KINNEY® KVA/KVAH™ SERIES
Single Stage Rotary Vane Pumps
Models
INSTALLATION
OPERATION
MAINTENANCE
REPAIR
MANUAL
WARNING
DO NOT OPERATE
BEFORE READING MANUAL
07/2009
Tuthill Vacuum & Blower Systems
4840 West Kearney Street
Springfield, Missouri USA 65803-8702
o417.865.8715 800.825.6937 f417.865.2950
www.tuthill.com
KVA12 KVA21 KVA25 KVAH25
KVA40 KVAH40 KVA63 KVAH63
KVA100 KVAH100 KVA160C KVAH160C
KVA250D KVAH250D KVA400C KVA630C

2
NOTICE
The above safety instruction tags were permanently affixed to your pump prior to shipment.
Do not remove, paint over or obscure in any manner.
Failure to heed these warnings could result in serious bodily injury
to the personnel operating and maintaining this equipment.
DO NOT VALVE OR RESTRICT PUMP
DISCHARGE OPENING.
USE OIL MIST ELIMINATOR WHEN
OPERATING PUMP, ENSURE ADEQUATE
VENTILATION WHEN DISCHARGING INDOORS
REFER TO MANUAL SAFETY INSTRUCTIONS.
CAUTION
SAFETY PRECAUTIONS FOR VANE PUMPS
Please read the following safety information on this page before operating your vacuum pump.
• Do not operate the pump without the guards properly attached. Disconnect the pump motor from the electrical supply at the
main disconnect before removing the guards. Replace the belt guard before reconnecting the power supply to the pump motor.
Operating the pump without the belt guard properly installed exposes personnel in the vicinity of the pump to risk from rotating
drive components.
• Do not operate the pump with oxygen-enriched gas (greater than 21% by volume) in the suction line, unless the pump has
been prepared with an inert fluid suitable for the application and equipped with seal and start/stop purge system.
WARNING: Pumping oxygen-enriched gases with mineral oil or other non-inert fluids and without proper
purges can cause fire or explosion in the pump, resulting in damage or serious bodily injury.
• Take precautions to avoid prolonged or excessive exposure to oil mist or process materials emanating from the discharge of
the pump.
• Do not allow the pump to discharge into a closed, or inadequately ventilated room. Where process vapor contains environmentally
unfriendly chemical vapor, pump discharge must be connected to the properly sized scrubber system to neutralize the harmful
chemicals prior to the discharge to the atmosphere. Laws and ordinances may pertain to your local area regarding discharge of
oil mist, oil vapor, chemical vapor to atmosphere. Check local laws and ordinances prior to operation of the pump with discharge
to outside atmosphere.
• Do not restrict the pump discharge in any way, or place valves in the discharge line. The vacuum pump is a compressor and will
generate high pressures without stalling the motor when operated at low suction pressures. Excessive pressure could cause
damage or serious bodily injury.
• Disconnect the pump motor from the electrical supply at the main disconnect before disassembling or servicing the pump. Make
sure pump is completely reassembled, the guards are properly installed, and that all fill and drain valves are installed and closed
before reconnecting the power supply. Accidental starting or operation of the pump while maintenance is in progress could cause
damage or serious bodily injury.
• Lift pump only by the lifting lugs supplied with the pump. DO NOT lift equipment attached to pump by the pump lifting lugs.
• Do not touch hot surfaces on the pump. In normal operation at low pressures, surface temperatures will not normally exceed
180° F (82° C). Prolonged operation at 200 Torr (267 mbar a) may cause surface temperatures as high as 220° F (104° C)

3
TABLE OF CONTENTS
SAFETY PRECAUTIONS FOR VANE PUMPS 2
INTRODUCTION 4
INSTALLATION 4
UNPACKING 4
LOCATION 4
POWER REQUIREMENTS 4
VACUUM CONNECTIONS 5
FILLING THE PUMP WITH OIL 5
OPERATION 6
START-UP 6
STOPPING THE PUMP 6
GAS BALLAST 6
MAINTENANCE 6
INLINE (INLET) FILTER 6
EXHAUST FILTER 6
MAINTENANCE SCHEDULE 6
OVERHAUL KIT AND ACCESSORIES 7
OIL LEVEL 7
OIL TYPE AND QUANTITY 7
OIL CHANGE 7
OIL SPIN-ON FILTER 7
MOTOR AND ELECTRICAL DATA 7
SPECIFICATIONS TABLE 7
TROUBLESHOOTING 8
EXPLODED VIEW DRAWINGS AND PARTS LISTS 10-21
KVA12 / KVA21 EXPLODED VIEW DRAWING 10
KVA12 / KVA21 PARTS LIST 11
KVA25 / KVAH25 / KVA40 / KVAH40 EXPLODED VIEW DRAWING 12
KVA25 / KVAH25 / KVA40 / KVAH40 PARTS LIST 13
KVA63 / KVAH63 / KVA100 / KVAH100 EXPLODED VIEW DRAWING 14
KVA63 / KVAH63 / KVA100 / KVAH100 PARTS LIST 15
KVA160C / KVAH160C / KVA250D / KVAH250D EXPLODED VIEW DRAWING 16
KVA160C / KVAH160C / KVA250D / KVAH250D PARTS LIST 17
KVA400C EXPLODED VIEW DRAWING 18
KVA400C PARTS LIST 19
KVA630C EXPLODED VIEW DRAWING 20
KVA630C PARTS LIST 21
WARRANTY – VACUUM PRODUCTS 22

4
INTRODUCTION
CONGRATULATIONS on your purchase of a new KINNEY®KVA or KVAH oil lubricated, rotary vane vacuum pump from Tuthill
Vacuum & Blower Systems. Please examine the pump for shipping damage, and if any damage is found, report it immediately to the
carrier. If the pump is to be installed at a later date, make sure it is stored in a clean, dry location and rotated regularly. Make sure
covers are kept on all openings. If pump is stored outdoors be sure to protect it from weather and corrosion.
KINNEY KVA/KVAH vacuum pumps are built to exacting standards and if properly installed and maintained will provide many years
of reliable service. We urge you to take time to read and follow every step of these instructions when installing and maintaining your
pump. We have tried to make these instructions as straightforward as possible. We realize that getting any new piece of equipment
up and running in as little time as possible is imperative to production.
This manual is written to cover KVA and KVAH Model vacuum pumps. Please identify the model number and serial number when
ordering parts.
WARNING: Serious injury can result from operating or repairing this machine without first reading the service
manual and taking adequate safety precautions.
IMPORTANT: Record the model and serial numbers of your pump in the OPERATING DATA form on the inside back cover
of this manual. You will save time and expense by including this reference identification on any replacement part orders,
or if you require service or application assistance.
INSTALLATION
UNPACKING
Inspect the box and pump carefully for any signs of damage incurred in transit. Since all pumps are ordinarily shipped F.O.B. from our
factory or regional warehouse, such damage is the normal responsibility of the carrier and should be reported to them.
The vacuum pump is bolted to the skid, and the fasteners must be removed to free the pump.
The inlet and exhaust of the pump are covered with plastic caps to prevent dirt and other foreign substances from entering the pump.
Leave these caps in place until you are ready to pipe the pump to your equipment.
LOCATION
Install the pump in a horizontal position on a level surface so that the pump is evenly supported on its rubber feet. Leave 12-18” of
access around the pump to allow proper cooling. Adequate ventilation must be provided for the fans, radiator, and motor.
Allow access to the oil sight glass in order to inspect the oil level, and the exhaust port for easy access to change the exhaust filters.
Do not tip the pump over if filled with oil.
POWER REQUIREMENTS
A schematic diagram for the electrical motor terminal connections is located in the junction box of the motor or on the motor
nameplate.
The motor must be connected according to the electrical codes through a fused switch in order to protect the motor against electrical
or mechanical overload conditions. The overload of the motor starter must be set at a level equal to the full load motor current listed
on the motor nameplate.
If the pump is supplied with a motor starter, it is preset at the factory according to customer specifications. It is advisable to check that
these settings are in line with the voltage at your location. If the voltage is different, please contact Tuthill Vacuum & Blower Systems
for motor and starter information.
Correct direction of rotation is marked by an arrow on the motor fan housing and is counter clockwise when looking at the motor from
the motor’s fan side.
NOTE: After electrical connections have been made, but prior to filling with oil, the rotation of the motor should be checked.
If backward, reverse any two leads of the three at the power connection.

