Shell NewMotion Business Pro 2.1 User manual

Business Pro 2.1
Business Lite 2.1
Business Pro 2.1 Cable
Business Lite 2.1 Cable
3,7 - 22 kW
100 cm
VERSION 091NM20INT04 2020
INSTRUCTION MANUAL – EN | INSTALLATIEHANDLEIDING – NL | INSTALLATIONSANLEITUNG - DE | MANUEL D’INSTALLATION - FR

Table of contents / Inhoudsopgave /
Inhaltsverzeichnis / Table des matières
Instruction manual (EN)
Pages 4 - 19
Installatiehandleiding (NL)
Pagina 20 - 35
NewMotion
Business Pro 2.1
Business Lite 2.1
Business Pro 2.1 Cable
Business Lite 2.1 Cable
3,7 - 22 kW
Installationsanleitung (DE)
Pagina 36 - 52
Manuel d’installation (FR)
Page 53 - 69
NL: [phone]
BE: [phone]
DE: [phone]
FR : [phone]
UK: [phone]

INSTALLATIEHANDLEIDING – P4 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P4 | P4 091NM20INT04
EN NL FRDE
1.1 PRODUCT DESCRIPTION &
INTENDED USE
Thank you for choosing a NewMotion Electric Vehicle
(EV) Charge Point.
This charge point is intended to charge the batteries of
EVs compatible with IEC-61851 MODE3 denition and
requirements. Dedicated EV specic plugs will need to be
utilised. No adaptors, conversion adaptors or extension
sets for cables are allowed to be used. EVs and cables
used with this charge point should always be undamaged
and in their original state.
1.2 SAFETY WARNING + CAUTION!
The electrical system must be voltage-free during the
entire installation procedure. Failing to do so can lead to
serious injury or even death. The installation procedure
must be carried out by a trained electrician who works in
accordance with all relevant local laws and regulations.
Do not install in potentially explosive atmospheres and/
or zones with high electromagnetic radiation and/or in
ood-prone areas.
The charge point is connected to the electricity grid
and even if the equipment is switched o, hazardous
voltages may be present at the input terminals. Always
switch o the AC supply before starting any work on
the charge point and/or its installation. Do not carry out
any work in rainy conditions or when the humidity is
above 95%. The safety guidelines are intended to ensure
correct installation and usage. Any failure to comply with
the valid safety guidelines or instructions provided in this
manual may result in re, electrocution or severe injury.
The charge point is a product in Safety Class I and is
supplied with an earth terminal for protection. The AC
input clamps must be tted with an uninterruptible earth
for protection purposes. Ensure that the connection
cables are tted with appropriate Miniature Circuit
Breaker and Residual Current Device. Never replace a
protection component with another type. First check the
full installation to determine if that component can be used
with the existing installation components.
Before you switch on the charge point, check that
the available power source matches the conguration
settings of the product, as described in this manual.
Tripping of the RCD could be caused by an earth fault
or a defect relay. If, after resetting the RCD, the device
cannot be activated or immediately trips again; please
contact NewMotion or your installer.
1.3 LEGAL DISCLAIMER
This manual is created for you with care.
We however do not guarantee that all information is
complete, accurate and correct.
If you nd any unclarities or mistakes in this installation
manual, or if you have any feedback or suggestions in
general about this manual, please inform us at
[e-mail] and men-
tion the document version in the subject.
Please check our website www.newmotion.com for
the latest version of this manual.
We strongly advise you to have our product installed
by certied professionals. How our product should be
installed and used depends on local circumstances and
local and national regulation, which are not mentioned
in our manual. NewMotion is not responsible for any
loss or damage whatsoever caused – including without
limitation, any indirect, personal or consequential loss or
damage - arising from or in connection with the use of
this manual. Nor does NewMotion accept any liability for
any such loss or damage arising out of your reliance on
any information contained in this manual.
1. INTRODUCTION

INSTALLATIEHANDLEIDING – P5 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P5 | P5
EN NL FRDE
091NM20INT04
To ensure the charge point is ready for use, the owner
needs to activate the charge point through our online
portal at my.newmotion.com. The serial number of the
charge point is needed for this process which can be
found on the right hand side of the charge point.
Charge cards can be activated in the same online portal.
2. ACTIVATING CHARGE POINT BEFORE USE

