Food Mixer User Manual
Please read this manual before using.
Introduction
The food mixer is designed for high performance. They can be used for flour mixing, mixing pieces,
powdered and liquid food ect. They are used planetary motion, which the agitator is done planetary
motio into bowl, have the food be full blend. The machine work smoothly and reliably. There are
some grades of working speed and agitators of various styles result. All the machine parts in
contact with food are made of stainless steel or their surfaces are specially treated in conformity
with Chinese hygiene standard.
1. Technical Data
Model
B20L B25L B30L
Container capacity (L)
15 20 30
Max. dough mixing (kg)
5 6 8
Mixing speed (r/min) Dough Others Egg
130/450
Rated input power (kW)
1.1 1.5 1.5
Rated Voltage
~220、230V/3~380、420V
Rated frequency
50、60Hz
Dimension (mm)
513*405*760 580*455*780 580*455*780
General Weight (kg)
98 102 105
2. Installation
①Take apart the package. Place the machine steadily. Bed installation is unnecessary.
②Make sure the voltage printed on the nameplate. Connect the wire to the power source by a
creepage protector. The yellow/green two-color wire must be connected to a safe ground wire. The
wiring terminal on the back side of the machine is equipotential terminal.
3. Operation
Check
Make sure that the voltage of power source is corresponding to the rated
volatge of the machine, the wire connection is reliable and the connection
to ground is well done.
Machine test: 1.If the motor is three-phase,, user should place the
gearlever in M grade.
If the turn is not conform to the direction which
marked on the machine, user should turn the among two phase wiring,
shift the grade when two turns are same, or the machine will be damaged.
2. If the motor is single-phase, the turn has been
Adjusted well
before it leaves the factory, as long as get through the power
source user can test the machine.
Spedshift
Stop the machine to shift the speed grade in order not to damage the
machine. If it is hard to shift the speed grade, user can start up the motor
again.
Snake agitator
Pad agitator
Bud agitator
Choose the proper agitator and turn speed according to the mixed things.
1.
Mix dough should use the snake agitator and work at L grade, do not
use the M grade and H grade to mix dough.
2. Mix other things should use the pad agitator and work at M grade.
3. Mix cream or egg should use bud agitator and work at H grade.
2
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Food Mixer User Manual
When mixing, user should adjust the container to a proper height by the
guide way. After mix or replace the agitator user should lower the
container.
4. Maintenance
The bearing and the driver of the mixer have been added grease when the mixer leave the factory,
the grease usually can work for half a year. When add or replace grease, user should take apart the
upper cover and the bearing cover and add the same grease, User should add some grease in the
ascend and descend guide way periodically to make sure the agility. Keep the machine clean after
use it. Do not uses spout to wash the machine.
5. Breakdown and Settlement
Breakdown Cause Settlement
Motor not run
Electricity loose contact Check the circuits, centrifugal
switch, switch
Start-
up capacitance
damaged Replace the capacitance
Mixing shaft not roll or rollback Turn of motor not correct Turn the wiring
Motor is noisy, the centrifugal
switch
pulse frequently or not
come away
Too many things in the
container, the machine
overload.
Reduce things in the
container
The centrifugal switch loose Tight the centrifugal switch
gear case generate heat seriously
and very noisy Grease not enough Add or replace grease
Machine generate heat seriously,
turn speed drop down or not run
Voltage not enough Check the power source
Leak grease The cover damaged Replace the cover
Ascend and descend not flexible
The guide way too dirty or
rust
Wash, get rid of the rust and
add grease
Mixer tough sides
The mixer or the container is
out of shape Adjust or replace
6. Safety Cautions
①Must install ground wire before use.
②Must stop the machine before change the grades.
③Don’t overload.
④If the machine runs unusual, user should cut off the power source at once.