5
VACUUM CONNECTIONS
Use a pipe size that is at least the size of the pump inlet connections. Smaller lines result in a reduced pump capacity and
performance.
Pumps operating in parallel on a common main line should have a manual or automatic operated shut-off valve or positive action
check valve, installed in the suction line adjacent to the pump suction flange. The built-in anti-suck back valve should not be used as
a shut-off valve for the vacuum system.
Remove the plastic protective cap from the inlet port prior to connection of the pump to the system.
Should process gas contain dust or other foreign particles, a suitable in line (inlet) filter should be connected to the inlet port. Consult
Tuthill Vacuum & Blower Systems for recommendations.
The vacuum piping should be designed to ensure that no liquids such as condensate or liquid carried over from the process can
reach the pump. If this possibility exists, a knock-out liquid separator should be installed. Consult Tuthill Vacuum & Blower Systems
for recommendations.
If an exhaust manifold is connected, install a drip leg and drain near the pump exhaust to prevent exhaust condensation from entering
the exhaust box. The following thread sizes are standard on KVA/KVAH pumps:
PUMP MODEL INLET SIZE EXHAUST SIZE
KVA12 / KVA21 1/2” NPT Open Grid
KVA25 / KVAH25
KVA40 / KVAH40 1 1/4” NPT 1 1/4” NPT
KVA63 / KVAH63
KVA100 / KVAH100 1 1/4” NPT 1 1/4” NPT
KVA160C / KVAH160C
KVA250D / KVAH250D 2” NPT 2” NPT
KVA400C 3” NPT 3” NPT
KVA630C 3” NPT 3” NPT
FILLING THE PUMP WITH OIL
The pump is shipped without oil. After level installation and correct rotation has been established, fill the pump with recommended
motor oil through the oil fill port. Oil level should be at the 3/4 position on the oil sight glass.
A non-detergent oil should be used. Tuthill Vacuum & Blower Systems recommends the use of KV-100 oil for normal duty operation
or S500 oil for severe duty operation.
Oil detergent additives can cause exhaust filters to become clogged and shorten their service life.
The following table gives the approximate quantities of oil required for each model.
PUMP MODEL CAPACITY (QUARTS)
KVA12 / KVA21 0.5
KVA25 / KVAH25
KVA40 / KVAH40 1.0
KVA63 / KVAH63
KVA100 / KVAH100 2.0
KVA160C / KVAH160C
KVA250D / KVAH250D 7.0
KVA400C 19
KVA630C 19
WARNING: Do not add or fill oil with pump running or through the inlet or exhaust ports! Do not overfill.

6
OPERATION
START-UP
Check rotation of the motor as described in “Power Requirements” on page 4. Fill the pump with oil as described in “Filling the Pump
with Oil” on page 5.
Start the pump with the inlet closed. Run the pump for a few minutes and then shut down. Check the oil level again and make sure
the oil level is between the ¾ mark and full on the upper oil sight glass.
Add oil, if necessary. Pump oil should only be added when the pump is off and circulating oil has sufficient time to return to the oil
sump.
STOPPING THE PUMP
To stop the pump, turn off the power. A built in anti-suck back valve will prevent oil from the oil reservoir being sucked back into
the cylinder after the pump is shutdown. Do not utilize the anti-suck back valve as a check valve. Consult Tuthill Vacuum & Blower
Systems for proper check valves.
GAS BALLAST
KVA and KVAH pumps are equipped with a gas ballast. The gas ballast valve is located between the inlet port and the exhaust box.
Its main function is to prevent water vapor from condensing in the pump that causes emulsification of the oil resulting in possible
pump failure.
In applications, when the quantity of water vapor is moderate, it is recommended to run the pump for 10 minutes to its normal
operating temperature, prior to going on process. The pump should also be operated off process for 10 minutes prior to shut down. A
slight air bleed (purge) is recommended during these 10-minute cycles to prevent the vapor from condensing in the pump.
MAINTENANCE
KVA Series vacuum pumps require very little maintenance. To ensure optimum performance, the following maintenance steps should
be followed.
INLINE (INLET) FILTER
Check inline (inlet) filter on a weekly basis. The filter cartridge should be cleaned or replaced when dirty. Consult Tuthill Vacuum &
Blower Systems for replacement element information.
CAUTION: Depending on the mounting position of the filter, be careful not to allow accumulated foreign material
to fall in the pump suction inlet when removing the filter cartridge. Horizontal filter installation is recommended
to prevent this.
EXHAUST FILTER
Replace the exhaust filters every 9 to 18 months of operation or as necessary. The service life of these filters varies depending upon
the application, and frequency of oil change. It is necessary to change these filters only when they become clogged. Indications
of clogged filters are smoke or oil mist coming from the exhaust of the pump, higher than normal motor current, and the exhaust
pressure gauge reading of 3 psig or greater.
Do not clean or re-use these filters. Filters must be disposed of in a proper way as they might contain toxic substances carried over
from the process. Replace O-rings on filter when changing.
MAINTENANCE SCHEDULE
See the motor manufacturer’s manual for the periodic motor maintenance.
DAILY: visually check oil level and color.
WEEKLY: inspect inline (inlet) filter.
EVERY 2-6 MONTHS: drain and discard oil from pump while hot. Refill with fresh oil.
EVERY 9-18 MONTHS: replace exhaust filter elements and O-ring.
The operating life of the pump is greatly enhanced based on the oil quality and condition of the filters. Periodic maintenance will
ensure a reliable operating vacuum pump.