INSTALLATIEHANDLEIDING – P6 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P6 | P6 091NM20INT04
EN NL FRDE
Way of mounting
Standard: charge
point wall bracket
mounting
Optional pole
mounting
Optional concrete
base (for in soil) for
pole
Optional Wall bracket
for two NewMotion
charge points
Required tools & additional materials
(not provided)
- Installation materials (power cable and
cable mount clips, RCD(‘s), MCB(‘s), etc.)
- Network switch (optional and not sold
by NewMotion)
- UTP cable(s) (CAT5 or CAT6)
- RJ45 UTP cable crimp tool
- RJ45 connectors
- 5 x screws (at least 6.3 x 60/70) and
plugs for mounting in wall
- Drill and bit
- Torx screwdrivers (T20 and PH3)
- Voltage tester
- Tape measure
- Spirit level
- All mentioned for standard mounting
- Pole (sold separately)
- 4 x M8 wedge bolts or chemical
anchors, plus nuts and washers
- All mentioned for pole mounting
- Concrete base (sold separately)
- DIN 912 HEX allen key (size 6)
- Shovel
- All mentioned for standard mounting
- 4 x screws (at least M8 x 70)
- Pole (sold separately)
Package contents charge point
- Charge point
- Wall bracket
- Rubber grommets (various sizes)
- 2 x plastic spacers
- Sticker sheet for the sides of the
charge point
- 1 x M4 x 20 mm bolt (Torx)
- 6 x M4 x 12 mm bolts (Torx)
- 2 x M8 x 12 mm bolts (PH) plus
washers
- Optional: Tethered charge cable
- 4 x M8 x 12 mm bolts (PH) plus
washers
- 4 x M8 x 35 mm bolts (HEX DIN 912)
plus washers
- 4 x M8 x 12 mm bolts (PH) plus
washers
3. PRODUCT OVERVIEW
3.1 MOUNTING OPTIONS, PACKAGE CONTENTS AND REQUIRED TOOLS

INSTALLATIEHANDLEIDING – P7 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P7 | P7
EN NL FRDE
091NM20INT04
3.2 TECHNICAL SPECIFICATIONS
3. PRODUCT OVERVIEW
CONTINUED ON NEXT PAGE
Serial number format Business Pro (Cable)
Serial number format Business Lite (Cable)
Maximum number of Business Pro in one group
Models allowed in group
Maximum number of Business Lites per Business Pro
network
Maximum charge capacity
Standard congured charge capacity
Electric safety category
DC-fault current protection
Dimensions (H x W x D)
Weight
Standard colours
IEC-62262 IK code (robustness)
IEC-60529 IP code (protection class)
Certicates
kWh measurement
User interface
09 1_ _ _ _ _
08 1_ _ _ _ _
1
Business 2.0 and Business 2.1 chargepoints
Daisy chain conguration: 15
Star conguration: 40
1-phase 32A (7,4 kW)*
3-phase 32A (22kW)*
1-phase 16A (3,7kW)**
3-phase 16A (11kW)**
Class I
Built-in 6mA DC fault current protection
503.5 x 200 x 137 mm
± 4.0 kg
Rear side RAL 7031 (grey)
Front side RAL 9010 (white)
IK10
IP54 (for indoor and outdoor use)
IEC 61851-1
IEC 61851-22
IEC 62196
IEC 62262 -> IK10
IEC 60529 -> IP54
IEC 62955 -> 6mA DC-fault protection
EV-Ready 1.4 G& ZE-Ready
ISO 9001-2008 norm
MID certied
LED

