for DALI-2 devices

2 / 106
MA01994300
Document Version Edition Comment
MA01994300 V1.00 20220812 Initial version
F V1.1.1 | A V1.8.4
© ESYLUX GmbH
An der Strusbek 40 | 22926 Ahrensburg | Germany
Subject to change without notice.
Reproductions, including translations into other languages or reuse of content for other pur-
poses, may only be authorised by written consent from ESYLUX GmbH.

Table of contents
3 / 106
MA01994300
EN
Table of contents
1 Introduction................................................................................................................................. 5
1.1 Manufacturer/Contact................................................................... 5
1.2 Product identification................................................................... 5
1.3 Content and meaning of the document .......................................... 6
1.4 Typographical conventions ............................................................ 7
2 Safety........................................................................................................................................... 8
2.1 Intended use ............................................................................... 8
2.2 Staff qualifications ...................................................................... 8
2.3 Safety instructions ....................................................................... 8
3 Overview ...................................................................................................................................... 10
3.1 Scope of delivery ......................................................................... 10
3.2 APC technical data ...................................................................... 10
3.3 System overview .......................................................................... 14
3.4 Features and advantages of the APC .............................................. 15
3.5 Features and advantages of the app............................................... 15
3.6 Declaration of conformity.............................................................. 16
3.7 Accessories ................................................................................. 16
4 Installation .................................................................................................................................. 17
4.1 Mechanical work.......................................................................... 17
4.2 Circuit diagram............................................................................ 18
4.3 Electrical work............................................................................. 18
4.4 Installing the app ........................................................................ 23
4.5 Initial commissioning ................................................................... 24
5 Configuration............................................................................................................................... 26
5.1 APC basics.................................................................................. 26
5.1.1 Broadcast mode............................................................... 26
5.1.2 Group operation............................................................... 27
5.1.3 Open-loop light control - Closed-loop light control ............... 28
5.1.4 Minimum constellations ................................................... 29
5.1.5 APC LED indicators.......................................................... 31
5.1.6 BlueMode ....................................................................... 32
5.2 App basics .................................................................................. 33
5.2.1 Home screen ................................................................... 33
5.2.2 Menu structure ................................................................ 34
5.2.3 Using the app.................................................................. 36
6 Settings menu.............................................................................................................................. 39

Table of contents
4 / 106
MA01994300
7 Products section ......................................................................................................................... 42
7.1 Products ..................................................................................... 42
7.2 Bluetooth connection ................................................................... 44
7.3 Setup Wizard............................................................................... 46
7.4 Setup Wizard............................................................................... 46
7.5 Manual setup .............................................................................. 51
7.6 Address ...................................................................................... 52
7.7 Create groups .............................................................................. 54
7.8 Configure groups ......................................................................... 56
7.8.1 Operating mode ............................................................... 58
7.8.2 Light .............................................................................. 61
7.8.3 Afterglow ........................................................................ 69
7.8.4 Orientation light............................................................... 71
7.9 Scenes ....................................................................................... 73
7.10 Group offset ................................................................................ 75
7.11 Change over groups...................................................................... 79
7.12 Parameterise devices ................................................................... 85
7.12.1 Control gear (lighting)....................................................... 86
7.12.2 Motion sensors ................................................................ 86
7.12.3 Light sensors ................................................................... 88
7.12.4 Push-button .................................................................... 89
7.12.5 Switch ............................................................................ 93
7.12.6 Actuators ........................................................................ 95
8 Projects section .......................................................................................................................... 97
9 Menu information ........................................................................................................................ 98
10 FAQ............................................................................................................................................... 100
10.1 What does this APC indicator mean?.............................................. 100
10.2 What does this app indicator mean? .............................................. 100
11 Decommissioning ........................................................................................................................ 101
11.1 Disassembly ................................................................................ 101
11.2 Disposal...................................................................................... 101
12 APPENDIX..................................................................................................................................... 102
12.1 Abbreviations .............................................................................. 102
12.2 Glossary...................................................................................... 103

MA01994300
EN
Introduction
5 / 106
1 Introduction
1.1 Manufacturer/Contact
If you have questions about the product, need help with the app or are
planning extensions, do not hesitate to get in touch with us:
ESYLUX GmbH
An der Strusbek 40
22926 Ahrensburg
Germany
Phone: [phone]
E-mail: [email protected]
Internet: www.esylux.com
1.2 Product identification
This document applies to the following products:
Item name A B C H Hmax Item number
PD-C 360bt/8 APC10 PS plus DALI-2 8 6 4 3 5 EP10428142
PD-C 360bt/24 APC10 PS plus DALI-2 24 11 8 3 10 EP10428159
PD-C 360bt/32 APC10 PS plus DALI-2 32 11 8 3 10 EP10428265
A: Detection range transverse ø [m]
B: Detection range frontal ø [m]
C: Presence range ø [m]
H: recommended mounting height [m]
Hmax: maximum mounting height [m]