7
OVERHAUL KIT AND ACCESSORIES
An overhaul kit contains a set of gaskets, o-rings, vanes, bearing, bearing sleeves, shaft seals, and taper pins. Please consult Tuthill
Vacuum & Blower Systems’ Service Department for information.
OIL LEVEL
Under normal circumstances it should not be necessary to add oil between oil changes. A significant drop in oil level means there is
either an oil leak, a defective exhaust filter or O-ring, or a leaking anti-suck back valve.
If the pump is smoking excessively, the exhaust filter may be installed improperly.
It is normal for the oil to be foamy or lightly colored in an operating pump. This may be normal aeration of the oil. If the oil appears
milky or dark colored, it is contaminated or burned and must be changed.
Check the oil level only when the pump is shut off. Replenish oil if it drops below the ¼ mark of the top sight glass. Oil must be added
through the oil fill port only.
CAUTION: Do not add oil while the pump is running, since hot oil can escape from the oil fill port.
OIL TYPE AND QUANTITY
See “Filling the Pump with Oil” section on page 5 for details on oil type and quantity.
OIL CHANGE
When using KV-100 oil, it is recommended to change the oil every 500-750 operating hours. When using S500 oil, it is recommended
to change the oil ever 750-1000 operating hours.
Oil change frequency is dependent upon the application and ambient temperature. It is recommended that the customer monitor the
condition of the oil.
OIL SPIN-ON FILTER
Replace spin on filter at every oil change.
KVA25 / KVAH25 - KVA100 /KVAH100 Fram® PH966 WIX® 51374
KVA160C / KVAH160 - KVA250D / KVAH250D Fram PH8A WIX 51515
KVA400C - KVA630C Fram PH3776 WIX 51820
MOTOR AND ELECTRICAL DATA
KVA12 /
KVAH12
KVA21 /
KVAH12
KVA25 /
KVAH25
KVA40 /
KVAH40
KVA63 /
KVAH63
KVA100 /
KVAH100
KVA160C /
KVAH160
KVA250D /
KVAH250D KVA400C KVA630C
HP 0.5 1 1.5 2 3 5 7.5 10 15 25
RPM 1725 3600 1725 1725 1725 1725 1725 1725 1160 1160
Full Load AMP 2.6/1.3 3.2/1.6 5.3/5/2.5 6.5/6.2/3.1 9/8.6/4.3 14/13.4/6.7 22/20/10 28.5/28.4/14.2 43/41/20.5 68/62/31
Voltage 230/460 230/460 208/230/460 208/230/460 208/230/460 208/230/460 208/230/460 208/230/460 208/230/460 208/230/460
SPECIFICATIONS TABLE
UNIT
KVA12 /
KVAH12
KVA21 /
KVAH12
KVA25 /
KVAH25
KVA40 /
KVAH40
KVA63 /
KVAH63
KVA100 /
KVAH100
KVA160C /
KVAH160
KVA250D /
KVAH250D KVA400C KVA630C
Displacement CFM 7 15 21 31 45 70 117 180 330 460
Guaranteed End Vac-L TORR 2 2 2 2 2 2 2 2 15 15
Guaranteed End Vac-H TORR NA NA 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Max Sound Level dB(A) 59 62 67 67 70 70 79 81 81 83
Motor Size 3PH 0.5 1 1.5 2 3 5 7.5 10 15 25
Pump Rotation Speed RPM 1725 3600 1725 1725 1725 1725 1725 1725 1160 1160
Oil Capacity QUARTS 0.5 0.5 1 1 2 2 7 7 19 19
Inlet Connection NPT 1/2” 1/2” 1 1/4” 1 1/4” 1 1/4” 1 1/4” 2” 2 3” 3”
Weight LBS. 42 42 103 116 168 185 415 460 1022 1342

8
TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE REMEDY
Pump smokes
at the exhaust
side or expels
oil droplets
from the
exhaust.
Exhaust filters are not properly installed with O-ring
Check exhaust filter placement and replace if needed
Filter media is damaged
Exhaust filters are clogged with foreign particles Replace filter and O-ring.
Oil is not recirculating properly. Check oil quality and make certain oil lines are clean.
Pump is
running too
hot. (Typical
operating
temperature of
KVA pumps is
120-200° F)
Not enough oil in the oil reservoir or oil is badly
burned or carbonized.
Drain oil and refill with the proper oil; change oil more
frequently.
Not enough air ventilation to pump Clean radiator and motor fins. Make certain a sufficient
amount of fresh air is supplied to the pump.
Pump will
not operate
(seized up)
Pump operated without oil and vanes broke Call Tuthill Vacuum & Blower Systems for service and
repair.
Liquid carry over into pump cylinder broke vanes
while pump was running. Install knock-out pot at inlet of pump
Pump does
not reach end
pressure.
This is the
lower absolute
(best vacuum)
when running
with the inlet
closed.
Oil condition is most often the cause of not reaching
end vacuum.
Drain oil from pump and refill with fresh oil. Run pump
with fresh oil for 15 minutes, then take new pressure
reading.
Inlet screen clogged with debris. Clean screen and check inlet filter element.
Shaft seal leak Replace shaft seal, from overhaul kit, or call Tuthill
Vacuum & Blower Systems for service and repair.
Vane stuck in rotor slot
Drain oil with flushing oil. Run pump for 15 minutes and
drain. Replace fluid with fresh oil, exhaust filter, and spin
on filter.
Replace vane.
Call Tuthill Vacuum & Blower Systems for service and
repair
Anti-suck back valve stuck in closed position due to
oil contamination.
Disassemble valve and screen, and clean as required.
Drain old oil and replace with fresh oil.
No oil or low oil level in reservoir Shut down pump, drain balance of oil, and refill with fresh
oil.
Vacuum fitting or hose is not leak tight. Check hose and pipe connections for leaks.
Radial clearance between rotor and cylinder are no
longer adequate.
Overhaul pump or call Tuthill Vacuum & Blower Systems
for service and repair.

9
TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE REMEDY
Pump
operation is
very noisy
Coupling insert is worn Replace coupling insert in motor/pump coupling
Vanes stuck Replace vane, or call Tuthill Vacuum & Blower Systems
for service and repair.
Bearing noise Replace bearings or call Tuthill Vacuum & Blower
Systems for service and repair.
Pump starts,
but labors and
draws high
amperage.
Oil is too viscous Drain and change with fresh oil
Exhaust filter is clogged.
Replace exhaust filters, maintain proper oil condition, oil
level, and use KV-100 oil. Use S500 oil for severe duty
operation. Make sure inlet filter is operational to prevent
particulate carryover.
Loose connection in motor terminal box wired for
wrong voltage.
Check wiring diagram for proper connections and tighten
or replace loose connections.
Foreign particles in pump.
Overhaul pump or call Tuthill Vacuum & Blower Systems
for service and repair.
Broken vanes or seized bearings.
The pump is overfilled with oil or the wrong kind of
oil is in the pump.
Drain oil and replace with the correct type of oil and the
appropriate amount of oil.
Pump runs in wrong direction. Check for correct rotation. If incorrect, switch any two
leads.
Pump will not
start
Supply voltage is not proper or is overloaded. Motor
starter overload settings are too low or improper;
fuses are burned; wire size is too small or too long
causing a voltage drop.
Check voltage supply; overload settings in motor starter
for size and settings according to motor nameplate. Install
proper size wire. If ambient temperature is high, use the
next larger size overloads or adjust settings 5% above
motor nameplate valve.
Turn pump fan by hand. If it will not turn, remove motor
from pump and check motor and pump separately. Repair
or replace if needed or call Tuthill Vacuum & Blower
Systems for service and repair.