INSTALLATIEHANDLEIDING – P8 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P8 | P8 091NM20INT04
EN NL FRDE
* The maximum charge capacity of the charge point depends on several factors. This includes: local rules & regula
tions, the type of EV, the grid connection at your location and the electricity usage of your building
** Contact NewMotion for changing charge capacity
*** Contact NewMotion for further information: [phone] and press option 1
3.2 TECHNICAL SPECIFICATIONS
3. PRODUCT OVERVIEW
Identication
Communication backoce (Pro)
Communication backoce (Lite)
Backoce protocol
Stand-by consumption
Operating temperature range
Operating humidity range
Operating air pressure range
Maximum mounting height socket
Advised mounting height socket
Mounting position
Function for ventilation according to IEC-61851
Maximum length of tethered cable
RFID (NFC) Mifare 13.56 MHz
IEC 14443A
IEC 14443B
Plug & Charge (through online portal)
GPRS 2G (minimal -80dBm Vodafone Partners)
Ethernet connection (DHCP, TCP 443, TCP80, TCP21)
2G/3G/4G with mobile router***
Ethernet connection with Pro
OCPP protocol
3-5W
-30℃ to +50℃
5% to 95%
860 hPa to 1060 hPa
1.5 meter above ground
1 meter above ground
Vertical and upright position only
Not supported
8 meters

INSTALLATIEHANDLEIDING – P9 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P9 | P9
EN NL FRDE
091NM20INT04
3.3 OVERVIEW OF PRODUCT
3. PRODUCT OVERVIEW
Type 2 EV Plug
socket & Cover lid
RFID reader
Identication label
with serialnumber
Product details
LED status indicator

INSIDE
INSTALLATIEHANDLEIDING – P10 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P10 | P10 091NM20INT04
EN NL FRDE
If connecting to a 230V 3-phase grid without neutral, only install 1-phase and connect one of the two other phase
wires in the neutral wire connection on the terminal block
3. PRODUCT OVERVIEW
Business Pro:
UTP data port for
connection Switch
in star conguration
or Business Lites
in daisy chain
conguration
Business Lite:
UTP data port
for daisy chain
outgoing
Business Pro:
UTP data port for
Ethernet / Mobile
router connection
Business Lite:
UTP data port for
connection switch
(star conguration) or
daisy chain incoming
Earthing pole
UTP data cable inlet
with rubber seal
UTP data cable inlet
with rubber seal
Inlet for
power cable
Power cable clamps
3.4.1 OVERVIEW OF CONNECTIONS
Phase 2
Phase 3
Phase 1
Terminal block
Neutral
Earthing
DC-protection module
Connection
DC-protection module
kWh meter

INSIDE
INSTALLATIEHANDLEIDING – P11 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P11 | P11
EN NL FRDE
091NM20INT04
3. PRODUCT OVERVIEW
3.4.2 OVERVIEW TETHERED CABLE CONNECTIONS
Placement tethered cable
When installation is complete, place the plug of the cable in the designated dummy socket on the charge point
Caution: The phase 1 (brown), phase 2 (black), phase 3 (grey) and neutral (blue) of the xed cable must go through the
DC-protection module. Failing to do so will result in no protection against DC-fault current
Tethered
cable inlet
Earthing
tethered cable
Connector for
communication
with the car to red wire
Cable clamp
DC-protection
module
Connection
DC-fault protection
module
Keep the same wiring
order as the connection
under relay
L1 = portal 1
L2 = portal 3
L3 = portal 5
Neutral = portal 7
Earthing tethered cable
DC-fault protection
module for
L1, L2, L3 & N

