TURY FAST 3.0 User manual

FAST 3.0

2. INSTALLATION
3. PROGRAMMING AND SETTINGS
2.1 Tools and parts required
2.2 Electronic accelerator in the car
2.3 Installing FAST in the electronic accelerator
3.1 Download
3.2 Initial settings
3.3
Pairing
3.4 Accelerator pedal programming
3.5 Learn how to use your Fast
3.6
Activation and Deactivation of the Parking Function
3.7 Activation and Deactivation of the Lock Function
3. 8
Automatic closing function by TURY App
3.9 User Control and Password Pairing Function
1.APRESENTAÇÃO
www.tury.com.br
5.1 Troubleshoot
4.1 Technology
5. VALIDATION
4. SECURITY
1.1 Functions
1.2 Characteristics
1.3 Technical Specifications
1.4 Application
1.5 Package Content
1.PRESENTATION

2
www.tury.com.br
CONGRATULATIONS, YOU HAVE PURCHASED A HIGH QUALITY PRODUCT THAT
FROM NOW ON WILL ALLOW YOU TO IMPROVE YOUR VEHICLE BY ADJUSTING
IT TO YOUR DRIVING PREFERENCES. FAST REDUCES THE ORIGINAL
ACCELERATION RESPONSE TIME DELAY, SO YOUR VEHICLE WILL HAVE THE
SAME TECHNOLOGY ALREADY USED IN HIGHEND SPORTS CARS, WITHOUT
CAUSING ANY INCOMPATIBILITY WITH YOUR VEHICLE. CAN BE OPERATED
THROUGH THE TURY APP.
Read the entire installation manual completely. Pay special attention to the icons below,
because they have fundamental installation tips.
1. PRESENTATION
We recommend that the installation of TURY products is always done by an
experienced, skilled and qualified professional who has all the necessary
tools to install our products.
ATTENTION, TIPS
AND CARE
TECHNICAL SUPPORT:
JUST CLICK TO
START THE SERVICE
VIDEOS:
PROGRAMMING, SETTING
INSTALLAT ION AND TIPS
THE AVERAGE
INSTALLATION TIME IS
ABOUT 5 MINUTES
INSTALLATION
TIME:

3
www.tury.com.br
1.1.1 FAST: It is the main feature of the product, it provides 4 acceleration maps with 9 levels
of adjustment that allow the user to adjust the acceleration profile of the vehicle according to
his needs and preferences. It is the same feature already present in high-end vehicles, now
available for your vehicle.
1.1.2 ORIGINAL MODE: Feature that allows the deactivation of the FAST returning the
original factory operation mode. It can be easily activated at any time via the App.
1.1.3 PARKING: This function limits the vehicle's acceleration and can be adjusted between
15% and 50% of the acceleration level. Indicated for occasions such as: parking lots, use of the
vehicle by third parties, workshops and other situations, and can be easily activated or
deactivated (by password) defined by the vehicle user.
1.1.4 LOCK: This function blocks the operation of the vehicle's electronic accelerator and is
indicated as an anti-theft device or when the owner does not want the vehicle to be used by
third parties. Its activation is done through a password in the App, and when activated it
blocks the vehicle's throttle operation.
1.1 FUNCTIONS
1.2 CHARACTERISTICS
• It can be installed in any vehicle equipped with electronic accelerator, with manual or
automatic transmission and with any type of fuel, from light vehicles, pick-ups, SUVs, Vans,
motorcycles, etc;
• Its installation is done through an original connector already existing in the vehicle, in a
very fast and simple way, keeping all the originality and warranty of the vehicle;
• From the installation on, any acceleration to which the vehicle is subjected, including
reverse gear, there will be a gain in response while the product is activated in FAST mode and
according to the selected acceleration level;
• FAST always stores the last acceleration level used in each map. It does not lose the
settings in case of battery failure;
• Exclusive Tury App to control all functions by smartphone.