10
KVA12 / KVA21 EXPLODED VIEW DRAWING
NOTES: x = KVAH xx = Oil return line to inlet xxx = KVA

11
KVA12 / KVA21 PARTS LIST
ITEM
# DESCRIPTION
12
QTY
21
QTY
1 CYLINDER 1 1
15 ROTOR 1 1
18 SLEEVE, BEARING 2 2
22 VANE 3 3
25 A-END PLATE 1 1
26 B-END PLATE 1 1
30 BEARING 2 2
35 SHAFT SEAL 1 1
36 O-RING, BRACKET 1 1
37 BRACKET 1 1
38 HEXAGON HEAD SCREW 3 3
50 O-RING, END PLATE 2 2
53 HEXAGON HEAD SCREW 6 6
54 SPRING LOCK WASHER 6 6
60 TAPER PIN 4 4
65 SHAFT KEY 1 1
75 OIL SUMP 1 1
83 OIL SIGHT GLASS 1 1
84 GASKET, OIL SIGHT GLASS 1 1
88 PLUG, OIL FILL 1 1
89 O-RING, OIL FILL PLUG 1 1
95 PLUG, OIL DRAIN 1 1
96 O-RING, OIL DRAIN PLUG 1 1
120 EXHAUST FILTER 1 1
121 O-RING, EXHAUST FILTER 1 1
125 FILTER SPRING 1 1
126 SLOTTED CHEESE HEAD SCREW 1 1
145 EXHAUST COVER (W/ THREADED FLANGE) 1 1
145-1 RUBBER FLAP FOR 02145 1 1
145-2 WASHER FOR 02145 1 1
145-3 SLOTTED CHEESE HEAD SCREW FOR 02145 1 1
150 GASKET, EXHAUST COVER 1 1
155 ALLEN BOLT 4 4
156 OUTLET SCREEN 1 1
159 EXHAUST VALVE ASSY( 159.1~ 159.6) 1 1
159-1 EXHAUST VALVE FIXED BOLT 1 1
159-2 EXHAUST VALVE WASHER 1 1
159-3 EXHAUST VALVE SPRING 1 1
159-4 EXHAUST VALVE PLATE 1 1
159-5 EXHAUST VALVE LOCK NUT 1 1
159-6 EXHAUST VALVE SEAT PLATE 1 1
186 ALLEN BOLT 4 4
190 SPRING LOCK WASHER 4 4
200 PLUG, DRUM 1 1
201 O-RING, DRUM PLUG 1 1
221 ELBOW HYDRAULIC FITTING 1 1
222 ELBOW HYDRAULIC FITTING 1 1
223 STRAIGHT HYDRAULIC FITTING 1 1
231 OIL TUBE(B) 1 1
233 ELBOW HYDRAULIC FITTING 1 1
ITEM
# DESCRIPTION
12
QTY
21
QTY
240 COOLING SPIRAL 1 1
251 CHECK VALVE PLATE 1 1
252 CHECK VALVE GUIDE 1 1
253 O-RING, CHECK VALVE PLATE 1 1
254 CHECK VALVE SPRING 1 1
255 O-RING, INLET PART 1 1
260 INLET FLANGE, KVA TYPE 1 1
260 INLET FLANGE, ORL TO INLET ONLY 1 1
261 INLET SCREEN 1 1
262 RETAINING RING FOR BORES 1 1
265 HEXAGON HEAD SCREW 4 4
266 SPRING LOCK WASHER 4 4
270* PLUG (FOR KVAH VERSION ONLY) 1 1
275* OIL RETURN VALVE (FOR KVAH VERSION ONLY) 1 1
275S* SEALING RING
(FOR KVAH VERSION ONLY) FOR 275* 1 1
285**/*** OIL RECIRC SCREW
(FOR ORL OR KVA TYPE ONLY ) 1 1
286**/*** BANJO FITTING
(FOR ORL OR KVA TYPE ONLY ) 1 1
285S-1** SEALING RING
(FOR ORL OR KVA TYPE) FOR 285** 1 2
285S-2** SEALING RING
(FOR ORL OR KVA TYPE) FOR 285** 2 2
290** OIL RETURN TUBE (FOR ORL TO INLET ONLY) 1 1
291** ELBOW HYDRAULIC FITTING
(FOR ORL TO INLET ONLY) 1 1
295S*** SEALING RING
(FOR KVA VERSION ONLY) FOR 295** 2 2
295*** OIL RETURN VALVE (FOR KVA VERSION ONLY) 1 1
296*** BANJO FITTING (FOR KVA ONLY) 1 1
297*** OIL RETURN TUBE (FOR KVA ONLY) 1 1
300 MOTOR MOUNTING BRACKET 1 1
301 ALLEN BOLT 3 3
302 SPRING LOCK WASHER 3 3
310 COUPLING SET( 311 ~313) 1 1
311 COUPLING, PUMP SIDE 1 1
312 COUPLING, SLEEVE 1 1
313 COUPLING, MOTOR SIDE 1 1
316 SET SCREW (PUMP SIDE) 2 2
317 SET SCREW ( MOTOR SIDE) 2 2
400.3 MOTOR FAN BLADE 1 1
400.4 MOTOR FAN COVER 1 1
401 HEXAGON HEAD SCREW 4 4
402 SPRING LOCK WASHER 4 4
416 SLOTTED SET SCREW 1 1
417 FOOT MOUNTING SCREW 2 2
419 SLEEVE 1 1
421 RUBBER FOOT 3 3
430 MOTOR 1 1
431 DIRECTIONAL ARROW LABEL 1 1
433 NAME PLATE 1 1