INSTALLATIEHANDLEIDING – P12 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P12 | P12 091NM20INT04
EN NL FRDE
3.5 BACKOFFICE CONNECTIONS
BUSINESS PRO
The Business Pro can be connected to the NewMotion
backoce in three dierent ways:
1. Ethernet connection
2. GPRS 2G
3. 2/3/4G with NewMotion mobile router
The Business Pro will connect to the NewMotion
backoce so settings can be changed remotely and
for remote support. Without the back oce connection
none of our online services can be used.
In groups of multiple Business charge points there
should be exactly one Business Pro. Connecting a
Business Pro to another Business Pro is not possible.
3.5.1 BUSINESS PRO
– ETHERNET / NEWMOTION MOBILE ROUTER
Connecting the Business Pro to ethernet or mobile
router can be done by connecting the network to the left
UTP Ethernet data port with a cable max 50 meter long.
Settings might have to be changed in the network to
allow the Business Pro make a successful connection to
NewMotion backoce.
The network should have:
- DHCP enabled
- TCP port 80 and 443 opened
- FTP* port 21 opened for the Business Pro
- UDP port 123 (NTP)
- UDP port 53 (DNS)
- All opened ports should be outbound
* FTP is needed to update the rmware of the charge point and
exchange diagnostics
3.5.2 BUSINESS PRO - GPRS 2G
The Business Pro will rst attempt to connect online
through the left UTP Ethernet data port. If no connection
can be made the Business Pro will try to set up a GPRS
connection. The connection will only be possible if the
signal strength is -80dBm or better for Vodafone (or
partners).
3.6 BUSINESS LITE - BACKOFFICE
CONNECTION
The Business Pro will handle all communication with
the backoce for the Business Lites. This means that
a Business Lite without being connected to a Business
Pro will not connect to the NewMotion backoce and
remote settings can not be changed or remote support
can not be provided. Without the backoce connection
none of our online services can be used.
The Business Lite should, directly or indirectly, be
connected to the right hand side UTP data port of a
Business Pro. An indirect connection can be through a
switch or another Business Lite (Daisy chain).
3.6.1 BUSINESS LITE - DAISY CHAIN CONFIGURATION
The Business Lites have two ethernet ports which can
daisy chain the connection to the next Business Lite.
The left port should be closest to the Pro and the right
port should be going to the next Lite (see gure below).
The daisy chain conguration can be used up to 15
charge points. For higher quantities of Business Lites a
star conguration needs to be used. A star conguration
can also be used to minimize downtime of backoce
connection and Dynamic Power Sharing.
3.6.2 BUSINESS LITE - STAR CONFIGURATION
In a star conguration all Lites are connected from the
left UTP Ethernet data port to a switch. Up to 40 Lites
can be connected to the Pro via a non-DHCP switch.
From the right hand side of the Pro there is a cable going
to the same switch (please note that the left port of the
Pro is reserved for ethernet or mobile router connection,
see backoce connection business Pro). Only one Pro is
allowed to be connected to the switch.
3. PRODUCT OVERVIEW
(Mobile)
Router 09.......
(PRO)
Optional
(Mobile)
Router 09.......
(PRO)
Optional
(Mobile)
Router
Switch
08.......
(LITE)
08.......
(LITE)
08.......
(LITE)
08.......
(LITE)
09.......
(PRO)
08.......
(LITE)
08.......
(LITE)
08.......
(LITE)
08.......
(LITE)

INSTALLATIEHANDLEIDING – P13 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P13 | P13
EN NL FRDE
091NM20INT04
Wiring advice*
Power cable size
Earthing advice*
Required nominal
input voltage at
charge point
MCB
RCD
Ethernet connection
cable requirements
Ø 10mm - Ø 22,5mm
10mm2 solid wire
6mm2 stranded wire with end ferrules
PE-cable (PEN conductor is not allowed)
Separately installed grounding electrode
< 100 Ohm spreading resistance
230V +/-10% 50Hz
400V (3 x 230V+N) +/-10% 50Hz
Cable grommets sizes
Maximum cable terminal block
TN-system
TT-system
Single phase**
Triple phase**
4. INSTALLATION DETAILS
The electrician is responsible for selecting a cable thickness & safety components appropriate
for the specic situation and according to regulations;
* The electrician is always responsible for selecting a cable thickness appropriate for the specic
situation and according to regulations
** 3-phase charge point can also be connected to 1-phase. In this case the charge point can only
charge on 1-phase
*** The electrician must select a suitable MCB to match the amperage setting of the charge point,
taking into account MCB manufacturer specications
NOTE: The charge point can be set between 10A and 16A / 32A (depending on version)
- Wire for the maximum hardware amperage under continuous load
- Calculate with a COS-Phi of 0.8
- Calculate with a max allowable voltage drop over the cable of 2%
- Use shielded cable for underground wiring
C-characteristic***
30 mA Type A (HI, HPI, SI, KV), or 30 mA type B
Standard CAT5 or CAT6 Ethernet cable (UTP cable with RJ45 connectors)

