Turin Castle Instruction and safety manual

1
*For illustration only. Your model may be dierent.
Turin Castle (TU18787)
Turin Castle II (TU18707)
Turin Extreme (TU11191)
Turin Galaxy (TU18701)
Turin Normandie (TU18703)
Turin Pro (TU11196, TU13593)
Turin Valence (TU18709)
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION, USE AND CARE MANUAL
INTENDED FOR DOMESTIC COOKING ONLY
For additional information or support visit
www.myturin.com

2
Read all Instructions before Installing and operating this appliance
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. Use only metal ducts and this unit MUST be grounded.
2. Sucient air is needed for proper combustion and exhaust-
ing of gases through the duct to prevent back drafting.
3. When cutting or drilling into wall or ceiling, be careful not to
damage electrical wiring or other hidden utilities.
4. All electrical wiring must be properly installed, insulated and
grounded.
5. Old duct work should be cleaned or replaced if necessary to
avoid the possibility of a grease re.
6. Check all joints on duct work to insure proper connection
and all joints should be properly taped.
7. Use this unit only in the manner intended by the manufac-
turer. If you have questions, contact the vendor.
8. For general ventilating use only. DO NOT use to exhaust haz-
ardous or explosive materials and vapors.
9. The combustion air ow needed for safe operation of fu-
el-burning equipment may be aected by this unit’s opera-
tion. Follow the heating equipment manufacturer’s guideline
and safety standards such as those published by the National
Fire Protection Association (NFPA), the American Society
of Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
10. Before servicing or cleaning unit, switch power OFF at service
panel and lock service panel to prevent power from being
switched ON accidentally.
11. Clean grease laden surfaces frequently. To reduce the risk of
re and to disperse air properly, make sure to vent air out-
side. DO NOT vent exhaust into spaces between walls,crawl
spaces, ceiling, attics or garages.
12. Ducted fans MUST always be vented to the outdoors.
WARNING
TO REDUCE THE RISK OF A RANGE TOP GREASE
FIRE:
1. Keep all fan, bae, spaces, lter, grease tunnel, oil container
and grease-laden surfaces clean. Grease should not be
allowed to accumulate on fan, bae, spaces, lter, grease
tunnel and oil container.
2. Always turn range hood ON when cooking at high heat or
when cooking aming foods.
3. Use high settings on cooking range only when necessary.
4. Never leave surface units unattended at high settings. Boil
overs cause smoking and greasy spillovers that may ignite.
Heat oils slowly on low or medium settings.
5. Clean ventilating fan frequently.
6. Always use appropriate cookware and utensils size.
7. Always use cookware appropriate for the size of the surface
element.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN
THE EVENT OF A RANGE TOP GREASE FIRE,
OBSERVE THE FOLLOWING:
1. SMOTHER FLAMES with a close-tting lid, cookie sheet,
or metal tray, then turn OFF the burner. BE CAREFUL TO
PREVENT BURNS. NEVER PICK UP A FLAMING PAN—you
may be burned. KEEP FLAMMABLE OR COMBUSTIBLE
MATERIAL AWAY FROM FLAMES. If the ames DO NOT go out
immediately, EVACUATE AND CALL THE FIRE DEPARTMENT or
dial your local emergency services immediately.
2. DO NOT USE WATER, including wet dishcloths or towels —a
violent steam explosion will result.
3. Use an extinguisher ONLY if:
a) You know you have a Class A, B, C extinguisher,
and you already know how to operate it.
b) The re is small and contained in the area where it
started.
c) The re department has being called.
d) You can ght the re with your back to an exit.
WARNING
1. For indoor use only.
2. The installation in this manual is intended for qualied
installers, service technicians or persons with similar
qualied background. Installation and electrical wiring
must be done by qualied professionals and in accordance
with all applicable codes and standards including re-rated
construction.
3. DO NOT attempt to install this appliance yourself. Injury
could result from installing the unit due to lack of appropriate
electrical and technical background.
4. Range hood may have very sharp edges; please wear
protective gloves if it is necessary to remove any parts for
installing, cleaning or servicing.
5. Activating any switch ON before completing installation may
cause ignition or an explosion.
6. Due to the size and weight of this range hood, two person
installation is recommended.
7. Please read specication label on product for further
information and requirements.
CAUTION
The manufacturer and/or distributor/reseller declines all
responsibility in the event of failure to observe the instructions
given here for installation, maintenance and suitable use of the
product. The manufacturer and/or distributor/reseller further
declines all responsibility for injury due to negligence and the
warranty of the unit automatically expires due to improper
maintenance. The manufacturer and/or distributor/reseller will
not be held responsible for any damages to personal property
or real estate or any body injuries whether caused directly or
indirectly by the range hood.
WARNING