12
KVA25 / KVAH25 / KVA40 / KVAH40 EXPLODED VIEW DRAWING
NOTES: x = KVAH xx = Oil return line to inlet xxx = KVA

13
KVA25 / KVAH25 / KVA40 / KVAH40 PARTS LIST
ITEM
# DESCRIPTION
25
QTY
40
QTY
1 CYLINDER 1 1
15 ROTOR 1 1
18 SLEEVE, BEARING 2 2
22 VANE 3 3
25 A-END PLATE 1 1
26 B-END PLATE 1 1
30 BEARING 2 2
35 SHAFT SEAL 2 2
47 PLUG 1 1
50 O-RING, END PLATE 2 2
53 HEXAGON HEAD SCREW 6 6
54 SPRING LOCK WASHER 6 6
60 TAPER PIN 4 4
65 A-SHAFT KEY 1 1
66 B-SHAFT KEY 1 1
75 OIL SUMP 1 1
79 SHEET METAL BAFFLE 1 1
83 OIL SIGHT GLASS 1 1
84 GASKET, OIL SIGHT GLASS 1 1
88 PLUG, OIL FILL 1 1
89 O-RING, OIL FILL PLUG 1 1
95 PLUG, OIL DRAIN 1 1
96 O-RING, OIL DRAIN PLUG 1 1
99 THEADED FITTING 1 1
100 OIL FILTER 1 1
105 OIL SUMP COVER PLATE 1 1
106 GASKET, OIL SUMP COVER 1 1
107 ALLEN BOLT 4 6
108 SEALING RING 4 4
120 EXHAUST FILTER 1 1
121 O-RING, EXHAUST FILTER 1 1
125 FILTER SPRING 1 1
126 SLOTTED CHEESE HEAD SCREW 1 1
136 GASKET, SERVICE COVER 1 1
137 SEALING RING 4 4
138 ALLEN BOLT 4 4
139 SERVICE COVER 1 1
145 EXHAUST COVER (W/ THREADED FLANGE) 1 1
150 GASKET, EXHAUST COVER 1 1
155 ALLEN BOLT 4 4
156 OUTLET SCREEN 1 1
159 EXHAUST VALVE ASS’Y (159.1~159.6) 2 2
159-1 EXHAUST VALVE FIXED BOLT 2 2
159-2 EXHAUST VALVEWASHER 2 2
159-3 EXHAUST VALVE SPRING 2 2
159-4 EXHAUST VALVE PLATE 2 2
159-5 EXHAUST VALVE LOCK NUT 2 2
159-6 EXHAUST VALVE SEAT PLATE 2 2
185 GASKET, CYLINDER 1 1
186 STUD 4 4
187 SPRING LOCK WASHER 4 4
191 HEXAGON NUT 1 4
221 BSLM HYDRAULIC FITTING 1 1
221S SEALING RING FOR 221 2 2
222 STRAIGHT HYDRULIC FITTING 1 1
222S SEALING RING FOR 222
223 ELBOW HYDRAULIC FITTING 1 1
233 BSLM HYDRAULIC FITTING 1 1
230 OIL TUBE(A) 1 1
231 OIL TUBE(B) 1 1
233 BSLM HYDRAULIC FITTING 1 1
233S SEALING RING FOR 233 2 2
251 CHECK VALVE PLATE 1 1
252 CHECK VALVE GUIDE 1 1
253 O-RING, CHECK VALVE PLATE 1 1
254 CHECK VALVE SPRING 1 1
250 INLET FLANGE, LOWER HOUSING 1 1
ITEM
# DESCRIPTION
25
QTY
40
QTY
255 O-RING, INLET PART 2 2
260 INLET FLANGE, UPPER HOUSING 1 1
261 INLET SCREEN 1 1
265 ALLEN BOLT 4 4
266 SPRING LOCK WASHER 4 4
270* PLUG (FOR KVAH VERSION ONLY) 1 1
275* OIL RETURN VALVE (FOR KVAH VERSION ONLY) 1 1
275S* SEALING RING (FOR KVAH VERSION ONLY) FOR
275* 1 1
285**/*** OIL RECIRC SCREW (FOR KVA OR OLR TO INLET) 1 1
286**/*** BANJO FITTING (FOR KVA OR ORL TO INLET ) 1 1
285S-1** SEAL RING (FOR KVA OR ORL TO INLET) FOR 285** 1 1
285S-2** SEALING (FOR KVA OR ORL TO INLET) FOR 285** 3 3
290** OIL RETURN TUBE (FOR ORL TO INLET ONLY) 1 1
291** ELBOW FITTING (FOR ORL TO INLET ONLY) 1 1
295S*** SEALING RING (FOR KVA VERSION ONLY) FOR
295** 2 2
295*** OIL RETURN VALVE (FOR KVA VERSION ONLY) 1 1
296*** BANJO FITTING (FOR KVA VERSION ONLY) 1 1
297*** OIL RETURN TUBE (FOR KVA VERSION ONLY) 1 1
300 MOTOR MOUNTING BRACKET (IEC) 1 1
301 ALLEN BOLT 3 3
302 SPRING LOCK WASHER 3 3
310 COUPLING SET( 311 ~313), 1PH 1 1
311 COUPLING, PUMP SIDE 1 1
312 COUPLING INSERT 1 1
313 COUPLING, MOTOR SIDE 1 1
310A COUPLING SET( 311 ~313), 3PH 1 1
311A COUPLING, PUMP SIDE 1 1
312A COUPLING, SLEEVE 1 —
313A COUPLING, MOTOR SIDE 1 1
316 SET SCREW (PUMP SIDE) 2 2
317 SET SCREW (MOTOR SIDE) 2 2
321 FAN, PUMP SHAFT END 1 1
325 WASHER, SPRING LOCK 1 1
326 WASHER, PLAIN 1 1
327 HEXAGON HEAD SCREW 1 1
340 FAN HOOD 1 1
341 HEXAGON HEAD SCREW 3 3
391 EYE BOLT 1 1
400 MOTOR (IEC)-50HZ 1 1
400 MOTOR (IEC)-60HZ 1 1
400.3 MOTOR FAN (IEC) 1 1
400.4 MOTOR FAN COVER (IEC) 1 1
401 HEXAGON HEAD SCREW 4 4
402 SPRING LOCK WASHER 4 4
415 HEXAGON NUT 1 1
416 SLOTTED SET SCREW 1 1
417 SLOTTED SET SCREW 2 2
421 RUBBER FOOT 3 3
423 SPRING LOCK WASHER 1 1
425 WASHER 1 1
430 NAME PLATE 1 1
431 DIRECTIONAL ARROW LABEL 1 1
470 BSLM HYDRAULIC FITTING 1 1
470S-1 SEALING RING FOR 470 1 1
470S-2 SEALING RING FOR 470 1 1
471 OIL TUBE 1 1
472 NON RETURN VALVE 1 1
474 AIR FILTER 1 1
600 MOTOR (NEMA) 1 1
600.3 MOTOR FAN (NEMA) 1 1
600.4 MOTOR FAN COVER (NEMA) 1 1
601 HEXAGON HEAD SCREW (NEMA) 1 1
602 SPRING LOCK WASHER (NEMA) 4 4
612A COUPLING SET (313A+312C=613),NEMA 1 1
613 COUPLING, MOTOR SIDE (NEMA) 1 1
630 MOTOR MOUNTING BRACKET (NEMA) 1 1