MA01994300
Introduction
6 / 106
Detection ranges of the presence detector:
The name of the item contains important information about the product:
1.3 Content and meaning of the document
This document contains detailed information about the installation, con-
figuration and complex functions of the product.
The current document is available for download as a PDF at www.esy-
lux.com. It can be printed out if required.
• Read the document before using the product.
• Pay particular attention to the safety and warning instructions.
• If you have any questions, contact the manufacturer.
• Keep the document in a safe place.
• If other people use the product, give this document to them.
360°
B
A
C
Element of the item name Meaning
PD Presence Detector device category
C Compact series
360 Detection angle (in degrees)
bt Configuration via Bluetooth and app
8/24/32 Detection range transverse (ø in meters)
APC10 Application Controller Variant
PS Including power supply
plus with HVAC contact
DALI-2 DALI-2 control system

MA01994300
EN
Introduction
7 / 106
1.4 Typographical conventions
The following typographical conventions are used in this document:
The warnings in this document have the following meanings:
DANGER
... warns of a hazard with a high degree of risk.
Failure to observe will result in death or serious injury.
WARNING
... warns of a hazard with a medium degree of risk.
Failure to observe may result in death or serious injury.
CAUTION
... warns of a hazard with a low degree of risk.
Failure to observe may result in moderate or minor injury.
NOTICE
... warns of possible property damage.
Failure to observe may result in damage to equipment or the environ-
ment.
In addition:
Information
Important or useful additional information
Typographical depiction Meaning
<Factory settings> Menu, screen, button
[Fully automatic] Condition, parameters
"Connection established" Message, input
see
2 Safety Cross-reference to chapter or section
1. -
2. -
3. -
Binding sequence of actions
» - Action result

MA01994300
Safety
8 / 106
2Safety
2.1 Intended use
This product is a DALI-2 certified ceiling-mounted presence detector with
integrated DALI-2 controller for room-wide light control of a maximum of
16 groups. Configuration is done via an app.
The product may only be used as follows:
– The product is intended exclusively for indoor use and ceiling
mounting with fixed installation.
– The product is designed for the use DALI-2 components in the DALI-
2 bus.
– The maximum number of DALI-2 components that can be connected
and the operating conditions must be observed. For details see
3.2 APC technical data.
– The use of unsuitable components, modifications to the product and
unauthorised repairs are not permitted.
– The product may only be used if it is in technically fault-free condi-
tion.
In the event of improper use, the manufacturer generally excludes any
resulting personal injury or property damage.
2.2 Staff qualifications
Installation, commissioning and other work on the 230 V mains may only
be carried out by electricians or electrical specialists in keeping with the
country-specific regulations.
Configuration and operation can also be performed by individuals with no
electrical engineering qualification.
• If you need assistance with the configuration, contact an electrical
fitter or a qualified electrician.
2.3 Safety instructions
Installation, commissioning and other work on the 230 V mains may only
be carried out by electricians or electrical specialists in keeping with the
country-specific regulations.
The connection must be protected with a 10 A circuit breaker.

MA01994300
EN
Safety
9 / 106
Nevertheless, there are the following residual risks:
WARNING
Risk of fatal injury from electric shock.
Working on the 230 V mains can result in death or serious injury.
– Always observe the 5 safety rules:
1. Switch off.
2. Secure against being switched on again.
3. Make sure that no voltage is present.
4. Earth and short-circuit.
5. Cover adjacent live parts.
WARNING
Risk of fatal injury from interfering with the device.
Opening and modifying the device can result in death or serious injury –
also for any others working on the system.
– Only remove the connection cover of the Powerbox for installation.
CAUTION
Risk of injury due to improper installation.
When inserting the device into the installation opening, the raised mount-
ing springs may snap back.
– Do not release the mounting springs before inserting them into the
installation opening.
NOTICE
Risk of damage due to faulty connection.
Reversed polarity or short circuit of the bus line can result in malfunc-
tions or damage to the components.
– Observe the DALI-2 specifications (IEC 62386).
– Only use bus cables (not included) for all DALI-2 connections in
accordance with DALI-2 specifications.
NOTICE
Risk of damage due to improper cleaning.
Cleaning with alcoholic, corrosive or abrasive cleaning agents or scouring
pads can damage the surface and lens of the device and cause malfunc-
tions.
– Use a soft cloth dipped in detergent solution for cleaning.

