Twister T6 User manual

Version 1.0

TABLE OF CONTENTS
www.twistertrimmer.com
Important Safety Information
Component Overview
Initial Assembly
T6-Leaf Collector Parts List and Assembly
Setup and Operation
Leg Leveler
Bed Knife Clicker Controls
Bed Knife Adjustment
Tandem Setup
Tandem Leg Leveler
Tandem Disassembly
Maintenance
Inspection
Cleaning
Disassembly Instructions
Reassembly Instructions
Troubleshooting
Warranty
Electrical Specifications
Replacement Parts
1
2
2
4
5
5
6
6
7
9
9
9
10
10
11
13
16
17
18
19

SAFETY PRECAUTION
Operating the T6 without reading the instructions that accompany a cautionary label
i.e.: a “Danger”, “Caution”, “Warning” or “Notice” symbol, may result in serious or
fatal injury.
General
Connection
Operation
Maintenance
Do not expose the T6 control box to water. Always remove before cleaning.
Do not move, disassemble, clean or inspect the T6 while the power is connected to the machine.
Replacement parts are specific to the T6 and must be purchased from an authorized dealer only.
Substituting factory parts with third-party parts may result in bodily harm or damage to the T6.
If used, do not allow lubricants or mineral oils to collect on the ground. This could cause a slipping
hazard for the operator and others working in the area.
Keep everyone a safe distance from your work area. Never operate the T6 around children.
Do not remove safety labels. Replace any and all safety labels if they become damaged or obscured.
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
Like any home appliance, the T6 must be used in connection with a properly grounded receptacle.
Never plug in or power up the T6 with protective shrouds removed.
Do not use extension cords over 15m (50ft) in length to power up your T6.
The T6 comes from the manufacturer set with the optimal blade contact. The initial set up will show
assembly instructions to put the chute and hopper on.
Safety glasses must be worn at all times when operating the T6.
Do not operate the T6 while tired or under the influence of drugs, alcohol or medication.
Do not put objects in the tumbler that cannot be properly processed by the T6. Doing so may cause
bodily harm or damage to property. Plant matter only.
Operate the T6 in a well ventilated area to prevent overheating.
Never let the T6 run unattended.
Never conduct maintenance while the T6 is plugged in.
Ensure the T6 is powered off and the machine is unplugged before cleaning.
Do not change or modify any part of the T6 or its accessories. Doing so may cause bodily harm or
damage to property.
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
ĺ
IMPORTANT SAFETY INFORMATION
This document refers to the Twister T6 leaf trimming machine as the T6.
The T6 is a high-speed cutting unit that requires special safety precautions
to be practiced while in operation to reduce the risk of personal injury.
Improper use of the T6 may cause serious or fatal injury. Please read the
precautions and warning labels before using the T6.
Do not lend out or rent your T6 without this operating manual. A first time
operator should obtain proper instruction before using this machine.
www.twistertrimmer.com
1

1
COMPONENT OVERVIEW
www.twistertrimmer.com
2
32
NEVER PLUG IN MACHINE
WITH LID REMOVED
1
CHUTE
HOPPER
ADJUSTABLE LEGS
TANDEM PLATE
HANDLE
VACUUM INLET
CONTROL BOX CAM
CONTROL BOX
LEG ADJUSTER
INITIAL ASSEMBLY
TANDEM SLIDER
LID LATCHES
BELT COVER
REEL BLADE
LID
TUMBLER
BED KNIFE CLICKERS
BED KNIFE
REMOVE LID AND TUMBLER

2
3
4
www.twistertrimmer.com
3
INSTALL CHUTE THEN REINSTALL TUMBLER
INSTALL HOPPER
REINSTALL LID

3
2
1
T6-LEAF COLLECTOR (T6-LC) PARTS LIST
PART NO DESCRIPTION QTYREF
A
B
C
G
F
H
23-02-002101 4” HOSE CUFF
23-02-002102 4” HOSE X 8.25’, PVC
23-02-002103 5” BAG CLAMP, QUICK CONNECT
23-02-002104 BLACK FILTER BAG, 5” MOUNT, 200-400 MICRON
23-02-002105 WHITE FILTER BAG, 5” MOUNT, 70 MICRON
23-02-002106 VACUUM BASEPLATE
23-02-002107 CASTER
23-02-002108 1 HP VACUUM MOTOR
2
1
1
1
1
1
4
1
A
B
C
D
E
F
G
H
TOOLS NEEDED FASTENERS
D
E
A B
7/16” OR 10 MM WRENCH
1/2” OR 12 MM WRENCH
DESCRIPTION
A
B
REF
T6-LC ASSEMBLY
5/16-18
ACORN NUT
x4
5/16 FLAT WASHER
1/4-20 X 3/4
HEX HEAD SCREW
x4 x4
x4
ABC
1/4-20 X 3/4” HEX HEAD SCREW
5/16” FLAT WASHER
5/16” ACORN NUT
DESCRIPTION
A
B
C
REF
www.twistertrimmer.com
4

