TURBRO FIRESIDE FS48 User manual

TV STAND
IMPORTANT
READ ALL INSTRUCTIONS BEFORE ASSEMBLING
YOUR TV STAND.FAILURE TO FOLLOW
INSTRUCTIONS MAY LEAD TO DAMAGE TO
TV STAND OR PERSONAL INJURY.
KEEP THIS USER MANUAL FOR FUTURE
REFERENCE.
FIRESIDE FS48

Safety Instructions
Pre-Assembly
Tools Required
Hardware Included
Parts List
Assembly
Care and Maintenance
Warranty Information
...................................................................................02
...........................................................................................02
....................................................................................02
..............................................................................03
.............................................................................................05
..................................................................................................07
............................................................................21
...............................................................................22

Safety Instructions
Pre-Assembly
Before assembly, remove all parts from the package and compare with the below parts list. If any part appears missing or damaged, do
not assemble this product and contact our customer service team at [email protected].
TOOLS REQUIRED
Phillips screwdriver
(not included)
Please read the following instructions before attempting to assemble, operate, or install this product. Save these
instructions for future reference.
WARNING: Use only with flat panel TVs and audio/video equipment meeting recommended size and weight limits.
Never use it with any larger/heavier than recommended flat panel TVs or equipment. To avoid instability, place flat
panel TV in the centre of the unit; the base of the television must be able to rest on the supporting surface of the unit
without hanging over the edge. Improperly positioned flat panel TVs, or other equipment that exceed recommended
size and weight limits could fall off or break the unit, causing possible serious injury.
Fits most flat panel TVs up to 70 inches
Maximum load: 154.3 lbs / 70 kg
Maximum load: 55.1 lbs / 25 kg

Pre-Assembly
HARDWARE INCLUDED
For reference only. Parts are not shown to actual size.
A B C D E
FGH I J
KLM N O
PQ
36x+1
4x
2x
4x 16x+1
25x+1 8x 4x 4x
4x 2x 2x 2x
36x+1 8x 2x36x+1

Pre-Assembly
Part
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
Description
Cam Bolt
Wooden Dowel
Cam Lock
Screw
Drywall Anchor Kit
Screw
Spacer
Protective Sticker
Door Handle
Bolt
Anti-tilt Nylon Strip
Bolt
Screw
Pulley Joint
Bolt
Guide Rail Joint
Shelf Support Bracket
Quantity
36 + 1 (extra)
36 + 1 (extra)
36 + 1 (extra)
8
2
4
4
2
2
2
2
25 + 1 (extra)
8
4
4
4
16 + 1 (extra)

Pre-Assembly
PARTS LIST
1
15
11
9
4
12
13
6
14
14
3
3
3
3
2
10
16
17
8
5
7

Pre-Assembly
Part
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Description
Top Panel
Top Crossbar
Removable Shelves
Fixed Shelf
Center Crossbar
Sliding Door Track
Right Vertical Stretcher
Left Vertical Stretcher
Right Inner Panel
Left Inner Panel
Right Outer Panel
Left Outer Panel
Base Panel
Lower Rear Panel
Top Rear Panel
Right Sliding Door
Left Sliding Door
Quantity
1
1
4
1
1
1
1
1
1
1
1
1
1
2
1
1
1

Assembly
INSTALLATION WARNINGS
●The TV stand is heavy and should be assembled near its desired location.
●It is recommended that two people move the fully-assembled TV stand to prevent injury.
●Make sure that the unit is installed so that any power cords are not compressed against or caught on the TV stand and that it has
an unobstructed path to a grounded power outlet.
BEFORE INSTALLATION
Open the unit and check carefully for visible damage. If you have any problems with installation, operation, missing parts, or other
damage, please contact the TURBRO customer service team. Do not dispose of packaging until you are satisfied with your fireplace.
Contact the TURBRO customer service team ([email protected]) before returning the unit.
Unpack the unit and confirm that you have all the hardware and parts listed. Assemble the unit on a carpeted floor or the empty box to
avoid any scratches.
Note: This TV stand uses cam bolts for assembly. During installation, do not fully tighten cam locks until you finish assembly. This will
help make assembly much easier.
A
B
8
8
STEP 1
Insert wooden dowels (B) and cam bolts (A) into the designated
holes on the base panel (13).
A
B
13

Assembly
STEP 2
Attach vertical stretchers (7 & 8) to inner panels (9 & 10).
8
10
C
A
B
C
6
6
6
7
9
B
A

Assembly
STEP 3
Attach center crossbars (5) to fixed shelf (4). A
B
C
2
2
2
A
5
B
4
5

Assembly
STEP 4
Connect now-assembled fixed
shelf (4) to inner panels (9 & 10).
STEP 5
Attach the now-assembled inner panels and shelf to the base panel (13).
A
B
C
4
4
4
C 4
C
9
4
10
A
B
13
C

Assembly
STEP 6
Prepare outer panels (11 & 12) for assembly.
STEP 7
Attach the outer panels (11 & 12) to the base panel (13). C 4
A
B
2
2
11
12
A
B
11
12
C

STEP 8
●Attach the sliding door track (6) to the top crossbar (2).
●The spacers (G) should go between the sliding door track (6) and top crossbar (2)
and attached with 4 (F) screws.
STEP 9
Attach the top crossbar (2) to to inner panels (9 & 10) and outer panels (11 & 12).
Assembly
C 4
6
2
2
F
G
B
A
F
G
A
B
4
4
2
2
2
C

Assembly
A 12
B
C
12
12
STEP 10
Attach cam bolts (A) and dowels (B) to top panel (1).
STEP 11
Attach the top panel (1) to the rest of the assembled parts using cam locks (C).
1
A
1
C
B

Assembly
STEP 12
●Assemble the right sliding door (16) by attaching the sliding assembly (N/P) to both
sides of the door.
●Attach the handle (I) to the front of the door by screwing in from the back.
●Attach the protective sticker (H) to the top left of and bottom left of the
sliding door.
M
N
O
P
I
D
H
4
2
2
2
1
4
2
DP
16
16
16
OI
H
H
M
N

Assembly
M
N
O
P
I
D
4
2
2
2
1
4
STEP 13
●Assemble the left sliding door (17) by attaching the sliding assembly (N/P) to both
sides of the door.
●Attach the handle (I) to the front of the door by screwing in from the back.
17
17
17
DP
N
M
OI

Assembly
STEP 14
●Attach sliding doors (17).
17

Assembly
STEP 15
●Attach sliding doors (16).
16

Assembly
STEP 16
Insert shelf support brackets (Q) from rear, adjusting for the shelf height you desire.
These can be removed and readjusted later if needed.
STEP 17
Insert the removable shelves (3) onto the shelf support brackets (Q).
Q 16
3
3
3
3
Q

Assembly
STEP 18
Attach rear panels (14 & 15) to the TV stand.
14
14
15
L 25