3
TABLE OF CONTENTS
1. Tools needed................................ 3
2. Parts supplied .............................. 4
3. Venting Requirements / Height & Clearances . 5
4. Calculating vent system length .............. 6
5. Venting methods............................ 7
6 Electrical requirements ...................... 8
7. Preparation ................................. 9
8. Installation .................................10
9. Range hood operation......................13
10. Troubleshooting ...........................16
11. Use and care information ...................17
12. Replacing the filter .........................18
13. Replacing the light bulb ....................18
14. Warranty ..................................19
15. Specifications ..............................20
Marker or pencil Utility knife Measuring Tape
Level Drill or powered screwdriver Flat-head screwdriver
1. TOOLS NEEDED

4
2. PARTS SUPPLIED
Before proceeding to the installation, check the contents of the box. If items are missing or damaged,
please contact us form at www.myturin.com
WARNING
Appearance aws of the unit found after installation and not aecting hood performance are not covered under
by the warranty.
WARNING
Make sure that the
following items
are included:
• Hood
• Decorative ue
assembly
(lower and
upper ues)
• Mounting brackets
• Grease lter(s)
(type and quantity
vary depending
on the model)
• Installation instructions
• Parts bag (mounting
screws, bolts, nuts)
• Damper (pre-installed
on the range hood)
•
Parts sold separately:
• Flexible duct tube
• Elbows, wall and
roof caps.
Turin Normandie (TU18703)
Filters
(type and quantity depend on model)
Hood
(style varies by model)
Damper
(pre-installed)
Decorative
ue assembly
BC
A
A - 4 x 1 3/4”
B - 32 x Mounting bolts
C - 32 x Mounting nuts
Turin Castle (TU18787)
Turin Castle II (TU18707)
Turin Extreme (TU11191)
Turin Galaxy (TU18701)
Turin Pro (TU11196, TU13593)
Turin Valence (TU18709)
B
A
A - 4 x 1 3/4”
B - 32 x Mounting bolts
1 x Upper support frame 1 x Upper support frame
1 x Lower support frame
(may be pre-installed)
4x
Support
frame
extension
4x
Upper
support
frame
extension
4x
Lower
support
frame
extension

5
3. VENTING REQUIREMENTS / HEIGHT & CLEARANCE
• Vent system must terminate outside (roof or side wall).
• DO NOT terminate the vent system in an attic or other
enclosed area.
• DO NOT use 4 inches (10.2 cm) laundry-type wall caps.
• Use metal/aluminum vent only. Rigid metal/ aluminum
vent is recommended.
• DO NOT use plastic vent.
• Always keep the duct clean to ensure proper airow.
• Calculate the following gures before installation:
1. Distance from the oor to the ceiling.
2. Distance between the oor to the countertop/
stove - 28 to 31 inches (71 - 79 cm) is
recommended for electric cooktops and 30 to
36 inches (76 - 91 cm) is recommended for gas
ranges.
3. Distance between the countertop/stove to the
range hood.
4. Height of hood and duct cover.
For the most ecient & quiet operation:
• A distance of 228 to 31 inches (71 - 79 cm) is
recommended for electric cooktops and 30 to
36 inches (76 - 91 cm) is recommended for gas
ranges.
• It is recommended that the range hood be vented
vertically through the roof through 6 inches (15 cm)
[8 inches (20.3 cm) for Turin Extreme (TU11191)]
or larger round metal/aluminum vent work. The size of
the vent should be uniform.
• Use no more than three 90° elbows.
• Make sure there is a minimum of 24 inches
(61 cm) of straight vent between the elbows if more
than one elbow is used.
• DO NOT install two elbows together.
• The length of vent system and number of elbows
should be kept to a minimum to provide ecient
performance.
• The vent system must have a damper. If roof or wall cap
has a damper, DO NOT use damper (if supplied) on top
of the range hood.
• Use silver tape or duct tape to seal all joints in the vent
system.
• Use caulking to seal exterior wall or roof opening
around the cap.
Electric - Min 28 - Max 31 inches
Gas - Min 30 - Max 36 inches
Cooktop
Hood

