4200L 42" I teractive Digital Sig age
Touch Display
The 4200L In erac ive Digi al Signage (IDS) display
combines precision Elo touch screen technology with a
professional-grade, large format LCD panel. The 4200L
offers System Integrators, Value-Added Resellers and
Software Developers a high-performance touch solution
for interactive digital displays in high traffic consumer
environments.
The 42-inch 4200L is part of a new family of touch displays
which bring interactivity to digital signage. The Elo
TouchSystems 4200L features a seamless, zero-bezel
design for an elegant appearance and the innovative
Acoustic Pulse Recognition (APR) touch technology for
a responsive touch experience. The display is housed in a
highly durable steel chassis for a long-life of reliable and
durable performance in almost any public-access location.
Elo Zero-bezel APR technology recognizes touch on
virtually the entire display surface, offering a full-screen
interface for navigation regardless of how the display is
touched—finger, prosthetic, stylus, card or pen—resulting
in an efficient display canvas for almost any commercial
application.
Optional high performance computer modules are well-
suited for running interactive media and are available
with a choice of two processing models: ECM1 with the
Intel Celeron Dual-Core 2.2G z and ECM2 with the Intel
Core 2 Duo 3.0G z. The computer modules are field-
installable, easily sliding into a dedicated bay behind the
touch display and locking into place with two thumbscrews.
These modules make the 4200L a reliable platform that
is interoperable with content management servers and
support optimal partitioning of locally cached and network
stored content.
Benefi s
■Professional-grade hardware provides improved
durability withstands rigors of public use over
“consumer-type” TV displays
■Advertising and content effectiveness measured in
real-time with interactive feedback
■Edge-to-edge glass design facilitates easy care and
cleaning, plus dust and liquid resistance
■Power and display control functions can be locked
out to prevent tampering
■Built-in speakers provide audio expansion capabilities
■Reliable and resilient APR technology delivers an
exceptional touch experience
■Landscape and portrait orientations allow flexible
configurations to suit a variety of design layouts

To find out more about Elo's extensive range of touch solutions, go to www.elotouch.com, or call the office nearest you.
Nor h America
Elo TouchSystems
301 Constitution Drive
Menlo Park, CA 94025-1110
Europe
Tel +32 (0)16 35 21 00
Fax +32 (0)16 35 21 01
elosales@elotouch.com
Asia-Pacific
Tel +81 (45) 478-2161
Fax +81 (45) 478-2180
www.tps.co.jp
La in America
Tel 786-923-0251
Fax 305-931-0124
www.elotouch.com.ar
800-ELO-TOUC
Tel 1-650-361-4800
Fax 1-650-361-4722
customerservic[email protected]om
4200L 42" I teractive Digital Sig age Touch Display
Model 4200L
Useful screen area orizontal: 36.6" (930 mm); Vertical: 20.6" (523 mm)
Monitor dimensions Width: 40.2" (1020 mm); Depth: 5.2" (132 mm); eight: 24.1" (613 mm)
(without stand)
Touch technology Zero-bezel Acoustic Pulse Recognition (APR)
Speakers A pair of 10 W stereo speakers facing down (in landscape mode)
Audio input connector 3.5 mm TRS jack
Audio input signal range 1 Vrms max stereo signal (standard PC line out)
eadphone output connector 3.5 mm TRS jack
eadphone output signal Delivers 90 mW of power into a 32 ohm stereo load
(for 1K z signal)
LCD technology Active matrix TFT LCD
Diagonal size 42"
Aspect ratio 16:9
On-screen display (OSD) Controls: menu, up, down, select; settings: brightness, contrast, clock, phase, auto-adjust,
-position, V-position; maintain aspect ratio, sharpness, color temperature, OSD timeout,
OSD language, mounting, OSD -position, OSD V-position, volume, mute, recall defaults,
video source, audio source; Languages: English, French, Italian, German, Spanish,
Simplified Chinese, Traditional Chinese, Japanese; Lockouts: OSD, power; accessible
through switches on the rear, or through the standard Elo OSD control box.
Stand options Optional stand available, order Part Number E448725
Mounting options VESA MIS-F, 600 x 400, Y, 6, 90
Native (optimal) resolution 1920 x 1080
Other supported resolutions 640 x 480 at 60 z; 720 x 480 at 60 z; 720 x 576 50 z; 800 x 600 at 56, 60 z;
1024 x 768 at 60 z; 1280 x 720 at 50, 60 z; 1280 x 960 at 60 z; 1280 x 1024 at 60 z;
1360 x 768 at 60 z; 1366 x 768 at 60 z; 1440 x 900 at 60 z; 1680 x 1050 at 60 z;
1920 x 1080 at 50, 60 z
Colors 16.7 million
Brightness (typical) LCD panel: 700 nits; with APR: 600 nits
Response time (Tr + Tf) 6.5 msec
total (typical)
Viewing angle (typical) orizontal: ±89° or 178° total; Vertical: ±89° or 178° total
Contrast ratio (typical) 3500:1
Input video format Analog VGA, DMI 1.3
Input video signal connector Female DE-15 for Analog VGA; DMI Type A receptacle for DMI
Input frequency orizontal: 32-80 k z; Vertical: 47-61 z
Power supply Internal AC
Input voltage 100-240 VAC, 50/60 z
Power connector IEC 60320 C14
Power consumption (typical) Monitor only: ON, max. audio, 100 V/60 z: 230 W; SLEEP, 100 V/60 z: 12.5 W;
OFF, 100 V/60 z: 11.5 W
Temperature Operating: 0°C to 40°C (32°F to 104°F); Storage: -20°C to 50°C (-4°F to 122°F)
umidity (non-condensing) Operating: 20-80%; Storage: 10-90%
Weight Actual: w/o Computer Module: 74.7 lb (33.9 kg); with Computer Module: 80.5 lb (36.5 kg)
Shipping 99.7 lb (45.2 kg) (Computer Module shipped separately)
Shipping box dimensions Width: 47.0" (1194 mm); Depth: 12.0" (305 mm); eight: 31.0" (788 mm)
Warranty 3 years
Backlight lamp life (typical) 50,000 hours to half-brightness
MTBF 50,000 hours demonstrated
Agency approvals Argentina S-mark; Australia C-Tick; Canada cUL; China CCC; Mexico NOM; Russia & CIS GOST;
United States UL; Elo declarations; Europe CE; Canada IC; Japan VCC; United States FCC
Tyco Electro ics Corporatio a d its Affiliates i the TE Touch Solutio s busi ess u it of the TE Co ectivity Ltd.
family of compa ies (collectively “TE”) reserves the right to cha ge or update, without otice, a y i formatio
co tai ed herei ; to cha ge, without otice, the desig , co structio , materials, processi g or specificatio s of a y
products; a d to disco ti ue or limit productio or distributio of a y products.
Elo (logo), Elo TouchSystems, TE Co ectivity, TE co ectivity (logo) a d TE (logo) are trademarks of the TE Co ectivity
Ltd. family of compa ies.
Copyright 2011 Tyco Electro ics Corporatio , a TE Co ectivity Ltd. Compa y. All rights reserved. 04/11