14
KVA63 / KVAH63 / KVA100 / KVAH100 EXPLODED VIEW DRAWING
NOTES: x = KVAH xx = Oil return line to inlet xxx = KVA

15
KVA63 / KVAH63 / KVA100 / KVAH100 PARTS LIST
ITEM
# DESCRIPTION
63
QTY
100
QTY
1 CYLINDER 1 1
15 ROTOR 1 1
18 SLEEVE, BEARING 2 2
22 VANE 3 3
25 A-END PLATE 1 1
26 B-END PLATE 1 1
30 BEARING 2 2
35 SHAFT SEAL 2 2
47 PLUG 1 1
50 O-RING, END PLATE 2 2
53 HEXAGON HEAD SCREW 6 6
54 SPRING LOCK WASHER 6 6
60 TAPER PIN 4 4
65 A-SHAFT KEY 1 1
66 B-SHAFT KEY 1 1
75 OIL SUMP 1 1
79 SHEET METAL BAFFLE 1 1
83 OIL SIGHT GLASS 1 1
84 GASKET, OIL SIGHT GLASS 1 1
88 PLUG, OIL FILL 1 1
89 O-RING, OIL FILL PLUG 1 1
95 PLUG, OIL DRAIN 1 1
96 O-RING, OIL DRAIN PLUG 1 1
99 THEADED FITTING 1 1
100 OIL FILTER 1 1
105 OIL SUMP COVER PLATE 1 1
106 GASKET, OIL SUMP COVER 1 1
107 ALLEN BOLT 8 8
108 SEALING RING 8 8
120 EXHAUST FILTER 2 2
121 O-RING, EXHAUST FILTER 2 2
125 FILTER SPRING 2 2
126 SLOTTED CHEESE HEAD SCREW 2 2
136 GASKET, SERVICE COVER 1 1
137 SEALING RING 4 4
138 ALLEN BOLT 4 4
139 SERVICE COVER 1 1
145 EXHAUST COVER ( THREADED FLANGE) 1 1
148 EXHAUST COVER (BLOCKED) 1 1
150 GASKET, EXHAUST COVER 2 2
155 ALLEN BOLT 8 8
156 OUTLET SCREEN 1 1
159 EXHAUST VALVE ASS’Y( 159.1~ 159.6) 2 2
159.1 EXHAUST VALVE FIXED BOLT 2 2
159.2 EXHAUST VALVE WASHER 2 2
159.3 EXHAUST VALVE SPRING 2 2
159.4 EXHAUST VALVE PLATE 2 2
159.5 EXHAUST VALVE LOCK NUT 2 2
159.6 EXHAUST VALVE SEAT PLATE 2 2
185 GASKET, CYLINDER 1 1
186 STUD 4 4
187 SPRING LOCK WASHER 4 4
191 HEXAGON NUT 4 4
219 ST HYDRAULIC FIT. (KVA100 ONLY) — 1
220 ST HYDRAULIC FIT. (KVA100 ONLY) — 1
221 BSLM HYDRAULIC FITTING 1 1
221S SEALING RING FOR 221 2 2
222 STRAIGHT HYDRULIC FITTING 1 1
222S SEALING RING FOR 222 1 1
223 ELBOW HYDRAULIC FITTING 1 —
230 OIL TUBE(A) 1 1
231 OIL TUBE(B) 1 1
232 A-OIL TUBING (B) (KVA100 ONLY) — 1
233 BSLM HYDRAULIC FITTING 1 1
233S SEALING RING FOR 233 2 2
240 COOLING COIL (KVA100 ONLY) — 1
250 INLET FLANGE, LOWER HOUSING 1 1
251 CHECK VALVE PLATE 1 1
ITEM
# DESCRIPTION
63
QTY
100
QTY
252 CHECK VALVE GUIDE 1 1
253 O-RING, CHECK VALVE PLATE 1 1
254 CHECK VALVE SPRING 1 1
255 O-RING, INLET PART 2 2
260 INLET FLANGE, UPPER HOUSING 1 1
261 INLET SCREEN 1 1
265 ALLEN BOLT 4 4
266 SPRING LOCK WASHER 4 4
270* PLUG (FOR KVAH VERSION ONLY) 1 1
275* OIL RETURN VALVE (FOR KVAH VERSION ONLY) 1 1
275S* SEALING RING (FOR KVAH VERSION ONLY) FOR
275* 1 1
285**/*** OIL RECIRC SCREW (FOR KVA OR ORL TO INLET) 1 1
286**/*** BANJO FITTING (FOR KVA OR ORL TO INLET ) 1 1
285S-1** SEALING RING (FOR KVA OR ORL TO INLET) FOR
285** 1 1
285S-2** SEALING RING (FOR KVA OR ORL TO INLET) FOR
285** 3 3
290** OIL RETURN TUBE (FOR ORL TO INLET ONLY) 1 1
291** ELBOW HYDRAULIC FITTING ( FOR ORL TO INLET
ONLY) 1 1
295S*** SEALING RING (FOR KVA VERSION ONLY) FOR
295** 2 2
295*** OIL RETURN VALVE (FOR KVA VERSION ONLY) 1 1
296*** BANJO FITTING (FOR KVA VERSION ONLY) 1 1
297*** OIL RETURN TUBE (FOR KVA VERSION ONLY) 1 1
300 MOTOR MOUNTING BRACKET (IEC) 1 1
301 ALLEN BOLT 3 3
302 SPRING LOCK WASHER 3 3
310A COUPLING SET( 311A TO 313A) 1 1
311A COUPLING, PUMP SIDE 1 1
312A COUPLING, SLEEVE 1 1
313A COUPLING, MOTOR SIDE 1 1
316 SET SCREW (PUMP SIDE) 2 2
317 SET SCREW ( MOTOR SIDE) 2 2
321 FAN, PUMP SHAFT END 1 1
325 WASHER, SPRING LOCK 1 1
326 WASHER, PLAIN 1 1
327 HEXAGON BOLT 1 1
340 FAN HOOD 1 1
341 HEXAGON HEAD SCREW 3 3
391 EYE BOLT 1 1
400 MOTOR (IEC)-50HZ 1 1
400 MOTOR (IEC)-60 1 1
400,3 MOTOR FAN (IEC) 1 —
400,4 MOTOR FAN COVER (IEC) 1 —
401 HEXAGON HEAD SCREW 4 4
402 SPRING LOCK WASHER 4 4
415 HEXAGON NUT 2 2
416 SLOTTED SET SCREW 2 2
417 SLOTTED SET SCREW 1 1
421 RUBBER FOOT 3 3
423 SPRING LOCK WASHER 2 2
425 WASHER 2 2
430 NAME PLATE 1 1
431 DIRECTIONAL ARROW LABEL 1 1
470* BSLM HYDRAULIC FITTING 1 1
470S*-1 SEALING RING FOR 470 1 1
470S*-2 SEALING RING FOR 470 1 1
471* OIL TUBE (C) 1 1
472* GAS BALLAST (NON RETURN VALVE) 1 1
474* AIR FILTER 1 1
480* GAS BALLAST KIT ( 470*~474*) 1 1
600 MOTOR (NEMA) 1 1
600.3 MOTOR FAN (NEMA) 1 1
600.4 MOTOR FAN COVER (NEMA) 1 1
601 HEXAGON HEAD SCREW (NEMA) 4 4
602 SPRING LOCK WASHER (NEMA) 4 4
613A COUPLING, MOTOR SIDE (NEMA) 1 1
630 MOTOR MOUNTING BRACKET (NEMA) 1 1

16
KVA160C / KVAH160C / KVA250D / KVAH250D EXPLODED VIEW DRAWING
312
NOTES: x = KVAH xx = Oil return line to inlet xxx = KVA