4
www.tury.com.br
Vehicles with electronic accelerator, manual or automatic transmission, and with any type of
fuel.
To check vehicles (makes, models, versions, and years) to which this product is applicable
go to www.tury.com.br and search in the product finder.
1.4 APPLICATION
1.3 TECHNICAL SPECIFICATIONS
2. INSTALLATION
1.5 PACKAGE CONTENTS
• Electronic Module
• Plug and Play Main Harness
• Nylon Clamp
• Consumption Current: 10mA;
• Voltage: 3V3/5V
2.1 TOOLS AND PARTS REQUIRED
* The tools and parts above are not included with the product.
GLOVES
ANTI-NOISE FOAM SCREW DRIVERINSULATING TAPE
INSULATING TAPE
MULTIMETER

5
www.tury.com.br
10minutes
Location of the original
vehicle connector
Accelerator pedal
Original harness
2.2 ELECTRONIC ACCELERATOR IN THE CAR
If you do not have a multimeter, with the driver's door open, turn off and remove the
ignition key and wait 10 minutes to perform step 2.4 (Step Two).
This time is needed to terminate the timed power supply to the original electronic accelerator
pedal module, in many vehicles this time is less. In vehicles equipped with the presence key,
keep it out of the vehicle. On many vehicles, stepping on the brake during the original timer
resets the power supply.
Locate in the accelerator pedal connector the pedal power supply wire that is at 5 Volts
with the ignition on, then with the door open turn off the ignition and wait for the power
supply to drop to 0 Volts, and only after the pedal has no power supply remove the connector
to proceed to item 2.4 (Second Step).
Connect to vehicle negative (-)
* Image merely illustrative.
If the original vehicle connector is disconnected with the electronic
throttle energized, the malfunction light on the vehicle's dashboard may
be activated, in some vehicles you will need an automotive scanner or
disconnect the battery to clear this light. In some cases it is possible to
turn the light off by turning the car off and on again after a few times.

6
www.tury.com.br
2.3 INSTALLING FAST IN THE ELECTRONIC ACCELERATOR
In some vehicles it is necessary to loosen the throttle body frame bolts
to access the electrical connection of the original electronic throttle
connector.
1º Make sure that the electronic throttle is de-energized;
2º Disconnect the throttle connector (remember, only perform this step after performing
the item 2.2);
3º Connect the original throttle connector to the FAST connector;
4º Connect the FAST connector to the electronic throttle.
Fix the FAST central unit with the plastic clamp in a place where it is completely isolated;
After the fixation of the central unit and the FAST harness, isolate them with foam tape to
avoid noise in the vehicle.
See the example below and follow the same sequence for installing FAST.
1º 2º 3º
4º Final Installation
MAKE SURE THAT THE ELECTRONIC
THROTTLE IS DE-ENERGIZED
CAUTION
DISCONNECT THE ELECTRONIC
ACCELERATOR CONNECTOR
ACCELERATOR
ORIGINAL CONECTOR
CONNECTION BETWEEN
ORIGINAL CONNECTOR
AND FAST CONNECTOR
CONNECTION BETWEEN
FAST CONNECTOR AND
ELECTRONIC ACCELERATOR
Location of the original
Vehicle connector
Accelerator pedal
Original Harness
FAST connectors
FAST Harness

7
www.tury.com.br
Example:
The connectors of this product have a correct position to be fitted in the vehicle, if these
connectors are installed in an inverted way in the electronic accelerator or in the original
harness, anomalies can be generated in the vehicle. Note that the connectors have a
mechanical design that ensures they do not reverse, however, if they are positioned the
wrong way around by applying excessive force, it is possible to make a reverse connection.
To avoid this, observe below in this press release an example of a connector with the
indications circled in yellow or red, and make sure that during the installation the FAST
harness is connected in the same position as the original harness, where it was connected to
the accelerator at these points.
Make sure that when connecting the FAST, the same positioning is maintained as
shown above.
1) Always keep the female connector lock of the FAST on the same side that the
original female connector lock was connected to the electronic throttle.
2) Straight corners with straight edges (yellow circles) and rounded corners with
rounded edges (red circles).
3) Pay the same attention to connectors that do not have a lock.
Lock
*This attention applies to any connector model, with or without latching, at the
time of installation.
L