INSTALLATIEHANDLEIDING – P14 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P14 | P14 091NM20INT04
EN NL FRDE
Thank you for installing this charge point.
Make sure there is enough space to properly do the work.
Ensure to work safely and take the safety of others into
consideration as well, always work according local
safety regulations.
When selecting the mounting location of the charge
point, make sure that future maintenance work can be
done easily.
5.1 PREPARATION
Step 1: Prepare the cabling & RCD and MCB (conform to
local rules & regulations)
Step 2: Indicate which circuit(s) the charge point is
connected to the distribution board
Step 3: Turn the socket lid anti-clockwise and out of the
cover of the charge point
Step 4: Then pull the cover from the rear edge to open the
charge point. Do not use any objects or tools to do this.
5.2 MECHANICAL MOUNT
For standard wall mount proceed with 5.2a, for optional
pole mount on pavement proceed with 5.2b, for optional
pole mount in soil proceed with 5.2c.
5.2A MECHANICAL MOUNT (WALL)
Step 1: Attach the wall bracket at the desired height (+/-
1 m height) on the wall
Step 2: Put the charge point on the wall bracket to
check its placement. On the wall, mark the positioning
of the bottom two attachment points of the charge point
and select the appropriate xtures (plugs, screws and
washers)
Step 3: Ensure that the grey spacers are placed on the
back of the charge point at the bottom two attachment
points
Step 4: Secure the charge point to the wall bracket using
the two M8 x 12 mm bolts and washers provided
Step 5: Secure the charge point to the wall using the
bottom two attachment points.
5.2B MECHANICAL MOUNT (POLE ON
PAVEMENT)
Step 1: Drill holes into the pavement for the wedge bolts
or chemical anchors (not provided)
Step 2: Route the power cable(s) and UTP cable(s)
through the pole
Step 3: Mount the wedge bolts or chemical anchor into
the pavement
Step 4: Mount the pole to the threaded ends with
washers and nuts (not provided)
Step 5: Mount the green/yellow pole earthing wire to the
terminal block earthing connection
Step 6: Secure the charge point to the pole bracket
using the four M8 x 12mm bolts and washers provided,
making sure to connect the pole earthing wire to the
bottom right bolt.
5.2C MECHANICAL MOUNT (POLE IN SOIL WITH
CONCRETE BASE)
Step 1: Dig the concrete base into the soil, make sure it
is steady and level
Step 2: Route the power cable(s) and UTP cable(s)
through the pole
Step 3: Mount the pole to the concrete base with the 4
bolts M8 x 35 and washers that are provided
Step 4: Mount the green/yellow pole earthing wire to the
terminal block earthing connection
Step 5: Secure the charge point to the pole bracket
using the four M8 x 12 mm bolts and washers provided,
making sure to connect the pole earthing wire to the
bottom right bolt.
5.3 POWER CONNECTION
Step 1: Select the appropriate grommet(s) that suits
the cable(s) thickness and place it in the opening of
the power cable inlet. Lubricate if necessary to make it
easier to feed the power cable through
Step 2: Secure the power cable(s) using the cable
clamp(s)
Step 3: Mount the (closed) black grommet in the
remaining cable inlet to make the charge point watertight
Step 4: Connect the power to the terminal blocks, like
indicated in the ‘3.4.1 Overview of Connections’ section.
5. INSTALLATION PROCEDURE