17
KVA160C / KVAH160C / KVA250D / KVAH250D PARTS LIST
ITEM
# DESCRIPTION
160
QTY
250
QTY
1 CYLINDER 1 1
15 ROTOR 1 1
18 SLEEVE, BEARING — 2
18-1 SLEEVE, BEARING 2 —
18-2 SLEEVE, BEARING 2 —
22 VANE 3 3
25 A-END PLATE 1 1
26 B-END PLATE 1 1
30 BEARING 2 2
35 SHAFT SEAL 2 2
47 PLUG 1 1
50 O-RING, END PLATE 2 2
53 HEXAGON HEAD SCREW 9 9
54 SPRING LOCK WASHER 9 9
60 TAPER PIN 4 4
65 A-SHAFT KEY 1 1
66 B-SHAFT KEY 1 1
75 OIL SUMP 1 1
79 SHEET METAL BAFFLE 1 1
83 OIL SIGHT GLASS 1 1
84 GASKET, OIL SIGHT GLASS 1 1
88 PLUG, OIL FILL 1 1
89 O-RING, OIL FILL PLUG 1 1
95 PLUG, OIL DRAIN 1 1
96 O-RING, OIL DRAIN PLUG 1 1
99 THREADED FITTING 1 1
100 OIL FILTER 1 1
105 OIL SUMP COVER PLATE 1 1
106 GASKET, OIL SUMP COVER 1 1
107 ALLEN BOLT 4 4
108 SEALING RING FOR 4 4
115 FILTER BRACKET 1 1
120 EXHAUST FILTER 4 4
121 O-RING, EXHAUST FILTER 4 4
125 FILTER SPRING 4 4
126 SLOTTED CHEESE HEAD SCREW 4 4
136 GASKET, SERVICE COVER 1 1
137 SEALING RING 2 2
138 ALLEN BOLT 2 2
139 SERVICE COVER 1 1
140 ALLEN BOLT 4 4
141 GASKET, SEPARATOR COVER 1 1
142 SEPARATOR COVER PLATE 1 1
143 SEALING RING 4 4
144 PERFORATED METAL SCREEN 2 2
145 STRAINER, BAFFLE 1 1
150 GASKET, EXHAUST COVER 1 1
152 SEALING RING 4 4
153 EXHAUST THREADED COVER 1 1
155 ALLEN BOLT 4 4
156 OUTLET SCREEN 1 1
159 EXHAUST VALVE ASS’Y (159.1~ 159.6) 4 4
159-1 EXHAUST VALVE FIXED BOLT 4 4
159-2 EXHAUST VALVE WASHER 4 4
159-3 EXHAUST VALVE SPRING 4 4
159-4 EXHAUST VALVE PLATE 4 4
159-5 EXHAUST VALVE LOCK NUT 4 4
159-6 EXHAUST VALVE SEAT PLATE 4 4
163 ALLEN BOLT 2 2
164 SEALING RING 2 2
168 O-RING, VALVE COVER PLATE 1 1
169 VALVE COVER PLATE 1 1
175 PLUG 1 1
176 HEX NUT 1 1
177 STUD BOLT 1 1
185 GASKET, CYLINDER 1 1
186 ALLEN BOLT 5 5
187 SPRING LOCK WASHER 5 5
189 STUD 2 2
190 SPRING LOCK WASHER 2 2
191 HEX NUT 2 2
205 SIDE COVER PLATE 1 1
206 GASKET, SIDE COVER PLATE 1 1
207 ALLEN BOLT 12 12
208 SEALING RING 12 —
218 SOCKET 1 —
219 STRAIGHT HYDRAULIC FITTING 1 —
220 STRAIGHT HYDRAULIC FITTING 2 2
221 BSLM HYDRAULIC FITTING 1 1
221S-1 SEALING RING FOR 221 1 1
221S-2 SEALING RING FOR 221 1 1
222 BSLM HYDRAULIC FITTING 2 1
222S SEALING RING — 2
222S-1 SEALING RING FOR 222 2 —
223 ELBOW HYDRAULIC FITTING 1 —
230 OIL TUBE (160: A) (250: A-1) 1 1
231 OIL TUBE (160: B) (250: B-1) 1 1
232 OIL TUBE (160: A-1) (250: B-2) 1 1
ITEM
# DESCRIPTION
160
QTY
250
QTY
233 BSLM HYDRAULIC FITTING 1
233S-1 SEALING RING FOR 233 1
233S-2 SEALING RING FOR 233 1
234 OIL TUBE (A-2) — 1
237 BLT HYDRAURIC FITTING — 1
240 COOLING SPIRAL 1 —
241 RADIATOR — 1
242 COVER( FRONT), RADIATOR — 1
243 COVER( REAR), RADIATOR — 1
250 INLET FLANGE,LOWER HOUSING 1 1
251 CHECK VALVE PLATE 1 1
252 CHECK VALVE GUIDE 1 1
253 O-RING, CHECK VALVE PLATE 1 1
254 CHECK VALVE SPRING 1 1
255 O-RING, IN-LET PART 2 2
260 INLET FLANGE, UPPER HOUSING 1 1
261 INLET SCREEN (CONICAL) 1 1
265 ALLEN BOLT 4 4
266 SPRING LOCK WASHER 4 4
270* PLUG (KVAH VERSION ONLY) 1 1
275* OIL RETURN VALVE (KVAH VERSION ONLY) 1 1
275S* SEALING RING (KVAH VERSION ONLY) FOR 275* 1 1
285**/*** OIL RECIRC SCREW (KVA AND ORL TO INLET VERSION) 1 1
286**/*** BSLM HYD. FITTING (KVA AND ORL TO INLET) 1 1
286** BANJO FITTING (FOR ORL TO INLET ONLY) 1 —
285S-1** SEALING RING (KVA AND ORL TO INLET) FOR 285** 1 1
285S-1**/*** SEALING RING (KVA AND ORL TO INLET) FOR 285** 1 —
285S-2** SEALING RING (KVA AND ORL TO INLET) FOR 285** 3 3
285S-2**/*** SEALING RING (KVA AND ORL TO INLET) FOR 285** 1 —
290** OIL RETURN TUBE (ORL TO INLET ONLY) 1 1
291** ELBOW HYDRAULIC FITTING (ORL TO INLET ONLY) 1 1
295S*** SEALING RING (KVA VERSION ONLY) FOR 295** 2 2
295*** OIL RETURN VALVE (KVA VERSION ONLY) 1 1
296*** BANJO FITTING (KVA VERSION ONLY) 1 1
297*** OIL RETURN TUBE (KVA VERSION ONLY) 1 1
300 MOTOR MOUNTING BRACKET (IEC) 1 1
301 STUD 3 3
302 SPRING LOCK WASHER 3 3
303 HEX NUT 3 3
310 COUPLING SET (310 ~313) — 1
311 COUPLING HALF, PUMP SIDE 1 1
312 CONNECTION BOLT WITH RUBBER BOOT 6 6
312.3 RUBBER BOOT — 6
313A RUBBER BOOT 6
313 COUPLING HALF, MOTOR SIDE — 1
314 HEXAGON HEAD SCREW FOR 50322B 5 5
316 SET SCREW ( PUMP SIDE) 2 2
317 SET SCREW ( MOTOR SIDE) 2 2
321 PUMP SHAFT END FAN 1 1
322 MOTOR SHAFT END FAN 1 1
340 FAN HOOD 1 —
341 HEXAGON HEAD SCREW 3 3
345 FAN COVER — 1
359 ALLEN BOLT — 4
360 ALLEN BOLT — 4
390 ADAPTER FOR EYE BOLT 1 1
391 EYE BOLT 1 1
392 SPRING LOCK WASHER 1 1
393 HEXAGON HEAD SCREW 1 1
400 MOTOR (IEC) (160: 50HZ) (250: 60HZ) 1 1
400,3 MOTOR FAN (IEC) 1 1
400,4 MOTOR FAN COVER (IEC) 1 1
401 HEXAGON HEAD SCREW 4 4
402 SPRING LOCK WASHER 4 4
415 HEX NUT 1 1
416 SLOTTED SET SCREW 2 2
417 SLOTTED SET SCREW — 1
419 SLEEVE 1 1
421 RUBBER FOOT 3 3
423 SPRING LOCK WASHER — 1
425 WASHER 1 1
470* BSLM HYDRAULIC FITTING 1 1
470S*-1 SEALING RING FOR 470 1 1
470S*-2 SEALING RING FOR 470 1 1
471* OIL TUBE(C) 1 1
473* FITTING 1 1
474* GAS BALLAST 1 1
477* BALL VALVE 1 1
600 MOTOR(NEMA) 1 1
600.3 MOTOR FAN(NEMA) 1 1
600.4 MOTOR FAN COVER(NEMA) 1 1
601 ALLEN BOLT (NEMA) 4 4
602 SPRING LOCK WASHER(NEMA) 4 4
610 MOTOR MOUNTING FLANGE (NEMA) 1 1
612 COUPLING SET (311 + 312 + 613), NEMA 1 —
613 COUPLING HALF, MOTOR SIDE(NEMA) 1 1
622 MOTOR SHAFT END FAN FOR NEMA MOTOR 1 1
623 COLLAR FOR FAN(# 622), FOR NEMA MOTOR 1 —