APPLY DISH SOAP OR ISOPROPYL ALCOHOL TO THE
INSIDE OF THE HOSE CUFF TO HELP TWIST IT ON.
34
SETUP AND OPERATION
12
1
LEG LEVELER
HIGHER LEG HEIGHT MEANS
FASTER THROUGHPUT
POWER ON/RESET
POWER OFF
3
2
www.twistertrimmer.com
5
INSTALL BLACK BAG FIRST

TOOLS NEEDED
BED KNIFE CLICKER CONTROLS
Light contact between the bed knife and reel blade is normal on a properly adjusted unit. Light contact is
indicated by a consistent light to medium ticking sound across the length of the blades. The design allows both
blades to receive a continual self-sharpening action. Blade contact is necessary to maintain a sharp cutting
edge and prolong the life of this machine. Having no contact will cause the blades to become dull.
2
1
BED KNIFE CLICKERS
BED KNIFE
REEL BLADE
TIGHTER CUT
www.twistertrimmer.com
6
The bed knife position has been adjusted and tested by the manufacturer, but it will need adjustments over time.
The amount of blade contact is adjusted by rotating the clickers which raise and lower the bed knife. Rotate the
clickers towards the “+” for a closer cut and away from the “+” for more clearance. Each clicker will adjust the bed
knife position at the point of that clicker. For example, clicking "+" at the hopper end will allow for a closer cut at
the hopper end. Care should be taken to ensure both clickers are adjusted evenly to make consistent contact
along the length of the bed knife.
To properly align the blades, rotate the clickers away from the “+” until you feel a resistance. This is maximum
clearance. Make sure both blades are clean then turn the T6 on (refer to the maintenance section for cleaning
instructions). It then takes about two full turns toward the “+” to start making blade contact. Make sure to rotate
both clickers simultaneously with each hand.
If contact is made at only one end, indicated by a ticking sound being louder at that end, back the corresponding
clicker out by rotating away from the ”+”. Then rotate the opposite clicker in towards the “+” to even out the bed
knife and begin engagement with the reel blade. When one click on each side evenly brings the bed knife into
contact with the reel blade, simultaneously rotate both clickers another few clicks closer.
BED KNIFE ADJUSTMENT

TOOLS NEEDED
1
2
TANDEM SETUP
3
4
5
3
FRONT AND BACK MACHINE
BACK MACHINE BACK MACHINE
FRONT MACHINE
FRONT MACHINE
4
3
www.twistertrimmer.com
7
The T6 is designed for quick setup to easily link multiple units for increased throughput.
3

5
6
7
BACK MACHINE
www.twistertrimmer.com
FRONT AND BACK MACHINE
When linking more than two machines, remove the chute, belt cover and hopper from middle machine(s)
8

MAINTENANCE
www.twistertrimmer.com
TANDEM LEG LEVELER
9
The T6 is a precision machine. It is essential that it is operated and cared for with this in mind. It has been
adjusted and tested by the manufacturer for optimal performance. However, at initial startup and at the begin-
ning of each use, it is important to inspect the machine for any damage, plant material buildup and check to
ensure the blades spin freely before operating.
It is also highly recommended to clean the machine at the end of every use and to keep the blades lubricated.
This will extend the life of the machine and the vacuum components, ensure performance of the machine and
make cleanup much easier. This is especially important if the machine is to be stored for extended periods of
time. Resins and other plant by-products will build up and harden, becoming difficult to remove.
Although the T6 may be run without lubrication, it is recommended to apply a lubricant such as Clear Cut to the
blades of the T6. Lubricant will limit plant material buildup and allow for easy cleaning. A thin coating prior to
and after each use, and especially prior to prolonged storage, will extend the life of the cutting surfaces and
ensure a smooth startup.
TANDEM DISASSEMBLY