INSTALLATIEHANDLEIDING – P15 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P15 | P15
EN NL FRDE
091NM20INT04
5.4 OPTIONAL TETHERED CABLE
Step 1: Select the appropriate grommet to suit the cable
thickness and place it in the opening of the power cable
inlet. Lubricate if necessary to make it easier to feed the
power cable through
Step 2: Detach the DC protection module and carefully
put the phase wires (brown, black and grey) and neutral
(blue) of the tethered cable one by one through the
module
Step 3: Connect the tethered cable wires on the relays,
PE cable on the terminal block, and car-communication
wire (red wire), like indicated in the ‘3.4.2 Overview
Tethered Cable Connections’ section
Step 4: Take the DC-protection module and attach the
DC-protection module cable to the PCB.
5.5 COMMUNICATION CONNECTION PRO
For Ethernet or NewMotion mobile router connection
(preferred) proceed with 5.5a, for GPRS connection
proceed with 5.5b.
5.5A BUSINESS PRO COMMUNICATION
CONNECTION(S) (UTP)
Step 1: Feed the UTP cable(s) through the rubber stop(s)
on the data cable inlet and then connect it to the left
Ethernet port(s), like indicated in the ‘3.4.1 Overview of
Connections’ section
Step 2: Connect the UTP cable to a internet enabled
router with DHCP or NewMotion mobile router.
5.5B BUSINESS PRO COMMUNICATION
CONNECTION(S) (GPRS)
Step 1: Check and make sure signal strength is sucient
5.6 COMMUNICATION CONNECTION
BUSINESS LITE
For Daisy chain conguration proceed with 5.6a, for Star
conguration proceed with with 5.6b.
5.6A BUSINESS LITE COMMUNICATION
CONNECTION (DAISY CHAIN CONFIGURATION)
Step 1: Feed the UTP cable(s) through the rubber stop(s)
on the data cable inlet and then connect it to the left
Ethernet port(s), like indicated in the ‘3.4.1 Overview of
Connections’ section.
The other end should be connected to the right hand
side Ethernet port of the Business Pro.
Step 2: Feed a cable from right hand side port of
the Business Lite to the left Ethernet port of the next
Business Lite.
Repeat Step 2 until all Lites have been connected.
5.6B BUSINESS LITE COMMUNICATION
CONNECTION (STAR CONFIGURATION)
Step 1: Business Pro: Feed a UTP cable(s) through the
rubber stop(s) on the data cable inlet and then connect
it to the right Ethernet port(s), like indicated in the ‘3.4.1
Overview of Connections’ section
Step 2: Business Pro: Connect the UTP cable to a switch
(no DHCP)
Step 3: Business Lite: Feed a UTP cable(s) through the
rubber stop(s) on the data cable inlet and then connect
it to the left Ethernet port(s), like indicated in the ‘3.4.1
Overview of Connections’ section
Step 4: Business Lite: Connect the UTP cable to a
switch (no DHCP).
5.7 FINISHING UP (CLOSE ENCLOSURE)
Step 1: Check and make sure that the rubber seal is
properly in place on the edge
Step 2: Place the cover on the charge point
Step 3: Hand-tighten the four M4 x 12 mm bolts provided
around the socket so that the cover closes on the rubber
seal but the rubber seal does not deform
Step 4: Hand-tighten the other two M4 x 12 mm bolts
provided in the bottom of the cover
Step 5: Turn the socket lid clockwise in the cover and
hand-tighten the M4 x 20 mm bolt provided
Step 6: Switch on power to the charge point
Step 7: Wait until charge point is fully started up (+/-10
minutes, LED should be o)
Step 8: Check that the business Pro is connected to the
network. A quick check can be done online via
http://chargeportal.newmotion.com/test. Simply
enter the serial number into the search eld and click
“Search”. ‘Online’ should appear after the serial number.
Step 9: Check if the Business Lites are
connected online. Check all Business Lites on
http://chargeportal.newmotion.com/test. ‘Online’
should appear after entering the serial number. If ‘Online’
does not appear, check whether the charge point is
properly connected and reset the Business Lites while the
Business Pro stays powered on.
Step 10: If conguration of charge point power settings
is needed (for example lower amperage settings) please
contact NewMotion.
5. INSTALLATION PROCEDURE

INSTALLATIEHANDLEIDING – P16 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P16 | P16 091NM20INT04
EN NL FRDE
For a successful installation of the Business Pro &
Lite charge points with Dynamic Power Sharing, the
following requirements need to be met:
- The group consists of one Business Pro and one or
more Business Lites
- All charge points are connected by UTP cables in a
either a daisychain or star conguration
- All charge points should be online before the
conguration can be completed
- The available charge capacity for all charge points
combined is known
- The charge capacity for each charge point is known
- Phase rotation has to be applied according to
installation form (see 6.1)
The following is recommended:
- The installation is executed with 3-phase / 32A power
cabling for each charge point
- Ideally, there is at least 10A per phase available per
charge point for the group at full occupancy
6.1 PHASE ROTATION (3-PHASE ONLY)
To make optimal use of the available power phase
rotations should be used. Beware, when this is not
correctly congured, Dynamic Power Sharing will not
work correctly and could result in overloading the grid
connection. Installation should be carried out, and
charge points should be connected, in accordance
with/to the installation procedure of this manual. The
phase rotation should be applied at the bottom of the
kWh meter. Connect the L1 (brown) and neutral (blue)
always to the terminal block.
The position in the installation form determines the
phase rotation the charge point will receive. There are
three dierent phase rotations which are used:
1. L1 L2 L3
2. L3 L1 L2
3. L2 L3 L1
Phase rotation L1 L2 L3 is the factory connection. To
change this to L2 L3 L1 or L3 L1 L2 loosen the three
left screws holding the power cables on the bottom of
the kWh meter. Rearrange them and tighten the screws
back up.
Make sure the power cables are rmly reapplied in the
bottom of the kWh meter. Failing to do so can result in
re, electrocution or severe injury.
The order for each phase rotation is as following:
6. OPTIONAL: DYNAMIC POWER SHARING
Description
Installation form /
Settings charge point
L1L 2L3
L3L1L2
L2L3L1
Order of power cables
located to the bottom
of the kWh meter
(from left to right)
Brown, Black, Grey, Blue
Grey, Brown, Black, Blue
Black, Grey, Brown, Blue

