Twisty Ride MOTORCYCLE & SCOOTER IPHONE 5 CHARGER User manual

www.twistyride.com
MOTORCYCLE & SCOOTER
IPHONE 5 CHARGER

www.twistyride.com 2
CONTENTS
Introduction..........................................................................3
What’s in the Box?...............................................................4
Fitting the iPhone Charger...................................................5
Caution ............................................................................5
Charger Cable .................................................................5
Fitting Instructions............................................................6
Safety Notices and Warnings..............................................8
Safety...............................................................................8
Maintenance and Security ...............................................8
Technical Specifications......................................................9
Warranty and Support .......................................................10
Warranty Cover.............................................................. 10
Exclusions from Warranty..............................................10
Your Legal Rights ..........................................................11
Limitation of Liability....................................................... 12
CE Marking....................................................................13
Copyright Notice................................................................ 14

www.twistyride.com 3
INTRODUCTION
Congratulations on your purchase and welcome to Twisty
Ride! This iPhone charger has been designed by Twisty
Ride to fit most motorcycles and scooter in order to keep
your mobile charged when riding.
This document provides details over the Motorcycle iPhone
Charger only. The other components of the Twisty Ride
iPhone case system are not discussed in this user guide. If
you have purchased other items such as the case or the
mount please refer to their associated documentations.
Visit us at www.twistyride.com to access our FREE
motorcycle journey planner as well as a range of expert tips
and specialised gear.

www.twistyride.com 4
WHAT’S IN THE BOX?
The following items are included with the motorcycle iPhone
charger:
- 6 mm battery ring clips
- 2 amp standard automotive blade fuse in its
waterproof lodging
- An on / off switch
- A power converter with LED operating indicator
- A waterproof “quick release” connector
- An iPhone connector with waterproof cap
- 4 zip ties

www.twistyride.com 5
FITTING THE IPHONE CHARGER
CAUTION
Extreme care must be taken when mounting the iPhone
charger on a motorcycle or scooter. Read this document
carefully before fitting the charger. The charger shall be
mounted in compliance with the relevant legislation and the
vehicle manufacturer's rules. Failure to mount the charger
correctly could result in damage to your vehicle and serious
injury to the vehicle rider and other road users. The iPhone
charger is fitted on your motorcycle or scooter at your own
risk. In doubt, always refer to a qualified professional.
CHARGER CABLE
The power cable shall be routed to avoid sharp bends,
abrasion, overheating, exhaust gases and battery acids and
other potential hazards. It must not be strained nor distorted
by e.g. excessive tightening of cable ties. Ensure that all
connections are mechanically and electrically safe and
secure. Keep away from heat sources and vehicle controls.
It must not hinder the operation of safety equipment nor
interfere with the driver’s ability to control the vehicle.
The charger has a total cable length of 3200 mm to the
quick release connector. It is long enough to accommodate
most types of motorcycles or scooters and be hidden within
the fairing. Excess length should be dealt with by rolling the

www.twistyride.com 6
excess cable into a 10 cm bundle and securing it to a fixed
part of the motorcycle using zip ties or electrician tape.
FITTING INSTRUCTIONS
In order to fit the charger, first pass the cable of the charger
through the fairing / body of the vehicle such that the
following is validated in order:
1. The quick release connector has enough leeway to
allow the rider to plug / unplug it easily from the
dashboard;
2. The quick release connector has enough leeway to
allow the iPhone connector to be plugged into the
iPhone without restricting any movement of the
handlebars;
3. The cable is as hidden from view as possible;
4. The cable is secured to the body of the vehicle
every 10 cm using zip ties or electrician tape;
5. The power converter is secured to the body of the
vehicle (zip ties / electrician tape);
6. The on / off switch is easily accessible from the
outside of the bike;
7. The on / off switch is secured to the body of the
vehicle (zip ties / electrician tape);
8. The battery connectors can reach their respective
battery poles (red to + and black to -).

www.twistyride.com 7
Once the cable is positioned correctly, it is time to connect
the battery connectors to the battery terminals. The steps
below must be followed in order:
1. Disconnect the negative terminal (black / -) of the
battery first. The negative terminal is the main
power link, so disconnecting it cuts off power to the
motorcycle. The positive terminal is usually red, so
disconnect the other one. To disconnect the
terminal, unscrew the bolt on it until the battery
cable can be removed and securely tucked away.
2. Disconnect the positive terminal (red / +) of the
battery.
3. Insert the red battery connector on the positive
terminal of the battery and screw the bolt back in
position. This will pinch both the original battery
cable and the charger cable. This means the
positive terminal is now connected.
4. Insert the black battery connector on the negative
terminal in a similar fashion. The motorcycle is now
operational again.
5. Verify that the LED indicator on the power
converter can be turned on and off by pressing the
on / off button.
6. Keep the charger turned off when not in use as it
would otherwise drain the battery.

