Turtle Beach Ear Force X-Ray User manual

LIMITED EDITION
User Guide

Congratulations on your purchase of the Call of Duty®: Black OPS II Earforce X-Ray headset
from Turtle Beach. You now have in your possession a premium product that will bring your
gaming experience to a whole new level, heightening your senses, sharpening your reexes and
enhancing your communications. Welcome to excellence!

Table of Contents
Package Contents 4
Feature / Function Map (Location of controls / inputs) 5
Setting Up the Transmitter 8
Using the Transmitter / Pairing Instructions 9
Using your X-Ray Headset on Xbox 360 10
Using your X-Ray Headset on PS3 12
Bluetooth Settings 13
Phone Settings 14
Surround Sound Settings 15
Recharging / Specications 17
Equalizer (EQ) Presets/Blast Limiter Presets 18
Chat Boost™ / Variable Mic Monitor 19
Troubleshooting / Safety Notice 20
Regulatory Compliance 21
Declaration of Conformity 23
Warranty 24

4
Package Contents
X-Ray Headset
Headset Charging
Cable
Quick Start Guide
X-Ray Transmitter
Digital Optical Cable Xbox 360
Talkback Cable
Turtle Beach Sticker
D
Quick Start Guide
For the full user guide, please go to http://www.turtlebeach.com/products/X-Ray
Package Contents |Contenu de la boîte
FOR / POUR
XBOX 360
®
|PS3™
X-Ray Headset
Casque X-Ray
D
X-Ray Transmitter
Émetteur X-Ray
T
U
R
T
L
E
B
E
A
C
H
.
C
O
M
TurtleBeach Sticker
Vignette TurtleBeach
Digital Optical Cable
Câble optique numérique
Headset Charging Cable
Câble casque Charge
XBOX 360 TalkbackCable
XBOX 360 câble Discussion

5
Feature / Function Map (Location of controls / inputs)
1
23
4
5
6
7
X-Ray Headset - Left View
1. Power Button: Turn on the headset by pressing the
power button for a couple of seconds, then release.
You will hear 2 beeps and the power LED should start
ashing. Turn off the headset by pressing the button until
the LED stays on and you hear 2 beeps, then release. To
enter Pairing Mode, press and hold the power button for
about 6 seconds until you hear 2 fast beeps and the LED
begins to ash rapidly (see pg 9).
The headset will turn off after several minutes if there’s
no audio detected or if the transmitter is turned off.
Tone Button: Press this button to activate the different
EQ presets. A beep will indicate which preset is selected.
(see pg. 18)
Blast Limiter Button: Press this button to activate the
different Blast Limiter presets. A beep will indicate which
preset is selected. (see pg. 18)
Variable Mic Monitor: Adjusts the level of your voice
heard in the headset. (see pg. 19)
NOTE: Turning up the mic monitor may cause the mic
to pick up room sounds which will make the silence
detector not automatically shut off the headset when it’s
not being used. If the power is not automatically shutting
down, turn down this mic monitor control.
Xbox 360 Controller Jack: Connect the Xbox 360
Talkback Cable from your headset to the controller jack.
Game Volume: Turn to adjust the game sound level.
Removable Microphone with Adjustable Boom:
The microphone can be removed from the headset
when chat is not required by detaching it from the
boom.To properly position the mic: Remove the foam
cover, insert the boom into the socket so the holes on
the mic casing are facing your mouth. Then replace
the foam cover. The boom jack also has a marker to
indicate the proper mic position.
2.
3.
4.
5.
6.
7.

6
Feature / Function Map (Location of controls / inputs)
X-Ray Headset - Right View
1. Bluetooth®Volume: Press Chat (+) or Chat (–) to adjust
Bluetooth volume level. A tone will sound each time the
volume level changes.
Bluetooth®LED: Flashes blue once per second when
paired with a device. Flashes blue twice per second when
not paired with a device. Flashes blue and red quickly
when in pairing mode.
Bluetooth®Multi-Function Button (BT MFB):
Powers on the Bluetooth and performs several other
functions described in the “Bluetooth” section.
(See page 12)
NOTE: The Bluetooth feature is normally powered on. If it
is not paired to another device, it will automatically turn
off after 5 minutes to conserve battery power.
Mic Mute Button: Press to toggle between muting and
unmuting the microphone. A high beep will sound
when the mic is unmuted and a low beep will sound
when the mic is muted. When using the XBA Bluetooth
Adapter, (Sold Separately) the mic can also be muted by
double-pressing the button on the puck. When using the
Talkback cable, the mic can be muted directly from the
switch on the Talkback cable.
Headset Charging Port: The headset may be charged
by connecting this Mini USB input to a free USB port
on your gaming console using the included Headset
Charging Cable. (See Page 17)
NOTE: The Headset Charging Cable included with the
X-RAY can only be used to charge the headset and cannot
be used as a standard USB data cable.
Charging LED: Turns red when charging and turns off
when charged.
2.
3.
4.
5.
6.