INSTALLATIEHANDLEIDING – P17 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P17 | P17
EN NL FRDE
091NM20INT04
6. OPTIONAL: DYNAMIC POWER SHARING
L1 L2 L3 L3 L1 L2 L2 L3 L1
INSIDE
Brown Black Grey Blue
INSIDE
Grey Brown Black Blue
INSIDE
Black Grey Brown Blue

INSTALLATIEHANDLEIDING – P18 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P18 | P18 091NM20INT04
EN NL FRDE
6. OPTIONAL: DYNAMIC POWER SHARING
For this Dynamic Power Sharing conguration to be
successful, please follow and complete the form below
during the installation.
Keep this information handy when in contact with
the NewMotion support desk.
INSTALLATION FORM
Table 1: Installation form
Position
1
2
3
4
5
6
7
8
9
10
11
12
Serial number
09 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
08 _ _ _ _ _ _
kWh meter inlets L1, L2, L3
Phase wire attached
L1
L3
L2
L1
L3
L2
L1
L3
L2
L1
L3
L2
L2
L1
L3
L2
L1
L3
L2
L1
L3
L2
L1
L3
L3
L2
L1
L3
L2
L1
L3
L2
L1
L3
L2
L1
Table 2: Information regarding the group charge capacity
Charge capacity settings
Max amperage per phase
all charge points combined
Max amperage per phase
each charge point
CommentsValue (A)

INSTALLATIEHANDLEIDING – P19 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P19 | P19
EN NL FRDE
091NM20INT04
7.1 BEFORE USE: ACTIVATION &
REGISTRATION
To make the charge point ready for use the owner needs
to activate the charge point through our online portal
my.newmotion.com. The serial number of the charge point
is required for this process and can be found on the right
hand side of the charge point.
Charge cards can be activated in the same online portal.
7.2 REGULAR USE
First step is to connect your car to the charge point by
plugging in the charge cable.
If you are using Plug&Charge the session will start
automatically.
If you have to identify rst; swipe your charge card above
the LED.
First the LED will ash green to authenticate the card,
after authentication, the session will start. If the LED
ashes red, the session is not accepted.
When the car has delayed charging congured, the LED
will remain green, until charging can start from car and
charge point.
Start charging? Plug in & identify
Stop charging? Identify & unplug
Full or waiting to charge
Plug in or identify
Charging
Not accepted
Error
Flashing green or multi colors: rebooting procedure
or software update procedure for charge point.
7. PRODUCT USE / OPERATION
7.3 TETHERED CABLE
If you have purchased a charge point with tethered cable
functionality, this chapter will explain how to properly store
the tethered cable at the end of a charge session. After
the charge session is complete and the car has unlocked
the tethered cable, you roll the cable around the back of
charge point and connect the connector into the dummy
socket of the charge point. Make sure to t the tethered
cable into the designed notch on the backside of the
charge point for optimal storage. Also, please be sure to
always hang the connector back into the dummy socket of
the charge point, so that the connector is protected against
water and dirt.