MAINTENANCE
www.twistertrimmer.com
10
A thorough cleaning of the T6 and T6-LC should be performed after each use. Any resin buildup on the
machine attracts more resin, compounding the problem. Buildup can cause decreased performance, overheat-
ing and could trip your circuit breaker. Future cleaning also becomes more difficult if buildup is given a chance
to dry out and harden.
Use only a soft cloth and gentle cleaning solutions on the control box, belt and belt cover. All other compo-
nents can be simply wiped with isopropyl alcohol or a mild degreaser such as Simple Green. Soaking each
component (excluding the control box, belt and belt cover) in hot water will help release the resin. Pay particu-
lar attention to the reel blade and the bed knife which should be cleaned at least every 4 hours of operation or
more as needed. If the machine was kept adequately lubricated during operation, and has had sufficient
amounts of degreaser sprayed on it during pre-soak, then all debris will come off easily.
Any stubborn areas, such as the bed knife and reel blade, may require scrubbing with a stiff bristled plastic
brush or a plastic scraper (do not use a metal scraper). Plant matter buildup is the most obvious sign that
more attention is needed in a particular area. Such areas are good indicators of the machine needing more
lubricant during operation next time or more thorough soaking.
Disconnect the vacuum hose from the T6 and the T6-LC and remove any leaf debris from the vacuum inlet.
Remove and empty the leaf collection bags. Remove the screws that hold the inlet on the leaf collector and
spray inside the cowling with degreaser to loosen up any built-up plant matter. Scrub the vacuum cowling and
impeller with a plastic brush and rinse with cold water. Avoid spraying the control box and motor.
Dry the machine with a soft cloth or compressed air.
Inspection of the T6 should be conducted prior to each use following the upcoming disassembly section and
these steps:
ĺUnplug the T6 and the T6-LC and visually inspect all of the components for wear, damage and
plant matter buildup
ĺRemove the lid, hopper, belt cover, belt and the control box
ĺVisually inspect the belt for fraying and/or worn teeth
ĺ,nspect the control box pulley and the reel blade pulley for damage and ensure that they are firmly
attached
ĺVisually inspect the tumbler for damage and remove
NOTICE
Be careful when removing the tumbler. This is a delicate precision component of the
machine. If dropped or damaged, the machine’s performance will be greatly reduced or
completely disabled.
ĺVisually inspect the bed knife for damage and remove
ĺRotate the reel blade by spinning the reel blade pulley by hand and ensure that is able to spin freely
ĺVisually inspect for the reel blade for damage, looking for any nicks, dents or bends
Damage to the blades is very rare on a properly adjusted machine. Typically rocks, hard metallic objects or poor
adjustment is the cause of blade damage. Damage will not be corrected by the self-sharpening feature. These
circumstances are not covered under warranty and replacement parts will need to be purchased from an
authorized dealer. To avoid these repair costs, please maintain your T6 - keep the bed knife properly adjusted
and do not allow objects other than plant material into the tumbler.
NOTICE
Be careful when removing the tumbler. This is a delicate precision component of the
machine. If dropped or damaged, the machine’s performance will be greatly reduced or
completely disabled.
Cleaning
Inspection

3
1
34
56
2
DISASSEMBLY INSTRUCTIONS
3
www.twistertrimmer.com
11

7
8
9
3
www.twistertrimmer.com
12

3
1
2
REASSEMBLY INSTRUCTIONS
www.twistertrimmer.com
13
ENSURE LOBE IS
FACING DOWN

4
3
4
5
3
www.twistertrimmer.com
14

6
8
7
www.twistertrimmer.com
15

TROUBLESHOOTING
1. Tumbler makes grinding sound
Ensure the lid tabs and latches are intact and the tumbler gear is properly engaged. This could be due to
damage to the tumbler causing it to rub. This may require a replacement tumbler.
2. Control box is very hot
The control box can get very hot if the T6 is run for long periods - this is normal. The motor is thermally
protected and will turn off if it becomes too hot.
3. There is a high pitch squeal coming from the blades
This can indicate the machine needs bed knife adjustment, cleaning or Clear Cut lubricant. First, raise the bed
knife so there is no reel blade contact. If the squeal stops, readjust the bed knife to evenly contact the reel
blade. If squeal persists, clean the reel blade and bed knife. Finally, spray Clear Cut lubricant on the blades
to stop the squeal.
4. There is a high speed ticking sound coming from the blades
This is normal. A ticking sound is the blades making slight contact. This is necessary to maintain the
self-sharpening of the blades. If the sound is more than a ticking sound, stop and unplug the machine.
Check for adjustment and damage to the blades.
5. There is a lot of material buildup on the brush, tumbler and blades
Increase frequency and amount of lubricant applications or clean the machine. If the brush is old,
a replacement may be required.
6. Suction from the T6-LC seems weak
Ensure there is nothing blocking the vacuum inlet and the filter bags are clean. A clean or new collection bag
will keep performance high. Buildup can also accumulate in the leaf collector housing around the impeller,
reducing performance. Unplug the leaf collector and remove the inlet housing to clean inside impeller housing.
7. The material comes out of the machine under-processed
Ensure all components are on and suction is high. Ensuring the machine is level will keep material in the
tumbler and trim for a longer time. Some materials may benefit from a second pass through the machine or
slowing the product feed rate.
8. The tumbler does not spin
Check the tumbler for obstructions, ensure the lid is correctly installed and make sure the tumbler is placed
correctly in and is aligned to the gear.
9. Bed Knife is difficult to install
If the green locking tabs are hard to turn, first check the bed knife lobe has the point facing down. If the green
tabs are still difficult to turn, back the bed knife clickers away from the “+” until you feel a resistance. Turn the
clickers one full rotation towards the “+” and try again.
For all other issues, please call tech support at 1-888-254-3204 or [email protected] we will be
glad to help you.
Tech support is available from 7am-7pm PST, 7 days a week.
www.twistertrimmer.com
16

