Twister T4 User manual

USER MANUAL
PN: 21-0028_REV02
TWISTERTRIMMER.COM

TWISTERTRIMMER.COM
Front Cover: T4 standard speed control ediঞon on a Trim Saver stand.

TWISTERTRIMMER.COM pg | 1
TABLE OF CONTENTS
Important Safety Informaঞon
Machine Overview
Stand Conversion
Iniঞal Setup
Control Panel Overview
Operaঞon
Disassembly
Reassembly
Inspecঞons
Cleaning
Maintenance
Storage
Troubleshooঞng
Warranty Informaঞon
Specicaঞons
Spare Parts and Accessories
Conveyor and Rails Guide
Contact Us
2
5
9
11
19
20
24
33
40
44
46
60
61
68
70
72
75
76

TWISTERTRIMMER.COMpg | 2
IMPORTANT SAFETY INFORMATION
This manual is for the Twister T4 Trimmer. In this manual,
the T4 Trimmer will simply be referred to as the T4.
The T4 is a high-speed cuমng machine requiring special
safety precauঞons to be pracঞced during operaঞon,
cleaning, and maintenance to reduce the risk of personal
injury. Read this manual, including all important safety
informaঞon, danger, warning, and cauঞon signs before
using the T4.
Keirton is conঞnually improving all its products. As
a result, engineering changes are someঞmes made.
If operaঞon or appearances di@er from this manual, please contact Keirton technical support for
assistance (see Contact Us on page 76).
Do not allow anyone to use the T4 without this manual. A rst ঞme user of the T4 should obtain
proper training or instrucঞon from this manual.
General Safety Information
• Do not operate, clean, or conduct maintenance on the T4 while ঞred or under the
inuence of drugs, alcohol, or medicaঞons.
• Safety glasses, dust masks, and ear protecঞon must be worn when operaঞng the T4.
• Do not wear loose clothing or jewellery when operaঞng, cleaning, or conducঞng
maintenance on the T4.
• Conne long hair when operaঞng, cleaning, or conducঞng maintenance on the T4.
• Do not move, disassemble, reassemble, clean, or conduct maintenance on the T4 while
power is connected to the machine.
• Ensure all protecঞve covers are installed and hands are clear of the machine before
plugging in the T4.
CARELESS USE OF THE T4
OR OPERATING IT WITHOUT
READING THE INSTRUCTIONS
AND ACCOMPANYING DANGER,
WARNING, AND CAUTION
NOTICES MAY RESULT IN
SERIOUS OR FATAL INJURY.
DANGER
!

TWISTERTRIMMER.COM pg | 3
IMPORTANT SAFETY INFORMATION
• Ensure the T4 is connected to a vacuum before connecঞng either to power.
• Do not reach inside the tumbler while the T4 is plugged in.
• Keep body parts away from the moving parts of the T4.
• Keep the T4 well venঞlated to prevent overheaঞng.
• Do not allow water to collect on the ground around the T4. This could cause a slipping
hazard.
• The T4 is heavy. Always use proper li[ing technique. If necessary, use two people to li[.
• Subsঞtuঞng factory parts with third-party parts may void warranty or result in bodily
harm or damage to the T4.
• Do not remove safety labels from the machine. Replace any safety labels if they
become damaged or obscured.
• Keep visitors and children a safe distance from the T4.
Connection and Electrical Safety Information
• The T4 standard ediঞon with speed control requires a circuit breaker with the following
specicaঞons:
• 15A, 120V, 60Hz (North America)
• 10A, 230V, 50Hz (Europe)
• The T4 must be used in connecঞon with a properly grounded receptacle. Refer to the
specicaঞons (starঞng on page 70) to determine the correct electrical requirements.
• Observe all applicable building and electrical codes.
• Do not overload outlets or extension cords as this can result in re or electric shock.
• Do not use extension cords for the trimmer with a diameter narrower than 14AWG.
• Do not use extension cords for the trimmer longer than 50’ (15M).
• To power down the T4, switch o@the motors via the control panel before unplugging the
machine.
• The control box is not water ঞght. Always remove the control box before cleaning to
avoid water damage and electric shock.