MA01994300
Overview
10 / 106
3Overview
3.1 Scope of delivery
The product scope of delivery comprises:
–Device
– Control unit (controller) with power supply (Powerbox)
– Sensor unit with lens
– 180° lens mask
– Cable tie for tension relief
– Brief instructions for installation and commissioning
3.2 APC technical data
APC10
General
Device category Ceiling-mounted presence detector with integrated
DALI-2 control unit and power supply
Control system DALI-2 bus
Status signaling Multicolour LEDs
User interface ESY Control App
User interface Bluetooth (BLE)
Bluetooth range approx. 10 m
Ambient temperature 0-40 °C
Relative humidity 5-93 %, non-condensing
Conformity CE, EAC, RoHS, WEEE

MA01994300
EN
Overview
11 / 106
Mounting
Mounting type Ceiling installation
Mounting location Soundproof ceiling
Installation opening ø 68 mm
Ceiling thickness max. 40 mm
Installation depth 80 mm + bending radius of installation cable
Connection type Plug-in terminal
Connectable conductor cross-section 0.5-2.5 mm2
Stripping length 10 mm
Bus cable length max. 300 m (conductor cross-section ≥1.5 mm2)
Cable length to a push-button/switch max. 30 m
Housing
Outer diameter ø 108 mm
Housing height 118 mm – 126 mm – 126 mm *
*each for model /8 – /24 – /32
Weight 237 g
Material UV-stabilised polycarbonate
Colour white, similar to RAL 9010
Protection class IP20
Electrical version
Mains voltage 230 V AC ± 10 %
Mains frequency 50-60 Hz
Starting current 20 A / 110 μs
Power consumption 5.0 W
Power consumption max. DALI load 3.7 W
Standby consumption <0.4 W
Protection class II
APC10

MA01994300
Overview
12 / 106
Control system/bus system DALI-2 (IEC 62386)
DALI output voltage 16 V DC
External power supply possible 9.5-22.5 V DC
DALI guaranteed output current 240 mA
DALI maximum output current 250 mA
DALI no-load current 2 mA
DALI quiescent current input 1.9 mA
DALI start-up time 600 ms
Push-button/switch connections 4x (non-floating)
Push-button/switch connections, potential 230 V AC
Switch actuator connection 1x (potential-free)
Switch actuator connection, potential max. 250 V AC / 24 V DC
Switch actuator connection, current max. 10 A
Motion sensor
Principle Passive infrared (PIR)
Warm-up time 25 s
Detection angle 360°
Detection range transverse ø 8 m – 24 m – 32 m *
Detection range frontal ø 6 m – 11 m – 11 m *
Presence range detection range ø 4 m – 8 m – 8 m *
Max. detection area 50 m2– 452 m2– 804 m2*
Recommended mounting height 3 m – 3 m – 3 m *
Maximum mounting height 5 m – 10 m – 10 m *
*each for model /8 – /24 – /32
Range adjustment mechanically, by means of cut-to-size lens mask
Light sensor
Light measurement Mixed light
Brightness range 5-2000 lx
APC10

MA01994300
EN
Overview
13 / 106
Functionality
Configurable bus participants max. 64
Configurable groups max. 16
Configurable scenes max. 16
Operating mode Fully automatic, semi-automatic, manual operation
Constant light control +
Group offset +
Manual adjustment of brightness setpoint +
Afterglow +
Orientation light +
Flexible group switching +
Switching of external lighting and HVAC +
Timer function –
Automatic dimming control –
Staircase lighting function –
Power cut-off –
Swarm function –
Central function –
HCL/ SymbiLogic –
Night operation –
Alarm operation –
APC10

MA01994300
Overview
14 / 106
3.3 System overview
Example connection diagram for an APC application with a BMS:
DALI-2 bus participants and bus communication between APC and BMS:
BMS
APC
APC DALI-2
BMS DALI-2 (optional)
Control gear (lighting)
Push-button/switch (external)
Mains cable
Bus cable
-101 - -304
*
Standards part of IEC 62386
Not available in model COMPACT MINI BMS DALI-2

