TYLER MOUNTAIN Storm User manual

1. Use latex or nitrile gloves or wash hands before and after handling water contact parts.
2. Remove drip tray assembly and set aside for cleaning (Figure 7-1).
Figure 7-2 Figure 7-3 Figure 7-4
3. Lift door up to open it properly (Figure 7-2). Turn off hot tank power switch (Figure 7-3) and unplug the
water cooler (Figure 7-4).
CAUTION: WATER IN HOT TANK IS VERY HOT AND CAN CAUSE SEVERE BURNS. ALLOW SUFFICIENT
TIME FOR THE HOT WATER TO COOL BEFORE DRAINING (1-2 HOURS).
Figure 7-1
DIY - Cleaning and Sanitization
Bottom Load Coolers
Notice:
Never attempt to service or repair a water cooler while it is plugged into any power supply.
Prior to any service or repair of the water cooler, ensure that the water has been completely drained from the system.
Scheduled cleaning and sanitizing is recommended to ensure the integrity of the drinking water.
The frequency of cleaning will vary depending on the conditions and environment.
Follow the steps outlined below for sanitizing the water cooler.
CAUTION: DO NOT IMMERSE THE UNIT IN WATER OR CLEAN USING PRESSURE WASHER.
©AFF 2020
PITTSBURGH
1 Commerce Drive
Pittsburgh, PA 15239
[phone]
CHARLESTON
159 Harris Drive
Poca, WV 25159
[phone]
LOUISVILLE
6708 Grade Lane Suite 705,
Louisville, KY 40213
[phone]
FAIRMONT
128 Roush Circle
Fairmont, WV 26554
[phone]

4. Take water bottle out from its base. (Caution: don’t break the corrugated tube.) Remove the connector
from bottle adaptor (Figure 7-5).
Figure 7-5
5. Use top cover key (an accessory of cooler, Figure 7-6), insert into the two holes (on the front top, at
approx 2 inch above and to the right of hot water safety button) towards the cooler, push key to open
top cover (Figure 7-7 and Figure 7-8).
Figure 7-6 Figure 7-7 Figure 7-8
©AFF 2020
PITTSBURGH
1 Commerce Drive
Pittsburgh, PA 15239
[phone]
CHARLESTON
159 Harris Drive
Poca, WV 25159
[phone]
LOUISVILLE
6708 Grade Lane Suite 705,
Louisville, KY 40213
[phone]
FAIRMONT
128 Roush Circle
Fairmont, WV 26554
[phone]

6. Nip the hook and latch’s end to open the latch (Figure 7-9 and Figure 7-10). Turn counter-clockwise
to release the 2 knobs (Figure 7-11 and Figure 7-12). Pull to removeSmartFlo™ Water Cartridge and set
aside (Figure 7-13 and Figure 7-14).
Figure 7-9 Figure 7-10 Figure 7-11
Figure 7-12 Figure 7-13 Figure 7-14
7. To drain the hot tank unscrew drain cap and remove red silicone plug at the rear of the cooler (Figure
7-15 and Figure 7-16). Drain water into a pail or container (approx 0.5 gallon or 1.8 L) (Figure 7-17). Re-
install red silicone plug and drain cap.
Figure 7-15 Figure 7-16 Figure 7-17
©AFF 2020
PITTSBURGH
1 Commerce Drive
Pittsburgh, PA 15239
[phone]
CHARLESTON
159 Harris Drive
Poca, WV 25159
[phone]
LOUISVILLE
6708 Grade Lane Suite 705,
Louisville, KY 40213
[phone]
FAIRMONT
128 Roush Circle
Fairmont, WV 26554
[phone]