6
IMPORTANT:
• A minimum of 6 inch round1(standard for this range hood) ) must be used to maintain maximum airow
eciency.
• Always use rigid type metal/aluminum ducts if available to maximize airow
• Please use Duct Run Calculation below to compute the total available duct run when using elbows,
transitions and caps.
• ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is required, increase
duct size from 6 to 7 or 8 inch1. If a reducer is used, install a long reducer instead of a pancake reducer.
Reducing duct size will restrict and decrease airow, thus reduce duct size as far away from opening as
possible.
• If turns or transitions are required, install as far away from opening and as far apart as possible.
• Minimum mount height between stove top to hood bottom should be no less than 28 inches* for
electric ranges and 30 inches* for gas ranges.
• Maximum mount height between stove top to hood bottom should be no higher than 31 inches* for
electric ranges and 36 inches* for gas ranges.
• It is important to install the hood at the proper mounting height. Hoods mounted too low could result
in heat damage and re hazard; while hoods mounted too high will be hard to reach and will loose
performance and eciency.
• If available, also refer to stove top manufacturer’s height clearance requirements and recommended
hood mounting height above range.
Minimum Duct Size:
• Round 6 inch minimum1
* Due to dierent ceiling height congurations, recommended height may not be applicable.
1Turin Extreme 48 Inch (TU11191S-I48) requires an 8 inch duct.
4. CALCULATING VENT SYSTEM HEIGHT
To calculate the length of the system you need, deduct the equivalent feet for each vent piece used in the
system from the recommended maximum duct run.
Duct Run Calculation:
Recommended maximum run
6” or 3-1/4 x 10” duct 50 ft
Vent piece deduction
Each 90º elbow used 9 ft
Each 45º elbow used 5 ft
Each 6” to 3/14 x 10” transition used 7 ft
Side wall cap with damper 0 ft
Roof cap 0 ft
Duct Run Calculation example:
One roof cap, two 90º elbow, and one 45º elbow used:
0ft + 9ft + 9ft + 5ft = 23ft used.
Deduct 23ft from 50ft, 27ft maximum available for
straight duct run.

7
5. VENTING METHODS
• This range hood is factory set for venting through the roof or wall. It is not intended for use in
non-vented/re-circulating)
• Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed.
• NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or
garages. All exhaust must be ducted to the outside.
• Use metal/aluminum duct work only.
• Fasten all connections with sheet metal screws and tape all joints with certied Silver Tape or Duct Tape.
• Use caulking to seal exterior wall or roof opening around the cap.
WARNING
Roof cap
Side
wall
cap

8
6. ELECTRICAL REQUIREMENTS
If codes permit and a separate ground wire is used, it is recommended that a qualied electrician determine that the
ground path is adequate.
A 120-Volt, 60 Hz, AC-only (USA & Canada standard), fused electrical supply is required on a separate 15-amp circuit,
fused on both sides of the line.
DO NOT ground to a gas pipe.
Check with a qualied electrician if you are not sure that the range hood is properly grounded.
DO NOT have a fuse in the neutral or ground circuit.
IMPORTANT: Save this Installation Guide for electrical inspector’s use.
The range hood must be connected with copper wire/plug only.
The range hood should be connected directly to the fused disconnect (or circuit breaker) box through exible
armored or non-metallic sheathed copper cable. A U.L. - or C.S.A. - listed strain relief must be provided at each end of
the power supply cable.
Wire sizes (copper wire only) and connections must conform with the rating of the appliance as specied on the
model/serial rating label. Wire sizes must conform to the requirements of the National Electrical Code ANSI/NFPA 70 —
latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code Part 1 and C22. 2 No. 0-M91 - latest edition** and
all local codes and ordinances. A U.L. - or C.S.A. - listed conduit connector must be provided at each end of the power
supply cable (at the range hood and at the junction box).
Copies of the standards listed may be obtained from:
* National Fire Protection Association, Batterymarch Park, Quincy, Massachusetts 02269
** CSA International, 8501 East Pleasant Valley Road, Cleveland, Ohio 44131-5575
• Contact a qualied electrical installer
• Assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA
70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22. 2 No. 0- M91- latest
edition** and all local codes and ordinances
• Do not use an extension cord. If the power supply cord is too short, have a qualied electrician install an outlet
near the appliance, in accordance with all applicable codes and standards.
• Turn o electrical power at service entrance before wiring.
WARNING

