2S1471-001-01 http://www.tyan.com
TableOfContents
1.Introduction.......................................................................3
1.1 Overview................................................................3
1.2Hardware Specifications..........................................4
1.3SoftwareSpecifications.......................................... 5
1.4 Environment........................................................... 5
2.Board Installation.............................................................. 6
2.1 Unpacking.............................................................. 6
2.2 Installation.............................................................. 6
3.S1471OnBoardResourceSettings................................. 7
3.1S1471BoardLayout&Jumper Locations................ 7
3.2 Quick Referencefor Jumpers.................................. 8
3.3 CMOS RTC............................................................12
3.4 Speaker Connector..................................................12
3.5 Turbo Switch.......................................................... 12
3.6Turbo LED Connect................................................12
3.7 Reset Connector..................................................... 13
3.8 Flash EPROM Jumpers.......................................... 13
3.9DRAM Installation..................................................14
3.10CPU Installation....................................................15
3.11 Cache Upgrade................................................... 16
3.12PeripheralDeviceInstallation................................16
3.13Connecting The Power Supply............................. 17
4. BIOS Configuration........................................................ 19
4.1 Entering Setup....................................................... 19
4.2 Control Keys......................................................... 20
4.3 Getting Help...........................................................21
4.4 The Main Menu......................................................21
4.5Standard CMOS Setup Menu...................................23
4.6 BIOS Features Setup.............................................. 26
4.7Chipset Features Setup............................................29
4.7.1PowerManagementSetup........................30
4.8PCISlotConfiguration............................................ 32
4.9 Integrated Peripherals............................................. 34
4.10 Load Setup Defaults.............................................. 35
4.11 Password Setting ..................................................35
4.12 IDE HDD Auto Detection.....................................37
4.13 Save & Exit Setup.................................................37
5.Flash WriterUtility.........................................................38
5.1TheFlash Memory Writer Utility Screen.................40
6. System Resources.............................................................41
6.1Timer& DMA Channel Map....................................41
