Tutti Bambini BARCELON 211095 User manual

SAFETY ADVICE 4
1) The bottom mattress base position is the safest. You should always use the
cot in this lowest position as soon as your baby is old enough to sit up.
2) Never leave anything in the cot or attached to the sides, that could provide
a foothold, or present a danger of strangulation or suffocation.
3) When choosing a mattress, ensure that the height between the surface of
the mattress and the top edge of the cot side is at least 50cm for the
lowest position and 20cm in the upper position.
4) There should never be a gap of more than 3cm between the mattress and
the sides or ends of the cot.
5) Regularly check that nuts & bolts are secure or evidence of damage, which
could make the bed unsafe or cause Lose fittings can result in snagging
clothes or cords posing a risk of strangulation.
6) The maximum height (i.e. upper surface) of any mattress fitted must not
exceed the line engraved on the outside of the cot leg.
7) Do not put cot in close proximity to heat sources e.g. open fires, radiators,
gas and electric heaters etc.
8) Clean with a damp cloth. Do not use abrasives or bleach.
9) Warning: your children’s safety is your responsibility.
10) If you leave the child in the cot, always make sure that the dropside is in
the highest position
11) WARNING:Do not use the cot if any part is broken,torn or missing and use
only spare parts approved by the manufacturer.
12) WARNING:Do not use more than one mattress in the cot.
13) To prevent child injury from falls,the cot should not be used when a child
can climb out from the cot.
14) Excessive Chewing may damage the wood and cause splintering.If any part is
damaged,stop using the cot untill the correct part has been replaced.
15) Warning: Be aware of the risk of open fire and other sources of strong heat,
such aselectric bar fires, gas fires, etc. in the near vicinity of the cot.
16) all assembly fittings should always be tightened properly and that fittings
should be checked regularly and retightened as necessary.
THIS PRODUCT HAS BEEN DESIGNED AND MANUFACTURED TO MEET BS
EN716-1 & 2: 2008
NEW SOUTHGATE LONDON N11 1QD
Office tel: [phone] Fax: [phone]
Code no: 211095
IMPORTANT RETAIN FOR FUTURE
REFERENCE- READ CAREFULLY

12 -A
2 -B
3
4
5
List of parts
AND DOWN
PUSH IN
UP
Step 4
NOTICE: All assembly fittings should always be tightened properly and that care should
be taken that no bolts are loose, because a child could trap parts of the body or clothing
(eg strings, necklaces, ribbons, for babies dummies), which could pose a risk of
strangulation. Unpack the cot and identify all the components against the parts and
fittings list shown above. Do not discard any packing until you are sure you have
indentified all the components. Make sure you have: 1) fixed Left end; 2) A & B
Detachable Right End; 3) Drop side rail 4)Fixed Side rail ; 5) Mattress Base; A) 12 x
89mm Bolts; B) Preattached Long barrel Nut and 2 Bolts ( Located in Detachable end) C)
12 Barrel Nuts, D) Allen Key.
ASSEMBLING INTO A COT 2
The help of an assistant will aid assembly. Do not tighten screws until assembly
is complete.
Step 1: Fixed Side Assembly.
Take the 2 Ends and connect to Fixed Side Rail 4
using 2 X A Bolts on each End and 2 x C Barrel Nuts
which are inserted underneath side rail bar and
aligned to the holes of the side rail - The line on one
end of the nut indicates the position of the threaded
hole. It is advisable to push the nut into its
ppropriate hole and check for correct alignment
before attempting to insert any Bolts
Step 2: Mattress Base Assembly.
Place Mattress Base no 5 on one of the three
base positions using 4 x A bolts and 4 x C
Barrel Nuts on Each end and align the bolts to
the nuts Remember bottom mattress base
position is the safest. You should always use the
cot in this lowest position as soon as your baby
is old enough to sit up
Step 3: Drop side Assembly.
Take drop side rail 3 and carefully align the
two metal pins located on each side of the
rail to the two channels located on each end.
When pins are fully engaged to cot end,
begin to tighten all bolts using Allen Key
ref D
YOUR COT IS NOW READY FOR USE
Step 4: Operating the Drop side rail.
With your hand holding the centre of the
rail, lift rail upwards. With the outside of
your leg pushed against the centre of the
lower part of the rail, push inward and at
the same time push hand down until the
drop side rail is lowered. To raise rail, place
hand in centre of rail and push upward.
If you leave the child in the cot, always
make sure that the dropside is in the
highest position.
ASSEMBLING INTO A BED 3
Remove Fixed and Drop sides 3 & 4 from
the cot by loosening all the bolts.. With
Allen Key ref D, detach ends A & B of
Cot Ends 2 by removing the two sets of
short bolts located on the drop side ends
and allowing you to remove item B.
You will now be able to detach part A and
part B of Ends 2 and remove the 2 long nut
sitting inside the drop side legs You have
now made ready the lower part of the bed.
Reposition the mattress base so that it is
now level to the new position for the use as
a bed.
YOUR BED IS NOW READY FOR USE
IMPORTANT- RETAIN FOR FUTURE REFERENCE- READ CAREFULLY.
Qty
ID # 12 pc
B1 set
ID # Qty
A
Hardware list
12 pc
Qty
C
ID #
Qty
ID # 1 pcD
M6*89MM
ON SPLIT COT BED END NO 2)
( PRE ATTCHED