9
7. PREPARATION
Advanced Preparations:
• Be familiar with the controls of the range hood by reading through Range Hood Operation, Page 11.
• Place the range hood on a at, stable surface. Connect the range hood to a designated standard outlet (please
refer the product label for the suitable voltage of this unit) and turn on the range hood. Verify all operations of the
range hood by referring to Range Hood Operation, Page 11.
• Place all supplied parts and required hardware on a at, stable surface and verify the existence of all supplied parts
listed on Page 4.
• Carefully remove the white plastic protective coat from the chimney covers and range hood.
CAUTION: To avoid damage to your hood, prevent debris from entering the vent opening.
Preparation:
• Determine and mark the center line on the ceiling where the range hood will be installed. Make sure there is
proper clearance within the ceiling or wall for exhaust vent.
• Due to the weight and size of this unit, please make sure that the support system or framework being used is
stable and secure in the wall.
• Put a thick, protective covering over countertop, cooktop or range to protect from damage or dirt. Remove any
hazardous objects around the area when installing.
• Mark the locations of the support mounting bracket holes, vent cutout (if used) and power supply cable cutout on
the ceiling. Use drill and saber saw or keyhole saw to cut openings for power supply cable and vent (see Venting
requirements and Electrical requirements, Pages 5-7).
• Install vent system (see Venting Methods, Page 5). Use caulking to seal exterior wall or roof openings.
• Disconnect main electrical supply, prepare and run electrical wiring through ceiling or wall. Leave approximately
12” of electrical cord hanging from the ceiling. Do not restore power until wiring is completed.
• Disconnect power cord, remove the lter(s) by pressing on the latch.
• Remove the grease cup or gutter (type depends on your model).
• Set aside the lters and grease cup until the range hood is properly installed.
• If the range hood comes with a glass canopy and has not already been mounted to the hood, loosen the four
canopy screws and washers from the hood top, carefully place the canopy on the hood top, and loosely tighten
the four canopy screws along with washers. DO NOT put excessive pressure against the glass.
This range hood requires three or more people to move and install this range hood due to excessive weight.
Body injuries could occur if it is not followed.
WARNING
Ceiling
joists
Cross
framing
Venting
ductwork
Wiring A

10
8. INSTALLATION
Turin Castle (TU18787)
Turin Castle II (TU18707)
Turin Galaxy (TU18701)
Turin Extreme (TU11191)
Turin Pro (TU11196, TU13593)
Turin Valence (TU18709)
• Align the upper support frame to desired ceiling
location. Mount to the ceiling using four “A”
screws. The support must be securely fastened to the
joists.
• If ceiling joists or stud blocks are not available, it
is required to build a supporting structure behind
the sheet rock for weight support. This may require
additional hardware.
• Position each upper support frame extensions on
the corners of the ceiling mount bracket and fasten
each with two “B” bolts. Adjust and mark each lower
support frame extensions as necessary to achieve
the proper height for the range hood (See Height
and Clearance on Page 5).
• Fasten lower support extensions to upper support
frame extensions two “B” bolts on each
• IMPORTANT: Always use rst and second holes on
the extensions on the upper (next to the ceiling) and
lower (next to the hood)
• Calculate the height of the duct tube (sold
separately) and extend approximately 6 inches
longer than required, connect the upper end of the
duct tube to the vent system.
• Slide the upper chimney cover over the completed
support frame and fasten with two“B” bolts to the
upper support frame.
• Slide the lower chimney over the lower support
frame and around the upper chimney cover. Have
second person to hold it in position.
• Have a third person raise up and hold the island
range hood in position, connect power plug to the
house wiring and connect the duct work to the
range hood.
• Mount the hood to the lower support frame
extensions sing eight “B” bolts.
• Slide the lower chimney cover down carefully so that
it sits on top of the hood.
• Install grease cup and aluminum lters then check
the operation of the range hood.
Turin Normandie (TU18703)
• Align the upper support frame to desired ceiling
location. Mount to the ceiling using four “A”
screws. The support must be securely fastened to the
joists.
• If ceiling joists or stud blocks are not available, it
is required to build a supporting structure behind
the sheet rock for weight support. This may require
additional hardware.
• Position the support frame extensions on the corners
of the ceiling mount bracket and fasten each with
two “B” bolts and “C”nuts. Adjust and mark each
support frame extensions as necessary to achieve
the proper height for the range hood (See Height
and Clearance on Page 5).
• IMPORTANT: Always use rst and second holes on the
extensions on the upper (next to the ceiling)
•Calculate the height of the duct tube (sold separately)
and extend approximately 6 inches longer than
required, connect the upper end of the duct tube to
the vent system.
• Attach the lower support frame to support
extensions and fasten each corner with two “B” bolts
and two “C” nuts
• Slide the upper chimney cover over the completed
support frame and fasten with two“B” bolts a to the
upper support frame.
• Slide the lower chimney cover the lower support
frame and around the upper chimney cover. Have
second person to hold it in position.
• Have a third person raise up and hold the island
range hood in position, connect power plug to the
house wiring and connect the duct work to the range
hood.
• Mount the hood to the lower support frame
extensions using eight “B” bolts and eight “C” nuts.
• Slide the lower chimney cover down carefully so that
it sits on top of the hood.
• Install grease cup and aluminum lters then check
the operation of the range hood.