8
www.tury.com.br
3. PROGRAMMING AND SETTINGS
The application for this product is called TURY App and can be downloaded for free
from the Play Store or Apple Store. Through TURY App, available for Android and IOS,
you can control all functions of the FAST. To use this app please refer to the
instructions and video tutorials available in the app.
3.1 DOWNLOAD
3.2 INITIAL SETTINGS
Click on the links below or view the QR Code with your
smartphone camera to download the application.
1st step
App Store
Available on the Available on the
2nd step 3rd step 4th step

9
www.tury.com.br
3.3 PAIRING
There are two ways to enable the pairing of the product, applying 3x clicks on the FAST
/ BLUETURY module button or using a 4-digit password directly in the TURY APP as
indicated below.
TURY APP automatically detects the pairing version of FAST and directs the correct
screen for each case as shown in the video below.
The product's original password is "0101" and we recommend changing it for security in
MENU/SETTINGS/USER AND PASSWORD to prevent anyone from being able to pair
without your permission.
For security, only smartphones paired with BLUETURY-FAST will be able to use the
TURY APP.
In order to pair the FAST product with the ANDROID or IOS Smartphone, it is necessary
to activate the BLUETOOTH module, and in the ANDROID system it is necessary to allow
and activate the LOCATION system of the device.

10
www.tury.com.br
There are two versions of pairing, using the button or using the 4-digit password as
shown in the videos below.
In addition to the video on pairing and programming the pedal, we have other videos on
how to use all FAST features through the TURY APP.
WATCH HOW
PAIR WITH BUTTON
WATCH HOW
PAIR WITH
PASSW O R D
If you are unable to pair due to too many users and you do not know the pairing
password, you can delete all users and reset the original pairing password "0101".
To activate this function, only turn on the ignition key and, within a 60-second
window, accelerate the accelerator pedal to the end of the course, keeping it
pressed for 20 seconds. It is not possible to perform this procedure if FAST is in
LOCK or PARKING mode.

11
www.tury.com.br
If you want to perform the pedal programming again, you must either delete your
user via menu/settings/users and return to the Tury app or delete all users
manually (see 3.9).
3.4 ACCELERATOR PEDAL PROGRAMMING
After finishing the installation and the pairing with the Smartphone, follow the
instructions on the TURY App screen to program the accelerator pedal as shown in the
video. Do this procedure before starting the vehicle, and use only the ignition key on
the second stage.
WATCH HOW
TO PROGRAM
1st step 2nd step 3rd step 4th step

12
www.tury.com.br
3.5 LEARN HOW TO USE YOUR FAST
Once you have completed the installation, pairing, and programming of the FAST pedal
it is ready for use. It starts in the original mode and to select the acceleration map just click
on the button of the desired map: CITY, TOUR, SPORT or FAST.
Some vehicles may be restricted from using the maximum levels on the
FAST Map. In these vehicles use the lower levels for everyday use and
the maximum levels only for overtaking.

13
www.tury.com.br
CLICK CLICK SLIDE
After selecting the desired map, adjust the acceleration level from 1 to 9.
There are two ways to adjust the acceleration level:
1° By clicking directly on the level.
2° Clicking on the last lit level and sliding until the desired level and releasing to finish the
adjustment.
Below is the example to program level 9 of the FAST map.
• You can select any level of adjustment in each of the 4 throttle maps, and the higher the
level the greater the gain in throttle response.
Setting the Acceleration
Level 1-9
Buttons for selecting
Acceleration Maps
Led color
indicates
selected
map
Indication of map and
acceleration level
1° 1° 2°

14
www.tury.com.br
You can turn FAST on and off and select the maps and throttle levels at any time, but
avoid setting them while the pedal is accelerating.
When you return to the throttle maps, the last throttle level set for each map is
always memorized. Thus, the user can easily change the maps already set to use each
one of them for different needs, such as overtaking, traffic, highways, shifting
downshifts, hills, city, without the need to reprogram the acceleration levels.
To return to the original acceleration mode of the vehicle, simply touch the OFF button,
as indicated in the image below.
This way the TURY App will be completely off, indicating that it is in the original mode of
the vehicle.