TWISTERTRIMMER.COMpg | 4
Operation Safety Information
• Ensure the T4 is fully assembled and all guards, covers, and shrouds are in place before
operaঞon.
• Conduct all pre-operaঞon inspecঞons listed under Step 1: Inspect the T4 on page 20
before operaঞng the T4.
• Never let the T4 run unaended.
•
Only place plant maer in the T4. Do not put foreign objects in the T4. Doing so
may cause bodily harm or damage to the machine.
Maintenance Safety Information
• Conduct regular maintenance on the T4.
• Do not aempt to service electrical components on the T4 yourself. Opening or
removing covers may expose you to dangerous voltage and possible re or
electric shock.
• Do not aempt maintenance not covered in this manual unless directed by Keirton
technical support.
• Some repair or damage will require a qualied service technician who is trained in
machinery maintenance, service, and repair.
• Improper adjustments may result in damage to the machine.
• Replacement parts are specic to the T4 and must only be purchased from an authorized
dealer. Failure to comply may void warranty, cause bodily harm, and/or damage to the
machine.
IMPORTANT SAFETY INFORMATION

TWISTERTRIMMER.COM pg | 5
MACHINE OVERVIEW
Fig. 1
Fig. 2
SIDE PLATE
CONTROL BOX
LIFTING HANDLE TUMBLER
TUMBLER GUARD
BLADE BELT COVER
BLADE BELT
COVER BOLT
VACUUM SHROUD
ADJUSTMENT
CLICKER
BRUSH
VACUUM
SHROUD OUTLET
ADJUSTMENT BAR
LOCK KNOB
ADJUSTMENT
BAR

TWISTERTRIMMER.COMpg | 6
MACHINE OVERVIEW
Fig. 3
ROLLER
BRUSH END CAP
BLADE END PLATE
BLADE END CAP
VACUUM SHROUD
LOCK PIN
Fig. 4
CONTROL
BOX LOCK PIN
GAS SPRING
CONTROL BOX
LOCK KNOB
BLADE MOTOR
PULLEY
DRIVE WHEEL
BLADE BELT
HOPPER MAGNET
BLADE PULLEY
HOPPER PIN
CONTROL BOX
GUIDE PIN

TWISTERTRIMMER.COM pg | 7
MACHINE OVERVIEW
Fig. 5
Fig. 6
CONTROL PANEL
HELIX BLADE
CONTROL BOX
HOUR METER
POWER CABLE
DRIVE WHEEL
MOTOR
CONTROL BOX
SIDE PANEL
BED KNIFE
CONTROL BOX
SUPPORT BAR
T4 with the Trim Saver
TRIM SAVER
CYCLONE INLET
5” HOSE
HOSE CUFF
VACUUM
ATTACHMENT
COUPLING TRIM SAVER
STAND

TWISTERTRIMMER.COMpg | 8
MACHINE OVERVIEW
Fig. 7
T4 with the Leaf Collector
LEAF COLLECTOR
LEVELLING FEET
FILTER BAGS
LEAF
COLLECTOR
SWITCH
VACUUM
ATTACHMENT
COUPLING
LEAF COLLECTOR
STAND

TWISTERTRIMMER.COM pg | 9
STAND CONVERSION
Fig. 8
TURN OFF ALL MOTORS, THEN
UNPLUG THE T4 AND VACUUM
BEFORE CONVERTING THE
STAND.
DANGER
!
If upgrading from a Leaf Collector to a Trim Saver, the
Leaf Collector stand must be converted into one that
is compaঞble with the Trim Saver. To convert the Leaf
Collector stand:
1. Ensure the T4 and Leaf Collector are
unplugged and all motors have come to
a complete stop.
2. Unaach the T4 and vacuum
aachment coupling from the Leaf Collector
(see Step 1: Detach the Vacuum on page 24).
3. Remove all 12 bolts from the top of the Leaf
Collector (see Fig. 8).
4. Remove the top of the Leaf Collector (see Fig. 8).
5. Remove the impeller:
a. Loosen the impeller set screw (see Fig. 9).
b. Remove the impeller reverse threaded top bolt and washer (see Fig. 10).
Fig. 9