www.twistyride.com 8
SAFETY NOTICES AND WARNINGS
SAFETY
Use of the iPhone case, RAM mount and charger for
navigation or other still means that you need to drive with
due care and attention.
MAINTENANCE AND SECURITY
Do not leave your iPhone device on view when you leave
your motorbike. It may become an easy target for thieves.
Take care of your charger and clean it correctly:
- Use a soft cloth to wipe the surface of your device;
do not use any liquid cleaners.
- If your device gets wet, dry it with a soft cloth.
- Do not disassemble the charger under any
circumstances. Doing so will invalidate your
warranty.
- Do not expose your charger to extreme high or low
temperatures, which can cause permanent
damage.

www.twistyride.com 9
TECHNICAL SPECIFICATIONS
- Water resistant at IP54 level
- Working temperature: -10°C to +55°C
- Input voltage: DC 6-12V
- Output voltage: DC 5V
- Output charging current: 1A
- Reverse Voltage Protection
- Short-Circuit Protection
- Overload Protection
- 6 mm battery ring clips
- 2 amp standard automotive blade fuse

www.twistyride.com 10
WARRANTY AND SUPPORT
WARRANTY COVER
Twisty Ride Ltd (“Twisty Ride”) warrants to you that the
Hardware will be free from defects in workmanship and
materials under normal use (“Defects”) for a period of one
(1) year from the date that the Hardware was first purchased
by you (“Warranty Period”). During the Warranty Period the
Hardware will be repaired or replaced at Twisty Ride’s
choice (“Limited Warranty”) without charge to you for either
parts or labour. This Limited Warranty covers the
replacement of the Hardware only. If the Hardware is
repaired after the Warranty Period has expired, the
Warranty Period for the repair will expire six (6) months after
the date of repair.
EXCLUSIONS FROM WARRANTY
The Limited Warranty does not apply to normal wear and
tear, does not apply when the Hardware is opened or
repaired by someone not authorized by Twisty Ride and
does not cover repair or replacement of any Hardware or
part thereof damaged by: misuse, liquids, proximity or
exposure to heat and accident, abuse, non-compliance with
the instructions supplied with the Hardware, neglect or
misapplication. The Limited Warranty does not cover
physical damage to the surface of the Hardware. This
Limited Warranty does not cover any software that may

www.twistyride.com 11
accompany or be installed on the Hardware. The Limited
Warranty does not cover the installation, removal or
maintenance of the Hardware or any costs related herewith.
YOUR LEGAL RIGHTS
- Some countries may not allow the exclusion or
limitation of damages. If any part of this Limited
Warranty is held to be invalid or unenforceable, the
remainder of the Limited Warranty shall
nonetheless remain in full force and effect.
- This Limited Warranty is the only express warranty
made to you and is provided in lieu of any other
express warranties or similar obligations (if any)
created by any advertising, documentation,
packaging, or other communications.
- Except for the Limited Warranty and to the
maximum extent permitted by applicable law,
Twisty Ride and its suppliers provide the Hardware
“AS IS AND WITH ALL FAULTS”, and hereby
disclaim all other warranties and conditions,
whether express, implied or statutory, including,
but not limited to, any (if any) implied warranties,
duties or conditions of satisfactory quality, of
fitness for a particular purpose, of reliability or
availability, of accuracy or completeness of
responses, of results, of workmanlike effort, of lack
of viruses, and of reasonable care and skill, all with
regard to the Hardware, and the provision of or
failure to provide support or other services,

www.twistyride.com 12
information, software, and related content through
the Hardware or otherwise arising out of the use of
the Hardware. Also, there is no warranty or
condition of quiet enjoyment, quiet possession, or
non-infringement with regard to the Hardware. This
exclusion does not apply to (i) any implied
condition as to title and (ii) any implied warranty as
to conformity with description.
- This Limited Warranty does not affect any legal
rights under applicable national legislation
governing the sale of consumer goods.
- This Limited Warranty cannot be transferred to any
other person.
LIMITATION OF LIABILITY
- Neither Twisty Ride Ltd nor its suppliers shall be
liable to you or to any third party for any damages
either direct, indirect, incidental, consequential or
otherwise (including in each case, but not limited
to, damages for the inability to use the equipment
or access data, loss of data, loss of business, loss
of profits, business interruption or the like) arising
out of the use of or inability to use the Hardware
even if Twisty Ride Ltd has been advised of the
possibility of such damages.
- Notwithstanding any damages that you might incur
for any reason whatsoever (including, without
limitation, all damages referenced herein and all
direct or general damages in contract or anything

www.twistyride.com 13
else), the entire liability of Twisty Ride Ltd and any
of its suppliers shall be limited to the amount
actually paid by you for the Hardware.
- Twisty Ride Ltd shall not be liable for (i) any fraud
on the part of its employees and/or agents; or (ii)
any fraudulent misrepresentation on the part of its
employees and/or agents.
- Notwithstanding the above, neither party’s liability
for death or personal injury resulting from its own
negligence shall be limited.
CE MARKING
This equipment complies with the
requirements for CE marking when used
in a residential, commercial, vehicular or
light industrial environment.

www.twistyride.com 14
COPYRIGHT NOTICE
© 2013 Twisty Ride Ltd
Any reproduction of the Twisty Ride logo or name is
governed by the laws standardized through the international
copyright agreements.