7
Feature / Function Map (Location of controls / inputs)
X-Ray Transmitter
1234
D
7
PAIR SURROUND
ANGLES
SURROUND
ON/ OFF
8 9
5 6
1. Digital Input LED: This LED turns on when a digital input
signal is detected. When this LED is ON, the analog input
is turned off.
Surround Sound LED: The LED will light whenever the
digital input is being processed by the surround sound
decoder. When this LED is off, the audio signal will be
heard in stereo.
Dolby® Digital LED: The LED will light whenever a Dolby
Digital encoded signal is detected on the digital input.
Power/Link LED: When the transmitter is powered on
and communicating with the headset, this LED will be on
solid. When the headset is turned off, the LED will turn off.
A slowly pulsing LED indicates that the transmitter can’t
communicate with the headset. This could happen when
the headset is out of range, turned off or not paired with
the transmitter.
Digital Input and Output: Connect the digital input to the
Xbox 360 digital output using the included digital optical
cable. The digital input is passed through to the digital
output so you can connect the X-RAY transmitter and
your home theater system to hear the Xbox sound on the
headset and speakers at the same time. When a digital
signal is detected by the optical input, the Digital Input LED
will be lit.
Analog Input Jack: Provides a 3.5mm input for digital
music players or additional audio sources. (3.5mm cable
sold separately)
NOTE: The analog input is deactivated whenever a digital
input is active, so both the digital and analog inputs cannot
be used at the same time.
Pair Button: Press and hold to activate pairing mode.
Surround Sound Angles Button: Press to select different
HRTF surround angles. (see pg. 16)
Surround Sound On/Off Button: Pressing this button toggles
between surround sound and stereo sound. When surround
sound is active, the Surround Sound LED will be lit.
2.
3.
4.
5.
6.
7.
8.
9.

8
2
D
1
DIGITAL OUT
CONSOLE
Digital Optical Cable
(included)
Transmitter USB Cable
1
Digital Optical Cable
(included)
Xbox 360
Audio Adapter Cable*
(sold separately)
Transmitter USB Cable
2
Setting Up the Transmitter
Xbox 360 (Slim) and PS3
1. Connect digital optical cable (DIGITAL IN) and
transmitter power cables (included) to game console.
NOTE: Remove the protective caps from each end of
the optical cable before inserting it into the sockets.
2. Connect to power.
Xbox 360 (Older Models)*
1. Connect the Digital Optical Cable(DIGITAL IN)
*(Requires Xbox 360 HDMI Audio Adapter, sold
separately).
2. Connect to power.

9
Using the Transmitter / Pairing Instructions
Pairing Instructions
The transmitter allows wireless exibility without the restrictions of cables when using your Turtle Beach X-Ray
headset. This wireless communication is through Dual Band WiFi transmitting a signal between the transmitter and your
headset from up to 30 ft. If you are beyond this range or there are obstructions to the signal, you may hear a popping or
clicking sound as the signal weakens and is eventually lost.
For optimal performance, place the transmitter in an open area free from interference from other objects that may
otherwise obstruct the WiFi signal. Avoid placement on a metallic surface such as a home theater A/V receiver as this
may cause interference or a weak signal.
In order for your Turtle Beach X-Ray headset to use the WiFi signal, they need to be “paired” with the transmitter. Follow
the pairing instructions below, keeping the headset and transmitter at least two feet apart while doing so. The headset
and transmitter are pre-paired out of the box. The instructions below are only necessary if pre-pairing appears to have
been lost.*
1. Headset and transmitter should be powered OFF and at least 2 feet away from each other.
2. Connect the transmitter to power (see previous page for instructions)
3. Press and hold the Pairing button on the transmitter for 5 seconds until the LED ashes rapidly. Release.
4. Press and hold Power button (approximately 6 seconds) on the headset until the LED ashes rapidly. Release.
5. Once your Turtle Beach X-Ray headset has been successfully paired, the Headset LED will blink once per second and
the transmitter Power LED will light solid.
PAIR SURROUND
ANGLES
SURROUND
ON/ OFF
3
4
*The pairing process can take up to 30 seconds to complete. If pairing is unsuccessful on
rst attempt, please try again. It may take as many as ve attempts to pair successfully.

10
Using your X-Ray Headset on Xbox 360
Your Turtle Beach X-Ray headset is designed to work with Xbox 360 game consoles. In order to get ideal functionality
from your headset, follow the directions below.
2. Go back to Xbox Settings
3. Power X-Ray ON:
- Choose “Preferences.”
- Choose “Voice.”
- Under “Voice Output,” choose “Play Through Headset.”
1. Go to Xbox Settings.
- Choose “Settings”
- Choose “System Settings”
- Choose “Console Settings”
- Choose “Audio”
- Choose “Accessory Settings”
- Choose “Audio Device Settings”
- Set “Digital Output” to “Dolby Digital 5.1.”
Select Back
Digital Output
Current Setting
Dolby Digital
Choose the digital output
type for your system.
This setting only applies
to optical digital and HDMI
audio outputs.
Digital Stereo
Dolby Digital 5.1
Dolby Digital 5.1 with WMAPro
Voice Volume 10
Voice
Mute Kinect
Voice Output
Play Through Headset
Play Through Speakers
Play Through Both
Game Volume 10
