TWNTech HDV-816 User manual

HDMI1x16Splitter
WithUSBmultimediaplayer
Usermanual

1
Thankyoufor purchasingthis product.For optimumperformance and safety,please read these
instructions carefully before connecting,operatingor adjustingthis product.Please keep this manual for
future reference.
nIntroduction
The 1x16 HDMISplitter use asingle HDMIsource or USBMultimedia source, accessingto
multiple HDMIsinks. The Splitter allows one HDMIdevices to be split easily to sixteen HDMI
compatible monitors or projectors. The Splittercan also be placed atthe end ofalongHDMIcable to
regeneratethe HDMIsignal. Itoffers HD videosolution for super market; shoppingMall; HDTV, STB,
DVD and projector factory; data control center; information distribution; conference roompresentation;
education and training, corporation show room, luxurious house, etc.
nFeatures
1. HDMIinput signal split to 16 HDMIsinkdevices.
2. Support deep color 30bit, 36bit, 48bit.

2
3. Support USBMultimedia Play,
a) Video Format support MPEG1/2/4, RM,RMVB,MOV
b) Audio format WMA,MP3
c) Images file format: JPEG,BMP,PNG
4. Digital audio format, as DTS-HD/Dolby-true-HD/LPCM 7.1/DTS/Dolby-AC3/DSD.
5. Support input up to 15m,AWG26 HDMIstandard cable, output up to15mAWG26cable.
nPackage
1. HDMISplitter 1to16 x1
2. 12V DC Power Supply adaptor x1
3. Remote controller x1
4. Operation Manual x1

3
nSpecifications
Frequency Bandwidth 2.25Gbps (single link)
HDMISplitter Input/Output Ports 1xHDMIFemale input port
1xUSBFemale input port
16xHDMIFemale output port
Power Supply 12V/3ADC
ESDProtectionHumanBody Model: 8kV(air-gap discharge)
4kV(contact discharge)
Dimensions (mm)115(W) X270 (D) X45(H)
Chassis Material Aluminum
OperatingTemperature 0˚C~40˚C/32˚F~104˚F
StorageTemperature -20˚C~60˚C/-4˚F~140˚F
RelativeHumidity 20~90% RH (non-condensing)

4
nOperationcontrols andFuctions
FrontPanel
1. POWER SWITCH: Power ON\OFF Switch.
2. 2CH/5.1CH: Select Audio between 2.1channel and 5.1channel.
3. 1080I/1080P:Select Video between 1080i and 1080p
4. 2D/3D: Select Video between 2D and 3D
5. SOURCE: Select input fromHDMIor USB
6. IRIN: Remote control signal receivewhen in USBMultimedia Play mode.

5
7. HDMIIndicator:When the TV plugin, The correspondingindicator will be light
RearPanel
1. HDMIOUTPUT: HDMIOutput port 1~16.
2. HDMIINPUT:HDMIinput port .
3. USBINPUT:USBInput port
4. Power: Plugthe 12VDC power supply into theunit and connect the adaptor toACwall outlet

6
nApplicationExample
Attention: HDV-816Asupport USB input,HDV-816B noUSB fuction.