11
Upper Support Frame
Lower Support Frame
Electric Circuit box
Motor Housing
Duct Exhaust
Support Frame
Extensions
(Upper and Lower
parts)
A Screws
A Screws
B Bolts
C Nuts
B Bolts
Turin Castle (TU18787)
Turin Castle II (TU18707)
Turin Galaxy (TU18701)
Turin Extreme (TU11191)
Turin Pro (TU11196, TU13593)
Turin Valence (TU18709)
Turin Normandie (TU18703)

12
Slide the upper chimney
onto the brackets and
secure it to the post of the
upper bracket
Secure the cover to the
brackets (connect the
power supply if not
already done)
Let the lower chimney
slide down and rest on
the hood
Slide the lower chimney over
the brackets and the upper
chimney and secure it
temporarily (using low tack
tape or having someone hold
it) to allow you to secure the
hood

9. RANGE HOOD OPERATION
If your range hood model is:
• Turin Castle (TU18787)
• Turin Castle II (TU18707)
• Turin Galaxy (TU18701)
• Turin Normandie (TU18703)
• Turin Pro (TU11196, TU13593)
Please see section:
9A - Electronic controls
If your range hood model is:
• Turin Extreme (TU11191)
•Turin Valence (TU18709)
Please see section:
9B - Electronic controls with remote
This range hood is designed to remove smoke, cooking vapors and odors from the cook top area. For best results,
start the range hood before cooking and allow it to operate several minutes after the cooking is completed to clear
all smoke and odors from the kitchen.
13

