TwinMOS USB 2.0 Mobile Disk User manual

USB2.0 Mobile Disk
All specifications and information are subject to changes without further notice 1
USB 2.0 Mobile Disk
Quick Installation Guide
1. System Requirements
1. Windows 98SE / ME / 2000 /XP
2. Mac OS 9.X or above
3. Linux Kernel 2.4 or above.
2. Driver Installation
2-1 Driver Installation for Windows2000 / ME / XP, Mac OS9.X or above :
1. Insert the Mobile Disk into the USB port of a computer.
2. The device will be recognized automatically by system.
3. Double-click “My Computer” from the desktop, a new “Removable Disk” can be
found in that window.
2-2 Driver Installation for Windows 98SE Driver Installation
Windows 98SE does not support Mass Storage Driver, therefore, please install device
driver before using the Mobile Disk.
1. Unplug the Mobile Disk from the computer.
2. Please visit our web site http://www.twinmos.com to download the device driver.
3. Please find “Type (XXX)” on the USB connector and download the device driver
according to the type of Mobile Disk from website .
4. Decompress (unzip) the “zipped” file to a target folder.
5. Locate and double click the program .
6. Click “Install” button and follow the program’s instruction to complete the
installation.
7. Please insert the device.
8. Double-click “My Computer” from the desktop, a new “Removable Disk” can be
found in that window.
9. If the device was not correctly recognized by the system, please unplug it and
restart the computer, than insert it again.
2-3 Driver Installation for Linux Kernel 2.4 or above :
Tracking NO Download the device driver according
to the type of Mobile Disk from
website .
XXXXXXXXXXXX XXX

USB2.0 Mobile Disk
All specifications and information are subject to changes without further notice 2
Please follow the instructions to “mount” the device
1. Execute cd / etc /sysconfig / ( cat /etc/sysconfig/hwconf | more )
2. Check device information in file hwconf and write down the mount point.
3. Create new folder in /mnt , for example: “mkdir /mnt/mobile disk”.
4. Then, execute mount /dev/sda1/mnt/mobile disk (if the mount point was .dev/sda).
3. How to unplug the Mobile Disk safely
Notice:
(a) Do not remove the Mobile Disk while the LED is still on or flashing. Doing so, it may cause
unrecoverable damage to the files or the device itself. Users may use the “Format” utility to
recover the device; however, the data will be lost.
(b) To prevent data lose or damage the device, please follow the procedures to eject the device
safely.
3-1 Windows ME / 2000 / XP: Hardware Safe Removal Procedures
1. Locate the “Safely Remove Hardware” icon from the system task bar and
double-click it
2. Select the device to unplug from the “Safely Remove Hardware” window and click
the “Stop” button.
3. Select the device from the “Stop a Hardware Device” window and click “OK”.
4. Now it’s safe to unplug the Mobile Disk.
3-2 Windows 98SE: Hardware Safe Removal Procedures
1. Please make sure the system is not accessing the Mobile Disk (reading, writing , or
opening files) before removal. If you were not sure about the operation status, please
log out from current user session or shut down the computer.
2. Unplug the Mobile Disk from USB port.
4. Application Software download and installing
1. Please visit our web site http://www.twinmos.com to retrieve the
application software for Mobile Disk and User’s manual.
2. For software installation and usage please reference the user’s manual.
-- END --