15
www.tury.com.br
3.6 ACTIVATION AND DEACTIVATION OF THE PARKING FUNCTION
1º Open TURY App and on the main screen press the letter P (PARKING) for 2 seconds;
2º Choose between the options Manual or Auto, type the 3-digit password and confirm
in the ENTER button to activate the function;
3º Choose the maximum acceleration level (between 15% and 50%) according to your
needs or parking place, because there may be a variation in acceleration according to the
power of each engine;
4º To exit the PARKING function when selected in the automatic function, just return to
the vehicle with the APP TURY open and the pedal will be unlocked. If the manual function is
selected, to unlock just open the TURY App and select one of the maps that the pedal will be
unlocked.
5º If the smartphone battery runs out you can unlock the PARKING function manually.
WATCH HOW
TO PROGRAM
* See below the sequence described above on your Tury App screen.
If the smartphone is not charged or you have forgotten the password
registered in the TURY APP, you can deactivate the function manually. To
deactivate the PARKING function one must turn on the vehicle's ignition
key without starting the engine, and wait for 10 minutes without moving
the accelerator pedal.
To avoid this situation of smartphone discharge with the function
activated, we recommend installing our FAST PANEL or having a charger
available in the vehicle.
1st step 2nd step 3rd step

16
www.tury.com.br
3.7 ACTIVATING AND DEACTIVATING OF THE LOCK FUNCTION
1º Open TURY App and in the main screen press the (LOCK) button for 2 seconds;
2º Choose between the options Manual or Auto, enter the 3-digit password and confirm
by pressing the ENTER button to activate the function;
3º To exit the LOCK function when selected in the automatic function, just go back to the
vehicle with the APP TURY open and the pedal will be unlocked. If the manual function is
selected, to unlock just open the TURY App and select one of the maps and the pedal will be
unlocked.
4º If the smartphone battery runs out you can unlock the LOCK function manually.
* See below the sequence described above on your Tury App screen.
If the smartphone is not charged or you have forgotten the password
registered in the TURY APP, you can deactivate the function manually. To
deactivate the LOCK function, you must turn on the vehicle's ignition key
without starting the engine and wait for 30 minutes without moving the
gas pedal.
To avoid this situation of smartphone discharge with the function
activated, we recommend installing our FAST PANEL or having a charger
available in the vehicle.
WATCH HOW
TO PROGRAM
1st step 2nd step 3rd step

17
www.tury.com.br
3.8 AUTOMATIC CLOSING FUNCTION BY TURY APP
See now one more advantage of your FAST product:
In it you can also have control of the automatic closing of the Tury App, follow the step-by-step
below to activate and deactivate the function.
1º Open TURY App and touch to open the settings menu;
2º Click on settings;
3º If the button is GREEN the closing is activated. To deactivate just tap the button and the
status changes to deactivated.
4º Confirmation that the auto close Tury App is deactivated.
After choosing just close the Tury App.
WATCH HOW
TO SELECT
1st step 2nd step 4th step
3rd step

18
www.tury.com.br
3.9 USER CONTROL AND PASSWORD PAIRING FUNCTION
See now one more advantage of your FAST product:
You can have control of the paired users and change the pairing password, remembering
that the maximum limit is 4 users. To Edit or Delete a user open the TURY App, click to open the
MENU and then click on USERS / PASSWORD. After viewing the registered users, click on the
user you want to edit or delete and confirm. Editing the username is only enabled by the paired
user itself.
After confirming the deletion of your user, the next time you open the TURY App it will be
necessary to perform the pairing again.
To change the pairing password just click on the current password, type in the new 4-digit
password and confirm on the ENTER button as indicated below.
1st step 2nd step 3rd step

19
www.tury.com.brwww.tury.com.br
4. SECURITY
• The FAST BLUETURY module uses Bluetooth 5.2 technology.
• This product is free of electromagnetic interference and can be used anywhere. It does not
suffer from irradiation and does not generate radiation that affects human health or other
equipment.
• When the application is put in the background on your smartphone (rest) it goes into
sleep-mode. In this condition there is no communication with the Bluetury FAST and the app
will not perform any task, to ensure safety and also to ensure that there is no consumption of
your smartphone battery by the TURY App.
• This product uses the highest quality components and production processes, and has 2 years
of warranty against manufacturing defects as per the attached certificate.
• To prevent accidents and traffic fines never use the application while driving.
4.1 TECHNOLOGY
This equipment is not entitled to protection against harmful
interference and must not cause interference to properly
authorized systems.