14
9A. RANGE HOOD OPERATION - ELECTRONIC CONTROLS
Applies to following models:
• Turin Castle (TU18787)
• Turin Castle II (TU18707)
• Turin Galaxy (TU18701)
• Turin Normandie (TU18703)
• Turin Pro (TU11196,
TU13593)
Power Decrease
Value
Increase
Value
Light
Blower Power
Indicator
Power-O Delay
Timer Indicator
Blower Speed
Indicator
Light Power
Indicator
Power-On Elapsed
Digital Timer
Power-O Delay
Digital Timer
Button functions:
• Power: Power ON/OFF the range hood and activate power-o delay timer.
• Decrease Value: Blower (motor) speed decrease, timer value decrease, and enter timer mode.
• Increase Value: Blower (motor) speed increase timer value increase, and cumulative timer reset.
• Blower Power Indicator: Lights up when blower (motor) is running.
• Blower Speed Indicator: Shows current blower (motor) speed (1-4).
• Light Power Indicator: Lights up when lights turned on.
•Light: Turns ON/OFF
• Power-On Elapsed Digital Timer: Indicates the accumulated time the system is running.
• Power-O Delay Digital Timer: Indicates the length of time left for delay o function.
• Power-O Delay Timer Indicator: Lights up when auto-shutdown delay timer function is on.
• Automatic cleaning reminder:
• This range hood is equipped with a cleaning reminder that will activate following 30 hours of use. When
blower (motor) starts to rotate, cumulative running time will be shown in Power-On Elapsed Digital Timer. This
timer icon ashes when 30 hours is up and reminds user to clean the lter(s).
• After cleaning the lter(s) and when the motor is not in use, press and hold Increase Value button over 3
seconds to reset the timer. Please note that turning o the system will not reset the Power-On Elapsed Digital
Timer.
• Adjusting the blower (motor) speed:
• Press Power button once to turn on the system. The Blower Power Indicator icon ashes showing that the
blower (motor) is ready. Decrease Value button will decrease the speed of the blower (motor) from 4 to
1(strongest to quietest). Increase Value button will increase the speed of the blower (motor) from 1 to 4
(quietest to strongest).
• Press Power button once to turn o the system.
• Adjusting the timer function:
• While the blower (motor) is not running : Press and hold Decrease Value button over 3 seconds to enter
timer mode. Adjust to desired period of delay o timer by pressing Increase Value or Decrease Value button
(minimum 1 minute to maximum 15 minutes). This setting will be saved immediately.
• While the blower (motor) is running : Press and hold Power button for over 3 seconds to activate delay o
timer. Power-o delay indicator will lit up and power-o delay digital timer will begin to countdown, when it
reaches zero, the blower (motor) will shut down.
• Adjusting the light:
• Press Light button once to turn on the lights, and once again to turn o the lights.
• Note: Light settings are independent from other settings (including power-o delay) and lights must be
manually turned on or o.
Note: The system saves user congurations, settings such as timer and blower (motor) speed will remain the same the
next time it is turned on.

15
9B. RANGE HOOD OPERATION - ELECTRONIC CONTROLS WITH REMOTE CONTROL
Applies to following models:
• Turin Extreme (TU11191)
•Turin Valence (TU18709)
ACTIVATING NORMAL BLOWER FUNCTION:
• While the range hood is o, touch (+) to start from lowest speed
or touch (-) to start from highest speed.
• Touch (+) or (-) again to change the blower speed as indicated
in LCD panel
ACTIVATING LIGHT FUNCTION:
• Touch Light button to turn the lights on or o.
• Light settings are independent from other settings (including
power-o delay) and lights have to be manually turned on or o.
ACTIVATING POWER-OFF DELAY FUNCTION:
• While the range hood is on and the blower is running in normal mode,
touch Power-O Delay button to activate delay o timer.
• Adjust to desired period of delay of timer by touching (-) or (+) button
quickly (1-15 minutes). Timer begins to countdown immediately, when
it reaches 0, the blower will shut o.
• Display screen will show ashing clock if timer is working.
CHANGING THE CLOCK (ONLY AVAILABLE IN SOME MODELS)
• While the blower is o:
1. Touch power sign once. The hour indicator will be ashing.
2. Use (+) or (-) to adjust to the desired hour.
3. Touch power sign again for the“minutes”. Indicator will be ashing.
4. Use (+) or (-) to adjust to desired minutes.
5. Touch power sign again to clear the screen. Touch light button to validate. To check time, touch light
button.
REMOTE CONTROL SENSOR:
• Remote control sensor receives infrared (IR) signal from the remote control. The maximum distance for IR data
transmission is 10 feet and requires direct line of sight. The transmission distance may vary depending on
temperature and remote control battery condition.
AUTO FUNCTION ACTIVE
• Once “Auto Function”is on or touched, all other functions will be DE-ACTIVATED and will NOT be working.
AUTOMATIC SHUT OFF
• This range hood will be shut o automatically after approximately 2 ½ hours. You can re-start operation
as usual after it was shut o.
LCD SCREEN
• This range hood is equipped with remote control. LCD panel WILL TURN OFF automatically after a period of
inactivity and every time when plugged into electrical outlet.
Remote
Control
Sensor
Power
O
Delay
Light Light
On
Indicator
Blower
On
Indicator
Decrease Increase Auto
Function
Power-O
Delay
Indicator
Auto Function
On
Indicator
Power Light
Decrease Increase
Auto
Function
Power
O
Delay

