Tynetec ZXT311 User manual

DocNo.FM0416issueBPage1
Adventxt(2013)
WardenCallSystem

_______________________________________________________________________________________________________________





UserGuide
ZXT311COMPACTTHERMALPRINTER

Tynetecoperatesapolicyofcontinualproductimprovementand
reservestherighttomodifythespecificationofitsproducts.

Ifanyvariationtothedetailsinthisdocumentaresuspectedplease
contactTynetec’sTechnicalSupporton01670352371.
Tynetec,abusinessunitofLegrandElectricLtd
Unit10CowleyRoad,BlythRiversideBusinessPark,Blyth
Northumberland,NE245TF.Tel:01670352371Fax:01670362807
Email:[email protected]Web:www.tynetec.co.uk

DocNo.FM0416issueBPage2
1.INTRODUCTION

TheAdventxtprinterrecordsthetimeanddateofallcallsmade/answered/cancelledonthewardencallsystem.All
othersystemactivitysuchastelephonelinefault,mainsfail,systemreset,etc.isalsorecorded.

2.PUSHBUTTON

Thepushbuttonperformsseveralfunctions;clickoncetoturntheprinteron,pressandholdforpaperfeedwhen
changingpaperrollsordouble‐clicktoperformaself‐testandprinttheinternalsettings.

3.LEDINDICATOR

TheLEDindicatoronthefrontoftheprinterwillnormallyflashshortgreen‐longorange,thereareanumberof
othercolourcombinationswhichprovideprinterstatusinformation;

LEDPatternBatteryStatusBufferMode
ShortGreen‐LongOrangeTrickleChargingNormal
LongOrangeFlashingTrickleChargingSpool
SteadyGreenRunningonBatteryNormal
FastFlashingGreenRunningonBatterySpool
LongGreen‐ShortRedBatteryLowNormal
ShortGreen‐ShortRedBatteryLowSpool
FastFlashingOrangeFastChargingSpool
FastFlashingRedErrorConditionSpool
NoLEDBatteryFlat‐orprinterinsleepmode

TheprinterwillenterSpoolModeifthepaperrunsout,thepapercompartmentflapisuporanerrorhas
occurred.Datawillbebufferedforprintingwhentheconditionisrectified.

4.BATTERYSTANDBY

IfthemainssupplyisdisconnectedtheLEDwillbesteadygreenforapre‐programmedtimeuntiltheprinterenters
sleepmode.Whenthemainssupplyisrestoredclickthepushbuttontoreturntostandbymodeandanymissedcalls
willbeprinted.

5.PRINT‐OUTDETAILS

Theprint‐outisdesignedtogiveasmuchinformationaspossibleaboutthestatusofthesystemwhilstusingthe
minimumofpaper.Allalarmcallprint‐outsarerestrictedtoonelineoftextinthefollowingformat:

Alarm
Prefix
Channel
ID
Call
Type
Date
(DDMM)
Time
(24HR)
Operating
Mode

Example:AL0001INTERCM22/1214:20ON

Theaboveexampletellsyouanintercomalarmfromflat1wasdetectedat14:20on22Decemberandthesystem
wasoperatinginonsitemode.Seebelowfordetailsoftheabbreviationsused;

ALARMPREFIXES

ALAlarmCallSASystemAlarm
CACallAnsweredSRSystemReport
CECallEndedFNFunctionStart/FinishTime(eg.FN1000=AllCall)
CBCallBackStart/FinishTime   



DocNo.FM0416issueBPage3
5.PRINT‐OUTDETAILSCONTINUED…

CALLTYPES

INTERCMIntercomAlarmCOGAS CarbonMonoxideAlarm
PENDANTPendantAlarmGAS  NaturalGasAlarm
PCORDPullcordAlarmFLOOD  FloodDetectorAlarm
SMOKESmokeAlarmLOTEMPHypothermiaAlarm
OPENCTOpenCircuitFault  BEDOCCBedOccupancyAlarm
ALFAULTIntercomFault(notresponding) CLWANDClientWanderingAlarm
INACTIVInactivityAlarmPILLDS  PillDispenserAlarm
INTRUDRIntruderAlarmENURES EnuresisAlarm
PARKEDIntercomParked

SYSTEMALARMS(SA)

4797BTFLTTelephoneLineFault 3999FIREAL FireAlarmActivated
4796BTOKTelephoneLineRestored4800NTRFLT NetworkReceiverFault(ID800‐815)
4799MAINFLMainsFailed  4816NEIFLT NetworkPBXI/FFault(ID816‐823)
4798MAINOKMainsRestored  4824NKSFLT NetworkKeyswitchFault(ID824‐827)
4793LOWBTLowBattery 
4794FUSEBLLowVoltageFuseBlown
 
SYSTEMREPORTS(SR)

CARECLExtracareCallCancelled  DIALTELE01 DialTelephoneNumber01
SYSTEMRESETSystemResetBTLINEDROP TelephoneLineDropped
RINGDETECTTelephoneLineRingDetected SUBPRIVACY IntercomswithPrivacyOn
BTLINESEIZTelephoneLineSeized  PSCHANNEL SystemParkStack

OPERATINGMODES

ONOnsiteMode
LOLocalOffsiteMode
RORemoteOffsiteMode

DOORENTRY

DE0032DOOR01 Flat32CalledFromDoorPanel1
DEDOOROPEN01 DoorEntryOpenedDoor1
TELTRANSEN0001TO0002Flat1DoorEntryTelephoneCallsTransferredtoFlat2
TELTRANSEN0001 ConfirmFlat1DoorEntryTelephoneCallsareTransferred
CALLTRANSEN0008 24HourCallingEnabledforFlat8
CALLTRANSDIS0008 24HourCallingDisabledforFlat8
TELPRIVACY0015 Flat15DoorEntryTelephonehasPrivacyON
TELFAULT0020  Flat20DoorEntryTelephonehasaFault

Note:toconservepaperalldoorentryrelatedprint‐outscanbedisabledviatheAdventxt“DoorEntrySetup”
webpage.









DocNo.FM0416issueBPage4
6.REPLACEMENTPAPER

PaperrollmustbereplacedwithTHERMALPAPERonly.
Thethermalsensitivecoatingmustbeontheoutside
Paperrollsmustbe58mmwide
Maximumpaperrolldiameter58mm(37.7metreslong)
Replacementpaperroll:TynetecP/No.W00336

7.LOADINGPAPER

1. Slidethelidreleasebuttonuntilthelidspringsopen
2. Unwindasmallamountofpaperandinsertintotheprinter
3. Closetheliddownandthepaperisloaded















Afterloading,checkthatthepaperadvancesproperlyandtear‐offanyexcessbypullingtowardsyouacrossthe
serratededge.