MA01994300
EN
Overview
15 / 106
3.4 Features and advantages of the APC
The APC offers the following features and applications:
– DALI-2 certified ceiling-mounted presence detector with integrated
DALI-2 control unit and power supply
– Presence and daylight-dependent constant light control for maxi-
mum energy efficiency
– Room-wide lighting control of up to 16 groups
– Wide range of manual override options and up to 16 scenes
– Easy adaptation to individual and complex room situations
– Automatic switching of groups when room use changes
– Fast start-up with factory settings in broadcast mode
– Individual groups immediately ready for operation with factory set-
tings
– Status signaling by multicolour LEDs for all operating states and
sensor actions
– 4 inputs for external push-buttons/switches (non-floating)
– Relay for switching external lighting and HVAC (max. 10 A)
3.5 Features and advantages of the app
The app offers the following features and applications:
– Simple and comprehensive configuration of the APC via the bidirec-
tional Bluetooth interface
– No internet access required for all relevant configuration steps
– Clear menu with self-explanatory structure and comprehensible oper-
ating elements
– Setup wizard and practical user guidance through the entire configu-
ration process
– Context-dependent information texts and explanatory diagrams for
most menu items
– Situation-dependent feedback for missing information or impossible
combinations
– Simple administration and documentation of configured projects as
PDF reports
– Free download and regular updates via your app store

MA01994300
Overview
16 / 106
3.6 Declaration of conformity
We, the company ESYLUX GmbH, hereby declare that the product com-
plies with the following requirements:
– Directive 2014/53/EU (Radio Equipment Directive)
– Directive 2011/65/EU (RoHS Directive)
The complete document is available for download as a PDF file:
https://www.esylux.com/ce/esylux_ce_pd-c_dali-2_apc_ce01994400.pdf
In the event of modification or extension of the product not agreed with
us, this declaration shall lose its validity.
3.7 Accessories
The following accessories are available for this product:
Item name Description Item number
COMPACT Cover Set 24/32 SR Cover set for COMPACT series, 24 m/32 m, con-
sisting of cover panel and design ring, silver
EP10425431
COMPACT Cover Set 24/32 BK Cover set for COMPACT series, 24 m/32 m, con-
sisting of cover panel and design ring, black
EP00007491
Basket Guard Round Large Basket guard for presence and motion detec-
tors as well as smoke detectors, diameter 180
mm, height 90 mm
EM10425608

MA01994300
EN
Installation
17 / 106
4 Installation
4.1 Mechanical work
Description
The device is intended for mounting in the ceiling panel of a suspended
ceiling.
Requirements
– The mains cable and the DALI-2 bus cable as well as any cables of
external push-buttons/switches and switch actuator components
have been prepared.
– There are no cables in the mounting area that could be damaged
during drilling.
– The installation dimensions shown can be adhered to.
The required clearance above the Powerbox depends on the bending
radius of the installation cables (example: 55 mm).
Procedure
1. Drill the installation opening in the ceiling panel.
2. Guide the installation cables downwards through the installation
opening.
It is best to insert the device into the installation opening only after
the installation lines have been connected.
80 mm
55 mm
46 mm
40 mm
Ø68 mm

MA01994300
Installation
18 / 106
4.2 Circuit diagram
Example circuit diagram for an APC application:
4.3 Electrical work
Requirements
WARNING
Risk of fatal injury from electric shock.
Working on the 230 V mains can result in death or serious injury.
– Always observe the 5 safety rules:
1. Switch off.
2. Secure against being switched on again.
3. Make sure that no voltage is present.
4. Earth and short-circuit.
5. Cover adjacent live parts.
COMPACT APC DALI-2
L/N
DA+/DA–
K1/K2
S1-S4
APC DALI-2
Mains (230 V AC)
DALI-2 bus
External switch actuator component (floating)
External push-buttons/switches (non-floating)
Control Gear (Driver)
DA1/DA2
Example of a DALI control gear (lighting)
DALI-2 bus
DALI-2 BMS Sensor
DA1/DA2
S1/S2
Example of a BMS DALI-2
DALI-2 bus
External push-buttons/ switches (floating)
Control Gear
(Driver)
L N DA1 DA2
250 mA
COMPACT APC DALI-2
N N L L DA+ DA- K1 K2 S1 S2 S3 S4
L
N
DA+
DA-
DALI-2 BMS
Sensor
DA1 DA2
S1S1 S2 S2

MA01994300
EN
Installation
19 / 106
Procedure
1. Remove the connection cover from the Powerbox. Loosen the screws
as shown in the illustration.

MA01994300
Installation
20 / 106
2. Remove the covers in the connection cover at the points where
cables are to be fed through.
3. Remove the insulation on each of the sheathed cables and the indi-
vidual wires.
4. Take note of the order in which they are connected:
–A: If external push-buttons/switches (on S1-S4) or switch actua-
tor components (on K1/K2) are used, connect these lines first.
–B: Connect the DALI-2 bus cable (to DA+/DA-).
–C: Connect the mains cable (to L/N).
100 mm
10 mm