TWISTERTRIMMER.COMpg | 10
STAND CONVERSION
c.Pull out the impeller*(see Fig. 10).
6. Remove the four bolts aaching the Leaf Collector to the stand (see Fig. 11).
7. Remove the two bolts aaching the Leaf Collector switch to the stand.
8. Li[the Leaf Collector and switch out of the stand (see Fig. 12).
*If the impeller cannot be pulled out manually, use a pulley
puller (see Disassembly Tools on page 72).
Fig. 12
Fig. 10 Fig. 11
CLOCKWISE
ROTATION

TWISTERTRIMMER.COM pg | 11
To safely operate the T4, it must be aached to one of
two vacuums: the Trim Saver or Leaf Collector. Each
vacuum requires a di@erent procedure for iniঞal setup.
For a list of available vacuums, see Vacuums and Bypass
on page 74.
Trim Saver Setup
Step 1: Secure the Stand Placement
If using mulঞple T4s in tandem, it is recommended they be placed on Twister Rails. For a list of
available rails, see Rails and Adapters on page 73.
1. Set up the stand where it will operate:
• If using a single T4, simply place the stand where the T4 will operate (see
Recommended Placement on page 12).
• If using T4s in tandem:
i. Assemble the rails (see the
corresponding Twister
Rails manual).
ii. Set up the rails where the
T4s will operate (see
Recommended Placement
on page 12).
iii. Adjust the stands’ levelling
feet so the stands are at
their minimum height
(see Fig. 13).
iv. Place the stands side by
side on the rails.
DO NOT CONNECT THE TRIMMER
OR VACUUM TO POWER UNTIL
ALL INITIAL SETUP STEPS HAVE
BEEN COMPLETED.
DANGER
!
INITIAL SETUP
Fig. 13

TWISTERTRIMMER.COMpg | 12
Step 2: Attach the Vacuum Attachment Coupling
1. Pull out and rotate the adjustment bar
lock knobs so they are facing straight
down* (see Fig. 14). This is to prevent
them breaking when the T4 is rotated.
1. Carefully rotate the T4 onto its side so it
rests on the adjustment bar (see
Fig. 15).
2. Place a hose clamp over the top of the
vacuum aachment coupling (see Fig. 16).
*The adjustment bar lock knobs, if pulled out, can rotate
without loosening the knobs.
RECOMMENDED PLACEMENT
For best and safest operaঞon, place the T4 stand/rails:
• On level ground.
• Near an outlet.
• In a cool environment*
• With enough space to easily access the tumbler inlet and outlet.
• With enough space to set up the vacuum(s).
*It is highly recommended to operate the T4 in as cold of an environment as possible. Operaࢼ ng the T4
in colder environments will improve the machine’s performance and signi cantly reduce build up on the
machine.
INITIAL SETUP
Fig. 14

TWISTERTRIMMER.COM pg | 13
3. Slide the coupling over the vacuum shroud (see Fig. 16).
4. Tighten the hose clamp around the coupling and shroud.
5. Place another hose clamp over the free end of the coupling (see Fig. 17).
6. Slide the coupling adapter into the vacuum aachment coupling (see Fig. 17).
7. Tighten the hose clamp around the coupling and adapter.
INITIAL SETUP
THE T4 IS HEAVY. IF NECESSARY,
USE TWO PEOPLE TO LIFT.
WARNING
!
Fig. 15
Fig. 17Fig. 16

TWISTERTRIMMER.COMpg | 14
Step 3: Place the T4 on the Stand
1. Using two people, li[the T4 and place it so it securely sits in the top of the stand.
Step 4: Adjust the Tilt
1. Review Tilt Guidelines on page 18.
2. Adjust the ঞlt of the stand or rails to best suit the product being trimmed:
• If using a single T4, adjust the levelling feet to be higher on one side unঞl the
trimmer is at the desired angle (see Fig. 18). Then ঞghten the jam nuts (see Fig. 19).
• If using T4s in tandem, see the corresponding Twister Rails manual for ঞlt
instrucঞons.
Step 5: Connect the Vacuum
1. Assemble the Trim Saver (see the Twister T4 Trim Saver User Manual).
2. Slide a hose clamp around the unaached hose cu@on the cyclone to trimmer hose (see
Fig. 20).
3. Slide the cyclone-to-trimmer hose cu@over the vacuum coupling adapter (see Fig 20).
4. Tighten the hose clamp around the cu@and adapter.
INITIAL SETUP
Fig. 18 Fig. 19