18
KVA400C EXPLODED VIEW DRAWING
NOTES: x = KVAH xx = Oil return line to inlet xxx = KVA

19
KVA400C PARTS LIST
ITEM
# DESCRIPTION QTY
1 CYLINDER 1
4 STUD 4
5 SET SCREW 6
9 STUD 6
15 ROTOR 1
18-1 SLEEVE, BEARING 2
18-2 SLEEVE, BEARING 2
22 VANE 3
25 A-END PLATE, MOTOR SIDE 1
26 B-END PLATE, FAN SIDE 1
30 BEARING 2
35 SHAFT SEAL, VITON 4
46 PLUG ( FOR KVA TYPE) 1
47 PLUG 1
50 O-RING, END PLATE 2
53 HEXAGON HEAD CAP SCREW 10
54 SPRING LOCK WASHER 12
56 HEX NUT 2
60 TAPER PIN 4
65 A-SHAFT KEY, MOTOR SIDE 1
66 B-SHAFT KEY, FAN SIDE 1
75 OIL SUMP 1
79 SHEET METAL BAFFLE 1
83 OIL SIGHT GLASS 1
84 GASKET, OIL SIGHT GLASS 1
88 PLUG, OIL FILL 1
89 O-RING, OIL FILL PLUG 1
95 PLUG, OIL DRAIN 1
96 O-RING, OIL DRAIN PLUG 1
99 PIPE NIPPLE 1
100 OIL FILTER 1
105 OIL SUMP COVER PLATE 1
106 GASKET, OIL SUMP COVER 1
107 ALLEN BOLT 8
108 SEALING RING FOR OIL SUMP COVER PLATE 8
115 EXH. FILTER BRACKET, UPPER 1
116 EXH. FILTER BRACKET, MEDIUM 1
117 EXH. FILTER BRACKET, LOWER 1
120 EXHAUST FILTER 8
121 O-RING, EXHAUST FILTER 8
125 EXH. FILTER SPRING ASSEMBLY 8
126 SLOTTED CHEESE HEAD MACHINE SCREW 8
136 GASKET, SERVICE COVER 1
137 SEALING RING 2
138 ALLEN BOLT 2
139 SERVICE COVER 1
140 ALLEN BOLT 8
141 GASKET, SEPARATOR COVER 1
142 SEPARATOR COVER PLATE 1
143 SEALING RING 8
144 PERFORATED METAL SCREEN 2
145 STRAINER, BAFFLE 1
150 GASKET, EXHAUST COVER 1
152 SEALING RING 4
153 EXHAUST COVER (THREADED) 1
155 ALLEN BOLT 4
156 OUTLET SCREEN 1
159 EXHAUST VALVE ASS’Y( 159.1~ 159.6) 7
159.1 EXHAUST VALVE FIXED BOLT 7
159.2 EXHAUST VALVE WASHER 7
159.3 EXHAUST VALVE SPRING 7
159.4 EXHAUST VALVE PLATE 7
159.5 EXHAUST VALVE LOCK NUT 7
159.6 EXHAUST VALVE SEAT PLATE 7
163 ALLEN BOLT 2
164 SEALING RING 2
168 O-RING, EXH. VALVE COVER PLATE 1
169 EXH. VALVE COVER PLATE 1
175 PLUG 1
176 HEX NUT 1
177 STUD BOLT 1
185 GASKET, CYLINDER 1
186 ALLEN BOLT 8
187 SPRING LOCK WASHER 8
205 OIL SUMP SIDE COVER PLATE 1
206 GASKET, OIL SUMP SIDE COVER PLATE 1
207 ALLEN BOLT (SOCKET HEAD CAP SCREW) 9
208 SEALING RING 9
224 BSLM, HYDRAULIC FITTING 4
224S-1 SEALING RING FOR 224 4
224S-2 SEALING RING FOR 224 4
225 BSLM, HYDRAULIC FITTING 2
225S SEALING RING FOR 225 2
226 BSLM, HYDRAULIC FITTING 1
226S SEALING RING FOR 226 2
230 OIL TUBE (A) 1
ITEM
# DESCRIPTION QTY
231 OIL TUBE (B-1) 1
232 OIL TUBE (B-2) 1
233 OIL TUBE 1
236 BSLM, HYDRAULIC FITTING 1
236S SEALING RING 1
238 HEX NUT 1
239 SPRING LOCK WASHER 1
241 OIL COOLER (TOP& BOTTOM OPENING) 1
241 OIL COOLER (STD) 1
250 INLET FLANGE, LOWER HOUSING 1
251 CHECK VALVE PLATE 1
252 CHECK VALVE GUIDE 1
253 O-RING, CHECK VALVE PLATE 1
254 SPRING, CHECK VALVE 1
255 O-RING, INLET FLANGE 2
258 RUBBER BALL 1
260 INLET FLANGE, UPPER HOUSING 1
261 INLET SCREEN (CONICAL ) 1
265 ALLEN BOLT 3
266 SPRING LOCK WASHER 3
270* PLUG (FOR KVAH VERSION ONLY) 1
275* OIL RETURN VALVE (FOR KVAH VERSION ONLY) 2
275S*(276*) SEALING RING (FOR KVAH VERSION ONLY) FOR 275 2
285** OIL RECIRC SCREW (FOR ORL TO INLET ONLY) 1
286** BSLM HYD. FITTING (FOR ORL TO INLET ONLY) 1
285S-1** SEALING RING FOR 285 (ORL TO INLET) 1
285S-2** SEALING RING FOR 285 (ORL TO INLET) 1
290** OIL RETURN TUBE (FOR KVA ONLY) 1
291** BSLM HYDRAULIC FITTING ( FOR KVA ONLY) 1
291S** SEALING RING, FOR 291 (FOR KVA ONLY) 2
300 MOTOR MOUNTING BRACKET 1
302 SPRING LOCK WASHER 4
303 HEX NUT 4
310 COUPLING SET( 310 ~313) 1
311 COUPLING HALF, PUMP SIDE 1
312 CONNECTION BOLT WITH RUBBER BOOT 8
313 COUPLING HALF, MOTOR SIDE 1
316 SET SCREW (PUMP SIDE) 2
317 SET SCREW ( MOTOR SIDE) 2
320 SPACER FOR FAN 1
321 FAN 1
327 LOCKING DISC 1
328 HEX HEAD CAP SCREW 1
329 SPRING LOCK WASHER 1
350 FAN SUPPORT RING (PUMP SIDE) 1
351 FAN SUPPORT RING (RADIATOR SIDE) 1
352 FAN GUARD 1
353 ALLEN BOLT 4
354 HEX NUT 4
355 FAN SUPPORTING BOLT 5
356 FAN SUPPORTING BOLT 1
357 HEX NUT 11
358 SPRING LOCK WASHER 11
359 MOUNTING BRACKET FOR RADIATOR 1
360 CHEESE HEAD CAP SCREW 12
391 EYE BOLT 1
400 MOTOR (IEC)-60HZ 1
400 MOTOR (IEC)-50HZ 1
400.3 MOTOR FAN BLADE 1
400.4 MOTOR FAN COVER 1
401 HEXAGON HEAD SCREW 4
402 SPRING LOCK WASHER 4
415 HEX NUT 2
416 STUD 2
417 SLOTTED SET SCREW 2
419 SPACER FOR FOOT, FOR IEC MOTOR 2
420 SLOTTED SET SCREW 1
421 RUBBER FOOT 5
423 SPRING LOCK WASHER 2
425 WASHER 2
430 NAME PLATE 1
431 DIRECTIONAL ARROW LABEL 1
470* ELBOW, HYDRAULIC FITTING 1
470S*-1 SEALING RING 1
470S*-2 SEALING RING 1
471* TUBE(C) 1
473* FITTING 1
474* GAS BALLAST 1
477* BALL VALVE 1
600 MOTOR ( NEMA) - 60HZ 1
600.3 MOTOR FAN BLADE 1
600.4 MOTOR FAN COVER 1
601 HEX HEAD BOLT 3
602 SPRING LOCK WASHER 3
603 ALLEN BOLT 4
610 MOTOR MOUNTING FLANGE ADAPTER (NEMA) 1

20
KVA630C EXPLODED VIEW DRAWING
NOTES: x = KVAH xx = Oil return line to inlet xxx = KVA
