Tusk RL-HM018R Quick setup guide

Page | 1
Installaon steps:
1. Choose a locaon to place the hour meter where the pick-up wire will reach to the ignion
coil wire. Make sure there is at least 6 inches extra to wrap the pick-up wire around the
ignion coil wire. DO NOT MOUNT THE METER WHERE THE SURFACE EXCEEDS 125°F
2. Loop the pick-up wire through the two holes on the hour meter (see gure 1).
3. If you choose to mount the hour meter with the screws, use a 7/64” drill bit to drill the holes
(see gure 2). DO NOT DRILL INTO GAS TANK, FRAME, or ENGINE CASE. *mounng bracket
sold separately*
4. Starng from the hour meter (aer it is mounted), secure the wire with zip es down to the
ignion coil to ensure it does not get pinched or caught on moving parts while the machine is
in operaon.
5. Wrap the pick-up wire around the ignion coil wire 5-10 mes and secure it with a zip e (see
gure 3). If your engine has a pencil/sck type ignion coil, wrap the pick-up wire around the
dust boot of the coil where it is secured to the spark plug (see gure 4). Test the installaon
by starng the engine and checking the hour meter display. The hourglass icon on the display
will be blinking if installed correctly.
INSTALLATION INSTRUCTIONS AND INFORMATION
Congratulations on your purchase of the Tusk Tach/Hour Meter.
This product is made to handle extreme riding conditions. Please take note of the information and
instructions below to get the most out of your Tusk Product.
Note: For instructional videos, refer to www.rockymountainatvmc.com/videos.
Assembly: Before you throw any packaging away, make sure you received all the necessary hardware.
INSTALLATION INSTRUCTIONS AND INFORMATION
INSTALLATION INSTRUCTIONS AND INFORMATION
Tusk Tach/Hour Meter

Page | 2
Operaon Instrucons:
Press and release the buon to change through Total Hours, Tach, and Service Modes.
Changing Spark/Pulse:
Press the buon 6 mes and the display should show “1P1r”, this is your tach mode. Release the buon if
this is your tach mode. Hold buon to view more opons. *Typically, motorcycles with a baery or lighng
have ignions that send two pulses for every revoluon (2P1r)*
“1P1r” indicates that the meter is set for 1 pulse per 1 revoluon.
“1P2r” indicates that the meter is set for 1 pulse per 2 revoluons.
“2P1r” indicates that the meter is set for 2 pulse per 1 revoluon.
To View Max RPM Display:
Scroll through unl you get to the RPM screen. Press and hold the buon unl 2RPM is displayed. This is
your Max RPM. To clear the max RPM, connue to hold the buon unl it zeros out.
Service Intervals:
Every 5 hours of operaon, display will ash “CLEAN AIR FILTER”. Every 10 hours of operaon, display will
ash “CHANGE OIL”. At 20 hours of operaon, display with ash “VALVE SERVICE”. All maintenance mers
count down showing you the balance of me before scheduled service. Reset each maintenance mer by
holding the buon down for 5 seconds while displaying the mer.
INSTALLATION INSTRUCTIONS AND INFORMATION
Tusk Tach/Hour Meter