16
10. TROUBLESHOOTING
If the range hood or light does not operate after installation:
Check if the range hood has been plugged in, make sure that all power has been turned back ON, fused not blown
and all electrical wiring are properly connected.
Swap out light assembly to working ones to determine whether it is caused by defective bulbs. See Replacing the light
bulbs on Page 17.
The range hood vibrates when the blower is on:
The range hood might not have been properly secured to the ceiling. Check with your installer
The lights work but the blower is not spinning at all, is stuck or is rattling:
The blower might be jammed or scraping the bottom due to shipping damage. Please contact us immediately.
The blower or fan seems weak:
Check that the duct sized used is at least 6”. Range hood WILL NOT function eciently if the duct size is insucient.
Check if duct is clogged or if damper unit (half-circular apper) is not installed correctly or opening properly. A tight
mesh on a side wall cap unit might also cause restriction to the air ow.
The hood is not venting out properly:
Make sure the distance between the stove top and the bottom of the hood is within 28 to 31” for electric ranges and
30 -36” for gas ranges.
Reduce the number of elbows and length of duct work. Check if all joints are properly connected, sealed, and taped.
Make sure the power is on high speed for heavy cooking.
Touching electrical connectors or other exposed electrical circuitry inside this range hood when they are energized
could result in death, injury or property damage.
WARNING

17
11. USE AND CARE INFORMATION
Operations:
• Read and understand all instructions and warnings in this manual before operating the appliance. Save these
instructions for future reference.
• Always leave safety grills and lters in place. Without these components, operating blowers could catch on to hair,
ngers and loose clothing.
• NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers.
• NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch re. The risk of self
combustion is higher when the oil has been used several times.
• NEVER cook on “open” ames under the range hood.
Cleaning Fan:
• The saturation of greasy residue in the blower and lters may cause increased inammability. Keep unit clean and
free of grease and residue build-up at all times to prevent possible res.
Cleaning Filters:
• Filters must be cleaned periodically and free from accumulation of cooking residue Old and worn lters must be
replaced immediately.
• DO NOT operate blowers when lters are removed. Never disassemble parts to clean without proper instructions.
Disassembly is recommended to be performed by qualied personnel only. Read and understand all instructions
and warnings in this manual before proceeding.
Never put your hand into area housing the fan while the fan is operating!
WARNING
Filters should be cleaned monthly. Our lters are dishwasher safe. However the soap you use and the water type
in your area may react with the lters discoloring them. Discoloration is NOT covered by the warranty and does not
aect performance. We suggest hand washing using warm water and phosphate-free dishwashing detergent to
clean the lters. Let them dry and reinstall them. Discoloration of the lters may occur if using phosphate deter-
gents or as a result of local water conditions.
WARNING
Cleaning Exteriors Surfaces:
• Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent (e.g.
Comet®, EZ-O® oven cleaner), or steel wool/scoring pads, which will scratch and damage the stainless steel
surface. For heavier soil use liquid degrease such as“Formula 409®” or “Fantastic®” brand cleaner.
• If hood looks splotchy (stainless steel hood), use a stainless steel cleaner to clean the surface of the hood. Avoid
getting cleaning solution onto or into the control panel. Follow directions of the stainless steel cleaner. CAUTION:
Do not leave on too long as this may cause damage to hood nish. Use soft towel to wipe o the cleaning solution,
gently rub o any stubborn spots. Use dry soft towel to dry the hood.
• After cleaning, you may use non abrasive stainless steel polish such as 3M® or ZEP®, to polish and bu out the
stainless luster and grain. Always scrub lightly, with clean cotton cloth, and with the grain.
• DO NOT allow deposits to accumulate or remain on the hood.
• DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface and cause rusting.
• DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact with stainless
steel for extended periods. Many of these compounds contain chemicals, which may be harmful. Rinse with water
after exposure and wipe dry with a clean cloth.