MANUFACTURER'S WARRANTY
The manufacturer will repair or replace, without charge, any parts proven defective in material or workmanship
for a period of 3 years.
The warranty period will begin on the date the machine is purchased by the initial purchaser. T6 warranty defects
can be remedied at any authorized service dealer or directly at the manufacturer. Any service work performed
and deemed valid due to a defective part will be free of charge. Keirton®reserves the right to use any
manufacture approved replacement part for warranty repair.
If warranty repair is required, please contact the manufacturer at 1-888-254-3204 or [e-mail] and
provide the following information:
1) Model and serial number
2) Proof of purchase date
3) A copy of the original Warranty Registration Card (unless registration was completed online)
4) Details of the defect or problem (including photos/video)
The machine or defective part then must be returned to the manufacturer for analysis and replacement.
Do not return the machine to the place of purchase for repair or warranty claims unless you have been
authorized by Keirton to do so. The place of purchase can only sell replacement parts and will not repair warranty
issues unless it is noted as an authorized repair dealer and has been authorized to work on your machine.
You may be denied warranty coverage if your machine has failed due to abuse, neglect, improper maintenance,
improper electrical connection, normal wear, accidental damage or unapproved modifications.
The manufacturer assumes no risk and shall be subject to no liability for damages or loss resulting from the
specific use or application made of the product. In no event will the manufacturer be liable for any special,
incidental or consequential damages (including loss of use, loss of profit and claims of third parties) however
caused, whether by negligence of the manufacturer or otherwise.
If you have any questions regarding you warranty rights and responsibilities, please contact the manufacturer.
The T6 is intended for use on legal aromatic herbs and hops. Please check all municipal, provincial/state and
federal laws and regulations before using the T6. Keirton®does not promote or condone the use of the T6 in any
way that may be deemed illegal.
Allow only persons who understand this manual to operate the T6. Keirton®claims no liability for any damage or
injury that result from the use of the T6 by persons who have not read and understood the cautions contained in
this manual or through any misuse of the T6. You are responsible for your safety while operating this machine -
please keep yourself safe!
To receive maximum performance and satisfaction from the T6, it is important that you read and understand the
safety and maintenance precautions before using the machine.
www.twistertrimmer.com
17

Additional Requirements
Extension Cord 14/3 AWG (minimum AWG size)
15m / 50ft max length
Connector (plug)
T6-LEAF TRIMMER T6-LEAF COLLECTOR
NEMA 5-15P NEMA 5-15P
ELECTRICAL SPECIFICATION
Input Voltage 115V
Motor 1HP
Amps (running) 7.5A (NA)
Amps (startup) 53A (NA)
Motor Speed 3450RPM
Airflow Capacity 1000 CFM
Static Pressure 6.45in of H20
Impeller 10in / 25.4cm
Inlet 4in / 10.1cm
Height 15in / 38.1cm
Weight 45lbs / 20.5kg
Circuit Breaker Required 15A / 120V
Connector (plug) NEMA 5-15P
Sound Rating 94 Db
Fused Yes, Thermally
T6-LC LEAF COLLECTOR
www.twistertrimmer.com
18
TWISTER T6
Input Voltage 115V
Current Draw 2A
Blade Motor 200W / 0.25HP
Cut Height .040in / 1mm
Discharge 4in / 10.1cm
Weight 42lbs /19kg
Shipping Weight (w/ T6-LC) 90lbs / 54.4kg
Length 30in / 76.2cm
Width 11in / 27.9cm
Height 10in / 25.4cm
Circuit Breaker Required 15A / 120V
Connector (plug) NEMA 5-15P
Fused Yes, Thermally