TWISTERTRIMMER.COM pg | 15
Step 6: Align the Conveyors/Attach the Hopper
To safely feed product into the tumbler, Twister Conveyors or a T4 Hopper are required. For a list of
available conveyors, see Conveyors on page 72. If using conveyors:
1. Assemble the conveyors (see the corresponding Twister Conveyor manual).
2. Adjust the heights of the conveyors to match the heights of the T4 tumbler(s) (see the
corresponding Twister Conveyor
manual).
3. Place the closed end of the QC
Conveyor under the T4 outlet*(see Fig. 21).
4. Place the open end of the Feed
Conveyor inside the T4 tumbler without
the conveyor touching the tumbler**
(see Fig. 22).
*If using T4s in tandem, place the end of the Feed Conveyor
inside the rst machine’s tumbler.
**If using T4s in tandem, place the end of the QC Conveyor
under the last machine’s outlet.
INITIAL SETUP
Fig. 21
Fig. 22
Fig. 20 Trimmer stand not shown for clarity

TWISTERTRIMMER.COMpg | 16
INITIAL SETUP
If using the Hopper:
1. Align the circular indents under the hopper
outlet with the hopper pins on the T4 (see
Fig. 23).
2. Place the three rectangular indents at
the top of the hopper outlet against the
magnets on the T4 (see Fig. 23).
Leaf Collector Setup
Step 1: Assemble the Leaf Collector
1. Assemble the Leaf Collector (see the
Twister Leaf Collector Operaࢼng Manual and Parts List).
2. Aach the lter bags by either following the steps below or scanning QR. 1 to watch an
instrucঞonal video.
a. Loop the outer bag on the lter bag hooks. The nest thread bag is the outer bag.
b. Place the opening of the outer
bag around the Leaf Collector
outlet.
c. Unzip the top of the outer bag.
d. Loop the inner bag on the lter
bag hooks.
e. Place the opening of the inner
bag around the Leaf Collector
outlet.
f. Tighten the inner bag draw string
around the outlet.
Fig. 23
QR. 1

TWISTERTRIMMER.COM pg | 17
INITIAL SETUP
g. Zip the top of both bags.
Step 2: Secure the Stand Placement
1. Follow the steps under Step 1: Secure
the Stand Placement on page 11.
Step 3: Attach the Vacuum Attachment
Coupling
1. Follow steps 1–4 under Step 2: Aach
the Vacuum Aachment Coupling on
page 12.
Only follow steps 1-4.
To aach the T4 to the Leaf Collector,
the coupling adapter is not needed.
Step 4: Connect the Vacuum
1. Place a hose clamp over the free end of the vacuum aachment coupling (see Fig. 24).
2. Li[and place the T4 on top of the Leaf Collector stand so the coupling slides over the
Leaf Collector Inlet. The control box on the T4 should be on the on the same side as the
Leaf Collector outlet (see Fig. 24).
3. Tighten the hose clamp around the coupling and Leaf Collector.
Step 5: Adjust the Tilt
1. Review Tilt Guidelines on page 18 and follow the steps under Step 4: Adjust the Tilt on
page 14.
Step 6: Align the Conveyors/Attach the Hopper
1. Follow the steps under Step 6: Align the Conveyors/Aach the Hopper on page 15.
Fig. 24 Lower crossbar not shown for clarity

TWISTERTRIMMER.COMpg | 18
INITIAL SETUP
TILT GUIDELINES
Increasing the incline of the T4 will decrease the ll level of the tumbler and increase
throughput. For opঞmal performance, the T4 should be 1/3 full of product at all ঞmes
during operaঞon. When trimming a new product, it is normal to adjust the incline mulঞple
ঞmes to opঞmize product throughput.
