Twothousand TT-WE64B User manual

Electric Commercial Toaster User Manual
1
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Electric Commercial Toaster
User Manual

Electric Commercial Toaster User Manual
2
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Thank you for purchasing this range of appliance of our company.
Proper attention to preventative maintenance and scheduled maintenance procedures will prolong
the life of the appliance.
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this appliance.
For your safety
Do not store gasoline or other flammable liquids in the vicinity of this or any other appliance.
WARNING: FIRE HAZARD
The area where the appliance is installed must be kept clear of combustibles and flammables. This
includes mops, rags, grease, wrapping paper and electrical cords.
Warning
Electrical Grounding Instructions
This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard
and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove
the grounding prong from this plug.
Notice
This appliance is designed for use in non-combustible locations only. Install the appliance on a firm,
level, non-combustible surface.
For servicing, a clearance of 6 inches (15cm) from rear of the appliance to wall should be kept.

Electric Commercial Toaster User Manual
3
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
This kind of commercial toaster is developed by our company. It absorbs the advantages of similar
products home and abroad. It is novel in design and reasonable in structure. It is easy to operate
and maintain. It is made of stainless steel. It is an ideal choice for hotels, super-markets, western
food kitchen, fast-food chains and other food industries.
1. General information
Proper installation, professional operation and consistent maintenance of this appliance will ensure
that it gives you the very best performance and a long, economical life.
This instruction manual contains the information needed to properly install the appliance, and to use
and care for the appliance in a manner which will ensure its optimum performance. This manual is
considered to be a permanent part of the appliance. This manual and supplied instruction, circuit
diagrams, schematics, pats breakdown illustrations, notices, warnings and naming plates must
remain with the appliance if it is sold or moved to another location. It should be easily accessible for
anyone carrying out the installation, servicing, and cleaning.
It is made of stainless steel. 2，4 or 6 slices can be cooked at the same time. Large and
ergonomically designed controls and handles give ease of use and the manual timer gives you total
control. The manual, hi-lift toast ejector ensures the toast stays warm and is safe and easy to
remove when the bread is ready.
2. Overview of product
①Slot ⑤Body
②Switch ⑥Hi-lift toasting ejector
③Power indicator ⑦Crumb tray
④Timer

Electric Commercial Toaster User Manual
4
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
3. Product Specification
Model
TT-WE64B
Voltage
220V
Power
3.24KW
Timer range
0～5min
Slices of toasting
2, 4 or 6 slices
Dimension
460×210×225(mm)
4. Electrical parts installation
4.1. Make sure the supplied voltage matches the rating voltage on the naming plate.
4.2. Make sure that the appliance is grounded safely. For convenient operation, never pile up the
sundry goods near the switch.
5. Operation
5.1 Insert the plug into the receptacle, and the red indicator ③is on. This means that the
appliance has been connected to power supply. Adjust the selecting switch ②, place bread into
the slot ①. Rotate the timer ④clockwise to the desired temperature. When the set time is up,
the timer will produce a sound. This means that the toasting process has ended. Press the hi-lift
toasting ejector, and take out the toasted bread.
5.2 During the process of heating, the crumbs of bread will fall automatically into the crumb tray.
The crumb tray should be cleaned in time to ensure the sanitation of the food stuff.
5.3 The toasted bread should be larger than the whole slot. If it is too small, it would be a little
difficult to take the bread out of the slot.
6. Transportation and storage
In the process of transportation, the appliance should be handled carefully, preventing the intense
shaking. The packaged appliance should be stored in a well-ventilated area free of caustic air. It
cannot be placed in the outside area and should never be put upside down. Keep it dry and dust-free.
Do not expose it to direct sunlight. Avoid mechanical shocks and vibrations. If it is for temporary
storage, the weather-proof method should be taken.
7. Cleaning and maintenance
7.1. Before cleaning and repairing the unit, cut off the power in case of electric shock.
7.2. After finishing a day’s work, pull out the tray and clean it. Use a piece of wet cloth dampened by
detergent solution which is not corrosive to clean the unit. Do not wash the unit with water jets.
7.3. Never toast any food whose surface is covered by a lot sugar, because the sugar will flow into the
unit and cause contamination to the unit. It may result in malfunctions of the unit.

Electric Commercial Toaster User Manual
5
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
8. Notice
8.1 The voltage and phase of power supply should match that one on the naming plate.
8.2 Operators should install suitable switch, fuse protector and three-prong receptacle.
8.3 The appliance should be grounded safely. No insulation material should be placed between the
body and earth. Make sure the appliance is grounded safely to avoid unnecessary electric shock.
8.4 Before using, be sure that the wire is not loose and the voltage is normal.
9. Daily checking
Check the appliance before and after use. Before using, make sure the appliance dose not lean. Be
certain that the power cord is not worn out or broken. When in use, make sure no unpleasant smell is
present and there is no any unusual noise.
This manual must be read and understood by all persons using or installing this appliance. Contact
your local dealer if you have any questions concerning installation, operation or maintenance of this
equipment.
MPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the owner or manager of the
hotel or restaurant, or to the person responsible for training operators of this appliance. It should be
retained for future reference. Additional manuals are available from your local dealer.
Parts breakdown illustration

Electric Commercial Toaster User Manual
6
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM
Serial No.
Name
Material
Quantity
Remark
1
Baffle mesh
Bronze wireφ2orφ1.5
12
2
Body
430 twin polishing
plateδ=0.6
1
3
Handle ball
Plastic Inside M6
1
4
Pulling bar
45(φ6) chrome plating
1
5
Spring for pulling
bar
Spring steel wireφ1.0
33 in length
1
6
Bread ejecting shelf
A3 Steelδ=2.0
chrome plating
6
7
Rotating shaft
45#steelφ10 chrome
plating
1
8
Heating elements
384W 220V (5)/284W
220V (2)
7
9
Cup head cross
screw
M4×8
14
10
Spring washer
φ4
14
11
Plain washer
φ4
14
12
Connecting terminal
φ5 aluminum
4
13
Timer knob
Bakelite
1
14
Timer setting screw
M2×10
2
15
Timer
5 min 250V 16A T125
1
16
Connection strap
Latten
11
17
Hex nut
M4
14
18
Crumb tray
SS (δ=0.7or0.8)
1
19
Bottom plate
Galvanized sheet or
Electrolyzation plate
δ=0.8
1
20
Holding screw
SS Cup head cross screw
M6×8
4
21
Foot
Plastic M6
4
22
Holding screw
SS Cup head cross screw
M4×8
6
23
Holding screw
Self-threading screw
ST3.2×8
2
24
Baffle plate for
heating elements
Electrolyzation plate
δ=0.8
1
25
Power cord jacket
Black plastic plug-in card
set screw
1
26
Power cord
3×1.5mm22.2m
300/500V
1
27
Indicator
220V Green
1
28
Switch
16A 250~T100
1