INSTALLATIEHANDLEIDING – P20 VERSION 0129NM02INT01MANUEL D’INSTALLATION – P20 | P20 091NM20INT04
EN FRDENL
1.1 PRODUCTBESCHRIJVING EN
BEOOGD GEBRUIK
Bedankt voor het kiezen van een NewMotion-laadpunt
voor elektrische voertuigen.
Dit laadpunt is bedoeld om de batterijen op te laden
van elektrische voertuigen die compatibel zijn met de
denitie en vereisten volgens IEC-61851 MODE3. Voor
gebruik van dit laadpunt dient u speciale EV-stekkers te
gebruiken. Er mogen geen adapters, conversieadapters
of verlengsets voor kabels worden gebruikt. De
elektrische voertuigen en kabels die u aansluit op dit
laadpunt moeten altijd onbeschadigd zijn en in de
oorspronkelijke staat verkeren.
1.2 VEILIGHEIDSWAARSCHUWINGEN
EN VOORZORGEN!
De elektrische installatie dient spanningsloos te zijn
gedurende de gehele installatieprocedure. Als dit niet het
geval is, kan dit leiden tot ernstig letsel of zelfs de dood.
De installatieprocedure moet worden uitgevoerd
door een deskundig elektromonteur die werkt
overeenkomstig alle relevante lokale wetten
en voorschriften. Installeer het apparaat niet in
explosiegevaarlijke omgevingen en/of zones met een
hoge elektromagnetische straling en/of in omgevingen
met kans op overstromingen.
Zelfs wanneer uitgeschakeld is het laadpunt aangesloten
op het elektriciteitsnet en daardoor kunnen gevaarlijke
spanningen aanwezig zijn bij de ingangsklemmen.
Schakel de netspanning altijd uit voordat u begint met
werkzaamheden aan het laadpunt of de installatie.
Voer geen werkzaamheden uit in regenachtige
weersomstandigheden of bij een luchtvochtigheid van
boven de 95%. De veiligheidsvoorschriften zijn bedoeld
om correcte installatie en gebruik te garanderen. Elke
inbreuk op de geldende veiligheidsvoorschriften of
instructies in deze handleiding kan leiden tot brand,
elektrocutie of ernstig letsel.
Het laadpunt is een product uit veiligheidsklasse I en
wordt geleverd met een aardklem ter beveiliging. De
ingangsklemmen van het elektriciteitsnet moeten zijn
voorzien van een onderbrekingsvrije massa-aansluiting
ter beveiliging. Zorg dat de aansluitkabels zijn voorzien
van zekeringen en overstroombeveiligingen. Vervang
een beveiligingsonderdeel nooit door een onderdeel van
een ander type. Controleer eerst de volledige installatie
om te bepalen of het onderdeel kan worden gebruikt
in combinatie met de bestaande componenten van de
installatie.
Controleer voordat u het laadpunt inschakelt of
de beschikbare spanningsbron overeenkomt met
de conguratie-instellingen van het product zoals
beschreven in deze handleiding.
Het activeren van de aardlekbeveiliging kan veroorzaakt
worden door een defect in de massa-aansluiting
of een defect relais. Als na het resetten van de
aardlekbeveiliging het apparaat niet kan worden
geactiveerd of de aardlekbeveiliging onmiddellijk
weer wordt geactiveerd, neem dan contact op met
NewMotion of uw installateur.
1.3 JURIDISCHE DISCLAIMER
Deze handleiding werd met zorg voor u opgesteld.
We kunnen echter niet garanderen dat alle informatie
compleet, accuraat en correct is.
Mocht u onduidelijkheden of fouten in deze
installatiehandleiding vinden of algemene feedback
of suggesties hebben over deze handleiding,
dan kunt u ons daarvan op de hoogte stellen via
[e-mail] met een
vermelding van de documentversie in het onderwerp.
Ga naar onze website www.newmotion.com voor de
nieuwste versie van deze handleiding.
Wij raden u sterk aan om ons product te laten installeren
door gecerticeerde professionals. Hoe ons product
moet worden geïnstalleerd en gebruikt hangt af van
de plaatselijke omstandigheden en lokale en nationale
regelgeving die niet in onze handleiding vermeld staan.
NewMotion is niet verantwoordelijk voor enig verlies
of schade - met inbegrip van, maar niet beperkt tot -
indirecte, persoonlijke of gevolgschade - voortvloeiend
uit of in verband met het gebruik van deze handleiding.
Evenmin aanvaardt NewMotion enige aansprakelijkheid
voor dergelijke schade of verlies die het gevolg is van uw
vertrouwen op enige informatie in deze handleiding.
1. INLEIDING