8. It is recommended that the hot tank be descaled periodically (frequency varies by mineral content).
Only the use of descaling agents that are compatible with 304 grade stainless steel are recommended.
The use of the descaling agents must be in accordance with the manufacturer’s safety instructions and
recommendations and performed by properly trained personnel.
Note: ensure the hot tank is empty and drain plug and cap are in place (Figure 7-18 and Figure 7-19).
Using a funnel, add the descaling solution to the hot tank, filling up to the top of the inlet (approx 38.7oz
/1100ml) (inlet position refer to Figure 7-20). Allow time for the solution to descale. Drain and dispose of
solution according to the manufacturer’s instructions (refer to step 7 for draining the hot tank).
Figure 7-18 Figure 7-19 Figure 7-20
9. Clean evaporator with a cloth (Figure 7-21).
Figure 7-21
©AFF 2020
PITTSBURGH
1 Commerce Drive
Pittsburgh, PA 15239
[phone]
CHARLESTON
159 Harris Drive
Poca, WV 25159
[phone]
LOUISVILLE
6708 Grade Lane Suite 705,
Louisville, KY 40213
[phone]
FAIRMONT
128 Roush Circle
Fairmont, WV 26554
[phone]

10. Using the brush attachment, vacuum the condenser and all accessible areas to remove dirt, lint and
debris. Or: Use a stiff non-metallic scrub brush to remove dirt and debris from the condenser. Use a
damp cloth to wipe down condenser (Figure 7-22).
CAUTION: DO NOT CLEAN USING PRESSURE WASHER OR ANY DIRECT WATER CONTACT.
Figure 7-22
11. Lift door up to open properly. Brush, vacuum and wipe to clean the interior of condenser (Figure
7-23 and Figure 7-24), refer to chapter 9.
Figure 7-23 Figure 7-24
©AFF 2020
PITTSBURGH
1 Commerce Drive
Pittsburgh, PA 15239
[phone]
CHARLESTON
159 Harris Drive
Poca, WV 25159
[phone]
LOUISVILLE
6708 Grade Lane Suite 705,
Louisville, KY 40213
[phone]
FAIRMONT
128 Roush Circle
Fairmont, WV 26554
[phone]

12. Reinstall or install a newSmartFlo™ Water Cartridge. Install the connector and corrugated tube into
the inlet through cooler to bottom (Figure 7-25 and Figure 7-26). Insert the reservoir into evaporator (Figure
7-27). Ensure theSmartFlo™ Water Cartridge is installed properly. Turn the 2 knob to lock theSmartFlo™
Water Cartridge (Figure 7-28 and Figure 7-29). Close and latch the locking arm (Figure 7-30).
Figure 7-25 Figure 7-26 Figure 7-27
Figure 7-28 Figure 7-29 Figure 7-30
13. Install the hose connector to bottle adaptor (Figure 7-31). Put the water bottle into the bottom of the
cooler. NOTE: The tube should droop naturally. Be careful that the tubing is not inserted into the water
bottle handle, if applicable (Figure 7-32 and Figure 7-33).
Figure 7-31 Figure 7-32 Figure 7-33
©AFF 2020
PITTSBURGH
1 Commerce Drive
Pittsburgh, PA 15239
[phone]
CHARLESTON
159 Harris Drive
Poca, WV 25159
[phone]
LOUISVILLE
6708 Grade Lane Suite 705,
Louisville, KY 40213
[phone]
FAIRMONT
128 Roush Circle
Fairmont, WV 26554
[phone]

14. Close the top cover and lower the door to close. Clean the drip tray assembly and install it back onto
cooler. Plug the cooler back into the power outlet. Push hot safety button and press the hot water faucet
lever, to activate water flow. Keep pressing the hot water faucet lever until water comes out (Figure 7-34).
Figure 7-33
15. Lift the door to open properly. Turn the hot tank power switch ON. Slide downwards to close the door.
CAUTION: TO PREVENT DAMAGE TO THE HOT TANK, DO NOT SWITCH ON IF HOT TANK IS EMPTY.
Crystal Mountain has a policy of continuous development and reserves the right to change specifications without
notification.
Video Links
How to Install the Storm Bottom Load Water Dispenser: https://youtu.be/_ZYTUbgSIrg
Replacing the Water Bottle on the Storm Bottom Load Water Dispenser: https://youtu.be/cd9bMMKskh8