18
12. REPLACING THE LIGHT BULB
LED LIGHT BULB : USA/Canada: 1.5W LED (please refer to the actual specication of the hood purchased)
1. Turn counterclockwise and remove.
2. Disconnect from socket.
3. Install the replacement LED lamp by connecting the leads in the socket.
4. Gently push upwards and turn clockwise until secure.
Do not touch lamps during or soon after operation. Burns may occur. Only use the LED light replacements available
separately from Turin.
WARNING
13. REPLACING THE FILTERS
Should lters wear out due to age, damage and/or prolonged use, please visit www.myturin.com to nd the retailer
closest to you who carries replacement lters.
Always replace damaged lter that has punctured or broken mesh, bent or broken frame.
WARNING

14. LIMITED WARRANTY
TURIN CANADA warrants its Range Hood products purchased in Canada against defects in material or workmanship for the time period of Two
(2) years from the original date of purchase of product. TURIN CANADA will supply new or equivalent replacement part in exchange for parts
determined to be defective. Repaired parts or replacement products will be provided by TURIN CANADA on an exchange basis, and will be either
new or refurbished to be functionally equivalent to new. This warranty is non-transferable from the original purchaser.
Warranty Performance : In the event of any malfunction or defect covered under the terms of this warranty,immediately contact TURIN CANADA.
Written notice of any malfunction or defect must be given within 7 days of thetime of the discovery of the malfunction or manufacturing defect
and must be accompanied by the original consumerpurchase receipt which shows the date of purchase.
Upon warranty validation, in order to obtain warranty service , the defective part must be delivered, freight prepaid,in either its original
packaging or packaging affording an equal degree of protection. You are responsible for all costsof removal, reinstallation, all shipping fees,
insurance or any other charges from the shipment of the product or part. TURIN CANADA reserve the rights to use refurbished, repaired or
reconditioned products or parts in the repair orreplacement process.
This Limited Warranty shall apply to any replacement part or replacement product for the remainder of the original Limited Warranty period. Any
part or product replaced under this Limited Warranty will become the property of TURIN CANADA.
This Limited Warranty only covers product issues caused by defects in material or workmanship during ordinaryconsumer use. It does not cover
product issues caused by any other reason, including but not limited to productissues due to (a) unit in a non residential use (b) acts of God (c)
misuse, accident or abuse (d) change in finish or colour due to chemical or other environmental factors (e) damage sustained during shipping,
handling or installation not in accordance with the instructions (f) unauthorized repair (g) modification of or to any part of the TURIN CANADA
product, (h) unit removed from its initial installation, (i) normal wear and tear (j) appearance flaws of the unit found after installation and not
affecting performance. This warranty does not cover fuses, ducts or any other accessories that may be purchased separately.
Any assistance that TURIN CANADA provides or procures outside the limitations, terms or exclusions of this limitedwarrant will not constitute a
waiver of such limitations, terms or exclusions, nor will it revive or extend the warranty.This Limited Warranty does not cover TURIN CANADA
Range Hoods sold AS IS or WITH ALL FAULTS or DEFECTS, normal maintenance and service, costs of removal and/or installation and shipping.
This Limited Warranty is invalid if the factory applied serial number has been altered or removed from the product.
DISCLAIMERS
TURIN CANADA shall not be responsible for loss of use or other incidental, consequential costs , expenses or damageswhich may occur. Under no
circumstances shall TURIN CANADA or any of its representatives be held liable for injury to any person or damage to any property, however
arising. This warranty gives you specific legal rights, and you may have others rights which vary from province to province.
All rights reserved to TURIN CANADA.
19

20
15. SPECIFICATIONS
Body Stainless Steel / Tempered Glass (vary with models)
Power Rating 220V/50Hz or 120V/60Hz (USA & Canada standard)
General Input Power 153 W (150W + 2 x 1.5W)
Motor Input Power 218 W
Motor Revolution 600 RPM (±10%) to 1800 RPM (±10%) (varies with models)
Levels Of Speed Control 4 (Varies with model. See section 9 for specics)
Maximum Airow 800-1800 CFM (varies with model)
Air Pressure 320 pa
Noise Level (dB / sone) Approximately 23 / 0.3 to 68 / 7.0 (Lowest to highest speed)
Motor Type Dual Chamber Ultra Quiet
Fan Type Dual Centrifugal / Sirocco
Control Type Button control / Electronic control (varies with models)
Filtration Type Aluminum Filter / Bae Filter (varies with models)
Illumination LED
Venting Size Top, 6 inches Round (except Extreme which is 8 inch round)
Interference Protection Radio Frequency Interference Protected
